Goldacres SuperFlow Programming manual

SuperFlow Mobile
Hopper
Operator’s & Parts Manual
GA8700134 REV 3 - NOV 2019

2
Contents
Contact
Goldacres
1-3 Morang Crescent,
Mitchell Park Vic 3355
P: 03 5342 6399
F: 03 5342 6308
[email protected]
Disclaimer
Any advice or recommendations given by Goldacres, Goldacres’ dealers, or employees is given in good faith and provided
based on the best information available to us. No liability or responsibility is accepted or implied as a result of any
information or advice tendered in this operating manual or by Goldacres its agents or employees. The end user accepts all
responsibility arising from that advice. No part of this manual may be reproduced without written permission from Goldacres.
All photographs and technical information remain the property of Goldacres.
Introduction ...........................3
Safety................................4
Goldacres Warranty Statement.............8
Terms & Conditions .....................9
General Information & Specications........11
Dimensions...........................12
Key Features .........................13
Operation ............................14
Flushing .............................14
Storage .............................15
Maintenance..........................16
Troubleshooting .......................16
Hopper Frame ........................17
Hopper Tank..........................18
Hopper Bottom .......................19
Drum Rinse Assembly ..................20
Hopper Rinse Assembly .................21
Water Inlet Assembly ...................22
Short Hose Assembly ...................22
Long Hose Assembly ...................23

3
Introduction
Congratulations on your purchase of a
Goldacres sprayer. For more than a quarter
of a century Goldacres has supplied
Australian farmers with quality, innovative
and technologically advanced spraying
solutions - equipment designed in Australia
for Australian conditions.
Goldacres not only produce Australia’s nest
range of spraying equipment - we also keenly
value the unique relationship we enjoy with
owners of our equipment. We are pleased to
welcome you as a Goldacres owner and look
forward to making your spray applications as
efcient as possible.
Please use this comprehensive resource to
gain a full understanding of your equipment,
and don’t hesitate to contact your Goldacres
Dealer or Goldacres for further information.
Roger Richards
General Manager

4
Safety
General
The following pages outline important
safety information. At Goldacres safety is
a high priority. These safety and warning
instructions MUST be followed to ensure the
safe operation of your Goldacres equipment.
Explanation of key terms used in this
operator’s manual are:
DANGER - You will be killed or seriously hurt
if you don’t follow instructions
WARNING - You can be seriously hurt if you
don’t follow instructions
CAUTION - You can be hurt if you don’t
follow instructions
NOTE - Is used to notify people of
installation, operation or maintenance
information that is important but not hazard
related.
The Operator
All operators of this equipment should be
adequately trained in the safe operation
of this equipment. It is important that all
operator’s have read and fully understand
the operators manual prior to using this
equipment.
All new operators should be trained in an
area without bystanders or obstructions and
become familiar with the sprayer prior to
operation.
Safety Precautions
WARNINGS
• Keep clear of overhead obstructions.
• CRUSH HAZARD - Keep hands clear of
moving parts
• Any unauthorised modications to this
equipment may affect its function and
create a serious safety risk.
• Never attempt to clean parts by blowing
with mouth.
• Never attempt to siphon chemicals, or
substances, by sucking.
NOTE: 1 LITRE WATER = 1KG.
• Water weighs 1kg per litre, however
conversion factors must be used when
spraying liquids that are heavier or lighter
than water. Example: liquid urea has a
density of 1.28 kg/L and will therefore be
signicantly heavier than water if the tank
is lled completely.
CAUTIONS
• A supply of fresh water should be with
the equipment at all times.
• Standard polyethylene tanks are not
designed for use with diesel fuel or any
ammable liquid.
• Do not use this machine in ambient
temperatures exceeding 40 degrees
Celsius.
• Ensure that all bolts are tightened and
secured before operation.
• Area surrounding equipment may
become slippery when wet.
NOTES
• Always read and understand the
operator’s manual prior to operation of
this equipment.
• It is the responsibility of the operator
to ensure that there are no decals
missing from the equipment and that any
damaged or missing decals are replaced
prior to operation.
• Goldacres equipment ordered or
operated, outside the guideline
limitations may not be warranted by
Goldacres for successful performance.
Operators working outside these
limitations do so at their own risk, unless
specic advice has been sought from
and provided by Goldacres in writing.
• Always read and follow the chemical
manufacturer’s guidelines for safe
application as per the chemical label.
Particular attention should be given to
the recommended target application rate
of the chemical being applied as per the
chemical label.
• Inspect the equipment thoroughly for
damage and wear before operation.
• Flush chemicals from equipment
immediately after use.
Continued over page

5
Continued over page
• Certain chemicals may be unsuitable for
use with Goldacres standard plumbing
designs. Consult your Goldacres dealer if
in doubt.
• Do not operate the equipment while
under the inuence of any drugs, alcohol
or if excessively tired.
• Make sure that the equipment complies
with all relevant road regulations when
transporting.
• When draining uids from the equipment
use appropriate, leak proof containers.
Do not use food or beverage containers
as someone may consume the contents
by mistake.
• After reading the operator’s manual
if there is any thing that you do not
understand please contact your
Goldacres dealer.
Safe Chemical Use
The safe use of Ag chemicals with this
equipment is the responsibility of the owner/
operators. All operators should be trained
in the safe use of Ag chemicals. Goldacres
suggest that a relevant course is completed
by owners/operators prior to operation of
this equipment as a spray unit.
Personal Protective Equipment (PPE)
Always wear close tting clothing and safety
equipment designed for the job.
Chemicals can be harmful to humans,
appropriate PPE should be used when
handling chemicals.
Always refer to the chemical manufacturers
label for guidelines on the appropriate PPE
to use with the chemicals you are using.
Goldacres also suggest that you read
and understand the following Australian
standards:
• Australian Standard for Chemical
protective clothing AS3765
• Australian Standard for Respiratory
protection devices AS1715
Airborne particles
Always stand well clear of equipment during
operation. Any spray drift is dangerous and
may be hazardous to humans and animals.
Fluids under pressure
Do not disconnect any hoses, nozzles
or lters while equipment is operating.
Disconnecting these components while
under pressure may result in uncontrolled
uid discharge which may be hazardous.
When the repair is complete ensure that
all ttings and lines are secured before re-
applying pressure.
Cuts, Stabs & Punctures
When Servicing machine, be mindful of sharp
edges on parts such as trimmed cable ties,
hose clamps, cut reinforced hose and the
edges of plates and brackets as they could
cause cut, stab or puncture injuries.

6
Safety Decals
Understanding safety decals and their
purpose assists in the safe operation of your
sprayer. Safety decals are there for your
protection and it is the responsibility of the
owner operator to replace damaged and/or
missing safety decals.
Regularly review safety decals with
operators. It is very important to ensure
that all new machine components and
replacement parts include current hazard
identication decals.
Replacement safety decals can be ordered
from all Goldacres dealers.
SuperFlow Mobile Hopper Kit GA8700450 = GA8701152 + GA8700451

7
