Automotive Power Supply Charger
GPC-55-AUTO
GPC-75-AUTO
GPC-100-AUTO
2www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
Installation and Maintenance 3
Troubleshooting 4
Warranty 5
SAFTEY ALERT
FOR YOUR SAFTEY, READ ALL INSTRUCTIONS BEFORE INSTALLATION AND OPERATION.
INSTALLER: Provide these instructions to the end user or consumer.
CONSUMER: Keep these instructions for future reference.
NOTICE: Products are not to be used nor are warranted in aerospace, medical or life safety applications.
WARNING - Avoid Possible Injury or Death
120 VAC is present. This Converter/Charger is designed to convert 120 VAC to 12 VDC. It also provides low voltage power
for charging on-board 12 VDC batteries. The Converter/Charger is a “switch mode” type and is designed to be maintenance-
free with no user serviceable components. The Converter/Charger power output is “current limiting” by design.
WARNING - Avoid Personal Injury or Death
NEVER store electrical devices in compartments where ammable liquids (such as gasoline) exist.
DO NOT mount/install unit in compartments designed for storage of batteries or ammable liquids.
Table of Contents
3
www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
1.0 Installation and Maintenance
1. DISCONNECT DC POWER. Disconnect the battery POS (+) wire at the battery end before connecting this Con-
verter/Charger to any vehicle/device wiring.
2. LOCATION. The mounting location may be on any interior (out of direct weather) surface. Location chosen must
be accessible after installation. When mounted inside a cabinet, the cabinet must be large enough to allow dissi-
pation of heated air. Make sure that there is a minimum of 1” free air space at each end of the unit so that cooling
air can move through the unit properly. AVOID foreign contaminants such as dirt, metal, particles or moisture.
3. MOUNTING. Flanges with holes are provided for ease of mounting using standard fasteners. Conrm the surface
that the converter is mounted to is solid and will hold the weight (6 lbs) during vehicle operation.
4. ELECTRICALREQUIREMENTS. A 120 VAC receptacle needs to be located within 36 inches of the Converter/
Charger to supply power. Electrical consideration should also be given to mounting near the location of the batter-
ies and the 12-volt DC distribution panel.
5. ELECTRICAL CONNECTIONS. Be sure to tighten all connections securely. A loose connection can quickly cause
terminals and wires to overheat. Review unit labels for recommended terminal torque values.
WARNING - Avoid Possible Injury or Death
• The terminal marked - or NEG is for the RV 12 VDC negative connection
• The 12 VDC output wiring does not require over-current protection because the Converter/Charger limits current
output. However, all electrical connections need to comply with the appropriate NEC code.
120 VAC Connection - First conrm that the 120 VAC power source AC circuit breakers are in the OFF position. DO
NOT turn on AC breakers until installation is complete.
• Using an 8 AWG minimum size copper wire, attach from the vehicle/device chassis to the Converter/Charger
Bonding Lug.
• Using the attached power cord on the Converter/Charger, connect rmly to the 120VAC receptacle.
12 VDC Wiring - It is important to use the correct wire gage. Use a minimum of 8 AWG size copper wire.
• The terminal marked + or POS is for the RV 12 VDC positive connection
4www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
6. BATTERY CABLES. This model includes 6 Gauge, 15’ battery cables, CCI code 08566. The cables are rated
at 250 Amp current with 400 Amp clamps, polarity indication label, TPE Insulation (-40°C to +60°C), tangle free
design. SPECS: Ø0.32MM*150STRANDS*OD.9MM.
7. TEST. First, disconnect the POS (+) clamp from the battery or load. Second, attach a multimetre instrument
between the positive and negative clamps of the Converter/Charger. Then energize the 120 VAC converter
circuit. Test for proper output power using the multimetre. Measure the output voltage from the positive and
negative clamps. The voltage should read 13.6 +/-0.2 VDC.
8. BATTERY. With the 120 VAC disconnected, reconnect the POS (+) clamp to a known good battery. With the con-
verter 120 VAC energized, measure the voltage at the converter and at the battery. The voltage should be about
the same. When connected to any charging source all batteries will “gas” and lose some uid.
WARNING - Avoid Personal Injury / Product Damage
9. HI-POT TESTING. (Vehicle/device Manufacturing Facilities Only) DO NOT hi-pot DC wiring with the Converter/
Charger connected to the vehicle/device wiring in order to prevent serious injury and/or damage.
2.0 Trouble Shooting
NOTE: Before removing and replacing the Converter/Charger, perform the following checks:
a. Disconnect the AC power from the Converter/Charger.
b. Disconnect the Battery from the Converter positive +output clamp.
c. Re-connect the AC power to energize the Converter.
d. Using a voltmeter, measure the voltage at the Converter - and +Output clamp.
• The Converter is OK if the voltage reading is between 13 VDC and 14 VDC (typically 13.6 VDC)
• Otherwise check the table on the following page:
AIR FLOW FAN
(on back-side)
Blows air out of front grill vents
Reversed- Battery Polarity Fuses
Chassis Bonding Lug
12 VDC Output Terminals
5
www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
CONDITION POSSIBLE CAUSE
No 12 VDC output • 120 VAC not connected to coach or the coach AC circuit breaker is in the OFF position
• Reversed battery polafuses blown (Battery wiring connections are reversed)
• Severe overload or shorted load. Remove all loads and retest per above instructions
• Converter/Charger internal failure
Converter cycles on and off • Fan air ow is inadequate or blocked (1” minimum free air space at each end required)
• Converter/Charger internal failure
Reversed Battery fuses blown • Battery wiring connections are reversed
• Defective battery, possible bad cells
12 VDC output is too low • Attached load exceeds rating of the Converter/Charger
• Defective battery, possible bad cells
• Converter/Charger internal failure
3.0 Warranty
3.1 Go Power!™ 2 Year Limited Warranty
Go Power!™ provides the following limited 2 year warranty (“warranty”) coverage as applicable to the purchaser
(“Purchaser”) of the Go Power!™ branded product (“Product”) directly from Go Power!™ The following constitutes the
terms and conditions of that limited warranty.
3.1.1 What the Go Power!™ Warranty Covers and for How Long
Subject to the exclusions and claim procedure set out below, Go Power!™ warrants for a period of 2 years from the
date of purchase at the point-of-sale to the original end-user customer (“Sale Date”), that the Go Power!™ Product
provides coverage as follows:
For the period ending 2 years from the Sale Date, Go Power!™ will, at Go Power!™’s discretion, repair or replace
the Product which fails to meet the Product Specications due to a defect in materials or workmanship or apply credit
towards the purchase of new Go Power!™ Product. To exercise this right, the Purchaser shall ship, at its own ex-
pense, and return the Product to Go Power! according to the return instructions detailed below, and Go Power!™ will,
repair or replace the Product and return it to the Purchaser free of charge, or offer credit towards the purchase of new
Product.
Go Power!™ shall be entitled, at its discretion, to use new and/or reconditioned parts in performing warranty repair or
providing a replacement Product. Go Power!™ also reserves the right to use parts or Product of original or improved
design in any repair or replacement. All replaced Product and/or any parts removed from repaired Products become
the property of Go Power!™
If Go Power!™ chooses to repair or replace a Product, the above warranty will continue to apply and remain in effect
for the balance of the warranty period calculated from the Sale Date (and not the repair or replacement date). If Go
Power!™ chooses to offer a credit towards the purchase of new Product, then the warranty in effect and applicable to
the new Product shall apply to the new Product.
6www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
3.1.2 What the Go Power!™ Warranty Does Not Cover
Go Power!™’s warranty does not provide coverage for the following which are expressly excluded from the above
warranty:
• Failure due to normal wear and tear of the Product
• Failure caused by separate computer software supplied with or associated with a Go Power!™ Product
• Failure due to re, water, neglect, improper installation, generalized corrosion, biological infestations, or input
voltages that create operating conditions beyond the maximum or minimum listed in the Go Power!™
specications including lightning strikes
• Products which have been altered other than by Go Power!™ or authorized by Go Power!™
• Products that have their original identication (trademark, serial number) markings defaced altered or removed
• Products utilized as a component part of a product expressly warranted by another manufacturer
• Operation or storage of the Product outside the specication ranges, and/or alteration or deployment of
Go Power!™ Products other than in accordance with any published or provided user, storage or maintenance
requirements
• Failure that is in any way attributable to the improper use, storage, maintenance, installation or placement of the
Go Power!™ Product
• Failure caused by abuse, misuse, abnormal use, or use in violation of any applicable standard, code or
instructions for use in installations, including, but not limited to, those contained in the National Electrical Code,
the Standards for Safety of Underwriters Laboratory, Inc., Standards for the International Electrotechnical
Commission, Standards for the American National Standards Institute, or the Canadian Standards Association
• Failure due to acts of God
3.1.3 Restrictions and Limitations to Go Power!™’s Warranty
• This Warranty is not transferable and only applies to the Purchaser
• Go Power!™ does not warrant the results obtained from the implementation of recommendations made by Go
Power!™ or its authorized distributors concerning the use, design or application of Go Power!™ Products
• The end-user who purchases the Product assumes all responsibility and liability for loss or damage resulting from
the handling or use of Go Power!™ Products
• Go Power!™’s liability on any claim, whether in warranty, contract, negligence, or any other legal theory, for loss,
damage or injury arising directly or indirectly from or in relation to the use of the Go Power!™ Product shall in
no event exceed the purchase price of the Go Power!™ Product which gave rise to the claim. IN NO EVENT
SHALL GO POWER! BE LIABLE FOR PUNITIVE, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
WHETHER FORSEEABLE OR NOT INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS OR REVENUES,
LOSS OF USE OF GOODS, OR LOSS OF BARGAIN.
• The Warranty set out above is the sole warranty granted by Go Power!™ with respect to the Product. No
oral understanding, representations or warranties shall be of any effect and Go Power!™ makes no further
warranties, express or implied concerning the Go Power!™ Products other than the Warranty set out above. The
Buyer, where permitted by applicable law, hereby expressly waives any statutory or implied warranty that the Go
Power!™ Product shall be merchantable or t for a particular purpose.
7
www.gpelectric.com
Auto Power Supply Charger:
GP-55-AUTO
GP-75-AUTO
GP-100-AUTO
3.2 Warranty Return Procedure
Visit www.gpelectric.com to read the “frequently asked questions” section of
our website to troubleshoot the problem. If trouble persists:
1. Call your Go Power!™ Technical Support team (1-866-247-6527).
2. Return defective product to place of purchase.
3.2.1 End Users
Contact your sales representative or Dealer and discuss the problem. Often the sales representative can troubleshoot
common scenarios. If applicable, warranty will be handled between the End User and the Dealer. Go Power!™ will
only accept returned items from an End User as a last resort. If you are unable to contact the Dealer, or the Dealer
refuses to provide service, please contact Go Power! directly.
3.2.2 Dealers
Dealers will handle warranty either through their supplier or Go Power! if they qualify as a Purchaser.
3.2.3 Units bought directly from Go Power!™
The Purchaser will return the product, freight prepaid, to Go Power!™ You must obtain a Return Material Authoriza-
tion (RMA) number from Go Power!™ before returning a product. The RMA number MUST be clearly indicated on the
outside of the box. Items received without an RMA number will be refused.
3.3 Additional Information
Unless approved by Go Power!™ management, all product shipped collect to Go Power!™ will be refused.
3.4 Out of Warranty Items
Go Power!™ electronic products are non-repairable, Go Power!™ does not perform repairs on its products nor does
it contract out those repairs to a third party. Go Power!™ does not supply schematics or replacement parts for any of
its electronic products.
8www.gpelectric.com
