Goodwe SCB3000 User manual

GoodWe Technologies Co., Ltd.
No. 90 Zijin Rd., New District, Suzhou, 215011, China
www.goodwe.com
[e-mail] V1.0-2022-01-25
SCB3000
User Manual
Solar Communication Box
Local Contacts
340-00712-00

1 Symbol Definition..................................................................................................... 01
2 Installation Instructions and Warnings ...................................... 01
3 Product Introduction .......................................................................................... 02
3.1 Product Overview ...................................................................................................................... 02
3.2 Appearance Introduction.......................................................................................................... 02
3.3 Packaging Information.............................................................................................................. 03
4 Equipment Installation ..................................................................................... 04
4.1 Installation Instructions............................................................................................................ 04
4.2 Installation Location ................................................................................................................. 04
4.3 Installation Method ................................................................................................................... 05
4.4 Port Description ......................................................................................................................... 06
4.5 Wiring Instructions .................................................................................................................... 07
4.6 Networking Diagrams ............................................................................................................... 10
5 System Operations ................................................................................................. 11
5.1 Indicator Descrition...................................................................................................................11
5.2 Master Computer Operations & Parameter Configurations .............................................. 12
5.3 Configuration Instructions for Fiber Optic Switches ........................................................... 21
6 Program Upgrade ..................................................................................................... 22
6.1 Local Upgrade ............................................................................................................................ 22
6.2 Remote Upgrade ....................................................................................................................... 22
7 Maintenance and troubleshooting .................................................... 23
7.1 Maintenance ...............................................................................................................................23
7.2 Troubleshooting ........................................................................................................................ 23
8 Technical Parameters ......................................................................................... 24
9 Certifications ................................................................................................................. 24

The SCB3000 is designed and tested in strict accordance with relevant safety regulations. However, as electrical and
electronic equipment, the following safety instructions must be observed during installation and maintenance, and
improper operation will cause serious injury and property damage to the operator and a third party.
• The SCB3000 must be installed and maintained by professionals in accordance with local standards and regulations.
• When installing and maintaining the SCB3000, power must be disconnected from the SCB3000 to prevent electric
shock.
• During operation, do not touch any live parts of the SCB3000, such as its internal components and cables, to avoid
electric shock.
• Before replacing any components within the SCB3000, power must be disconnected from the SCB3000 and the newly
replaced components must be ensured to meet the requirements for use of the SCB3000, and GOODWE will not be
liable for any personal harms or warranty claims arising from noncompliance with this instruction.
• When the SCB3000 is in operation, do not plug in or remove any cable.
• The SCB3000 has an internal lightning protection module installed, inside which the PE is connected to ground when
installing the SCB3000.
• Ensure that the AC input voltage and current are matched with the voltage and current ratings of SCB3000, otherwise
the components could be damaged or not functioning properly, and GOODWE will not be liable for any responsibilities
or warranty claims arising from this mismatch.
2 Installation Instructions and Warnings
1 Symbol Definition 3 Product Introduction
3.1 Product Overview
The SCB3000 is used in photovoltaic power generation systems to integrate data collectors, allowing
for the port aggregation, data acquisition and storage, as well as centralized monitoring and
maintenance of inverters, environment monitors and instrumentations in photovoltaic power
generation systems.
SCB3000 model description:
SCB3000 includes the SCB3000P00 and SCB3000P01. The SCB3000 is the name of the series of
photovoltaic communication boxes; P means that the local communication mode is PLC2.0; 00
means that the cloud communication method supports LAN; 01 means that the cloud
communication method supports LAN and optical fibre. In this manual, the SCB3000P00 and
SCB3000P01 models are both referred to as the SCB3000.
Flexible networking:
Communication with inverters supported via PLC or RS485.
Communication with the server available via Ethernet, fiber optics, etc.
Note: When the SCB3000 uses PLC communication, it can only communicate with inverters supporting PLC2.0.
Currently, inverters equipped with PLC2.0 function include the HT and SMT series. For details, please contact
the Goodwe after-sales service centre.
3.2 Appearance Introduction
A fter opening the package, check the product to confirm whether it is consistent with the
specifications of the SCB3000 you purchased. The appearance of the SCB3000 is shown in Figure 3.2-1.
Solar Communication Box
SCB3000
Figure 3.2-1
Safety Warning - Ignoring the warning
signs in this manual may cause minor or
moderate injuries.
Danger of high voltage, avoid
electric shock
Recyclable
This side shall be upside, do not tilt
The product must not be
disposed of as ordinary waste,
but must be recycled by special
methods
Stacking limit, up to 4 layers
can be stacked
CE mark Fragile items, handle with care
Avoid humidity
01 02

4 Equipment Installation
4.1 Installation Instructions
• The SCB3000 is installed in places where there is no significant shaking, shock or vibration,
and not subject to rain or snow.
• The installation height shall be parallel to the line of sight for easy operation and
maintenance.
• The installation location of the SCB3000 should be free of explosive media containing gases
and dust sufficient to corrode metals and damage insulation.
• The parameter labels and warning signs must be clearly visible after the SCB3000 is
installed.
• The installation location of the SCB3000 shall avoid sunlight, rain, and snow.
Solar Communication Box
SCB3000
4.2 Installation Location
The following factors must be considered when choosing the installation location:
• The installation method and location must be suitable for the weight and size of the SCB3000.
• Install on a solid surface.
• The installation location must be sufficiently ventilated.
• The SCB3000 can be horizontally placed or vertically installed.
• The vertical installation or tilt back can not exceed 15 degrees, must not be tilted sideways, the
wiring area should be facing down, as shown in Figure 4.2-1.
MAX 15°
Figure 4.2-1
3.3 Packaging information
Key×4
..... .. ...
....... ..
..
.. ...
User Manual×1 Expansion Screw×3
Tubular Terminal×2
Fire Clay×1
O-Shaped Terminal×3 Wiring Terminal ×4 Panhead Screw x1
SCB3000×1
SolarCommunication Box
SCB3000
Cable Tie×5
Back Hanger×1
No.
1
2
3
4
5
6
7
8
Label
L1/L2/L3/PE
LAN/ANTENNA
COM1
COM2
COM3
COM4
FXL1/FXL2
L/N
Description
Three-phase AC and protective ground wiring port (with a waterproof cap)
Ethernet/Antenna port (with a waterproof cap)
RS485-1 port (with a waterproof cap)
RS485-2 port (with a waterproof cap)
RS485-3 port (with a waterproof cap)
RS485-4 port (with a waterproof cap)
Fiber Optic Wiring port (with a waterproof cap)
AC Power Supply port (with a waterproof cap)
Avoid sunlight Avoid rain
Avoid snow Sunlight Rain
Snow
03 04

Horizontal Placement:
1. The SCB3000 can be placed horizontally, as shown in Figure 4.3-4.
2. The SCB3000 needs to be placed indoors at a location where it can be fixed, as shown in Figure
4.3-5.
4.3 Installation Method
3. Install the enclosure as shown in Figure 4.3-3.
Figure 4.3-3 2
• To ensure good heat dissipation and easy disassembly, the minimum clearance around the
SCB3000 must not be less than the following values, as shown in Figure 4.2-2.
Vertical Installation:
1. Drill holes in the wall with a diameter of 8mm and a depth of 45mm. The spacing of the holes is shown in Figure 4.3-1.
2. Use the expansion screws in the accessory pack to fix the back plate on the wall, as shown in Figure 4.3-2.
Solar Communication Box
SCB3000
Mounting Backplate
Expansion Tube
Tapping Screw
L
o
Install the SCB3000 enclosure bracket on the back plate and tighten it securely with screws to prevent the enclosure from shaking.
Figure 4.3-1 Figure 4.3-2
Figure 4.3-4 Figure 4.3-5
4.4 Port Description
The internal ports of SCB3000 are described as follows:
NET
POWER
COM1
DI
NC
COM2
1
2
3
4
5
6
No. Port
COM3
COM4
For connections to third-party equipment such as environment monitors
7
8
DC Power Input (occupied)
Ethernet (occupied for fiber optic version)
DRED (for Australia) or RCR (for Germany) function
Reserved
RS485 port for communications with the inverter
Port Description
RS485 port for communications with the inverter
RS485 port for communications with the inverter
RUN FXL1FXL1B
DI
NET REF1 REF21 2 3 A B A B A B A B4
COM1 COM2 COM3 COM4
FXL1 FXL2
RESET
APWR FXL2
TP1 TP2 TP3
1000M ACT1000M ACT1000M ACT
TP1, TP2 Ethernet (for fiber optic version only)
9
TP3 Ethernet (occupied, for fiber optic version only) 10
FXL1, FXL2 Fiber Optical Port (for fiber optic version only)
11
Note: Item numbers 9, 10 and 11 in the above list are fiber optic module ports, and will only be used when the
fiber optic version is selected. These 3 ports will not exist if there is no fiber optic version. Ports 5, 6 and 7 are
RS485 ports, and will not be used when the SCB3000 is communicating with inverters through the PLC.
Figure 4.2-2
250mm
125mm
25mm
Top
Bottom
Front
Bothsides
05 06

10~12
L
N
No greater than 25mm
Value
Recommend for use: 2.5~4mm²
Approximately 45mm
Approximately 12mm
Wire outer diameter
Plier Crimping
Plier Crimping
Description
Cross-sectional area of copper conductors
Wire length
Copper bare wire length
A
Code
B
C
D
Wire outer diameter
Wire No Functions
Description Value
Cross-sect. area of copper conductors
Wire length
Copper bare wire length
A
Code
B
C
D
4.5.1 Description of SCB3000 Power Supply Cable
The single-phase power supply cable is connected to the internal single-phase switches L and N
of the SCB3000.
Input phase voltage range: AC100V~AC240V; AC frequency: 50Hz/60Hz
Input wire and crimping:
Note: Before connecting the AC power line, make sure that the switch upstream of SCB3000 is open
Flexible stranded copper wire
AC Input wire specifications and crimping:
No greater than 25mm
Recommend for use: 2.5~4mm²
6~8mm
Approximately 130mm (approximately 50mm for PE wire)
6~8Mm (5~6mm for PE wire)
L1
L2
L3
PE
Wire specifications and installation: for RS485 communication cables, shielded
twisted pair cables with a conductor cross-sectional area of 1mm² are recommended for use.
4.5.3 Description of RS485 communication wiring
COM1, COM2 and COM3 are RS485 ports for communications with the inverter that can be left
unused if communications with inverter PLC can meet the requirements, users can choose to
connect COM1, COM2 or COM3 for communications with the inverter as needed.
If using the SCB3000 to connect with a environment monitor, the connection can be made to the
COM4 port via the RS485 cable.
Note: 1. COM1, COM2 and COM3 are used only for communications with the inverter, while COM4 is only
connected to third-party equipment such as environment monitors, and must not be connected incorrectly.
2. For RS485 communication wiring, please use standard RS485 communication twisted pair.
3. The maximum number of inverters connected to each of COM1, COM2 and COM3 is 20 units, with the total
of 60 units allowed for the 3 ports.
4. In the ports COM1, COM2, COM3 and COM4, A corresponds to the differential signal +, and B corresponds to
the differential signal.
4.5 Wiring Instructions 4.5.2 PLC Wiring Instructions
(a) Protective Earth Wiring:
The protective ground wire is connected to the PE of the base plate of inside the SCB3000 enclosure.
(b) Remove the three-phase AC power line cover panel.
(c) Connect the three-phase AC power line
Note: Before connecting the AC power line, make sure that the switch upstream of SCB3000 is open.
Three-phase input line voltage range: AC342V~AC800V; AC frequency: 50Hz/60Hz.
The three-phase AC power line is connected to the transformer bus, and then to the circuit breakers L1, L2 and
L3 in the SCB3000 via port (1).
(d) Install the three-phase AC power line cover panel.
(1) (2) (3) (4) (5)
POWER NET REF1
DI COM1COM2 COM3COM4
REF22 3 4 A B A B A B A B1
FXL2FXL1
PE
Screw Nut
Isolator
Gasket
Nut Cable
07 08

One of the SCB3000s need to be set as the master (root node), with the others as
the slaves (slave nodes).
4.6 Networking Diagrams
4.5.5 Description of fiber optic communication wiring
The SCB3000 fiber optic version can be connected to fiber optic terminals through optical cables
for data transmission.
The optical cables are connected to the FXL1 and FXL2 ports inside the SCB3000.
Note: Both ends of the same fiber optic must be connected to the TX and RX ports, otherwise the fiber optic
connection will not be made correctly.
Cat 5e is recommended for use as the network cable. After wiring, please use the fire clay included
to block it to ensure its fireproof performance.
4.5.4 Description of LAN communication wiring
The SCB3000 can be connected to routers, computers, switches and other equipment through the
network cable; The network cable is connected to the internal NET port of the SCB3000; if you select
the fiber optic version of this device, the network cable can be connected to the TP1 or TP2 port (the
NET port has been connected to the TP3 port for the fiber optic version of this device).
Standalone
Multi-machine fiber optic
ring network
PV string
DC Cable
Inverter
Inverter
AC Combiner Box
Transformer
Grid
Three-phase AC
power line
Fiber Optic Device
Environment Monitor
Environment
Monitor
Inverter Transformer
Environment
Monitor
Inverter Transformer
Router
Router
Network Cable
Inverter
DC Cable
Fiber optic ring
network
DC Cable
PV string
PV string
1
2
3
45
4.5.6 Wiring instructions for other ports
The DI port of SCB3000 is compatible with both RCR (for Germany) and DRED (for Australia)
functions. The port definitions in different functions are as follows:
If the user does not need to use this function, the port does not need to be wired.
RCR
DRED
+5V
REF1
RefGen
D_IN1
1
DRM1/5
D_IN2
2
DRM2/6
D_IN3
3
DRM3/7
D_IN4
4
DRM4/8
+5V
Com/DRM0
REF2
09 10

5 System Operations
5.1 Indicator Description
Blue Light On
Blue Light Off
Blue Light flashing (on for 1 second, off for 1 second)
Blue Light On or Off continuously
Blue Light flashing (on for 1 second, off for 1 second)
Blue Light On continuously
Blue Light Off
Blue Light On
Blue Light Off
POWER
RUN
SERVER
PC
The power supply is OK
The power supply is Off
The SCB3000 is not operating properly
The SCB3000 is operating properly
The SCB3000 is connected to the external network server correctly.
The SCB3000 is connected to the router correctly, but not connected to the external network server.
No network connection for SCB3000
The SCB3000 is connected to a computer and ProMate software
The SCB3000 is not connected to a computer and ProMate software
The actual number of inverters acquired by SCB3000 is equal to the number of acquired inverters set for the port
The actual number of inverters acquired by SCB3000 is less than the number of acquired inverters set for the port
The number of inverters acquired by SCB3000 is not set for the port
The SCB3000 has not acquired any data from the inverter
The actual number of inverters acquired by SCB3000 is equal to the number of acquired inverters set for the port
The actual number of inverters acquired by SCB3000 is less than the number of acquired inverters set for the port
The number of inverters acquired by SCB3000 is not set for the port
The SCB3000 has acquired data from the inverter
The actual number of inverters acquired by SCB3000 is equal to the number of acquired inverters set for the port
The actual number of inverters acquired by SCB3000 is less than the number of acquired inverters set for the port
The number of inverters acquired by SCB3000 is not set for the port
The SCB3000 has not acquired any data from the inverter
Blue Light On
Blue Light flashing (on for 1 second, off for 1 second)
Blue Light flashing (on for 1 second, off for 3 seconds)
Blue Light Off
Blue Light On
Blue Light flashing (on for 1 second, off for 1 second)
Blue Light flashing (on for 1 second, off for 3 seconds)
Blue Light Off
Blue Light On
Blue Light flashing (on for 1 second, off for 1 second)
Blue Light flashing (on for 1 second, off for 3 seconds)
Blue Light Off
Port Status Status Description
COM4
COM3
COM2
COM1
Blue Light On
Other equipment (such as external environment monitors) communication good.
Blue Light Off No other equipment, such as external environment monitors
5.2 Master Computer Operations & Parameter Configurations
ProMate is a software released by us for the configuration of the SCB3000 functions, it
enables the modification of the network IP address of the SCB3000, the configuration of
the number of port-connected inverters, time settings, RCR and DRED feature
configuration, field debugging and more.
5.2.1 Connecting to the Master Computer Software
If the user wants to configure the SCB3000 using ProMate software, the master computer
needs to be connected in either dynamic IP (DHCP) or static IP according to the way the
network is connected.
1. SCB3000 dynamic IP address connection:
SCB3000 is set to dynamic IP mode by default, and the network connection is simply made
by connecting the SCB3000 NET port to the router LAN port with the network cable, which
is plug and play. To configure the SCB3000, connect your computer to the router with a
network cable, and launch the ProMate software in which you can click "Scan" to complete
the connection successfully. When the configuration is complete, disconnect the
computer from the router.
Note: If the SCB3000 is set to static IP mode, you need to switch to dynamic IP mode before you can configure
it using dynamic IP connection. Press and hold the "RELOAD" button for about 4 seconds, this will make the
LED signal indicators flash from right to left, indicating a completed reset and restart, after which the SCB3000
will be switched to static IP mode.
11 12

2. SCB3000 static IP address connection:
Note: SCB3000 is set to dynamic IP mode by default, you need to switch the SCB3000 to static IP mode first
by pressing and holding the "RELOAD" button for about 10 seconds, this will make the LED signal
indicators of the SCB3000 flash from right to left, indicating a completed reset and restart, after which the
SCB3000 will be switched to static IP mode (the default IP address is 192.168.1.200).
The user needs to set the computer to static IP mode, and configure the computer's IP address and the
SCB3000's IP address in the same network segment. The steps are as follows (using Windows 7 OS as an
example). Users can find the methods on the Internet that can be used to modify the IP addresses of
computers running different operating systems.
(a) Use a network cable to connect the "NET" of the SCB3000 to the Computer's Ethernet port.
(b) Right-click “Network" and select "Properties".
(c) Click "Change adapter settings".
The following popup dialog box is displayed:
(d) In the local connection popup dialog box, right-click "Local connection" and click "Properties".
13 14

(e) Double-click "Internet Protocol Version 4 (TCP/IPv4)" to show the "Internet Protocol Version 4
(TCP/IPv4)" popup dialog box, and set up the dialog box according to the requirements below.
The default IP address of the SCB3000 is 192.168.1.200. To keep the computer and SCB3000 in the
same network segment, the "IP address" and "Default Gateway" should be set at the
192.168.1.XXX segment (1≤XXX≤250且XXX≠200).
For example: The IP address can be set to 192.168.1.100 and the default gateway 192.168.1.254.
Click the "Connect" button in ProMate, when it shows that the connection is successful,
ProMate is connected to the SCB3000 successfully.
Note: If there is only one Box-type substation on the customer site, and the data is uploaded to GOODWE
servers, there is no need to configure the box number and address through ProMate, simply connect ProMate,
click to get the inverter list to see if the inverter is all online. If there are multiple box Box-type substations
onsite, refer to 5.2.2 for setup.
5.2.2 Parameter Configurations (for PLC communication with the inverter)
When the connection to ProMate is successful, parameter configurations can be made on
the SCB3000 and the inverter to which it is connected.
(a) Choose Protocol
Click the "Ezlogger Pro" button and select the protocol in the following popup.
Custom is used for parameter configuration and Modbus protocol for normal
communication.
The machine is set to "Custom" in the factory by default, and the following protocol
showed in grey is the one that is currently used. After switching protocols, ProMate waits
about 1 minute to proceed.
Note: Select the GOODWE custom protocol first to configure the BOX No and inverter address, then switch to
the Modbus protocol for communications after all parameters have been configured.
15 16
