Golight GXL 4211 Manual

Congratulations
You are now the owner of one of the finest lighting
products available today. Thank you for letting Golight®
assist you in your lighting application needs.
We’re proud of our products and the LED XtremeTM
Technology that we’ve developed to ensure our
customers the most durable, versatile and powerful
lights in the industry. Please read these instructions
before using your new Golight® GXL® Off-Road Light.
Golight Inc
37146 Old Hwy 17
Culbertson, NE 69024
800.557.0098 | 308.278.3131
www.golight.com | [email protected]
OFF-ROAD
MODEL 4211
INSTRUCTION GUIDE
MODEL 4211
FIVE YEAR LIMITED WARRANTY
Golight, Inc. warrants the GXL® against any deemed
defects that are due to workmanship for parts or faulty
materials, for five years from date of original purchase.
This warranty to the GXL®does not cover damage
resulting from unreasonable use or misuse, unreasonable
maintenance or loss, or labor costs.
Warranty information may be filled out online at:
http://golight.com/support/product-registration/
If the GXL®does fail to operate under warranted
specification, Please call 1-308-278-3131 for a Return
Goods Authorization number. After receiving an RGA#,
send the light and all necessary accessories postage
paid, plus $9.95 for shipping and handling to Golight, Inc.,
Service Department, 37146 Old Hwy 17, Culbertson, NE
69024. No C.O.D.’s accepted. Only the above manufac-
turer is authorized to perform warranty repair or replace
product.
Any consequential damages to person or property are
excluded from this warranty. Some states do not allow
the exclusion and limitation of incidental or consequential
damages, therefore, the above limitations or exclusions
may not apply to you. This warranty gives you specific
legal rights and you may also have other rights.
IMPORTANT SAFETY INFORMATION
This symbol is to alert you to important operating
or servicing instructions that appear in your
instructions. Always follow basic safety
precautions when using this product to reduce
the risk of injury, fire or electric shock.
This light is for off road and utility use only. It is not
designed for public road/highway use as a driving light.

The GXL®is an LED, fixed-mount off-road light
offering incredible intensity and durability in a small
package. Utilizing the latest in LED, lens and reflective
technology, the GXL®casts light where you need it.
CONTENTS:
A) Model 4211 Golight LED Off-Road Light – 1 each
B) Mounting Bracket – 1 each
C) 6 mm x 70 mm Carriage Bolt – 1 each
D) 6 mm Flat Washer – 2 each
E) 6 mm Spacer - 2 each
F) 6 mm Nylon Insert Lock Nut
G) 8 mm x 25 mm Carriage Bolt – 1 each
H) 8 mm Flat Washer – 1 each
I) 8 mm Nylon Insert Lock Nut – 1 each
INSTALLATION INSTRUCTIONS
It is highly recommended that the installer use a
torque wrench for tightening all fasteners.
DO NOT OVERTIGHTEN FASTENERS!
1) Using an 13 mm socket, loosen and remove the 8
mm nylon locking nut (I) and flat washer (H).
2) Place the bottom of the bracket (B) on the desired
mounting surface. If it is necessary to drill a hole,
use an 8 mm or 5/16 inch bit.
3) Reinstall the 8 mm flat washer and nylon locking
nut.
4) Torque the 8 mm nylon locking nut to 180 in-lb (15
ft-lbs or 20 Nm).
5) Adjust light vertically to desired angle.
6) Using a 10 mm socket, tighten the 6 mm nylon
locking nut to 85 in-lb (8 ft-lb or 11 Nm).
ELECTRICAL CONNECTION
1) Connect the negative wire (black) to a chassis
ground on the vehicle.
2) Connect the positive wire (red) to a switched and
fused circuit.
Voltage Input Range: 9 – 36V DC
Amp Draw: 2.0A @ 13.8V
A
FE
D
G
H
I
B
DC
E
