GOAL ZERO Light-A-Life mini User manual

1

1
Table of Contents
Get To Know Your Gear 2
How It Works 4
Chaining 4
Technical Specifications 5
Français 6-9
日本語 10-13
Deutsch 14-17
Español 18-21

2 3
Carabiner
CONTROL DECKGET TO KNOW YOUR GEAR
USB Output
for chaining USB Input for powering or chaining
Shade
Area Light (up)
Lantern Light (down)
Chainable
Power Switch
off/ low/ high settings

4 5
HOW IT WORKS
1. Insert the USB plug into any live USB port. We
recommend pairing it with a Goal Zero Recharger or
Power Pack.
2. Push the power switch on the top of individual lights
to turn them on, pushing the switch all the way
through for full brightness and halfway through for low
brightness.
3. Slide shades up or down for area or lantern light.
WARNING: While in use, the metal neck of the
Light-A-Life mini will become hot to the touch.
With one Light-A-Life mini plugged in, connect additional
lights together via the USB ports.
You can chain up to 4 Light-A-Life minis together. Chained
lights can be turned on and off independent of each other.
RUN TIME LOW HIGH
Goal Zero Switch 10 14+ hours 4 hours
Flip 20 28+ hours 8 hours
Venture 30 42+ hours 12 hours
Sherpa 50 70+ hours 20 hours
TECHNICAL SPECIFICATIONS
Light-A-Life mini
Light (output) 1.9W max
LED Rating 3500K LED
High: 110 Lumens each
Low: 30 Lumens each
Input (USB-male) 5V, 0.38A (1.9W max)
General
Chainable Up to 4
Weight 2.4oz (68g)
Dimensions (compact) 1.48Dia x 2.23in
(37.7Dia x 56.7mm)
Dimensions (extended) 1.48Dia x 2.82in
(37.7Dia x 71.5mm)
Operating Usage Temp. 0°-140° F (-18°-60° C)
Certs
Warranty 12 months
Use With Goal Zero rechargers
and power packs
CHAINING Be sure to activate your warranty at
goalzero.com/warranty

4 5
HOW IT WORKS
1. Insert the USB plug into any live USB port. We
recommend pairing it with a Goal Zero Recharger or
Power Pack.
2. Push the power switch on the top of individual lights
to turn them on, pushing the switch all the way
through for full brightness and halfway through for low
brightness.
3. Slide shades up or down for area or lantern light.
WARNING: While in use, the metal neck of the
Light-A-Life mini will become hot to the touch.
With one Light-A-Life mini plugged in, connect additional
lights together via the USB ports.
You can chain up to 4 Light-A-Life minis together. Chained
lights can be turned on and off independent of each other.
RUN TIME LOW HIGH
Goal Zero Switch 10 14+ hours 4 hours
Flip 20 28+ hours 8 hours
Venture 30 42+ hours 12 hours
Sherpa 50 70+ hours 20 hours
TECHNICAL SPECIFICATIONS
Light-A-Life mini
Light (output) 1.9W max
LED Rating 3500K LED
High: 110 Lumens each
Low: 30 Lumens each
Input (USB-male) 5V, 0.38A (1.9W max)
General
Chainable Up to 4
Weight 2.4oz (68g)
Dimensions (compact) 1.48Dia x 2.23in
(37.7Dia x 56.7mm)
Dimensions (extended) 1.48Dia x 2.82in
(37.7Dia x 71.5mm)
Operating Usage Temp. 0°-140° F (-18°-60° C)
Certs
Warranty 12 months
Use With Goal Zero rechargers
and power packs
CHAINING Be sure to activate your warranty at
goalzero.com/warranty

CA082316
GOAL ZERO HEADQUARTERS
675 West 14600 South
Bluffdale, UT 84065
1-888-794-6250
Designed in the U.S.A.
Made in China
Light-A-Life is a trademark of Goal Zero.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
