Goldair GOC137T User manual

Operating Instructions
OilColumnHeaterwithTimer
Model: GOC137T

General Care and Safety Guide
Thank you for choosing a Goldair Oil Heater. This Goldair Heater has been
designed and manufactured to high standards of engineering and with
proper use and care, as described in this leaflet, will give you years of
useful service. Please read these instructions carefully.
TECHNICAL SPECIFICATION
Model No: GOC137T
Supply: 220-240VAC 50Hz
Wattage: 1500W
1. Use only the voltage specified on the rating label
of the appliance.
2. Keep all objects at least 1 metre from the front,
sides and rear of the appliance. Do not place
appliance close to radiant heat source.
3. Do not operate in areas where petrol, paint or
other flammable liquids are used or stored.
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the
appliance. Do not sit on the appliance.
5. Do not operate this appliance with a damaged
cord, plug or after the appliance malfunctions or
has been dropped or damaged in any manner.
Return to a qualified electrical person for
examination, electrical service or repair.
6. This appliance is intended for household use
only and not for commercial or industrial use.
7. Use this appliance only as described in this
manual. Any other use is not recommended by
the manufacturer and may cause fire, electrical
shock or injury.
8. The common cause of overheating is deposits of
dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging
the appliance and vacuum cleaning the air vents
and grills.
9. Do not use abrasive cleaning products on this
appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove
plug from the mains supply before cleaning.
10. Do not connect the appliance to mains supply
until completely assembled and adjusted.
11. Switch off and use handles provided when
moving.
12. Do not operate with cord set coiled up as a heat
build up is likely, which could be sufficient to
become a hazard.
13. Do not use an extension cord, powerboard, or
external Timer with this unit.
14. Do not remove plug from power socket until the
appliance has been switched off.
15. Do not remove plug from power socket by
pulling cord; always grip plug.
16. Always unplug appliance when not in use.
17. Do not locate the heater directly below any
power socket during operation.
18. Do not twist, kink or wrap the cord around the
appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord
has been removed from any cord storage area
and is unrolled before use.
19. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they are
supervised or have been given instruction
concerning the use of the appliance by a person
responsible for their safety.
20. Do not use this appliance in the immediate
surrounds of a bath, a shower, or a swimming
pool or other liquids. The appliance must not be
immersed in any liquids.
21. When the appliance has been unpacked, check
it for transport damage and ensure all parts have
been delivered. If parts are missing or the
appliance has been damaged, contact the
Goldair Customer Services Team.
22. If your appliance does not work, or is not
working properly, contact the place of purchase
or the Goldair Customer Services Team. Repair
work on the appliance by unqualified persons
can cause serious risk to the user.
23. There are no user serviceable parts installed in
the unit.
24. Do not place the unit in wardrobes or other
enclosed spaces as this may cause fire hazards.
25. This unit is not supposed to be used in or
around locations where foodstuffs, works of art
or delicate articles of science, etc are stored.
26. Indoor use only.
27. Children should be supervised to ensure that
they do not play with the appliance.
28. Ensure heater is on a flat, stable, heat-resistant
surface.
29. It is important that you do not cover this heater.

IMPORTANT: Please fit the wheel bases as per the
picture. Any other position may affect the stability of
the heater
WARNING: Only operate the heater in normal
upright position with wheel assemblies attached to
the bottom, any other position could create a
hazardous situation.
Main Body x1
Wing Nut x2
U-shape Bolt x2
Wheel Castor x2
Components Of Your Oil Column Heater
ASSEMBLY OF THE HEATER
Carefully turn the Main Body upside-down on a
non-scratching and stable surface. Be careful to
prevent damage to the paint finish or your floor
surfacing (Fig.1).
Fit the wheel assemblies onto the Main Body by
placing the U-shaped bolts between the outermost
fins on each side of the Main Body (see Fig.2 - 4).
Securely fasten the wheel assemblies onto the
Main Body by screwing the wing nuts onto the U-
shaped bolts (see Fig. 5).

Operating Your Oil Column Heater
Always choose a safe location for the heater, keeping in mind the safety
precautions outlined. Ensure all packaging has been removed from the
unit before use. This appliance requires no installation, it should be used
solely as a portable appliance.
CLEANING YOUR HEATER
The heater requires regular cleaning to ensure
trouble free operation:
Unplug the heater from the mains supply before
cleaning.
Ensure that the heater has been allowed to cool
down completely before cleaning.
Use a damp cloth (not wet) to wipe the exterior of
the heater to remove dust and dirt.
Use a vacuum cleaner to remove dust and fluff
from around the fins.
Never use solutions such as benzene, thinners or
polishing agents.
Ensure the heater is dry before plugging back into
the mains supply.
Do not attempt to dismantle the Oil Column
Heater. There are no user serviceable parts. For
service or repair, contact an authorised electrical
service technician.
CAUTION
This heater generates heat during use. Proper
precautions must be taken to prevent the risk of
burns, scalds, fires or other damage to persons
WARNING: Do not use this heater with a
separate programmer, remote-control system,
separate timer or any other device that switches
the heater on automatically.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of
purchase.
WARNING Keep all objects at least 1 metre
from the front, sides and rear of the appliance.
PLEASE NOTE: As this product is fitted with a
Timer, the Timer has been set to the “ON”
position. Please refer to the Timer section for
setting instructions.
HEAT CONTROL SWITCH
The control switch positions are:
I Low heating
II Medium heating
III High heating
Check that the Heat Control Switch is set to Off
position before plugging the heater into the mains
supply. For greater economy, use the High Heat
setting initially and then switch to the Lower Heat
settings.
THERMOSTAT
Turn the thermostat knob clockwise until you
reach the maximum temperature on the
graduated scale. When the desired room
temperature is reached, slowly turn the knob anti-
clockwise until the heater turns off (you will hear a
click). The heater will now cycle on and off to
maintain the set temperature.
IMPORTANT! NEVER COVER THIS HEATER
SAFETY DEVICES
This appliance has three protection devices:
The first device will automatically turn the
appliance off if the appliance is not in the
appropriate operating position.
The second device automatically disconnects &
reconnects the appliance at a pre-set
temperature.
The third device disconnects the appliance
permanently in case of overheating, by means of
a thermal fuse. (It is non resettable).

Operating Your Oil Column Heater
TIMER
You must set the time prior to programming the
Timer. To do this; turn the outer dial of the timer
in a clockwise direction until the time of the day
(24-hour clock) corresponds with the triangular
marking. Example if it is 2pm (1400 hours) then
set the triangular mark in line with 14. One
complete turn of the dial corresponds to 24 hours.
There are 96 “riders”, positioned around the dial,
each rider represents 15 minutes.
Where all the “riders” are pushed to the outside of
the timer the heater will be ON continuously.
To set a specific time for example:
If you want the heater to be on from 6pm to
10pm, then set all the riders from 18 to 22 (1800
hours to 2200 hours) to the outside of the rim and
all other riders to the inside of the timer. The unit
will then turn on automatically at 6pm and off
again at 10pm.
Indicates actual time
Riders pushed to the
outside rim to turn ON
WARNING! Take care in positioning your
heater, using the timer will mean the heater
will come on automatically. Fire may result if
placed next to combustible material.
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]z
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[e-mail]
SUPPORT AND TECHNICAL ADVICE

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three
months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault
during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out
by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
