Goodwe SBP SERIES User manual

SBP SERIES USER MANUAL
AC-COUPLED BATTERY STORAGE RETROFIT
JIANGSU GOODWE POWER SUPPLY TECHNOLOGY CO.,LTD
No. 90 Zijin Rd., New District, Suzhou, 215011, China
www.goodwe.com
[e-mail]
340-00087-05
PV Master App SEMS Portal App SEMS Portal website
www.semsportal.com
LinkedIn Company's
offical website
Ver. 1.5

01 INTRODUCTION
TABLE OF CONTENTS
1.1 Operation Modes Introduction
1.2 Safety & Warning
1.3 Product Overview
01
02
04
03 MANUAL OPERATION
3.1 Wi-Fi Configuration
3.2 PV Master APP
3.3 CEI Auto-Test Function
3.4 Startup/shutdown Procedure
19
20
20
21
04 OTHERS
4.1 Error Messages
4.2 Troubleshootings
4.3 Disclaimer
4.4 Technical Parameters
4.5 Other Test
4.6 Quick Check List To Avoid Danger
23
25
29
30
32
32
02 INSTALLATION INSTRUCTIONS
2.1 Unacceptable Installations
2.2 Packing List
2.3 Mounting
2.3.1 Select Mounting Location
2.3.2 Mounting
2.4 Electrical Wiring Connection
2.4.1 Battery Wiring Connection
2.4.2 On-Grid & Back-Up Connection
2.4.3 Smart Meter & CT Connection
2.5 DRED / Remote Shutdown Connection
2.6 Earth Fault Alarm Connection
05
05
06
06
07
09
09
10
13
15
16

Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Mode Ⅰ
Energy from grid-tied inverters optimize loads, excess
energy will be used to charge the battery, if it is full, the
excess power
Mode Ⅲ
When grid power fails, battery will discharge to support
back-up Loads.
Mode Ⅳ
Battery could be charged by grid, and charge time/power
could be set flexibly on PV Master APP.
Mode Ⅱ
When energy from grid-tied inverters is weak, battery will
discharge to support the load in priority together with the
grid.
1.1 Operation Modes Introduction
Note:
The introduction describes a general behavior of S-BP
system. The operation mode can be adjusted on PV Master
App depending on the system layout. Below are the general
operation modes for BT system:
01 INTRODUCTION
GoodWe S-BP series bi-directional inverter is designed for both indoor and outdoor use, which
could be used with or without existing grid-tied inverter systems to store energy using batteries.
Energy produced from grid-tied inverters shall be used to optimize self-consumption, excess
energy will be used to charge the batteries, if the battery is already full, power excess power could
be exported to the grid. Loads will be supported in priority by grid-tied system, then battery
power, if there is insufficient energy, power will be supported by the grid.
S-BP system normally has the following operation modes based on your configuration and layout
conditions.
1.2 Safety & Warning
The S-BP series inverter of Jiangsu GoodWe Power Supply Technology Co., Ltd. (hereinafter
called as GoodWe) strictly complies with related safety rules for product design and testing.
Please read and follow all the instructions and cautions on the inverter or user manual during
installation, operation or maintenance, as any improper operation might cause personal or
property damage.
Caution!
Failure to observe a warning indicated in this manual may result in injury
Danger of high voltage and electric shock!
Components of the product can be recycled.
This side up! The package must always be transported, handled and stored in
such a way as the arrows always point upwards.
Danger of hot surface!
No more than six (6) identical packages being stacked on each other.
Products should not be disposed as household waste.
Fragile - The package/product should be handled carefully and never be
tipped over or slung.
Refer to the operating instructions.
Keep dry! The package/product must be protected from excessive humidity and
must be stored under cover.
Signals danger due to electric shock and indicates the time to wait (5 minutes)
before it is safe to touch the internal parts of the inverter after it has been
disconnected from it power source
CE Mark
Symbols explantion
5min
02
01

1.3 Product Overview
HYBIRD LED INDICATORS
INDICATOR
ENERGY
ON = SYSTEM IS READY BLINK = SYSTEM IS STARTING UP OFF = SYSTEM IS NOT OPERATING ON = BACK-UP IS READY / POWER AVAILABLE OFF = BACK-UP IS OFF / ON POWER AVAILABLE ON = BMS AND METER COMMUNICATION OK OFF = BMS AND METER COMMUNICATION FAIL ON = BATTERY IS CHARGING BLINK 1 = BATTERY IS DISCHARGING BLINK 2 = BATTERY IS LOW / SOC IS LOW OFF = BATTERY IS DISCONNECTED / NOT ACTIVE ON = BATTERY IS ACTIVE AND CONNECTED BLINK = GRID IS ACTIVE BUT NOT CONNECTED OFF = GRID IS NOT ACITVE ON =
CONSUMING ENERGY FROM GRID / BUYING
BLINK 1 = SUPPLYING ENERGY TO GRID / ZEROING BLINK 2 = SUPPLYING ENERGY TO GRID / SELLING ON = WiFi CONNECTED / ACTIVE BLINK 1 = WiFi SYSTEM RESETTING BLINK 2 = WiFi NOT CONNECT TO ROUTER BLINK 4 = WiFi SERVER PROBLEM OFF = WiFi NOT ACTIVE ON = FAULT HAS OCCURRED OFF = NO FAULT
STATUS EXPLANATION
SYSTEM BACK-UP COM BATTERY GRID ENERGY WiFi FAULT
BLINK1 = OVERLOAD OF BACK-UP
OUTPUT / REDUCE LOAD
BLINK 1 = METER COMMUNICATION OK,
BMS
COMMUNICATION FAIL
BLINK 2 = BMS COMMUNICATION OK,
METER
COMMUNICATION FAIL
OFF = GRID NOT CONNECTED OR
SYSTEM NOT OPERATING
SYSTEM
GRID
WiFi
COM
FAULT
BATTERY
2 0 1 9
BACK-UP
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
LED Lable
WiFi reset / Reload Button
Back-Up Port
On-Grid Port
DRED
Wi-Fi Box
Reserved RS485
Battery Terminals
Exhaust Valve
BMS Communication Cable
Smart Meter Communication Cable
To Battery
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
To Smart Meter
Safety warning
Any installation and operation on inverter must be performed by qualified electricians, in compli-
ance with standards, wiring rules or requirements of local grid authorities or companies (like AS
4777 and AS/NZS 3000 in Australia).
Prohibit inserting and pulling the AC and DC terminals when the inverter is running.
Before any wiring connection or electrical operation on inverter, all DC and AC power must
be disconnected from inverter for at least 5 minutes to make sure inverter is totally isolated
to avoid electric shock.
The temperature of inverter surface might exceed 60℃ during operation, so please make
sure it has cooled down before touching it, and make sure the inverter is out of reach of
children.
Do not open the inverter's cover or change any components without manufacturer's autho-
rization, otherwise the warranty commitment for the inverter will be invalid.
Usage and operation of the inverter must follow instructions in this user manual, otherwise
the protection design might be impared and warranty commitment for the inverter will be
invalid.
Appropriate methods must be adopted to protect inverter from static damage. Any damage
caused by static is not warranted by manufacturer.
The inverter, with built-in RCMU, will exclude possibility of DC residual current to 6mA, thus
in the system an external RCD (type A) can be used(≥30mA).
In Australia, the inverter internal switching does not maintain neutral integrity, which must
be addressed by external connection arrangements like in the Off-Grid System Connection
Diagram in page 17.
In Australia, output of back-up side in switchbox should be labeled "Main Switch UPS
Supply", the output of normal load side in switch box should be labeled "Main Switch Invert-
er Supply".
04
03

For inverter's protection and convenient maintenance, mounting location for inverter should be
selected carefully based on the following rules:
Any part of this system shouldn't block the switch and breaker from disconnecting inverter from
DC and AC power.
Rule 1. Inverter should be installed on a solid surface, where is suitable for inverter's dimensions
and weight.
Rule 2. Inverter installation should stand vertically or lie on a slop by a max of 15° .
2.3 Mounting
2.3.1 Select Mounting Location
300mm
500mm
200mm 200mm
Upward
Downward
Front
Both sides
---------- 300mm
------ 500mm
------------- 300mm
-------- 200mm
Inverter cannot be installed near flammable, explosive or strong electro-magnetic
equipment.[1]
Keep away from sunlight Keep dry Keep it clear of snow Sun Rain Accmulated snow
Max
15°
300mm
2.1 Unacceptable Installations
2.2 Packing List
On receiving the S-BP series inverter, please check to make sure all the components as below are
not missing or broken.
Inverter×1
Wall-mounted
Bracket
USB
Inverter Smart Meter Pin Terminal Pin Terminal AC Cover Battery Cover
PE TerminalBattery Terminal Expansion Bolts Hexagon Head Screw Pan Head Screw User Manual Quick Installation Guide
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Please avoid the following installations，which will damage the system or the Inverter.
Back-up cannot be connected in parallel.Back-up cannot be connected to grid.
On-Grid
Back-Up
One meter cannot connect to multiple inverters, and
different CT cannot connect to a Smart Meter.
Back-Up Back-Up
Smart Meter
Reset
SMARTMETER
USB
One battery bank cannot be connected to multiple
inverters.
Battery Battery
Incompatible battery
Battery
Incompatible battery
Back-Up Back-Up
Load
On-Grid
Inverter battery input cannot be
connected to incompatible batteries.
Inverter does not support off-grid
function in grid-less area.
On-Grid or back-up side cannot
connect to any ac generators.
Back-Up On-Grid
Generator
Battery
Battery
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Load
Back-Up
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
02 INTALLATION INSTRUCTIONS
SBP SERIES USER MANUAL
AC-COUPLED BATTERY STORAGE RETROFIT
JIANGSU GOODWE POWER SUPPLY TECHNOLOGY CO.,LTD
No. 90 Zijin Rd., New District, Suzhou, 215011, China
www.goodwe.com
[e-mail]
340-00087-04
PV Master APP SEMS Portal APP SEMS Portal website
www.semsportal.com
LinkedIn Company's
offical website
S-BP QUICK INSTALLATION INSTRUCTIONS
PART 1
QUICK
INSTALLATION
PART 2
BATTERY
CONNECTION
PART 3
Wi-Fi
CONFIGURATION
Wi-FiReset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Rule 3. Ambient temperature should be lower than 45°C.
(High ambient temperature will cause power derating of inverter.)
Rule 4. The inverter installation should be protected under shelter from direct sunlight or bad
weather like snow, rain, lightning etc.
Rule 5. Inverter should be installed at eye level for convenient maintenance.
Rule 6. Product label on inverter should be clearly visible after installation.
Rule 7. Leave enough space around the inverter according to the below figure.
06
05

Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
self-tapping screws
Wall bracket
Expansion pipe
Note: Bearing capacity of the wall must be higher than 25kg, otherwise it may not be able to
keep inverter from dropping.
Note: Make sure the heat sink on the inverter joints with mounting bracket.
2.3.2 Mounting
Inverter cannot be installed near flammable, explosive or strong electro-magnetic
equipment.[1]
The inverter is suitable for mounting on concrete or other non-combustible surface only.
Step 1
Step 3
• Please use the mounting bracket as a template to drill 6 holes in right positions (10mm
in diameter,and 80mm in depth)
• Use expansion bolts in accessory box and fix the mounting bracket onto the wall tightly
Ground cable shall be connected to the ground plate on grid side.
Carry the inverter by holding the heating sink on both sides and place the inverter on the
mounting bracket.
A lock could be used for anti-theft purposes if it is necessary for individual requirement.
125mm
125mm
265mm
120mm 120mm
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
The lock is not included in the package, It
can be purchesed by user.
Step 2
Step 4
Note:
• Move the inverter with care to prevent device damage and personal injury.
• Do not use the wiring terminals and ports at the bottom to support any weight of the inverter.
• Place a foam pad or cardboard under the inverter to protect the inverter
enclosure from damage
Lift the inverter from the packing case and move it to the specified installation position.
• Pack the inverter securely for transport.
• Carefully transport the inverter using the carrying handles in the boxes.
• Do not subject the inverter to shocks during the transport.
• Make sure that the arrows on the box always point upwards during the transport.
• Secure the inverter firmly in place for transport.
Deliver the inverter carefully.
08
07

Cable
Use Special Tool to Crimp
Battery Terminal
Waterproof Ring
Insulator
Screw Cap
• For lithium battery (pack) the capacity should be 50Ah or larger. lead acid batteries are not
allowed for use with GoodWe hybrid inverters without GoodWe's authority. Battery cable
requirement are shown below.
Make sure battery switch is off and battery nominal voltage meet S-BP specification
before connecting battery to inverter and make sure invereter is totally isolated from PV
and AC power.[4]
• Please be careful against any electric shock or chemical hazard
• Make sure there is an external DC breaker (≥125A) connected for batteries without build-in DC
breaker
* For the compatible lithium batteries (LG / PYLON / BYD / GCL / DYNESS / ALPHA) connection,
please refer to battery connection part in S-BP QUICK INSTALLATION INSTRUCTIONS.
Prepare battery cables and accessories and put
battery power cable through battery cover.
Make battery terminals:
• Strip cable coat, revealing 10mm length of metal core
• Use special crimper to compress battery terminal tightly
Note:
1.Please use accessories from GoodWe box
2. Battery power cable should be 25-35mm2
2.4.1 Battery Wiring Connection
2.4 Electrical Wiring Connection
Cable
A
B
C
Description
Outside Diameter
Isolation section
Conductor Core
Value
10-12mm
NA
20-35mm2
Battery wiring connection steps as below:
Step 1
Connect battery terminal onto inverter.
Step 3
Step 2
Note: Please make sure polarity (+/-) of
battery are not reversed
Pan Head Screw
Fastening torsion 6~8N.m
• Battery SOC is lower than I-DOD
• Battery voltage lower than discharge voltage
• Battery over temperature protection
• Battery communication abnormal for lithium battery
• BMS limitation for lithium battery
• Under on-grid mode, battery charge/discharge operation could be abnormal
• Under off-grid mode, Back-Up supply will shut down
Battery will act as protective charge/discharge current limitation under any condition as below:
When charge/discharge current limitation protection happens:
Note：
1. Under on-grid mode, battery is protected from over discharge by DOD and discharge voltage, under
o-grid mode, it is protected by only discharge voltage in priority.
2. The DOD setting of a battery prevents the inverter from discharging battery reserve power. As soon as
the DOD is reached the load of building will only be supported by either PV power or from the grid. If
there are continuous days when little or no battery charging occurs, the battery may continue to
self-consume energy to support communications with the inverter. This behaviour is dierent
between battery manufactures products, however, if the SOC of the battery reaches a certain level the
inverter will boost the SOC back up. This protection mechanism safegurads the battery to falling to
Battery Protection Description
1. Use a separate AC break for individual
inverter
2. On AC side, the individual break should
be connected before loads (between
inverter and loads)
AC break
AC break
AC break AC break
2.4.2 On-Grid & Back-Up Connection
An external AC breaker is needed for On-Grid connection to be isolated from grid when necessary.
Below are the requirements of On-Grid AC breaker.
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Make sure inverter inverter is totally isolated from any DC or AC power before connect-
ing AC cable.[5]
• On-grid wiring connection process is as below:
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
10
09

Grade
A
B
C
D
Description
Outside diameter
Isolation section
Conductor wire length
Conductor core section
Value
11-12 mm
NA
7-9 mm
4-6 mm2
ABC
D
1: Load is supplied from Back-Up side
2: Load is isolated
3: Load is supplied from grid side
Prepare the terminals and AC cables according to the right table.
Step 1
Step 3
Note:
1. Neutral cable shall be blue, line cable is black or brown (preferred) and protective earth cable
yellow-green.
2. For AC cables, PE cable shall be longer than N&L cables, so that if in any case the AC cable slips
Press the six connectors on cable conductor
core tightly.
Note: Make sure cable jacket is not locked within
the connector.
1. Connect the assembled AC
terminals onto the inverter.
Note: Make sure it is not
connected to a wrong side.
2. Lock the cover and screw the
cap on.
Put AC cable through the terminal cover in the
following sequence.
Note: Please use the terminals in
GoodWe components box
Connection Terminal
AC Cover
Screw Cap
The
Insulator
Single hole
seal ring
Cable
Fastening torsion 2~2.5N.m
Declaration for back-up function
The below statement lays out manufacturer's general policies governing the energy storage
inverters of the series ES, EM, SBP, ET, EH and BH.
• For Hybrid inverters (Series ES, EM, EH and ET), the standard PV installation typically consists of
the connection of the inverter with both panels and batteries. In the case where the systems
are not connected to the batteries, the back-up function is strongly not advised for use.
GoodWe shall not cover the standard warranty and be liable for any consequences arising from
users not following this instruction.
• Under normal circumstances, the back-up switching time is less than 10 ms (the minimal
condition to be considered as the UPS level). However, some external factors may cause the
system to fail on Back-Up mode. As such, we recommend the users to be aware of conditions
and follow the instructions as below:
1. Do not connect loads if they are dependent on a stable energy supply for a reliable operation.
2. Do not connect the loads which may in total exceed the maximum back-up capacity.
3. Try to avoid those loads which may create very high start-up current surges such as Inverter
Air-conditioner, high-power pump etc.
4. Due to the condition of battery itself, battery current might be limited by some factors
including but not limited to the temperature, weather etc.
Declartion for back-up loads
GoodWe S-BP inverter is able to supply a continuous 5000VA output(max 5500VA within 10s) on
Back-Up side. And the inverter will shutdown when it is full loading with high ambient tempera-
ture if grid is absent.
• Accepted Back-Up loads: television, computer, fridge, fan, illumination lamps, microwave oven,
electrical rice cooker and router etc.
• Unacceptable house loads for Back-Up side: air conditioner, water pump, heaters, washing
machine, electromagnetic oven, compression engine, hair drier and dust cleaner etc. with high
power and other loads with high inrush current at start-up.
Special adjustable settings
The inverter has field adjustable setting like tripping
point, tripping time, reconnect time, active and
invalid QU/PU curves etc. They can be adjusted
using special firmware, please contact after-sales
for the special firmware and adjustment methods.
For a convenient maintenance, an SP3T switch
could be installed on Back-Up and On-Grid side.
Then it is adjustable to support load by Back-Up or
by grid or left alone.
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2019
Grid
Ongrid
Back-Up
Loads
1
2
3
SP3T
Step 2
Step 4
12
11

Reset
SMARTMETER
USB
Smart Meter
3-Phase
Grid-Tied Inverter
S-BP
PV
L1
L2
L3
N
CT1
CT2
CT3
House → Grid Grid
Note:
1. The Smart Meter and CT are well congured, please do not change any setting of the Smart Meter.
2. CT must be connected to the same phase with Smart Meter power cable.
3. Do not connect CT2 to the power line when the CT2 is not in use.
Declartion for Back-Up overload protection
Inverter will restart itself if overload protection occurs. The preparation time for restarting will
extend (max one hour) if overload protection repeats. Take following steps to restart inverter
immediately：
• Decrease Back-Up load power within max limitation.
• On PV Master APP → Advanced Setting → Click "Reset Back-Up Overload History"
The single-phase Smart Meter with 2 CTs or 3-phase in product box is compulsory for S-BP
system installation, used to detect grid voltage, current direction and magnitude, further to
instruct the operation condition of S-BP inverter via RS485 communication.
2.4.3 Smart Meter & CT Connection
Single-phase Smart Meter & CT connection diagram
Three-phase Smart Meter & CT connection diagram
Make sure S-BP and grid-tied inverters are totally isolated from AC and DC power
before connecting Smart Meter and CT
Reset
SMARTMETER
USB
Smart Meter
Single-Phase
Grid-Tied Inverter
S-BP
L
N
CT1
House → Grid
House → Grid
CT2
PV
Grid
Reset
SMARTMETER
USB
Smart Meter
Single-Phase
Grid-Tied Inverter
S-BP
L
N
CT1
House → Grid
House → Grid
CT2
PV
Grid
Reset
SMART METER
USB
Smart Meter LED Indications
Detailed pin function of each port on S-BP
BMS：CAN communication is configured by default. If 485 communication is used, please contact
GOODWE to replace with the corresponding communication line.
POWER
ENERGY
COM
OFF
Not working
/
ON
Working
Importing
Blinks once when transferring data to inverter
Blinking
/
Exporting
POWER
ENERGY
COM
Position
1
2
3
4
5
6
7
8
Color
Orange&white
Orange
Green&white
Blue
Blue&white
Green
Brown&white
Brown
EMS
485_A
485_B
485_A
NC
NC
485_B
NC
NC
BMS Function
485_A2
NC
485_B2
CAN_H
CAN_L
NC
NC
NC
Smart Meter Function
NC
NC
485_B1
NC
NC
485_A1
485_B1
485_A1
Note:
1. Please use the Smart Meter with 3 CTs in GoodWe product box.
2. CT cable is 3m as default, could be extended to a max of 5m.
3. Smart Meter communication cable (RJ45) is attached on the inverter ("To Smart Meter"
cable), could be extended to a max of 100m, standard RJ45 cable and plug must be used, as
Anti-reverse function connection
If S-BP system (connected with grid-tied inverters) requires anti-reverse function, it is operable but
please note:
1. This diagram is only for installation where there is exporting power limit function requirement.
2. For anti-reverse function, it can be set on PV Master App → Advanced Setting → Power Limit.
3. This diagram will only applies if grid-tied inverter has anti-reverse function build-in. And the
power limitation value can be set on grid-tied inverter.
4. When using anti-reverse function, it would buy about 100W from the grid.
[1] This cable is a
theoretical
connection
supporting
anti-reverse
function, which
could be dierent
for dierent
grid-tied inverters.
[1]
Load
Load Load
14
13

2.5 DRED & Earth Fault Alarm
2.5.1 DRED Connection
Screw this plate off from the inverter.
Step 1
Step 2
1. Plug out the 6-pin terminal and dismantle the
resistor on it.
2. Plug the resistor out, leave the 6-pin terminal
for next step.
DRED is used for Australia and New Zealand installation (also used as remote shutdown function
in European countries), in compliance with Australia and New Zealand safety requirements( or
European countries). And DRED device is not provided by GoodWe.
Detailed connection of DRED device is shown below:
Note: DRED / Remote Shutdown device should be connected through "DRED port"
as the gure shows.
Note: The 6-pin terminal in the inverter serves
the same function as DRED / Remote
shutdown device. Please leave it in the
inverter if no external device are
Step 4
Step 3-1 For DRED
Connect the terminal to the
right position onto the
inverter.
NO
Function
5
REFGEN
6
COM / DRMO
NO
Function
1
DRM1/5
2
DRM2/6
3
DRM3/7
4
DRM4/8
5
REFGEN
6
COM / DRMO
1. Put the cable through the plate.
2. Connect the cable on the 6-pin terminal.
The function of each connection position as below:
1. Put the cable through the plate.
2. Connect cable on the 6-pin terminal.(Wiring from
the No. 5 and 6 holes respectively.)
The function of each connection position as below:
123456
Screw Nut The
Insulator
Screw Cap
RS485
communication board
Cable
Single hole
seal ring
123456
Screw Nut The
Insulator
Screw Cap
RS485
communication board
Cable
Single hole
seal ring
Step 3-2 For Remote Shutdown
2.6 Earth Fault Alarm Connection
S-BP series inverter complies with IEC 62109-2 13.9. Fault indicator LED on the inverter cover will
light up and the system will email the fault information to customer.
16
15

Wiring System For S-BP Series hybrid inverter
Reset
SMARTMETER
USB
PV
AC Breaker[4]
DC Breaker≥125A[1]
Power Meter
ON-Grid Load
L
N
PE
AC Breaker[4]
AC Breaker[4]
AC Breaker[4]
"To Battery" Cable[2]
House → Grid
Smart Meter
Battery
LN
Back-Up
Load
CT1[3]
CT2[3]
House → Grid
Grid
N
L
Grid
Single-Phase
Grid-Tied Inverter
For 3-phase Smart Meter wiring connection, please refer to "3-phase Smart Meter & CT
Connection Diagram"
Note: After the inverter is installed and in order to avoid problems connected , please turn off the
grid power to check whether the Back-Up function is normal, in order to avoid problems in
subsequent uses.
Note: For Australia safety country, the neutral cable of on-grid side and back-up side must be connected
together, otherwise back-up function will not work.
SYSTEM CONNECTION DIAGRAMS
Distribution box
On-Grid
Back-up
Battery
Normal Loads
L N PE
Meter
L
N
L
N
PE
L
N
PE
L
N
PE
E-N
Link
Smart
Meter
Don't connect this terminal
for Australian and New
Zealand grid system !!!
N-BAR
S-BP Series Inverter
E-BARE-BAR
RCD
CT
This diagram is an example for Australia，South Africa and New Zealand grid system.
This diagram is an example for grid system without special requirement on electrical
wiring connection.
Note: The Back-Up PE line and rack earth must be grounded properly and eectively.
Otherwise the Back-Up function may be abnormal when the grid fails.
Distribution box
On-Grid
Back-up
Normal Loads
L N PE
Meter
L
N
L
N
PE
L
N
PE
L
N
PE
RCD
Grid
E-BAR
E-BAR
Grounding screw hole
at the lower right corner
Grounding screw hole
at the lower right corner
RS485
RS485
RCD
Smart
Meter
CT
Battery
BMS
BMS
S-BP Series Inverter
Back-up
Loads
Grid
Back-up
Loads
RCD
1. For batteries with attached switch, the external DC switch is not
necessary.
2. Only for lithium battery which has BMS communication. 3. Direction of the CT cannot be connected in reverse, please follow
"House → Grid" direction to do the connection.
4. AC Breaker ≥40A for GW3600S-BP, and ≥50A for GW 5000S-BP.
Please select Breaker according to the specifications below
GW3600S-BP
GW5000S-BP
① ② ③ ④
125A/60V
DC breaker
Depends on
household
loads
40A/230V AC breaker
50A/230V AC breaker
18
17

03 MAMUAL OPERATION
3.1 Wi-Fi Configuration
This part shows configuration on the web page.
Wi-Fi configuration is absolutely necessary for online monitoring and maintenance.
Preparation:
1. Inverter must be powered up with battery or grid power.
2. Router with available internet access to the website www.semsportal.com is required.
1. Connect Solar-WiFi* to your PC or smart phone (* its
named the last 8 character of the inverter's serial
No.).
2. Open browser and login 10.10.100.253 Admin (User):
admin; Password: admin.
3. Then click "OK".
1. Click "Start Setup" to choose your router.
2. Then click "Next".
1. Fill in the password of ther router, then click
"Next".
2. Click "Complete".
Device information
Firmware version
MAC address
Wireless AP mode
SSID
IP address
Wireless STA mode
Router SSID
Encryption method
Encryption algorithm
Router Passowrd
1.6.9.3.38.2.1.38
60:C5:A8:60:33:E1
Enable
Solar-WiFi
10.10.100.253
Disable
WiFi_Bum-in
WAP/WAP2-PSK
AES
WiFi_Bum-in
Cannot join the network, may be caused by:
Save success!
Add wireless network manually
Please enter the wireless network passwork:
No router / weak WiFi signal / password is not correct
Network name (SSID)
Encryption method
Encryption algorithm
Passwork (8-63 bytes)
show psk
Help: Wizard will help you to complete setting with one
minute.
Note: Case sensitive for SSID and password, Please make sure
all parameters of wireless network are matched with router,
including password.
Click "Complete", the current configuration will take effect after
restart.
If you still neet to configure the other pages of information,
please go to complete your required configuration.
Configuration is completed, you can log on the Management
page to restart device by Click on "OK" button.
Confirm to complete?
Start Setup
Back Next
Back Complete
WiFi-Test
WPA/WPA2-PSK
AES
Router password
Step 1
Step 2
Step 3
Please select you current wireless network
Help: When RSSI of the selected Wi-Fi network is lower than
15%, the connection may be unstable.Please select other
available network or shorten the distance between the device
and router. If you wireless router does not broadcast SSID,
please click "Next" and add a wireless network manually.
SSID
WiFi_Burn-in
WiFi_Burn-in
WiFi_Burn-in
WiFi_Burn-in2
RSSI
66
100
70
72
Channel
1
1
1
1
AUTH/ENCRY
WPAPSKWPA2PSK/TKIPAES
WPAPSKWPA2PSK/TKIPAES
WPAPSKWPA2PSK/TKIPAES
WPAPSKWPA2PSK/TKIPAES
Refresh
Back Next
CancelOK
admin
Remember the password(R)
*****
Admin(U) :
Password :
10.10.100.253
Note:
1. Please make sure the password, Encryption method / algorithm is the same with the
router's.
2. If everything is correct, the Wi-Fi LED on inverter will change from double blink to quartic
blink then to solid status, which means Wi-Fi has connected to the server successfully.
3. Wi-Fi conguration could also be done on PV Master App, details please check on PV Master
App.
Wi-Fi reset & reload
Wi-Fi reset means restarting Wi-Fi module. Wi-Fi settings will be reprocessed and saved automat-
ically. Wi-Fi Reload means setting Wi-Fi module back to default factory setting.
19 20

21
22
3.2 PV Master App
PV Master is an external monitoring/ configuration application for
hybrid inverters, used on smart phones or tablet for both Android
and iOS system. Main functions are as below:
1. Edit system configuration to make the system work as customer
needs.
2. Monitor and check the performance of the hybrid system.
3. Wi-Fi configuration.
Please download "PV Master App" from www.goodwe.com or scan
the QR code on the back of this user manual.
3.3 CEI Auto-Test Function
PV auto-test function of CEI is integrated in PV Master App for Italy's safety country requirements.
For detailed instruction of this function please refer to "PV Master Operation Instructions".
95048EHU12345678
4:21 PM 100%
VIRGIN
Waiting
Safety Country
Battery Type
Operation Model
Meter Communication Status
BMS Communication Status
Back-Up Switch
Anti-Reverse Function Switch
English
Battery-Box H6.4
Normal
CT connection
Alarm warning
On
Off
Overview Param Set
0.00(kW)
0.00(kW)
0.00(kW)
0.00(kW)
?
Note: Wi-Fi Reset & Reload function is only used when:
1. Wi-Fi lost connection to internet or cannot connect to PV Master APP successfully.
2. Cannot nd “Solar-WiFi signal” or have other Wi-Fi conguration problem.
3. Please do not use this button if Wi-Fi monitoring works well.
3.4.2 shutdown Procedure
Note: After the inverter system is shut down, the machine still has residual electricity and heat,
which may cause electric shock or burns. So after the inverter system is powered off for 5
minutes, wear protective gloves before operating the inverter.
step 1 Turn off the AC breaker between the inverter and the grid.
step 2 Turn off the DC breaker between the inverter and the battery.
Wi-Fi reset
Short press the touch button
for about one second, Wi-Fi
LED on inverter will blink
once a second;
Wi-Fi reload
Long press the touch button
(3~5 seconds)
Wi-Fi LED on inverter will
quartic blink
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
201 9
Wi-Fi
Reset/Reload
SYSTEM
GRID
BACK-UP
ENERGY
COM
Wi-Fi
BATTERY
FAULT
2 0 1 9
Touch Button
3.4 Startup/shutdown Procedure
3.4.1 Startup Procedure
Note: Before closing the AC breaker between the inverter and the grid, you need to use a
multimeter to measure whether the AC voltage is within the allowable range.
step 1 Turn on the breaker between the inverter and the battery.
step 2 Turn on the AC breaker between the inverter and the grid.
step 3 Please wait for about 1 minute, observe the LED indicator of the inverter, and check the
running status of the inverter

04 OTHERS
The error messages below will be displayed on PV Master App or report by Email if the error
occurs.
4.1 Error Message
ERROR MESSAGE EXPLANATION REASON SOLUTIONS
1. Check (use multi-meter) if AC side has voltage . Make sure grid power is available.
2. Make sure AC cables are connected tightly and well.
3. If all is well, please try to turn off AC breaker and turn on again after 5 mins.
1. Make sure safety country of the inverter is set right.
2. Check (use multi-meter) if AC voltage (Between L & N) is within a normal range (Also on AC breaker side)
a. If AC voltage is high, then make sure AC cable complies with the requirements on user manual and AC cable is not too
long.
b. If voltage is low, make sure AC cable is connected well and the jacket of AC cable is not compressed into AC terminal.
3. Make sure the grid voltage of your area is stable and within normal range.
1. Make sure safety country of the inverter is set right.
2. If safety country is right, then please check the inverter display if AC frequency (Fac) is within normal range.
3. If FAC failure only appear a few times and is resolved soon, it should be caused by occasional grid frequency unstability.
1. Try to decrease surrounding temperature.
2. Make sure the installation complies with the instruction of the inverter user manual.
3. Try to turn off the inverter for 15 mins, then start up again.
Try to restart inverter, check if it still occurs, if not, means it is just an occasional situation or contact GoodWe.
Try to restart inverter, check if it still occurs, if not, means it is just an occasional situation or contact GoodWe.
Try to restart inverter, check if it still occurs, if not, means it is just an occasional situation or contact GoodWe.
Try to restart inverter, check if it still occurs, if not, means it is just an occasional situation or contact GoodWe.
Decrease Back-Up loads to make sure the total load power is lower than back-up nominal output power
(please refer to page 12).
Public grid power is not available
(Power lost or on-grid connection
fails)
Utility Loss
VAC Failure
FAC Failure
Over Temperature
DC Injection High
EEPROM R/W Failure
SPI Failure
DC Bus High
Back-up Over Load
Grid voltage is not within
permissible range
Grid frequency is not within
permissible range
Temperature inside of the
inverter is too high
Internal communication fails
BUS voltage is too high
Back-up side is over loaded
Inverter detects that AC voltage is beyond the
normal range required by the safety country
Inverter does not detect the connection of grid
Inverter detects that Grid frequency is beyond the
normal range required by the safety country
Inverter working environment leads to a high
temperature condition
Check using multi-meter if there if there is high voltage (normally should be lower than 10V) between N&PE cable on AC side.
If the voltage higher than 10V, it means the netural & ground cable are not connected well on AC side or restart inverter.
Relay Check Failure Self checking of relay fails Neutral & ground cable are not connected well on
AC side or just occasional failure
Inverter detects a higher DC component in AC output
Caused by a strong external magnetic field etc.
Caused by a strong external magnetic field etc.
Total back-up load power is higher than the back-up
nominal output power
/
/
/
NOTE: All the errors about battery happen only on Lithium battery with BMS communication.
24
23

Battery Settings, BMS Communication and Safety Country:
After connecting Solar-WiFi* (* means the last 8 characters of the inverter serial No.), check on PV
Master APP Param to make sure battery type is right what you have installed, and Safety Country
is right. If not right, please set it right in "Set".
1. For lead-acid battery: All the settings should comply with the parameter of the battery, and
please contact after-sales for advices before use it.
2. For lithium batteries, BMS status is "Communication OK".
Checking Before Starting S-BP Up
4.2-1 4.2-2 4.2-3
Battery connection:
Confirm the conncetion between S-BP and battery : polarity (+/-) are not reversed, refer to 4.2-1.
On-Grid & Back-Up conntecion:
Confirm On-Grid connected to power gird and Back-Up to loads: polarity (L/N) are not reversed,
refer to 4.2.2.
Smart Meter & CT Connection:
1. If connection between Smart Meter and CT (port 1 and 4 on Smart Meter) is OK.
Note: After turn on AC power, the COM led on Smart Meter should be blinking.
2. Make sure CT is connected between house loads and grid. And it follows the House Grid
direction on CT, refer to 4.2.3.
Note: For three-pahse Smart Meter, please refer to page 13 to check if the connection and communi-
cation of Smart Meter is OK.
Possible problems during operation
S-BP does not start up with only battery
Solution:
Make sure the voltage of battery is higher than 48V, otherwise battery cannot start S-BP up.
No discharge or output from S-BP to support loads
Possible Reason:
1. There is grid-tied inverter connected in the system, and the output power is higher than power.
2. Load is connected between gird and CT, thus the system cannot detect load power, which is
supported by grid power.
3. Load power is lower than 150W, as battery will only discharge if load power is higher than
150W.
4. Smart Meter communication fails or CT connected in a wrong direction, which gives S-BP
wrong data.
5. Battery is not in the condition fort discharging, such as low SOC, battery communication fail
for lithium batteries etc.
Solution:
1. Make sure communication between S-BP and SmartMeter is OK;
2. Make sure load power is higher than 150W;
a. Battery will does not discharge continuously unless load power is higher than 150W;
b. If battery still not discharge when Meter power is higher than 150W, then please check
SmartMeter & CT connection and direction;
3. Make sure SOC is higher than I-DOD. Or if battery discharged to below I-DOD, than battery will
only discharge again when SOC charged to [20% + (I-DOD)]/ 2 and SOC > 105% - DOD (if
battery discharge is required immediately, battery should be restarted);
4. Check on App if it is charge time,, during charge time, battery will not discharge (battery will
charge in priority during coincident time of charge/ discharge).
Battery does not charge:
Possible reason:
1. Smart Meter communication fails or CT connected in a wrong direction, which gives S-BP
wrong data.
2. Battery is not in the condition for charging, such as high SOC, battery communication fail for
lithium batteries etc.
Solution:
1. Make sure BMS communication is OK on PV Master (for lithium batteries);
2. Check if CT is connected in the right position and in the right direction as stated in the user
manual page 13;
4.2 Troubleshootings
To Back-Up load To Public Grid
Note: If BMS Status says "NG", then please make sure battery communication cable wiring
connection and all settings are all right, refer to battery connection SOP in S-BP QUICK
INSTALLATION INSTRUCTIONS.
Param
Battery (GCL 5.6kWH)
Battery Status
Battery Data
BMS Status
SOH (From BMS)
Protocol Code
Charge Current Limit (From BMS)
Discharge Current Limit (From BMS)
Waring (From BMS)
Temperature (From BMS)
SOC: 14%, Discharge
51.1V / 0.3A / 0.02kW
Normal
100.0%
256
23.0A
23.0A
Normal
25.0℃
Overview Param Set
Inverter
SN
Firmware Version
Safety country
Work status
Error
93648ENU172W0003
02024
Brazil
Normal (Back-Up)
① Power LED
② Energy consumption LED
③ Communications LED
④ Reset switch
⑤ USB Port
26
25

Question & Answers (Q&A)
About Wi-Fi configuration
Q: Why can't I find the Solar-WiFi* signal on smart phone?
A: Normally Solar-WiFi* signal can be found after inverter powered up.
Please check if Wi-Fi module is connected well, and make sure inverter is powered up
normally.
Note: If Wi-Fi LED on inverter is single-blinking (0.5s on & o ), then it means Wi-Fi module is not
connected or not connected well.
Q: Why can't I find the Solar-WiFi* signal on smart phone?
A: It can connect to only device at a time. So please make sure other devices are not already
connected to the signal.
Note: Please make sure the password of the Wi-Fi signal (12345678) is not wrong.
About battery operation
Q: Why does the battery not discharge when grid is not available, while it discharge
normally when grid is available?
A: On App, off-grid output and back-up function should be turned on to make battery discharge
under off-grid mode.
Q: Why is there output on Back-Up side?
A: For back-up supply, the Back-Up function on PV Master App must be turned on. Under off-grid
mode or grid power is disconnected, Off-Grid output function must be turned on as well.
Note: When turning on O-Grid output, don't restart inverter or battery, otherwise the function will
switch o automatically.
Q: Why battery switch always trip when starts it up (Lithium battery)?
A: For lithium battery like LG, normally the switch trips for following reasons:
1. BMS communication fails.
2. Battery SOC is too low, battery trips to protect itself.
3. An electrical short circuit occurred on battery connection side. Or other reasons please
contact GoodWe for details.
Q: Which battery should I use for S-BP?
A: For S-BP inverters, it could connect lithium batteries, with nominal voltage 48V, max charge
voltage 60V.
Compatible lithium batteries please refer to S-BP QUICK INSTALLATION INSTRUCTIONS
About PV Master operation and monitoring
Q: Why can't I save settings on PV Master APP
A: This could be caused by losing connection to Solar-WiFi*.
1. Make sure you are connected to Solar-WiFi* (make sure no other devices connected) or
router (if connected Solar-WiFi* to router) and on APP home page shows connection is
stable.
2. Make sure S-BP is under wait mode (on App) before you change any settings on PV Master
App disconect grid/load, only leave battery connected and then restart S-BP till the work
mode displays "wait" on the App.
Q: On the App, why are the data displayed on the homepage and param page different,
like charge/discharge, load or grid value?
A: The data refresh frequency is different, so there will be a data inconformity between different
pages on App as well as between that on the portal and App.
Q: On the App, some columns show NA, like battery SOH, etc. why is that?
A: NA means App does not receive data from inverter or server, normally it is due to communica-
tion problem, such as battery communication, and communication between inverter and the
App. (For lead-acid battery, NA is normal)
About Smart Meter and Power Limit Function
Q: Is power limit function possible for S-BP system?
A: Please refer to page 11 for details of this function on S-BP system.
Q: Can I use other brand's Meter to take over Smart Meter in S-BP system or change
some settings on Smart Meter?
A: No, because the communication protocol between inverter and Smart Meter is in-build in the
Smart Meter, other brand's Meter cannot communicate. Also any setting change could cause
Smart Meter communication failure.
Q: What is the max current allowed going through CT on Smart Meter?
A: The max current for CT is 120A
Other questions
Q: Is there a quick way to make the system work?
A: The shortest way, please refer to S-BP QUICK INSTALLATION INSTRUCITONS
Q: What kind of load can I connect on Back-Up side?
A: Please refer to user manual on page 11.
Q: Will the warranty of the inverter still be valid if for some special conditions we cannot
100% follow the installation or operation instructions of the user manual?
A: Normally we still provide technical support to problems caused from disobeying the instruc-
tions of the user manual, but we cannot guarantee a replacement or returns. So if there is any
special condition when you cannot 100% follow the instrucions, please contact after-sales for
suggestions.
28
27

4.4 Technical Parameters 4.3 Disclaimer
The S-BP series inverters are transported, used and operated under environmental and electrical
conditions. Manufacturer has the right not to provide after-sales services or assistance under
following conditions:
• Inverter is damaged during transfer.
• Inverter's warranty has expired and extended warranty is not bought.
• Inverter is installed, refitted or operated in improper ways without authorisation from manufac-
turer.
• Inverter is installed or used under improper environment or technical condition mentioned in
this user manual, without authorisation from manufacturer.
• Installation or configuration of the inverter does not follow requirements mentioned in this user
manual.
• The inverter is installed or operated against the requirements or warnings that are mentioned in
this user manual.
• Inverter is broken or damaged by any force majeure like lightening, earthquake, fire hazard,
storm and volcanic eruption etc.
• Inverter is disassembled, changed or updated on software or hardware without authorisation
from manufacturer.
• Inverter is installed, used or operated against any related items in international or local policies
or regulations.
• Any non-compatible batteries, loads or other devices connected to BT system.
• The Battery-Ready inverter activation code is obtained through illegal channels.
Note: Manufacturer will keep right to explain all the contents in this user manual. To insure
IP65, inverter must be sealed well, please install the inverters within one day after
unpacking, otherwise please seal all unused terminals/holes, terminals/holes are not
allowed to be kept open, conrm that there is no risk of water or dust entering the
terminals/holes.
Maintenance
The inverter requires periodical maintenance, details are shown below:
• Make sure inverter is totally isolated from all DC and AC power for at least 5 mins before mainte-
nance.
• Heat sink: Please use a clean towel to clean up heat sink once a year.
• Torque: Please use torque wrench to tighten AC and DC wiring connection once a year.
• DC breaker: Check DC breaker regularly, active the DC breaker 10 times in a row once a year.
• Operating DC breaker will clean contacts and extend lifespan of DC breaker.
• Water-proof covers: Check if water-proof covers of RS485 and other part are replaced once a year.
Technical Data GW3600S-BP GW5000S-BP
Battery Type
*1
Nominal Battery Voltage (V)
Max. Charging Voltage (V)
Max. Charging Current (A)
*1
75 100
Max. Discharging Current (A)
*1
75 100
Battery Capacity (Ah)
*2
Charging Strategy for Li-Ion Battery
Nominal Power Output to Utility Grid (W) 3680 5000
*3
Max. Apparent Power Output to Utility Grid
(VA)
*4
3680 5000
Max. Apparent Power from Utility Grid (VA) 7360 9200
Nominal Output Voltage (V)
Nominal Output Frequency (Hz)
Max. AC Current Output to Utility Grid (A) 16 22.8
*5
Max. AC Current From Utility Grid (A) 32 40
Output Power Factor
Output THDi (@Nominal Output)
Max. Output Apparent Power (VA)
*6
3680 5000
Peak Output Apparent Power (VA)
*6
4416, 10sec 5500, 10sec
Automatic Switch Time (ms)
Nominal Output Voltage (V)
Nominal Output Freqency (Hz)
Max. Output Current (A) 16 22.8
Output THDv (@Linear Load)
Max. Efficiency
Anti-islanding Protection
Output Over Current Protection
Output Short Protection
Output Over Voltage Protection
Li-Ion
48
≤60 (Configurable)
<3%
230
50/60
50~2000
Self-adaption to BMS
95.50%
<3%
50/60 (±0.2%)
<10
230 (±2%)
Integrated
Integrated
Integrated
Integrated
Battery Input Data
AC Output Data (On-grid)
AC Output Data (Back-up)
Efficiency
Protection
~1 (Adjustable from 0.8 leading to 0.8 lagging)
30
29

CERTIFICATES OF S-BP SERIES
G98 G59
G100 IEC62109-1
CEI 0-21 RD1699 VDE0126-1-1
VDE-AR-N 4105 NRS 097-2-1
Category I
Category II
Category III
Category IV
Applies to equipment connected to a circuit where measures have been
taken to reduce transient overvoltage to a low level.
Applies to equipment not permanently connected to the installation.
Examples are appliances, portables tools and other plug-connected
equipment.
Applies to a fixed equipment downstream, including the main distribution
board. Examples are switchgear and other euiquipment in an industrial
installation.
Applies to equipment permanently connected at the origin of an installa-
tion (upstream of the main distribution board). Examples are electricity
meters, primary over-current protection equipment and other equipment
connected directly to outdoor open lines.
4.5 Other Test
For Australian requirements, in the THDi test, Zref should be added between inverter and mains.
RA, XA for Line conduvtor
RN, XN for Neutral conductor
Zref:
RA=0, 24; XA=j0,15 at 50Hz;
RN=0, 16; XN=j0,10 at 50Hz
4.6 Quick Check List To Avoid Danger
1. Inverter cannot be installed near flammable, explosive or strong electro-magnetic equipment,
please refer to page 06
2. Remember that this inverter is heavy! Please be careful when lifting out from the package,
please refer to page 07
3. Make sure battery breaker is off and battery nominal voltage meets S-BP specification before
connecting battery to inverter and make sure inverter is totally isolated from AC power, please
refer to page 10
4. Make sure inverter is totally isolated from any DC or AC power before connecting AC cable,
please refer to page 11
5. Make sure AC cable is totally isolated from AC power before connecting Smart Meter & CT,
please refer to page 14
Appendix protection category defintion
Overvoltage category definition
Operating Temperature Range (℃)
Relative Humidity
Operating Altitude (m）
Cooling
Noise (dB)
User Interface
Communication with BMS
*7
Communication with Meter
Communication with Portal
Weight (kg)
Size (Width*Height*Depth mm）
Mounting
Protection Degree
Standby Self Consumption (W)
Topology
Grid Regulation
Safety Regulation
EMC
EN 61000-6-1, EN 61000-6-2, EN
IP65
<15
Battery Isolation
VDE-AR-N 4105; VDE 0126-1-1
EN 50549-1; G98, G100; CEI 0-21; AS/NZS 4777.2 NRS
IEC62477-1, IEC62040-1
RS485
Wi-Fi
18.5
347*432*190
Wall Bracket
*1: The actual charge and discharge current also depends on the battery.
*2: Battery capacity could be not less than 100Ah where the back-up function is to be applied.
*3: 4600 for VDE0126-1-1&VDE-AR-N 4105 and CEI 0-21.
*4: For CEI 0-21 GW3600S-BP is 4050，GW5000S-BP is 5100; for VDE-AR-N4105 GW5000S-BP is 4600.
*5: 21.7A for AS4777.2.
*6: Can be reached only if battery capacity is enough, otherwise will shut down.
*7: CAN communication is configured by default. If 485 communication is used, please replace the
corresponding communication line.
*8: Not all certifications & standards listed, check the official website for details.
General Data
Certifications & Standards
-25~60
0~95%
4000
Nature Convection
<25
LED & APP
RS485; CAN
32
31

Environment category definition
Level
3K3
0~+40℃
5%~85%
4K3
-33~+40℃
15%~100%
4K4H
~20~+55℃
4%~100%
Environment Condition
Outdoor
Indoor Unconditioned
Indoor conditioned
Ambient Termperature
-20~50℃
-20~50℃
0~40℃
Relative Humidity
4%~100%
5%~95%
5%~85%
Applied to
PD3
PD3
PD2
No pollution or only dry, non-conductive polllution occurs.
The pollution has no influence.
Normally only non-conductive pollution occurs. Occasionally,
however, a temporary conductivity caused by condensation
must be expected.
Conductive pollution occurs, or dry. non-conductive pollution
occurs, which becomes conductive due to condensation,
which is expected.
Persistent conductive pollution occurs, for example, the
pollution caused by conductive dust, rain or snow.
Moisture location category definition
Pollution degree definition
Pollution Degree I
Pollution Degree II
Pollution Degree III
Pollution Degree IV
Moisture Parameters
Temperature Range
Moisture Parameters
33
