D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible ISM0012-14
D1020S - D1020D
INSTRUCTION & SAFETY MANUAL
SIL 2 Powered Isolating Driver
Smart-Hart compatible
DIN-Rail Models D1020S, D1020D

D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible G.M. International ISM0012-14
2
General Description: The single and dual channel DIN Rail Isolating Driver, D1020S and D1020D, isolates and transfers a 4-20, 0-20 mA signal from a controller located in Safe Area
to a load of up to 750 in Hazardous Area. It has a high output capacity of 15 V at 20 mA combined with a low drop across its input terminals. The circuit allows bi-directional
communication signals, for Smart I/P. In the 4-20 mA input range, a field open circuit reflects a high impedance to the control device output circuit.
Function: 1 or 2 channels I.S. mA analog output for 2 wire I/P Smart converters or valve positioners, provides 3 port isolation (input/output/supply).
Signalling LED: Power supply indication (green).
Smart Communication Frequency Band: 0.5 to 40 KHz within 3 dB (Hart and higher frequency protocols).
EMC: Fully compliant with CE marking applicable requirements.
Functional Safety Management Certification:
G.M. International is certified by TUV to conform to IEC61508:2010
part 1 clauses 5-6 for safety related systems up to and included SIL3.
Supply: 24 Vdc nom (20 to 30 Vdc) reverse polarity protected, ripple within voltage limits 5 Vpp.
Current consumption @ 24 V: 95 mA for 2 channels D1020D, 50 mA for 1 channel D1020S with 20 mA output typical.
Power dissipation: 1.9 W for 2 channels D1020D, 1.0 W for 1 channel D1020S with 24 V supply voltage and 20 mA output typical.
Max. power consumption: at 30 V supply voltage and overload condition, 2.7 W for 2 channels D1020D, 1.4 W for 1 channel D1020S.
Isolation (Test Voltage): I.S. Out/In 1.5 KV; I.S. Out/Supply 1.5 KV; I.S. Out/I.S. Out 500 V; In/Supply 500 V; In/In 500 V.
Input: 0/4 to 20 mA with 2.0 V voltage drop, reverse polarity protected.
Output: 0/4 to 20 mA, on max. 750 load, current limited at 23 mA.
Response time: 50 ms (10 to 90 % step change).
Output ripple: 20 mVrms on 250 communication load on 0.5 to 40 KHz band.
Frequency response: 0.5 to 40 KHz bidirectional within 3 dB (Hart and higher frequency protocols).
Performance: Ref. Conditions 24 V supply, 250 load, 23 ± 1 °C ambient temperature.
Calibration accuracy: ± 0.1 % of full scale.
Linearity error: ± 0.05 % of full scale.
Supply voltage influence: ± 0.05 % of full scale for a min to max supply change.
Load influence: ± 0.05 % of full scale for a 0 to 100 % load resistance change.
Temperature influence: ± 0.01 % on zero and span for a 1 °C change.
Compatibility:
CE mark compliant, conforms to Directive: 2014/34/EU ATEX, 2014/30/EU EMC, 2014/35/EU LVD, 2011/65/EU RoHS.
Environmental conditions:
Operating: temperature limits -20 to + 60 °C, relative humidity max 95 % .
Storage: temperature limits – 45 to + 80 °C.
Safety Description:
ATEX: II (1)G [Ex ia Ga] IIC, II (1)D [Ex ia Da] IIIC, I (M1) [Ex ia Ma] I; II 3G Ex nA IIC T4 Gc
IECEx / INMETRO: [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I; Ex nA IIC T4 Gc
UL: NI / I / 2 / ABCD / T4, AIS / I, II, III / 1 / ABCDEFG, AEx nC [ia] IIC
C-UL: NI / I / 2 / ABCD / T4, AIS / I, II, III / 1 / ABCDEFG, Ex nC [ia] IIC
FM: NI / I / 2 / ABCD / T4, NI / I / 2 / IIC / T4, AIS / I, II, III / 1 / ABCDEFG, AEx [ia] IIC
FM-C: NI / I / 2 / ABCD / T4, NI / I / 2 / IIC / T4, AIS / I, II, III / 1 / ABCDEFG, Ex [ia] IIC
EAC-EX: 2Ex nA [ia Ga] IIC T4 Gc X, [Ex ia Da] IIIC X, [Ex ia Ma] I X
UKR TR n. 898: 2ExnAiaIICT4 X, ExiaI X
associated apparatus and non-sparking electrical equipment.
Uo/Voc = 25.2 V, Io/Isc = 87 mA, Po/Po = 548 mW at terminals 14-15, 10-11.
Um = 250 Vrms, -20 °C Ta 60 °C.
Approvals:
DMT 01 ATEX E 042 X conforms to EN60079-0, EN60079-11, EN60079-26.
IECEx BVS 07.0027X conforms to IEC60079-0, IEC60079-11, IEC60079-26.
IMQ 09 ATEX 013 X conforms to EN60079-0, EN60079-15.
IECEx IMQ 13.0011X conforms to IEC60079-0, IEC60079-15.
INMETRO DNV 13.0108 X conforms to ABNT NBR IEC60079-0, ABNT NBR IEC60079-11, ABNT NBR IEC60079-15, ABNT NBR IEC60079-26, ABNT NBR IEC 61241-11.
UL & C-UL E222308 conforms to UL913, UL 60079-0, UL60079-11, UL60079-15,
ANSI/ISA 12.12.01 for UL and CSA-C22.2 No.157-92, CSA-E60079-0, CSA-E60079-11, CSA-C22.2 No. 213 and CSA-E60079-15 for C-UL.
FM & FM-C No. 3024643, 3029921C, conforms to Class 3600, 3610, 3611, 3810,
ANSI/ISA 12.12.02, ANSI/ISA 60079-0, ANSI/ISA 60079-11, C22.2 No.142,
C22.2 No.157, C22.2 No.213, E60079-0, E60079-11, E60079-15.
C-IT.MH04.B.00306 conforms to GOST R IEC 60079-0,GOST R IEC 60079-11, GOST R IEC 60079-15.
C16.0034 X conforms to  7113,  22782.5-78,  I 60079-15.
TÜV Certificate No. C-IS-236198-03, SIL 2 conforms to IEC61508:2010 Ed.2.
TÜV Certificate No. C-IS-236198-09, SIL 3 Functional Safety Certificate conforms to IEC61508:2010 Ed.2, for Management of Functional Safety.
DNV No.A-13778 and KR No.MIL20769-EL001 Certificates for maritime applications.
Mounting: T35 DIN Rail according to EN50022.
Weight: about 180 g D1020D, 120 g D1020S.
Connection: by polarized plug-in disconnect screw terminal blocks to accommodate terminations up to 2.5 mm2.
Location: Safe Area/Non Hazardous Locations or Zone 2, Group IIC T4, Class I, Division 2, Groups A, B, C, D Temperature Code T4 and Class I, Zone 2, Group IIC, IIB, IIA
T4 installation.
Protection class: IP 20.
Dimensions: Width 22.5 mm, Depth 99 mm, Height 114.5 mm.
Technical Data
Characteristics
FSM
SIL 3

3
D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatibleG.M. International ISM0012-14
Front Panel and Features
Ordering information
SIL 2 according to IEC 61508:2010 Ed.2 for Tproof = 3 / 10 years (10% / >10 % of total SIF).
PFDavg (1 year) 2.60 E-04, SFF 62.04 %.
SIL 3 Systematic capability.
2 fully independent channels.
Output to Zone 0 (Zone 20), Division 1, installation in Zone 2, Division 2.
4-20 or 0-20 mA Input, Output Signal.
Wide Band Smart Communication, Hart compatible.
Field open circuit detection.
High Accuracy.
Three port isolation, Input/Output/Supply.
 EMC Compatibility to EN61000-6-2, EN61000-6-4, EN61326-1.
ATEX, IECEx, UL & C-UL, FM & FM-C, INMETRO, EAC-EX, UKR TR n. 898, TÜV Certifications.
TÜV Functional Safety Certification.
Type Approval Certificate DNV and KR for maritime applications.
High Reliability, SMD components.
High Density, two channels per unit.
Simplified installation using standard DIN Rail and plug-in terminal blocks.
250 Vrms (Um) max. voltage allowed to the instruments associated with the barrier.
Not used
Terminal block connections
HAZARDOUS AREA SAFE AREA
+ Output Ch 2 for I/P Converter
- Output Ch 2 for I/P Converter
Not used
Not used
+ Output Ch 1 for I/P Converter
- Output Ch 1 for I/P Converter
Not used
9
10
11
12
13
14
15
16
+ Input Ch 1 for Current Source mode
1
- Input Ch 1 for Current Source mode
2
+ Ch1 Power Supply 24 Vdc
3
- Ch1 Power Supply 24 Vdc
4
+ Input Ch 2 for Current Source mode
5
- Input Ch 2 for Current Source mode
6
+ Ch2 Power Supply 24 Vdc
7
- Ch2 Power Supply 24 Vdc
8
D1020
1 2 3 4
9 10 11 12
16151413
5 6 7 8
PWR ON
1 2
Model: D1020
1 channel S
Power Bus enclosure
2 channels D
/B
Power Bus and DIN-Rail accessories:
DIN rail anchor MCHP065 DIN rail stopper MOR016
Terminal block male MOR017 Terminal block female MOR022

4 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible G.M. International ISM0012-14
Parameters Table
Must
be
Hazardous Area/
Hazardous Locations
Device Parameters
D1020 Associated
Apparatus Parameters
Uo / Voc = 25.2 V Ui / Vmax
In the system safety analysis, always check the Hazardous Area/Hazardous Locations devices to conform with the related system documentation, if the device is Intrinsically Safe check
its suitability for the Hazardous Area/Hazardous Locations and gas group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded
by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D1020 series Associated Apparatus connected to it. Also consider the maximum operating temperature of the field device, check
that added connecting cable and field device capacitance and inductance do not exceed the limits (Co/Ca, Lo/La, Lo/Ro) given in the Associated Apparatus parameters for the effective
gas group. See parameters on enclosure side and the ones indicated in the table below:
D1020 Terminals
Ch1
Ch2
14 - 15
10 - 11
Io / Isc = 87 mA
Ch1
Ch2
14 - 15
10 - 11
Po / Po = 548 mW
Ch1
Ch2
14 - 15
10 - 11

Ii/ Imax
Pi / Pi
For installations in which both the Ci and Li of the Intrinsically Safe apparatus exceed 1 % of the Co and Lo parameters of the Associated Apparatus (excluding the cable),
then 50 % of Co and Lo parameters are applicable and shall not be exceeded (50 % of the Co and Lo become the limits which must include the cable such that
Ci device + C cable 50 % of Co and Li device + L cable 50 % of Lo).
If the cable parameters are unknown, the following value may be used: Capacitance 60pF per foot (180pF per meter), Inductance 0.20µH per foot (0.60µH per meter).
The Intrinsic Safety Entity Concept allows the interconnection of Intrinsically Safe devices approved with entity parameters not specifically examined in combination as a system when
the above conditions are respected.
For Division 1 and Zone 0 installations, the configuration of Intrinsically Safe Equipment must be FM approved under Entity Concept (or third party approved);
for Division 2 installations, the configuration of Intrinsically Safe Equipment must be FM approved under non-incendive field wiring or Entity Concept (or third party approved).
Must
be
Hazardous Area/
Hazardous Locations
Device + Cable Parameters
D1020 Terminals
Ch1
Ch2
14 - 15
10 - 11
D1020 Associated
Apparatus Parameters
Ci / Ci device + C cable

IIC (A, B)
Co / Ca = 105 nF
Co / Ca = 819 nF
Co / Ca = 2.899 µF
IIB (C)
IIA (D)
NOTE for USA and Canada:
IIC equal to Gas Groups A, B, C, D, E, F and G
IIB equal to Gas Groups C, D, E, F and G
IIA equal to Gas Groups D, E, F and G
Co / Ca = 4.15 µF
Co / Ca = 819 nF
I
IIIC
Ch1
Ch2
14 - 15
10 - 11
Li / Li device + L cable

IIC (A, B)
Lo / La = 4.6 mH
Lo / La = 18.7 mH
Lo / La = 37.5 mH
IIB (C)
IIA (D)
Lo / La = 61.5 mH
Lo / La = 18.7 mH
I
IIIC
Ch1
Ch2
14 - 15
10 - 11
Li / Ri device and
L cable / R cable

IIC (A, B)
Lo / Ro = 64.9 µH/
Lo / Ro = 259.6 µH/
Lo / Ro = 519.3 µH/
IIB (C)
IIA (D)
Lo / Ro = 851.9 µH/
Lo / Ro = 259.6 µH/
I
IIIC

5
D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatibleG.M. International ISM0012-14
Function Diagram:
HAZARDOUS AREA ZONE 0 (ZONE 20) GROUP IIC,
HAZARDOUS LOCATIONS CLASS I, DIVISION 1, GROUPS A, B, C, D,
CLASS II, DIVISION 1, GROUPS E, F, G, CLASS III, DIVISION 1,
CLASS I, ZONE 0, GROUP IIC
SAFE AREA, ZONE 2 GROUP IIC T4,
NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2,
GROUPS A, B, C, D T-Code T4, CLASS I, ZONE 2, GROUP IIC T4
MODEL D1020S
==
=
14
15
3 +
4 -
1
2
+
-
HHT
Supply 24 Vdc
Source I
In 1
+
-
HHT
I
P
Out 1 =
=
I/P Converter
MODEL D1020D
==
=
14
15
3 +
4 -
1
2
+
-
HHT
Ch1 Supply 24 Vdc
Source I
In 1
+
-
HHT
I
P
Out 1
==
=
10
11
5
6
+
-
Source I
+
-
HHTHHT
I
P
=
=
I/P Converter
I/P Converter
In 2Out 2 =
=
7 +
8 - Ch2 Supply 24 Vdc

6 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible G.M. International ISM0012-14
Functional Safety Manual and Application
Application for D1020S or D1020D
Failure category Failure rates (FIT)
dd = Total Dangerous Detected failures 0.00
du = Total Dangerous Undetected failures 59.27
sd = Total Safe Detected failures 0.00
su = Total Safe Undetected failures 96.85
λtot safe =Total Failure Rate (Safety Function) =λdd +λdu +λsd +λsu 156.12
MTBF (Safety Function, one channel) = (1 / λtot safe) + MTTR 731 years
no effect = “No Effect” failures 238.29
not part = “Not Part” failures 10.80
λtot device = Total Failure Rate (Device) = λtot safe + λno effect + λnot part 405.21
MTBF (Device, one channel) = (1 / λtot device) + MTTR 281 years
λsd λsu λdd λdu SFF
0.00 FIT 96.85 FIT 0.00 FIT 59.27 FIT 62.04%
T[Proof] = 1 year T[Proof] = 3 years
PFDavg = 2.60 E-04 Valid for SIL 2 PFDavg = 7.80 E-04 Valid for SIL 2
PFDavg vs T[Proof] table (assuming Proof Test coverage of 99%), with determination of SIL supposing module contributes >10% of total SIF dangerous failures:
PFDavg vs T[Proof] table (assuming Proof Test coverage of 99%), with determination of SIL supposing module contributes 10% of total SIF dangerous failures:
Failure rates table according to IEC 61508:2010 Ed.2 :
Failure rate table:
Safety Function and Failure behavior:
D1020 is considered to be operating in Low Demand mode, as a Type A module, having Hardware Fault Tolerance (HFT) = 0.
The failure behaviour of the D1020 S and D1020D modules (when the output current range is 4 to 20 mA) is described by the following definitions:
□ Fail-Safe State: it is defined as the output going to Fail Low.
□ Fail Safe: failure mode that causes the module / (sub)system to go to the defined Fail-Safe state without a demand from the process.
□ Fail Dangerous: failure mode that does not respond to a demand from the process (i.e. being unable to go to the defined Fail-Safe state) or deviates the output current by more
than 5% full span (+/- 0.8 mA).
□ Fail High: failure mode that causes the output signal to go above the maximum output current (> 20 mA). This failure mode is considered as a Dangerous Undetected failure.
□ Fail Low: failure mode that causes the output signal to go below the minimum output current (< 4 mA). This failure mode is considered as a Safe Undetected failure.
□ Fail “No Effect”: failure mode of a component that plays a part in implementing the Safety Function but that is neither a safe failure nor a dangerous failure. When calculating
theSFF, this failure mode is not taken into account.
□ Fail “Not part”: failure mode of a component that is not part of the Safety Function but is part of the circuit diagram and is listed for completeness. When calculating the SFF, this
failure mode is not taken into account.
The 2 channels of D1020D module could be used to increase the hardware fault tolerance, needed for a higher SIL of a certain Safety Function, as they are they are completely inde-
pendent each other, not containing common components. In fact, the analysis results got for D1020S (single channel) are also valid for each channel of D1020D (double channel).
Failure rate date: taken from Siemens Standard SN29500.
Description:
The module is powered by connecting 24 Vdc power supply to Pins 3 (+ positive) - 4 (- negative) for Channel 1 and Pins 7 (+ positive) - 8 (- negative) for Channel 2.
The greens LED are lit in presence of each power supply line.
The current input signals from the Safety PLC outputs are applied to Pins 1-2 (In 1 - Ch.1) and Pins 5-6 (In 2 - Ch.2).
The source output currents for I/P converters are applied to Pins 14-15 (for Channel 1) and Pins 10-11 (for Channel 2).
Channel 1
Channel 2
(only for D5020D)
In 2
5 +
6 -
1 +
2 - In 1 Source current from
Safety PLC Output
T[Proof] = 10 years
PFDavg = 2.60 E-03 - Valid for SIL 2
Ch.1 Supply
24 Vdc
3 + 4 -
+ 14
- 15
Out 1
+ 10
I/P
Converter
- 11
Source current from
Safety PLC Output
I/P
Converter
P
I
P
I
D1020S
or
D1020D
7 + 8 -
Ch.2 Supply
24 Vdc
Out 2
Systematic capability SIL 3.

7
D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatibleG.M. International ISM0012-14
Testing procedure at T-proof
The proof test must be performed to reveal dangerous faults which cannot be otherwise detected. This means that it is necessary to specify how dangerous undetected faults, which
have been noted during the FMEDA analysis, can be revealed during the proof test.
The Proof Test 1 consists of the following steps:
This test will detect approximately 70% of possible Dangerous Undetected failures in the repeater.
The Proof Test 2 consists of the following steps:
This test will detect approximately 99% of possible Dangerous Undetected failures in the repeater.
Steps Action
1Bypass the Safety-related PLC or take any other appropriate action to avoid a false trip.
2Provide a 20 mA control signal to the driver to open/close the valve and verify that the valve is open / closed. This test is for voltage compliance
problems, such as a loop power supply voltage or increased wiring resistance, and for other possible failures. It requires, however, that the positioned
has already been tested without the driver and does not contain any dangerous undetected failures.
3Provide a 4mA control signal to the driver to close/open the valve and verify that the valve is closed /open. This test is for possible quiescent current
related failures. It requires, however, that the positioner has already been tested without the driver and does not contain any dangerous undetected
failures
4Restore the loop to full operation.
5Remove the bypass from the Safety-related PLC or restore normal operation.
Steps Action
1Bypass the Safety-related PLC or take any other appropriate action to avoid a false trip.
2Perform steps 2 and 3 of the Proof Test 1.
3Perform a two-point calibration of the positioner (i.e. 4 mA and 20 mA) and verify that the output current from the module is within the specified accuracy.
This test requires, however, that the positioner has already been tested without the driver and does not contain any dangerous undetected failures.
4Restore the loop to full operation.
5Remove the bypass from the Safety-related PLC or restore normal operation.
D1020 series are isolated Intrinsically Safe Associated Apparatus installed into standard EN50022 T35 DIN Rail located in Safe Area/Non Hazardous Locations or Zone 2, Group IIC,
Temperature Classification T4, Class I, Division 2, Groups A, B, C, D, Temperature Code T4 and Class I, Zone 2, Group IIC, IIB, IIA Temperature Code T4 Hazardous Area/Hazardous
Locations (according to EN/IEC60079-15, FM Class No. 3611, CSA-C22.2 No. 213-M1987, CSA-E60079-15) within the specified operating temperature limits Tamb -20 to +60 °C,
and connected to equipment with a maximum limit for AC power supply Um of 250 Vrms.
Non-incendive field wiring is not recognized by the Canadian Electrical Code, installation is permitted in the US only.
For installation of the unit in a Class I, Division 2 or Class I, Zone 2 location, the wiring between the control equipment and the D1020 associated apparatus shall be accomplished
via conduit connections or another acceptable Division 2, Zone 2 wiring method according to the NEC and the CEC. Not to be connected to control equipment that uses or generates
more than 250 Vrms or Vdc with respect to earth ground. D1020 series must be installed, operated and maintained only by qualified personnel, in accordance to the relevant
national/nternational installation standards (e.g. IEC/EN60079-14 Electrical apparatus for explosive gas atmospheres - Part 14: Electrical installations in hazardous areas (other than
mines), BS 5345 Pt4, VDE 165, ANSI/ISA RP12.06.01 Installation of Intrinsically Safe System for Hazardous (Classified) Locations, National Electrical Code NEC ANSI/NFPA 70 Section
504 and 505, Canadian Electrical Code CEC) following the established installation rules, particular care shall be given to segregation and clear identification of I.S. conductors from non
I.S. ones. De-energize power source (turn off power supply voltage) before plug or unplug the terminal blocks when installed in Hazardous Area/Hazardous Locations or unless area is
known to be nonhazardous. Warning: substitution of components may impair Intrinsic Safety and suitability for Division 2, Zone 2. Explosion Hazard: to prevent ignition of
lammable or combustible atmospheres, disconnect power before servicing or unless area is known to be nonhazardous. Failure to properly installation or use of the equipment
may risk to damage the unit or severe personal injury. The unit cannot be repaired by the end user and must be returned to the manufacturer or his authorized representative.
Any unauthorized modification must be avoided.
Warning
D1020 Associated Apparatus
FM Approved
under Entity Concept
and non-incendive field wiring
Unclassified Locations or
Hazardous (Classified) Locations
Class I, Division 2, Groups A, B, C, D, T-Code T4
Class I, Zone 2, Group IIC, IIB, IIA, T-Code T4
FM Approved under Entity Concept,
or third party approval
Hazardous (Classified) Locations
Class I, Division 1, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class III, Division 1
Class I, Zone 0, Group IIC, IIB, IIA
Intrinsically
Safe Equipment
Must not use or generate
more than 250 Vrms or Vdc
Control
Equipment
Unclassified Locations
Unclassified Locations or
Hazardous (Classified) Locations
Class I, Division 2, Groups A, B, C, D, T-Code T4
Class I, Zone 2, Group IIC, IIB, IIA, T-Code T4
Hazardous (Classified) Locations
Class I, Division 2, Groups A, B, C, D
Class II, Division 2, Groups E, F, G
Class III, Division 2
Class I, Zone 2, Group IIC, IIB, IIA
FM Approved under non-incendive field
wiring (permitted only for US installations),
or third party approval
Non-incendive
Equipment
Unclassified Locations
14
15
1
2
+
-
+
-
-
+
Power Supply
3
4
Must not use or generate
more than 250 Vrms or Vdc
-
+Control
Equipment
6
5
Intrinsically
Safe Equipment -
+
11
10
-
+
-
-
+
+Control
Equipment
Power Supply
Control
Equipment
D1020 Associated Apparatus
FM Approved
under Entity Concept
and non-incendive field wiring
15
11
10
14
2
3
4
6
5
1
-
-
+
+
Non-incendive
Equipment

8 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible G.M. International ISM0012-14
Operation
D1020 isolates and transfers a 0/4-20 mA signal from a controller located in Safe Area/Non Hazardous Locations to an I/P converter, displays or similar equipment located in Hazardous
Area/Hazardous Locations. The circuit allows bi-directional communication signals for smart/hart converters. In the 4-20 mA input range, a field open circuit presents a high impedance to
the control device. A “POWER ON” green led lits when input power is present.
Installation
D1020 series are powered isolating driver smart/hart compatible housed in a plastic enclosure suitable for installation on T35 DIN Rail according to EN50022.
D1020 unit can be mounted with any orientation over the entire ambient temperature range, see section “Installation in Cabinet” and "Installation of Electronic Equipments in Cabinet"
Instruction Manual D1000 series for detailed instructions. Electrical connection of conductors up to 2.5 mm² are accommodated by polarized plug-in removable screw terminal blocks
shich can be plugged in/out into a powered unit without suffering or causing any damage (for Zone 2 or Division 2 installations check the area to be nonhazardous before
servicing). The wiring cables have to be proportionate in base to the current and the length of the cable. On the section “Function Diagram” and enclosure side a block diagram identifies
all connections. Identify the number of channels of the specific card (e.g. D1020S is a single channel model and D1020D is a dual channel model), the function and location of each
connection terminal using the wiring diagram on the corresponding section, as an example:
Connect 24 Vdc power supply positive at terminal “3” and negative at terminal “4”.
For Model D1020D connect 24 Vdc power supply positive at terminal “7” and negative at terminal “8” for channel 2.
For Model D1020S connect positive input of channel 1 at terminal “1” and negative input at “2”.
For Model D1020D in addition to channel 1 connections above, connect positive input of channel 2 at terminal “5” and negative input at “6”.
For Model D1020S connect output at terminal “14” for positive and “15” for negative.
For Model D1020D in addition to channel 1 connections above, connect terminal “10” for positive and “11” for negative on channel 2.
Intrinsically Safe conductors must be identified and segregated from non I.S. and wired in accordance to the relevant national/international installation standards
(e.g. EN/IEC60079-14 Electrical apparatus for explosive gas atmospheres - Part 14: Electrical installations in hazardous areas (other than mines), BS 5345 Pt4, VDE 165,
ANSI/ISA RP12.06.01 Installation of Intrinsically Safe System for Hazardous (Classified) Locations, National Electrical Code NEC ANSI/NFPA 70 Section 504 and 505,
Canadian Electrical Code CEC), make sure that conductors are well isolated from each other and do not produce any unintentional connection.
The enclosure provides, according to EN60529, an IP20 minimum degree of mechanical protection (or similar to NEMA Standard 250 type 1) for indoor installation, outdoor installation
requires an additional enclosure with higher degree of protection (i.e. IP54 to IP65 or NEMA type 12-13) consistent with the effective operating environment of the specific installation.
Units must be protected against dirt, dust, extreme mechanical (e.g. vibration, impact and shock) and thermal stress, and casual contacts. If enclosure needs to be cleaned use only a
cloth lightly moistened by a mixture of detergent in water. Electrostatic Hazard: to avoid electrostatic hazard, the enclosure of D1020 must be cleaned only with a damp or
antistatic cloth. Any penetration of cleaning liquid must be avoided to prevent damage to the unit. Any unauthorized card modification must be avoided. According to EN61010, D1020
series must be connected to SELV or SELV-E supplies.
Start-up
Before powering the unit check that all wires are properly connected, particularly supply conductors and their polarity, input and output wires, also check that Intrinsically Safe conductors
and cable trays are segregated (no direct contacts with other non I.S. conductors) and identified either by color coding, preferably blue, or by marking. Check conductors for exposed
wires that could touch each other causing dangerous unwanted shorts. Turn on power, the “power on” green led must be lit, output signal should be corresponding to the input from the
controller. If possible change the input value and check the corresponding Hazardous Area output.

9
D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatibleG.M. International ISM0012-14
Configuration
Screwdriver
for Trimmers
Ch1 and Ch2
1 x 0.5 mm
Calibration Trimmer Ch1
Span Trimmer
CH1
Calibration Trimmer Ch2
Side B Panel View
Turn the trimmer clockwise to
Increase Output value or turn
the trimmer counterclockwise
if you want to decrease Output
value.
Side A Panel View Span Trimmer
CH2
Calibration instruction and Troubleshooting
In case a calibration check or readjustment is necessary the following equipment is required:
Set power supply (PS) at 24.0 V at terminals 3 (+) and 4 (-), the calibrator (CAL) in the function “mA” 20 mA range at terminals 1 (+) and 2 (-), the multimeter (V1) for the reading in
DC supply 30 V range at terminals 1 (+) and 2 (-), the multimeter (DMM) for the reading in DC supply 20 mA range at terminals 14 (+) and 15 (-).
Execute the next test to verify D1020S unit channel or execute it twice to verified both D1020D unit channels.
Verify that green led on the front panel is ON.
Connect the unit as shown below:
If the power ON Led is off, check supply voltage, polarity and wiring.
Set calibrator (CAL) at 4.000 mA and verify that the output current, read by multimeter (DMM), is correspondent with a maximum deviation presented in the section “Technical Data”.
Set calibrator (CAL) at 20.000 mA and verify that the output current, read by multimeter (DMM), is correspondent with a maximum deviation presented in the section “Technical Data”.
Set calibrator (CAL) at 20.000 mA and power supply (PS) at 20.0 V; verify that multimeter (V1) reads input voltage as presented in the section “Technical Data”.
If the maximum deviation is exceeded, repeat the board calibration and proceed in the following way:
Set the calibrator (CAL) at 20.000 mA and regulate the current, read by multimeter (DMM), by turning the span trimmer of the unit (see “Configuration” section) until reading 20.000
mA ± 5 µA value.
To execute a linearity test: set the calibrator (CAL) at 4.000, 8.000, 12.000, 16.000, 20.000 mA and verify current output is correspondent with
a maximum deviation presented in the section “Technical Data”.
Adjustable Power Supply Range 0-35 V Resolution 0.1 V,
Accuracy 1% Output Capability 200 mA
Current Meter range 20 mA, Resolution 1 µA Accuracy 0.01%
or Voltage Meter Range 10 V, Resolution 1 mV Accuracy 0.01%
Voltage Meter range 30 V, Resolution 1 mV Accuracy 0.05 %
Current Calibrator range 20 mA, Resolution 1 µA Accuracy 0.01 %
Agilent
E3611A
Agilent
34410A
Fluke
175
Yokogawa
7651
Equipment Required Instrument
PS
DMM
V1
CAL
Identification
PS
Supply
=
_
+
V1 CALDMM
mA mA
MODEL D1020D
==
=
14
15
3 +
4 -
1
2
==
=
10
11
5
6
=
=
=
=
In 1
V1 CAL mA
Out 1
+
DMM
mA
Out 2
7 +
8 -
In 2
