Go Power GP-ISW-700 User manual

PURE SINE WAVE INVERTER
GP-ISW-700/1000/1500/2000/3000/4000
User Manual
GP-ISW
© 2018 Go Power!®
Worldwide Technical Support and Product Information gpelectric.com
Go Power! Headquarters
201-710 Redbrick St, Victoria, BC Canada V8T 5J3
Tel: [phone]
78158_MAN_ISW_RevD.indd

[page 2] | gpelectric.com
Congratulations on purchasing your Go Power! GP-ISW Inverter. The unit is a highly reliable DC-
AC inverter system, designed with advanced power electronic and microprocessor technology
o󰀨ering the following features;
• Pure Sine wave output (THD <5%).
• Intelligent power management software.
• Load and temperature controlled cooling fan.
• GP-SWR-A/GP-ISW-R management and control.
• Dry contact terminals.
• Advance protection features;
• Input over/under voltage protection.
• Internal over temperature protection.
• Input reverse polarity protection (fuse).
• Output overload protection.
• Output short-circuit protection.
Product Packaging
Please safely store the packaging the GP-ISW was delivered in or please
recycle the packaging components as outlined below;
CFB
CFB
3
4
7
CFB
CFB
3
4
7
Plastic Bag
Plastic Foam
Plastic Bubble
Wrap
LDPE
Low Density
Polyethylene
CFB
CFB
3
4
7
CFB
CFB
3
4
7
CFB
CFB
3
4
7
Corrugated berboard
Main box &
Internal sleeve
CFB
CFB
3
4
7
Corrugated
Recycles
www.corrugated.org
www.earth911.com/recycling-center-search-guides
Local recycling centres can be found here;

gpelectric.com | [page 3]
1. CONTENTS
2. GENERAL INFORMATION .................................................................................................4
2.1 CAUTIONS / WARNINGS.................................................................................4
2.2 DISCLAIMERS................................................................................................10
2.3 GP-ISW KIT PARTS........................................................................................ 11
2.3.1 PARTS CHECKLIST ......................................................................... 11
2.4 GP-ISW FEATURES.......................................................................................12
2.5 UNIT DIMENSIONS........................................................................................14
2.6 VOLTAGE AND TEMPERATURE PERFORMANCE ......................................15
3. INSTALLATION .................................................................................................................16
3.1 TYPICAL SYSTEM OVERVIEW.................................................................... 16
3.2 MOUNTING REQUIREMENTS ..................................................................... 20
3.3 DC WIRING ................................................................................................... 22
3.3.1 DC WIRING SIZING .........................................................................23
3.3.2 DC OVERCURRENT PROTECTION ...............................................24
3.3.3 PREPARING THE DC CABLES .......................................................24
3.3.4 DC CABLE CONNECTIONS ............................................................24
3.3.5 WIRING THE INVERTER TO THE BATTERIES ..............................25
3.3.6 DC GROUNDING .............................................................................26
3.4 AC WIRING.................................................................................................... 27
3.4.1 AC OUTPUT INTERFACE ................................................................27
3.4.2 GP-ISW 3000/4000 AC OUTPUT INTERFACE................................27
3.4.3 GFCI (GROUND FAULT CIRCUIT INTERRUPTION) OUTLETS .....28
4. OPERATION......................................................................................................................29
4.1 FINAL INSPECTION.......................................................................................29
4.2 TESTING THE INSTALLATION ......................................................................29
4.3 CONNECTING THE AC LOADS.....................................................................29
4.4 LED INDICATORS ..........................................................................................30
4.4.1 INPUT VOLTAGE LEVEL..................................................................30
4.4.2 INVERTER STATUS TO DISPLAY FAULT CONDITION ..................31
4.5 FUNCTION SWITCH ......................................................................................31
4.5.1 OUTPUT VOLTAGE SELECTION (S1&S2)......................................32
4.4.2 OUTPUT FREQUENCY SELECTION (S3) ......................................32
4.6 POWER SAVING SELECTION (S4)...............................................................32
4.8 SHUTDOWN CONDITIONS ...........................................................................33
5. WARRANTY RETURN PROCEDURE ..............................................................................34
6. SPECIFICATIONS .............................................................................................................35
7. PRODUCT END OF LIFE & RECYCLING........................................................................41
www.earth911.com/recycling-center-search-guides

[page 4] | gpelectric.com
2.1 CAUTIONS / WARNINGS
This document contains important safety instructions for the products produced by
Go Power. Read all instructions and cautionary markings on the product and on any
accessories or additional equipment included in the installation. Failure to follow these
instructions could result in severe shock or possible electrocution. Use extreme caution at
all times to prevent accidents.
All electrical work must be performed in accordance with local and national electrical codes.
These instructions are for use by qualied personnel who meet all local and governmental
code requirements for licensing and training for the installation of electrical power systems
with AC and DC voltage up to 600 volts.
Installation, maintenance, and connection of inverters must be performed by qualied
personnel, in compliance with local electrical standards, wiring rules, and the requirements
of local power authorities and/or companies.
Safety regulations relevant to the location shall be followed during installation, operation and
maintenance. Improper operation may have a risk of electric shock or damage to equipment
and property.
2. GENERAL INFORMATION

gpelectric.com | [page 5]
GENERAL INFORMATION
General Safety
WARNING!
Limitations on Use
CAUTION!
Equipment Damage
This equipment is NOT intended for use with life support
equipment or other medical equipment or devices.
This product is designed for indoor/compartment
installation. It must not be exposed to any liquids, moisture
of any type.
Only use components or accessories recommended or sold
by Go Power! or its authorized agents.
IMPORTANT
Do not attempt to install this equipment if it appears to
be damaged in any way. See the Warranty section for
instructions on returning the equipment.
WARNING!
Hazard to Human Life
This type of notation indicates that the
hazard could be harmful to human life.
WARNING!
Shock Hazard Danger of shock or electrocution.
WARNING!
Burn / Fire Hazard Danger of hot surface and/or re.
CAUTION!
Hazard to Equipment
This type of notation indicates that
the hazard may cause damage to the
equipment.
IMPORTANT
This type of notation indicates that the
information provided is important to the
installation, operation and/or maintenance
of the equipment. Failure to follow the
recommendations in such a notation could
result in annulment of the equipment
warranty.
i

[page 6] | gpelectric.com
GENERAL INFORMATION
Personal Safety
WARNING!
Personal Injury
Use safe lifting techniques when lifting this equipment as
recommended by the Occupational Safety and Health
Association (OSHA) or other local codes.
Use standard safety equipment when working on this
equipment, such as safety glasses, ear protection, steel-
toed safety boots, safety hard hats, etc.
Use standard safety practices when working with electrical
equipment. (Remove all jewelry, use insulated tools, wear
cotton clothing, etc.)
Never work alone when installing or servicing this
equipment. Have someone nearby that can assist if
necessary.
Ensure that children, pets, and other animals are kept away
from the inverter, solar arrays, battery bank, and utility grid
components.
If the equipment is used in a manner not specied by the
manufacturer, the protection provided by the equipment may
be impaired.

GENERAL INFORMATION
Equipment Safety
WARNING!
Lethal Voltage
Review the system conguration to identify all possible
sources of energy. Ensure ALL sources of power are
disconnected before performing any installation or
maintenance on this equipment. Conrm that the terminals
are de-energized using a validated voltmeter (rated for
a minimum 1000 VAC and 1000 VDC) to verify the de-
energized condition.
Do not perform any servicing other than that specied in the
installation instructions unless qualied to do so, or have
been instructed to do so by Go Power! Technical Support
personnel.
To avoid electric shock, disconnect the DC input and AC
input of the inverter at least 5 minutes before performing any
installation or maintenance.
Do not tighten the AC and DC terminals or pull on the AC and
DC wiring when the inverter is running.
WARNING!
Fire Hazard
Do not keep combustible or ammable materials in the same
room with the equipment. Some products contain relays with
moving parts and are not ignition-protected.
Ensure AC, DC, and ground cable sizes conform to local
codes. See product manuals for minimum size requirements.
Ensure all conductors are in good condition.
Do not operate the unit with damaged or substandard cabling.
CAUTION!
Equipment Damage
When connecting cables from the inverter to the battery
terminals, ensure the proper polarity is observed. Connecting
the cables incorrectly can damage or destroy the equipment
and void the product warranty.
Thoroughly inspect the equipment prior to energizing. Verify
that no tools or equipment have been inadvertently left
behind.
Keep all vents clear of obstructions that can prevent proper air
ow around, or through, the unit.
CAUTION!
Equipment Damage
Static electricity may damage electronic components. Take
appropriate steps to prevent such damage to the inverter;
otherwise the warranty may be annulled.
gpelectric.com | [page 7]

[page 8] | gpelectric.com
GENERAL INFORMATION
Battery Safety
WARNING!
Explosion, Electrocution,
or Fire Hazard
Ensure the cables (conductors) are properly sized.
Ensure clearance requirements are strictly enforced around
the batteries.
Ensure the area around the batteries is well ventilated and
clean of debris.
Never smoke, or allow a spark or ame near, the batteries.
Always use insulated tools. Avoid dropping tools onto
batteries or other electrical parts.
Never charge a frozen battery.
Never use old or untested batteries. Check each battery’s
label for age, type, and date code to ensure all batteries are
identical.
If a battery must be removed, always remove the grounded
terminal from the battery rst. Make sure all devices are de-
energized or disconnected to avoid causing a spark.

gpelectric.com | [page 9]
IMPORTANT
Use the battery types recommended by Go Power. Follow
the battery manufacturer’s recommendations for installation
and maintenance.
Insulate batteries as appropriate against freezing
temperatures. A discharged battery will freeze more easily
than a charged one.
If a remote or automatic generator control system is used,
disable the starting circuit and/or disconnect the generator
from its starting battery while performing maintenance to
prevent accidental starting.
Wear complete eye and clothing protection when working
with batteries. Avoid touching bare skin or eyes while working
near batteries.
Keep plenty of fresh water and soap nearby in case battery
acid contacts skin, clothing, or eyes.
If battery acid contacts skin or clothing, wash immediately
with soap and water. If acid enters the eye, immediately
ood it with running cold water for at least 20 minutes and get
medical attention as soon as possible.
CAUTION!
Equipment Damage
When connecting cables from the inverter to the battery
terminals, ensure the proper polarity is observed. Connecting
the cables incorrectly can damage or destroy the equipment
and void the product warranty.
Thoroughly inspect the equipment prior to energizing. Verify
that no tools or equipment have been inadvertently left
behind.
Ensure clearance requirements are strictly enforced.
Keep all vents clear of obstructions that can prevent proper
air ow around, or through, the unit.
CAUTION!
Equipment Damage
Static electricity may damage electronic components. Take
appropriate steps to prevent such damage to the inverter;
otherwise the warranty may be annulled.
i

[page 10] | gpelectric.com
2.2 DISCLAIMERS
IMPORTANT: Please follow installation and wiring instructions exactly as outlined to ensure
safety. We recommend installation by an RV/marine technician or professional electrician
to ensure adherence to relevant electrical codes. We have made every reasonable e󰀨ort to
ensure the accuracy of the instructions in this manual, but Go Power does not guarantee that
the information is error free, nor do we make any other representation, warranty or guarantee
that the information is accurate, correct, reliable or current. The specications in this manual
are for reference purposes only and are subject to change without notice. For additional
information please see www.gpelectric.com.
DISCLAIMER: Go Power disclaims liability for any direct, indirect or incidental damages
caused by, or in case of, installation not performed following the instructions and cautions in this
manual. Go Power will refuse requests for exchanges or returns, resulting from the purchase
and installation of items which do not comply with local codes. To avoid such concerns Go
Power recommends installation by a professional electrician or RV technician. Examples that
are shown within this manual are for illustrative purposes only.
GENERAL INFORMATION

gpelectric.com | [page 11]
GENERAL INFORMATION
2.3 GP-ISW KIT PARTS
Please unpack and make sure all parts shown in the list below are included in the kit. If any
parts are missing please contact Carmanah’s customer service team at customerservice@
gpeledtric.com or 1.866.247.6527.
2.3.1 PARTS CHECKLIST
ITEM # DESCRIPTION
01 GP-ISW Unit 1
02 Ring lugs 2
03 Phillips Screws 4
04 DC Terminal Covers 2
2 134

[page 12] | gpelectric.com
A
A
A
B
C
D
B
C
D
B
C
D
E
F
E
F
E
F
A
B
E
D
C
A
B
E
D
C
A
B
E
D
C
GENERAL INFORMATION
2.4 GP-ISW FEATURES
D
E
C
B
APower saving adjustment - This dial is used to adjust the power saving function, it is
used to set the input and wake up power thresholds (see page 33).
Function Switch - This dip switch is used to select between di󰀨erent voltages,
frequencies and to turn the power saving mode ON and OFF (see page 31).
Function LEDs - These 3 LEDs are used to display (1) Input Voltage Level, (2) Output
Load Level, (3) Fault Conditions (see page 30).
AC Output Socket or Output Terminal (3000W and 4000W only) - Use these sockets/
terminal to connect the AC loads (appliances) to the Inverter.
ON / OFF / REMOTE- Use this button to turn the inverter ON, OFF or to switch the
inverter into REMOTE MODE.

gpelectric.com | [page 13]
GENERAL INFORMATION
Remote port - Use this port to connect the optional remote control unit to the Inverter.
Remote control green terminal - This terminal may be connected to a form C relay for
“FAULT” indication. When “FAULT” occurs, the relay switches.
Chassis Ground - Use this connection to ground the exposed chassis of the inverter to
the chasis ground.
DC Input Connector - Use these connection points to secure the battery bank negative
and positive cables to the Inverter. Always ensure the DC terminal covers are used to
protect the terminals.
4
3
2
1
1
1
2 3
2
3
4
4
4 4
4
1
2
3

[page 14] | gpelectric.com
DC Input Side
DC Input Side
AC Output SideAC Output Side
ISW-700/1000
ISW-1500/2000/3000/4000
D
E
A
B
C
E
F
F
A
D
B
C
F
F
DC Input Side
DC Input Side
AC Output SideAC Output Side
ISW-700/1000
ISW-1500/2000/3000/4000
D
E
A
B
C
E
F
F
A
D
B
C
F
F
Model A (mm) B (mm) C (mm) D (mm) E (mm) F (mm)
GP-ISW700 330 80 132 200 7.0 83
GP-ISW1000 372 69 196 200 7.0 83
GP-ISW1500 421 92 196 248 7.0 83
GP-ISW2000 443 103 196 248 7.0 83
GP-ISW3000 442 103 196 255 7.0 158
GP-ISW4000 462 113 196 255 7.0 158
GENERAL INFORMATION
2.5 UNIT DIMENSIONS

gpelectric.com | [page 15]
0%
10.5V
Continue
1 Min
1 Sec
1 Sec
21V
42V
16V
32V
64V
Voltage (V)
Power (W)
ISW-700~2000
Power / Voltage Curve
16.5V
33V
66V
100%
115%
175%
0%
10.5V
Continue
1 Min
1 Sec
1 Sec
21V
42V
16V
32V
64V
Voltage (V)
Power (W)
ISW-3000/4000
Power / Voltage Curve
16.5V
33V
66V
100%
115%
200%
0%
-20oC 0oC 40oC 60oC
Continue
Output Power
1 Min
1 Sec
Power (W)
Temperature (oC)
ISW-700-2000
Power / Temperature Curve
100%
40%
115%
175%
0%
-20oC 0oC 40oC 60oC
Continue
Output Power
1 Min
1 Sec
Power (W)
Temperature (oC)
ISW-3000-4000
Power / Temperature Curve
100%
40%
115%
200%
0%
10.5V
Continue
1 Min
1 Sec
1 Sec
21V
42V
16V
32V
64V
Voltage (V)
Power (W)
ISW-700~2000
Power / Voltage Curve
16.5V
33V
66V
100%
115%
175%
0%
10.5V
Continue
1 Min
1 Sec
1 Sec
21V
42V
16V
32V
64V
Voltage (V)
Power (W)
ISW-3000/4000
Power / Voltage Curve
16.5V
33V
66V
100%
115%
200%
0%
-20oC 0oC 40oC 60oC
Continue
Output Power
1 Min
1 Sec
Power (W)
Temperature (oC)
ISW-700-2000
Power / Temperature Curve
100%
40%
115%
175%
0%
-20oC 0oC 40oC 60oC
Continue
Output Power
1 Min
1 Sec
Power (W)
Temperature (oC)
ISW-3000-4000
Power / Temperature Curve
100%
40%
115%
200%
GENERAL INFORMATION
2.6 VOLTAGE AND TEMPERATURE PERFORMANCE

[page 16] | gpelectric.com
Cable to
GP-ISW Unit
FM
80
30 Amp
Breaker
Fuse
Block
Battery Bank
MC4 Connector
Refrigerator
Vent Cover
100W or 160W
Solar Panel
Mate 2
Legend
Remote
10 Ft Extension Cable
10AWG (Included)
25 Ft Cable
10AWG (Included)
For this system we
recommend a minimum of
6 batteries / 600 Amp Hour
Battery Bank
RV Console
Area
Solar
Controller
Cable to
Battery Bank
Battery Bank
GP-ISW
Inverter
Solar Panels
Cables From
Solar Charge Controller
Internal
View
GP-ISW
Remote
Cable to
Inverter
Refrigerator
Vent Cover
100W or 160W
Solar Panel
Solar
Controller
Fuse
Block
Inverter
Inverter
Remote
AC
Loads
AC
Panel
Transfer
Switch
Fuse
Block
Converter /
Charger
Shore Power
/ Generator
AC Power OUTPUT
- to RV appliances
Cables to / from
Battery Bank
3. INSTALLATION
3.1 TYPICAL SYSTEM OVERVIEW
The following diagrams on pages 16-19 show how the GP-ISW-Inverter and GP-ISW-R are
typically installed in a mobile RV application. The diagrams show where the remote and Inverter
are installed and how the mobile power system can be integrated with a Go Power! RV Solar
Kit (sold separately by Go Power, please contact an authorized dealer directly).

gpelectric.com | [page 17]
Cable to
GP-ISW Unit
FM
80
30 Amp
Breaker
Fuse
Block
Battery Bank
MC4 Connector
Refrigerator
Vent Cover
100W or 160W
Solar Panel
Mate 2
Legend
Remote
10 Ft Extension Cable
10AWG (Included)
25 Ft Cable
10AWG (Included)
For this system we
recommend a minimum of
6 batteries / 600 Amp Hour
Battery Bank
RV Console
Area
Solar
Controller
Cable to
Battery Bank
Battery Bank
GP-ISW
Inverter
Solar Panels
Cables From
Solar Charge Controller
Internal
View
GP-ISW
Remote
Cable to
Inverter
Refrigerator
Vent Cover
100W or 160W
Solar Panel
Solar
Controller
Fuse
Block
Inverter
Inverter
Remote
AC
Loads
AC
Panel
Transfer
Switch
Fuse
Block
Converter /
Charger
Shore Power
/ Generator
AC Power OUTPUT
- to RV appliances
Cables to / from
Battery Bank
INSTALLATION

[page 18] | gpelectric.com
ON
OFF
Sub Panel
ISW Remote Control (Optional)
Solar Panel
Solar Panel
Solar Charge
Controller
Refrigerator
Vent Cover
or
Cable Entry Plate
Fuse
Battery Disconnect Switch
(not required if circuit breaker is used)
Battery Bank
Fuse or Circuit Breaker
GP-ISW
To Battery
Bank
To Battery
Bank
DC Panel
Earth Ground (RV Ground)
AC
Loads
INSTALLATION

gpelectric.com | [page 19]
ON
OFF
Sub Panel
ISW Remote Control (Optional)
Solar Panel
Solar Panel
Solar Charge
Controller
Refrigerator
Vent Cover
or
Cable Entry Plate
Fuse
Battery Disconnect Switch
(not required if circuit breaker is used)
Battery Bank
Fuse or Circuit Breaker
GP-ISW
To Battery
Bank
To Battery
Bank
DC Panel
Earth Ground (RV Ground)
AC
Loads
INSTALLATION

[page 20] | gpelectric.com
3.2 MOUNTING REQUIREMENTS
1. TEMPERATURE
Make sure the GP-ISW is installed in a location where the normal air temperature is between
-20°C and 40°C. The cooler the better within this range.
2. MOISTURE
Do not allow water or other uids to come into contact with the GP-ISW. Do not expose to
rain, snow or water.
3. VENTILATION
For optimum Inverter performance the GP-ISW must be installed so the front and rear air vents
are not blocked or obstructed in any way. Do not install the GP-ISW in an area with limited
air ow. Allow as much space around the Inverter as possible, leaving at least 4 inches of
airspace clearance around all ventilation areas.
CAUTION! Equipment Damage. Do not mount the GP-ISW in a zero clearance
compartment. Do not cover the ventilation openings. Overheating and mechanical
failure may occur.
4. FIRE
Install the GP-ISW away from the battery bank, away from any ammable or combustible
material (paper, ammable liquids, gasoline, cloths) that may be ignited by heat, sparks or
ames. Never place the Inverter directly above the battery bank - gases from the batteries will
corrode and damage the Inverter, never allow battery acid to drip onto the unit.
5. ACCESSIBILITY / ORIENTATION
Do not block access to the GP-ISW remote control access port, status LEDs and the On/O󰀨
switch. Allow enough room to access the AC and DC wiring terminals and connections as
they will need to be checked and tightened periodically. The GP-ISW must be installed in one
of the approved mounting orientations detailed on page 20. DO NOT MOUNT VERTICALLY.
6. CLEAN
The GP-ISW should be installed in a location which is clean and limits the introduction of dust,
fumes, insects or rodents which could enter and block the Inverter ventilation openings.
7. PROXIMITY TO BATTERY BANK
The GP-ISW should be located as close to the batteries as possible but not within the same
compartment. The length and size of the DC Cables will a󰀨ect performance. Long DC wires
tend to lose e󰀩ciency and reduce the overall performance of the Inverter/Charger. Use the
DC cables recommended on page 23.
INSTALLATION
