Glowworm Climapro2 RF User manual

Climapro2 RF
Instructions for use

0020094583_02 - 06/11 - Glow-worm - 1 -
HOW TO USE YOUR CLIMAPRO2 RF
1 Climapro2RF is delivered with:
- User instruction manual
- Installation manual
- Guarantee booklet with user
precautions.
• For more information,
consult: www.glow-worm.co.uk
2 Screen description
6 7
8
9
10
11
5
4
3
2
1
Legend
1 Scroll button (top/bottom)
Navigate in the menus.
Reduce/increase the value to be adjusted.
2 Selection button
Validate the selection or the setting.
3 Return button
Return to the previous menu.
Return to the previous setting.
4 Menu button
To access the main menu.
Return to the main screen (at any time).
5 Current functioning mode display zone
6 Display area for messages
7 Day of the week
8 Current time
9 Current date
10 Room temperature*
11 Outside temperature measured by the
outdoor sensor (only if the sensor is
connected)
(*) Please note: the value of the
room temperature displayed on
Climapro2RF but may vary when
the thermostat is held in your
hand.
3 Description of the main menu
Menu Browsing
Browse with buttons:
Press the button:
to return to the previous screen.
Select with the button:
Press the button:
to return to the main screen. (at
any time)
(**) Menus available according
to the configuration of the
system.
The standby screen appears
after 1 minute without use
HOW TO USE YOUR CLIMAPRO2 RF
EN

0020094583_02 - 06/11 - Glow-worm
- 2 -
3.1 Heating
Menu This menu allows you to:
Activate or deactivate the
heating
Program the timed intervals
for the heating
Override the program (if
activated)
3.2 Hot water**
Menu This menu allows you to:
Activate or deactivate the
hot water heating
Adjust the temperature of
the hot water
Program the on/offtimes for
hot water heating
Override the program (if
activated)
3.3 Cooling** (Heat Pump only)
Menu This menu allows you to:
Activate or deactivate
cooling
Program the timed intervals
for cooling
Override the program (if
activated)
Adjust cooling to the desired
temperature
3.4 Holiday
Menu This menu allows you to:
Set a period of absence.
Activate or deactivate the
holiday function.
3.5 Parameters
Menu This menu allows you to:
Adjust the date and time
Choose the language
Personalise the name of the
control
Turn the keyboard lock on
or off
Adjust the brightness and
contrast of the screen
Return to factory settings
Display information: zone,
type and software version for
the room thermostat
(**) The heating, hot water
and cooling functions must be
activated ("ON") to use the timed
programs.
HOW TO USE YOUR CLIMAPRO2 RF
EN

0020094583_02 - 06/11 - Glow-worm - 3 -
4 Programming
4.1 Heating program
• Press button > then select on
screen > heating > program > set up >
choose a day.
Programming for a day begins at 00:00
with a maximum of 7 time intervals over 24
hours.
• Increase or decrease with the
buttons to display the desired room
temperature setting and validate with
button .
• Define the end of the time interval with
the buttons and validate with the
button.
• Begin the programming again if you wish
to add other time intervals.
To modify a setting:
• Use the buttons (go back) or
go forward) to highlight the
setting.
• Modify a temperature or a time with
the buttons and validate with the
button.
To delete a time interval:
Deletion is performed:
- time interval by time interval,
- from the last time interval to the first.
• Use the button to highlight the
last time interval that was set.
• Use the button to display .
The display automatically goes to
and deletes the programmed temperature.
The setting for the previous time interval
then applies up to .
• Validate with the button or
delete another time interval.
To delete another time interval:
• Use the button to highlight the
previous time interval and perform the
action again.
HOW TO USE YOUR CLIMAPRO2 RF
EN

0020094583_02 - 06/11 - Glow-worm
- 4 -
4.2 Hot water heating and cooling
program (**)
• For hot water heating program: press
button > then select on screen > hot
water > program > set up > choose a day.
• For cooling program : press button
> then select on screen > cooling >
program > set up > choose a day. (NOTE:
HEAT PUMP ONLY)
• Define the time slots with the same
programming principle (see heating
program).
Programming for a day begins at 00:00
with a maximum of 7 time intervals over 24
hours.
(**) Menus available according
to the configuration of the
system.
4.3 Copy a day
This function lets you apply the rules for
one day to other days.
Once a day has been programmed, you
are automatically returned to the selection
screen of the day to be programmed.
• Select the day to copy
• Copy to the day or group of days of your
choice.
4.4 Override of central heating/hotwater
(available program activated)
This feature allows the temporary override
of current programmes.
• From the main screen, press .
• Select the program to which the override
will be applied.**
• Set the setting and the end time of the
override.
To cancel:
• From the main screen, press .
• Select the override(s) to be cancelled.**
(**) Menus available according
to the configuration of the
system.
HOW TO USE YOUR CLIMAPRO2 RF
EN

0020094583_02 - 06/11 - Glow-worm - 5 -
4.5 Holiday
• Press button >
then select on screen > holiday > set up.
• Set the start and end date of your
holiday (date and time).
• Remember to adjust the room
temperature.
4.6 Protection against frost
The device’s anti-freezing system controls
the start-up of the heating when the
temperature of the room in which the
device is installed falls below 5°C, or if the
outside temperature falls below 3°C.
(**) Menus available according
to the configuration of the
system.
HOW TO USE YOUR CLIMAPRO2 RF
EN

0020094583_02 - 06/11 - Glow-worm
- 6 -
ANY ASSISTANCE?
5 Trouble-shooting
This chapter contains all the messages
that the thermostat may display, and the
corrective actions that you can carry out to
put the appliance back into service.
• If after carrying out this basic advice and
your appliance still does not work, leave
it turned offand contact your qualified
engineer.
Warning Procedure
Check that power is
supplied to the heating
system.
See the manual for the
appliance
Replace the batteries,
following the instructions
(see "battery replacement").
See the appliance manual
to reset.
See the appliance manual
to increase the system
pressure.
Warning Procedure
Call the telephone number
displayed on the screen.
No display
Check that:
- the batteries are installed
in compartment
- the battery polarity is not
reversed
- the batteries are not
exhausted. If so, replace
with new batteries.
ANY ASSISTANCE ?
EN

0020094583_02 - 06/11 - Glow-worm - 7 -
6 Replacing the batteries
When the message "low battery - change
the batteries" appears on the main screen,
the remaining life of the batteries is about
one month.
Note :
- If the batteries are not changed in time,
the boiler functions without the room
thermostat.
- Programme settings will not be lost.
- Clean the battery compartment before
inserting new batteries.
- Do not mix new and used batteries or
batteries of different types.
- Do not use rechargeable batteries.
- Never expose the batteries to excessive
heat or a naked flame, never try to take
them apart, and make sure that they are
never short-circuited.
- If electrolyte leaks and comes into
contact with skin or clothing, rinse them
immediately with water.
4
3
2
1
C
A
B
Legend
1 Battery cover
2 Batteries
3 Battery compartment
4 Room thermostat
• Remove the battery cover (1) for the
room thermostat (4) respecting the order
of operations from (A) to (C).
• Remove the batteries (2).
• Replace the batteries with new batteries
of type "AA LR6", respecting their
polarity (direction "+" and "-").
The batteries must not be
placed in household waste, but
disposed of in accordance with
the regulations in force.
ANY ASSISTANCE ?
EN

*2702187_rev2*
