I NSTALLATION I NSTRUCTIONS FOR
*MSS9* & *CSS9*
S
INGLE -S TAGE G AS F URNACE
IOG-2009
08/14
(Type FSP CATEGORY IV Direct
or Non Direct VentAir Furnace)
These furnaces comply with requirements em-
bodied in theAmerican National Standard / Na-
tional Standard of CanadaANSI Z21.47·CSA-2.3
Gas Fired Central Furnaces.
Installer:
Affix all manuals
adjacent to the unit.
As a professional installer you have an obligation to know
theproductbetterthanthecustomer.Thisincludesallsafety
precautions and related items.
Prior to actual installation, thoroughly familiarize yourself
with this Instruction Manual. Pay special attention to all
safety warnings. Often during installation or repair it is
possible to place yourself in a position which is more
hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product
safely and to know it well enough to be able to instruct a
customer in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific good
safety practices...follow them.
Theprecautionslistedinthis Installation Manual areintended
as supplemental to existing practices. However, if there is
adirect conflict between existing practices and the content
ofthismanual, the precautions listed here takeprecedence.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS........................................... 3
SHIPPING INSPECTION ................................................. 4
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS ........................ 4
TOTHE INSTALLER .................................................. 5
PRODUCT APPLICATION ............................................. 5
LOCATION REQUIREMENTS & CONSIDERATIONS ................ 6
CLEARANCES AND ACCESSIBILITY ....................................... 7
EXISTING FURNACE REMOVAL .......................................... 8
THERMOSTAT LOCATION ............................................... 9
COMBUSTION & VENTILATION AIR REQUIREMENTS ........................ 9
INSTALLATION POSITIONS .......................................... 9
HORIZONTAL APPLICATIONS & CONSIDERATIONS .............. 10
FURNACE SUSPENSION ............................................... 10
FRONT COVER PRESSURE SWITCH TUBE LOCATION ..................... 10
DRAIN TRAP AND LINES ............................................. 10
LEVELING .......................................................... 10
ALTERNATE ELECTRICAL AND GAS LINE CONNECTIONS ................... 10
DRAIN PAN ........................................................ 10
FREEZE PROTECTION ................................................ 10
PROPANE GAS/HIGH ALTITUDE INSTALLATIONS ................ 10
VENT/FLUE PIPE & COMBUSTION AIR PIPE ..................... 11
DUAL CERTIFICATION: NON-DIRECT/DIRECT VENT ..................... 11
MATERIALS AND JOINING METHODS ................................... 11
PROPER VENT/FLUE
AND COMBUSTION AIR PIPING PRACTICES ........................... 12
TERMINATION LOCATIONS ............................................ 12
CANADIAN VENTING REQUIREMENTS ................................... 13
STANDARD FURNACE CONNECTIONS ................................... 13
VENT/INTAKE TERMINATIONS FOR INSTALLATION OF
MULTIPLE DIRECT VENT FURNACES ................................ 17
CONCENTRIC VENT TERMINATION ..................................... 18
SIDE WALL VENT KIT .............................................. 18
CONDENSATE DRAIN LINES & DRAIN TRAP ...................... 18
GENERAL DRAIN INFORMATION ........................................ 19
FIELD SUPPLIED DRAIN .............................................. 19
UPFLOW MODEL INSTALLED VERTICALLY ............................... 20
DRAIN EXITING RIGHT SIDE .......................................... 20
DRAIN EXITING LEFT SIDE ........................................... 20
UPFLOW MODEL INSTALLED HORIZONTALLY
WITH RIGHT SIDE DOWN.......................................... 20
UPFLOW MODEL INSTALLED HORIZONTALLY
WITH LEFT SIDE DOWN ........................................... 21
COUNTERFLOW MODEL INSTALLED VERTICALLY ......................... 21
DRAIN EXITING LEFT SIDE ........................................... 21
DRAIN EXITING RIGHT SIDE .......................................... 22
COUNTERFLOW MODEL INSTALLED HORIZONTALLY
WITH RIGHT SIDE DOWN.......................................... 22
COUNTERFLOW MODEL INSTALLED HORIZONTALLY
WITH LEFT SIDE DOWN ........................................... 22
is a registered trademark of Maytag Corporation or its related companies and is used
under license to Goodman Company, L.P., Houston, TX. All rights reserved.

2
ELECTRICAL CONNECTIONS ....................................... 23
WIRING HARNESS ................................................... 23
115 VOLT LINE CONNECTIONS ....................................... 23
JUNCTION BOX RELOCATION.......................................... 24
24 VOLT THERMOSTAT WIRING ...................................... 24
SINGLE-STAGE HEATING THERMOSTAT APPLICATION ...................... 24
FOSSIL FUEL APPLICATIONS ........................................... 25
GAS SUPPLY AND PIPING ............................................ 25
HIGH ALTITUDE DERATE ............................................. 25
PROPANE GAS CONVERSION .......................................... 25
GAS PIPING CONNECTIONS ........................................... 26
PROPANE GAS TANKS AND PIPING .................................... 28
CIRCULATING AIR & FILTERS ....................................... 29
DUCT WORK -AIR FLOW ............................................ 29
CHECKING DUCT STATIC ............................................. 29
BOTTOM RETURN AIR OPENING [UPFLOW MODELS] .................... 30
FILTERS - READ THIS SECTION BEFORE
INSTALLING THE RETURN AIR DUCT WORK .......................... 30
UPRIGHT INSTALLATIONS ............................................. 31
HORIZONTAL INSTALLATIONS .......................................... 32
STARTUP PROCEDURE & ADJUSTMENT .......................... 32
DRAIN TRAP PRIMING ............................................... 32
FURNACE OPERATION ............................................... 32
GAS SUPPLY PRESSURE MEASUREMENT ................................ 32
GAS MANIFOLD PRESSURE MEASUREMENT
AND ADJUSTMENT ................................................ 33
GAS INPUT RATE MEASUREMENT (NATURAL GAS ONLY) ............... 34
TEMPERATURE RISE ................................................. 34
CIRCULATOR BLOWER SPEEDS ........................................ 35
BLOWER HEAT OFF DELAY TIMINGS .................................. 35
NORMAL SEQUENCE OF OPERATION............................. 35
POWER UP........................................................ 35
HEATING MODE .................................................... 35
COOLING MODE .................................................... 36
FAN ONLY MODE .................................................. 36
OPERATIONAL CHECKS ............................................. 36
SAFETY CIRCUIT DESCRIPTION .................................... 36
INTEGRATED CONTROL MODULE ...................................... 36
PRIMARY LIMIT ..................................................... 37
AUXILIARY LIMIT .................................................... 37
ROLLOUT LIMIT .................................................... 37
PRESSURE SWITCHES ................................................ 37
FLAME SENSOR ..................................................... 37
TROUBLESHOOTING................................................ 37
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS ....................... 37
DIAGNOSTIC CHART ................................................. 37
RESETTING FROM LOCKOUT .......................................... 38
MAINTENANCE....................................................... 38
ANNUAL INSPECTION ................................................. 38
FILTERS ........................................................... 38
BURNERS .......................................................... 39
INDUCED DRAFT AND CIRCULATOR BLOWERS ........................... 39
CONDENSATE TRAP AND DRAIN SYSTEM
(QUALIFIED SERVICER ONLY) ..................................... 39
FLAME SENSOR (QUALIFIED SERVICER ONLY) .......................... 39
FLUE PASSAGES (QUALIFIED SERVICER ONLY) ......................... 39
BEFORE LEAVING AN INSTALLATION .............................. 39
REPAIR AND REPLACEMENT PARTS ............................... 40
TROUBLESHOOTING CHART....................................... 41
AIRFLOW *MSS92*** & *CSS92***A* ............................... 43
AIRFLOW *MSS96*** & *CSS96***A* ................................ 44
WIRING DIAGRAM ................................................... 46
SPECIAL INSTRUCTIONS FOR PRODUCTS INSTALLED
IN THE STATE OF MASSACHUSETTS ........................ 47

3
