DeWalt DXPAEV2000 User manual

DXPAEV2000
DEWALT Wall Mount Holder
DEWALT Soporte para montaje en pared
DEWALT Support de xation murale
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS

WARNING:
Lea las instrucciones antes de operar
el producto. Si no se siguen todas las instrucciones enu-
meradas a continuación, se pueden producir descargas
eléctricas, incendios y/o lesiones graves.
ADVERTENCIA:
Read and follow instruction manual for the
charger that will be used with this product. Failure to follow
all instructions listed below may result in electric shock, fire
and/or serious injury.
Lire les instructions avant d'utiliser
le produit. Le non-respect de toutes les instructions ci-des-
sous peut entraîner un choc électrique, un incendie et/ou
des blessures graves.
AVERTISSEMENTt:

Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS
DEWALT EV CHARGER, CALL US TOLL FREE AT: 1-855-815-1171..
• The product is intended to be installed and used in indoor and
protected outdoor areas.
SAVE THESE
INSTRUCTIONS
Before First Use
DANGER: Risk of suffocation! Keep any packaging materials
away from children and pets - these materials are a potential
source of danger, e.g. suffocation.
• Remove all packaging materials
• Remove and review all components before use.
• Check the product for transport damages.
IMPORTANT SAFETY
INSTRUCTIONS
INSTRUCTIONS PERTAINING TO RISK OF
FIRE OR ELECTRIC SHOCK!
Read these instructions carefully and retain them for future
use. If this product is passed to a third party, then these
instructions must be included.
WARNING:
Do not use this product if there is any damage to the
unit.
a. Read all the instructions before using this product.
b. Do not put inflammable, explosive or combustible materials,
chemicals, combustible steam or other dangerous goods near
the product.
c. Take care not to drill into any pipes or power lines beneath the
surface during mounting holes preparation. Use a power line /
metal detector.
In the Box
Designed specically for DEWALT 16A (DXPAEV016) and 32A
(DXPAEV032) portable EV chargers for a secure t.
3
English
Main Unit Components
A. Dock Station B. Cable Management
Wall Mounting Hardware
C. Screws (x5) D. Wall Anchors (x5)
C D
AB
DEWALT Wall Mount Holder

REQUIRED TOOLS (NOT INCLUDED)
1. Stud finder
2. Screwdriver
3. Pencil
4. Ø5/16" (8 mm) drill bit
REQUIRED TOOLS (NOT INCLUDED)
4
English
2. Drill the holes into the installation surface.
3. Insert the wall anchors into the holes.
4. Firmly mount the mount holder using the provided screws.
Wall Bracket Installation for
Concrete Walls
1. Use a power line/ metal detector to verify the installation
area has no pipes or power lines beneath the surface. Hold
the wall bracket against the installation surface. Use a level to
ensure that the placement of the wall bracket is horizontal.
Use a pencil to mark the screw holes in the wall bracket onto
the surface.
2. Hold the wall bracket against the installation surface. Align
the vertical line to the holes of the wall bracket. Firmly mount
the wall bracket using the provided screws.
1. Level
2. Pencil 5. Ø5/16" (8 mm) drill bit
3. Stud finder
4. Screwdriver
Wall Bracket Installation for Drywall or
Unfinished Walls
1. Use a stud finder to locate the center of a wall stud. Use a
level and a pencil to draw a vertical line down the center of
the wall stud.
MOUNTING THE WALL BRACKET
MOUNTING THE WALL BRACKET
CAUTION:
It is preferred to mount to a stud.

5
English
Specifications
Max. load 53 Ibs
Model: DAPAEV2000
Working
temperature -22 °F to + 122 °F (-30 °C to + 50 °C)
3. Control box inserted into the dock station and charging
handle inserted into the charging hook.
Accessories
WARNING: Since accessories, other than those offered by
DEWALT, have not been tested with this product, use of such
accessories with this product could be hazardous. To reduce
the risk of injury, only DEWALT recommended accessories should
be used with this product.
If you need assistance regarding accessories, please contact the
manufacturer at 1-855-815-1171 or [email protected]
Service Information
Whether you need technical advice, repair or genuine factory
replacement parts, contact the manufacturer at 1-855-815-1171
or [email protected]
This warranty gives you, the original retail purchaser, specific legal
rights and you may have other rights which vary in certain states or
provinces. This product is not intended for commercial use.
90 DAYS Refund Policy
If you are not completely satisfied with the performance of this
product for any reason, you can return it within ninety (90) days from
the date of purchase with a receipt for a full refund.
Please visit our website www.DEWALT.com/register to register
your new DEWALT product and to be kept up to date on
new products and special offers.
Three Years Limited Warranty
The manufacturer warrants this product against defects in material
and workmanship for a period of three (3) years from the date of retail
purchase by the original end-user purchaser (“Warranty Period”).
If there is a defect and a valid claim is received within the Warranty
Period, the defective product can be repaired, replaced or refunded,
without charge, in the following ways: (1) Return the product to the
manufacturer for repair, replacement or refund at manufacturer’s
option. Proof of purchase may be required by manufacturer. (2)
Return the product to the retailer where product was purchased
for an exchange (provided that the store is a participating retailer).
Returns to retailer should be made within the time period of the
retailer’s return policy for exchanges only (usually 30 to 90 days after
the sale). Proof of purchase may be required. Please check with
the retailer for their specific return policy regarding returns that are
beyond the time set for exchanges.
This warranty does not apply to: accessories, bulbs, fuses and
batteries; defects resulting from normal wear and tear, accidents;
damages sustained during shipping; alterations; unauthorized use or
repair; neglect, misuse, abuse; and failure to follow instructions for
care and maintenance for the product.
