Golight Stryker HID Manual

Class B digital device. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
 FCC RULE Part. 15.21 - Changes or modications made by the
user not expressly approved by Golight, Inc. for compliance
could void the user’s authority to operate the equipment.
For safe and efcient operation of your Golight® Stryker™,
observe these guidelines:
Your Golight® Stryker™ HID is a radio transmitter and receiver
operating at 433MHz. Whenever the light is on, the internally
mounted antenna sends out and receives radio frequency (RF)
energy.
• Modern electronic equipment, i.e. Personal medical devices
such as pacemakers, hearing aids, etc., are shielded from RF
energy. However, RF energy may affect some electronic
equipment.
• Vehicle electronic systems may be affected by RF energy.
Check with your vehicle manufacturer representative to be sure
that your Golight® Stryker™ will not affect the electronic
system of your vehicle.
Five Year Limited Warranty
Golight, Inc. warrants the Stryker™ HID against any deemed
defects that are due to workmanship for parts or faulty materials,
except bulb & ballast, for ve years from the date of the original
purchase. This warranty to the Stryker™ HID does not cover
damage resulting from unreasonable use or misuse, unreasonable
maintenance or loss, or labor costs.
The ballast carries a 1 year warranty while the bulb is not covered
under warranty.
Mounting the light upside down will void the warranty.
Warranty cards must be lled out and sent in within 30 days of
purchase to Golight, Inc. • 37146 Old Hwy 17 • Culbertson, NE
69024, for warranty protection. Register online at
www.golight.com.
If the Golight® Stryker™ HID does fail to operate under warranted
specications, send the light and remote control postage paid,
plus $9.95 for shipping and handling to: Golight, Inc. • Service
Department • 37146 Old Hwy 17 • Culbertson, NE 69024. No
C.O.D.’s accepted. Only the above manufacturer is authorized to
perform warranty repair or replace product.
Any consequential damages to person or property are excluded
from this warranty. Some states do not allow the exclusion and
limitation of incidental or consequential damages, therefore the
above limitations or exclusions may not apply to you. This
warranty gives you specic legal rights and you may also have
other rights.
Golight Inc
37146 Old Hwy 17
Culbertson, NE 69024
www.golight.com | [email protected]
Congratulations
You are now the owner of one of the nest
remote control searchlights available today.
Thank you for letting Golight® assist you in your
lighting application needs. We’re proud
of our products and the technology that
we’ve developed to ensure our customers
the most durable, versatile and powerful
searchlights in the lighting industry.
Please read these instructions before using
your new Golight® Stryker™ HID.

The Golight® Stryker™ HID is designed to permanently attach to
a vehicle. The 2-Speed Searchlight with Directional Flexibility is
controlled by a wireless remote, which gives the operator a full
370 horizontal rotation and a 135 vertical tilt with ngertip control.
The Stryker™ provides superior light penetration with the new
HID.
The Stryker™ HID Includes:
Stryker™ Searchlight
Remote Control
2 GP Super Alkaline Batteries 23A 12V
Rockguard
Permanent Mounting Gasket
Permanent Mounting Plate
Mounting Screws
MOUNTING INSTRUCTIONS
Determine the location for the light on your vehicle or boat. Center
the mounting plate with the vise screw on the mounting plate to
the back. Mark the hole locations for the three mounting screws
and drill a pilot hole for each with 1/8 inch bit. Fasten the stain-
less steel mounting plate with the 3 #10 – 16x3/4 type AB cross
recessed pan head tapping screws, stainless steel. Drill a 1/4
inch hole in the center mounting plate hole to accommodate a
power cord. Install the provided grommet in the hole. Bring the
power cord through the grommet. When connecting the positive
and negative wires keep in mind that the Stryker™ electronics are
not polarized. You do not have to be concerned with connecting
the positive and negative wires incorrectly. The 12volt DC power
wire should be joined to the leads under the lamp with appropriate
automotive wire attachments. Keep the wire connection above
the mounting surface. It is recommended that the power wire be
connected to an ignition circuit or install a separate on/off toggle
switch between the light and the power source.
Wet mounting surface with a small amount of water or lubricant
for easier installation, then place the light over the mounting plate
by sliding the front of the light over the front of the mounting plate,
rst pull the light backwards, then seat the back of the light on to
the mounting plate. Displace the back of the gasket and install the
vise screw (provided). Tighten the vise screw using a Phillips head
screwdriver. Replace the gasket.
Each spotlight needs to be wired on a single dedicated circuit and
the power fused at 10 amps. With the power connected, your light
is ready for operation. A minimum of 14 awg wire is recommended
and may need to be larger depending on total length of run.
The HID will have an initial startup amp draw of 8 amps and will
quickly scale down to a 3.5 constant draw.
PROGRAMMABLE REMOTE INSTRUCTIONS
The Golight® Stryker™ HID is controlled with a programmable
remote with 6561 different channels. This feature allows you
freedom to change the channel selection, and the receiver relearns
the new selection.
PROGRAMMING THE TRANSMITTER.
This light has been pre-programmed at the factory, and it is not
necessary to re-program the transmitter, unless you experience
outside interference.
1. IMPORTANT: Disconnect power by removing fuse or
disconnecting vehicle battery.
2. Remove battery cover from remote control.
3. Set the 7 dip switches to a selection of your choice. There are 3
positions on each; positive, negative and neutral. Use a small
screwdriver and select a position for each dip switch. *Please
note that the orientation of the +/- switch positions may vary
among different models of wireless remote controls.
4. Insert both GP 23A 12V batteries. Be sure batteries have
adequate charge.
5. Replace battery cover.
a. Depress the on/off button and hold it down. Red LED will
light.
b. While holding the on/off button down, reinstall the power
(replace fuse or connect vehicle battery).
c. Keep your nger on the on/off button for 5-6 seconds, and
then release. The light should now be programmed.
INSTALLATION OF WIRELESS DASH CONTROL
If you have a wireless dash control, please note that it is vital for
this to be attached to a at / smooth surface with the 4 mounting
screws included. The arrow under the rubber cover should point
up.
OPERATION OF STRYKER™ HID
1. Using the remote control, turn on the light by depressing the
on/off button.
2. With the 4-way arrows on the remote control, rotate your light
to the desired location. Depending upon conditions, the
wireless remote may be used up to 100 feet from the Stryker™.
3. The speed of the light rotation can be controlled by depressing
the fast/slow button one time and by depressing it again to
restore the original speed.
4. The spotlight should not be turned on when the snap on lens
cover (rockguard) is attached.
BULB REPLACEMENT
The Golight® Stryker™ HID utilizes a Philips® D1S bulb, which
may be purchased through Golight, Inc. — 308.278.3131 or
800.557.0098.
IMPORTANT SAFETY INFORMATION
 This symbol is to alert you to important operating
or servicing instructions that appear in your instructions.
Always follow basic safety precautions when using this
product to reduce the risk of injury, fire or electric shock.
 The HID bulb/ballast requires a short ramp-up phase which
takes 15 seconds to reach full brightness.
This light is for off road and utility use only. It is not designed
for road use as a driving light.
 The Stryker™ HID complies with Part. 15.105 of the FCC Rules.
This equipment has been tested and found to comply with the
limits for a
