GlucoRx Nexus Voice TD-4280 User manual

Version 1.0 2012/10
311-4280100-003
MANUAL
OWNER'S
BLOOD GLUCOSE
MONITORING SYSTEM
TD-4280
Voice

Dear GlucoRx Nexus Voice TD-4280
System Owner:
Thank you for purchasing the GlucoRx Nexus Voice TD-4280
Blood Glucose Monitoring System. This manual provides important
information to help you to use the system properly. Before using this
product, please read the following contents thoroughly and carefully.
Regular monitoring of your blood glucose levels can help you and
your doctor gain better control of your diabetes. Due to its compact
size and easy operation, you can use the GlucoRx Nexus Voice TD-
4280 Blood Glucose Monitoring System to easily monitor your blood
glucose levels by yourself anywhere, any time.
If you have other questions regarding this product, please contact
the place of purchase, or call the local customer service.

IMPORTANT SAFETY PRECAUTIONS
READ BEFORE USE
1. Use this device ONLY for the intended use described in this
manual.
2. Do NOT use accessories which are not specied by the manufac-
turer.
3. Do NOT use the device if it is not working properly or if it is dam-
aged.
4. Do NOT use the equipment in places where aerosol sprays are
being used, or where oxygen is being administered.
5. Do NOT under any circumstances use the device on newborns or
infants.
6. This device does NOT serve as a cure for any symptoms or
diseases. The data measured is for reference only. Always consult
your doctor to have the results interpreted.
7. Before using this device to test blood glucose, read all instructions
thoroughly and practice the test. Carry out all the quality control
checks as directed.
8. Keep the device and testing equipment away from young children.
Small items such as the battery cover, batteries, test strips, lan-
cets and vial caps are choking hazards.
9. Use of this instrument in a dry environment, especially if synthetic
materials are present (synthetic clothing, carpets etc.) may cause
damaging static discharges that may cause erroneous results.
10. Do not use this instrument in close proximity to sources of strong
electromagnetic radiation, as these may interfere with the ac-
curate operation.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE

TABLE OF CONTENTS
IMPORTANT SAFETY PRECAUTIONS 5
BEFORE YOU BEGIN 8
Important Information 8
Intended Use 9
Test Principle 9
Contents of System 10
Meter Overview 11
Display Screen 12
Test Strip 13
Talking Function 14
Setting the Meter 15
THE FOUR MEASURING MODES 20
BEFORE TESTING 21
Control Solution Testing 21
Performing a Control Solution Test 21
TESTING WITH BLOOD SAMPLE 24
Overview of the Lancing Device 24
Preparing the Puncture Site 24
Alternative Site Testing 26
Performing a Blood Glucose Test 27
METER MEMORY 30
Reviewing Test Results 30
Reviewing Blood Glucose Day Average Results 32
Downloading Results onto a Computer 34

MAINTENANCE 35
Battery 35
Caring for Your Meter 37
Caring for Your Test Strips 37
Important Control Solution Information 38
SYSTEM TROUBLESHOOTING 39
Result Readings 40
Error Messages 41
Troubleshooting 42
DETAILED INFORMATION 43
Reference Values 43
Comparing Meter and Laboratory Results 44
SPECIFICATIONS 46
SYMBOL INFORMATION 47

8
Important Information
Severe dehydration and excessive water loss may cause readings
which are lower than actual values. If you believe you are suffering
from severe dehydration, consult a healthcare professional im-
mediately.
If your blood glucose results are lower or higher than usual, and
you do not have any symptoms of illness, rst repeat the test. If
you have symptoms or continue to get results which are higher
or lower than usual, follow the treatment advice of your healthcare
professional.
Use only fresh whole blood samples to test your blood glucose.
Using other substances will lead to incorrect results.
If you are experiencing symptoms that are inconsistent with your
blood glucose test results and you have followed all the instruc-
tions given in this owner’s manual, contact your healthcare profes-
sional.
We do not recommend using this product on severely hypotensive
individuals or patients in shock. Readings which are lower than
actual values may occur for individuals experiencing a hypergly-
caemic-hyperosmolar state, with or without ketosis. Please consult
your healthcare professional before use.
BEFORE YOU BEGIN

9
Intended Use
This system is intended for use outside the body (in vitro diagnostic
use) by people with diabetes at home and by health care profes-
sionals in clinical settings as an aid to monitoring the effectiveness
of diabetes control. It is intended to be used for the quantitative
measurement of glucose (sugar) in fresh whole blood samples from
the nger.
It should not be used for the diagnosis of diabetes, or testing on
newborns.
Professionals may test with capillary and venous whole blood; home
use is limited to capillary whole blood testing.
Test Principle
Your system measures the amount of sugar (glucose) in whole
blood. The glucose testing is based on the measurement of electrical
current generated by the reaction of glucose with the reagent of the
strip. The meter measures the current, calculates the blood glucose
level, and displays the result. The strength of the current produced
by the reaction depends on the amount of glucose in the blood
sample.

10
Contents of System
Your new GlucoRx Nexus Voice TD-4280 system kit includes:
Sterile Lancets
2 x 1.5V AAA Alkaline Batteries
Lancing Device
Test strips
Control Solution
Meter
Owner’s Manual
Protective Wallet
Quick Start User Guide
Daily Log Book
Warranty Card
If any items are missing from your kit or opened prior to use,
please contact local customer services or place of purchase for
assistance.
NOTE
Quick Start User Guide

11
Meter Overview
TEST SLOT
Insert test strip here to turn the meter on for testing.
TEST STRIP EJECTOR
Eject the used strip by pushing up this button.
DISPLAY SCREEN
DATA PORT
Download test results with a cable connection.
M BUTTON
Enter the meter memory and silence a reminder alarm.
SET BUTTON
Enter and conrm the meter settings.
BATTERY COMPARTMENT
FrontLeft Side BackRight Side

12
Display Screen
Blood Drop Symbol
Test Strip Symbol
Low Battery Symbol
Test Result
Measurement Unit
Day Average
Time
Reminder Alarm
Measuring Modes
Date
Memory Mode
Control Solution Mode
Error Message
Ketone Warning
Volume Symbol

13
Test Strip
The GlucoRx Nexus Voice TD-4280 meter should only be used
with GlucoRx Nexus Voice TD-4280 Test Strips. Using other test
strips with this meter can produce inaccurate results.
NOTE
Test results might be wrong if the contact
bar is not fully inserted into the test slot.
Attention!
The front side of the test strip should face
up when inserting the test strip.
Front Back
Contact Bars
Insert this end of the test strip into the meter.
Push it in rmly until it will go no further.
Test Strip Handle
Hold this part to insert the test strip into the slot.
Conrmation Window
This is where you conrm if enough blood has been
applied to the absorbent hole of the test strip.
Absorbent Hole
Apply a drop of blood here. The blood will be automati-
cally absorbed.

14
Talking Function
GlucoRx Nexus Voice TD-4280 “talks” aloud with step by step in-
structions to guide you through the process of blood glucose testing.
The following table tells you when and what the meter “talks”.
WHEN does the meter talk? WHAT does the meter talk?
When turning on the meter Thank you for using this product.
Please relax during measurement.
After inserting test strip.
Please apply blood onto the test strip
When the meter is ready to test.
(Symbol appears on display)
When the test is completed.
(Result appears on display)
The blood glucose is (number)
millimoles per liter.

15
Setting the Meter
Before using your meter for the rst time or if you change the meter
battery, you should check and update these settings. Make sure you
complete the steps below and have your desired settings saved.
Entering the setting mode
Start with the meter off (no test strip inserted).
Press SET to turn on the meter.
1. Setting the date
With the year ashing, press to select the
correct year. Press SET.
With the month ashing, press to select the
correct month. Press SET.
With the day ashing, press to select the
correct day . Press SET.

16
2. Setting the time format
Press and release to select the desired time format --- 12h or 24h.
Press SET.
3. Setting the time
With the hour ashing, press to select the correct
hour. Press SET.
With the minute ashing, press to select the cor-
rect minute. Press SET.
4. Deleting the memory
With “dEL” and a ashing “ ” symbol on the
display, press and select “No” to keep the results
in memory then press SET to skip.

17
5. Setting the talking volume
There are seven (7) talking volume options to
choose from. Press to select the desired talking
volume. To conrm your selection, press SET.
Volume 0 indicates that the talking function is
turned off, and “ ” will not display during testing.
Volume 1 to 7 indicates talking volume from low
to high, and “ ” will be displayed throughout the
testing.
6. Choosing a language
Press to select L1/L2.The default language for
the meter is L1, which is English. To conrm your
selection, press SET.
To delete all the results, press and select “Yes” then press SET to
conrm. “OK” and “ ” are displayed on the meter, which indicates
that all data stored is deleted.

18
If you do not want to set an alarm, press SET to skip this step.
If you want to turn off an alarm, nd the alarm number by pressing
SET in the setting mode, press to change from “ON’ to “OFF”.
7. Setting the reminder alarm
You may set up any or all of the reminder alarms (1-4). The meter
displays “On” or “OFF” and , press to turn on or turn off to set
the rst reminder alarm.
Press to select “On”, then press SET to set the hour. When the
hour is ashing, press to add an hour. Press SET to conrm and
go to minutes, press to add one minute. Press SET to conrm
and go to the next alarm setting.

19
At the time of your alarm, the meter will beep and automatically turn
on. You can press to silence the alarm and insert a test strip to
begin testing. If you do not press , the meter will beep for 2 min-
utes then switch off. If you do not want to test at this time, press to
switch off the meter.
Congratulations! You have completed all settings!
These parameters can ONLY be changed in the setting mode.
If the meter is idle for 3 minutes during the setting mode, it will
switch off automatically.
NOTE

20
THE FOUR MEASURING MODES
The meter provides you with four modes for measuring General, AC,
PC and QC.
2. Press to switch between General, AC, PC and QC.
Modes Use when
General (displays as “Gen”) any time of day regardless of time since last
meal
AC no food intake for at least 8 hours
PC 2 hours after a meal
QC testing with the control solution
You can switch between each mode by:
1. Start with the meter switched off. Insert
a test strip to turn on the meter. The screen
will display a ashing blood drop and
“Gen”.

21
BEFORE TESTING
TaiDoc Control Solution contains a known amount of glucose that
reacts with test strips and is used to ensure your meter and test
strips are working together correctly.
Do a control solution test when:
you rst receive the meter,
at least once a week to routinely check the meter and test strips,
you begin using a new vial of test strips,
you suspect the meter or test strips are not working properly,
your blood glucose test results are not consistent with how you
feel, or if you think the results are not accurate,
practicing the testing process, or
you have dropped or think you may have damaged the meter.
Performing a Control Solution Test
1. Insert the test strip to turn on the meter
Insert the test strip into the meter. Wait for the meter to display the
test strip and blood drop symbol.
Control Solution Testing

22
2. Press to mark this test as a control solution test
If you press again, the “QC” will disappear and this test is no
longer a control solution test.
3. Apply control solution
Shake the control solution vial thoroughly before
use.
Squeeze out a drop and wipe it off, then squeeze
out another drop and place it on the tip of the vial
cap.
Hold the meter to move the absorbent hole of the test strip to touch
the drop. Once the conrmation window lls completely, the meter
will begin counting down.
To avoid contaminating the control solution, do not directly apply
control solution onto a strip.
