gopart FGP455239GP User manual

Push spreader
125LB / 55kg
DE
FR
NL
DK
ES
IT
PL
Schiebestreuer
Épandeur à pousser
Duw stooier
Skubbespreder
Carro esparcidor
Spargitore a spinta
Rozsiewacz pchany
FGP455239GP

2
UK
GENERAL WARNINGS
READ and UNDERSTAND this manual completely before using Push Spreader.
Operator must read and understand all safety and warning information, operating
instructions, maintenance and storage instructions before operating this equip-
ment. Failure to properly operate and maintain the push spreader could result in
serious injury to the operator or bystanders.
Operation Warnings
• Do not at any time carry passengers on the spreader.
• Do not allow children to play on, stand upon or climb in the spreader.
• Always inspect the spreader before using to assure it is in good working condi-
tion.
• Replace or repair damaged or worn parts immediately.
• Always check and tighten hardware and assembled parts before operation.
• Do not exceed equipment maximum load capacity of 125lb.
• Avoid large holes and ditches when transporting loads.
• Be careful when operating on steep grades (hill) the spreader may tip over.
• Do not push close to, ditches and public highways.
• Do not use spreader on windy days when spreading grass seed or herbicides.
• Always use caution when loading and unloading spreader.
• Never tow the spreader with a motorized vehicle.
Crush and Cut Hazards
• Always keep hands and feet clear from moving parts while operating the equip-
ment.
• Always clear and keep work area clean when operating.
• Always wear safety gear, eye protection, gloves and work boots when operating
the spreader.
WARNING
The warnings, cautions, and instructions outlined in this instruction manual can-
not cover all possible conditions or situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which cannot be
built into this product and must be supplied by the operator.
Assembly Is Required
This product requires assembly before use. See “Assembly” section for instructions.
Because of the weight and/or size of the push spreader, it is recommended that
another adult be present to assist with the assembly. INSPECT ALL COMPONENTS closely
upon receipt to make sure no components are missing or damaged.

3
UK
HAZARD SIGNAL WORD DEFINITIONS
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
CAUTION used without the safety alert
symbol indicates a potentially hazardous
situation which, if not avoided, may result in
property damage.
ABOUT YOUR PUSH SPREADER
This push spreader is designed to spread a wide range of materials (Fertilizer,
Grass Seed and Ice melt). Materials such as Powders, Manure, Top Soil, Gravel,
and Mulch have the wrong physical characteristics and should not be used with
this spreader. Never exceed the rated load capacity of 125lbs when operating the
spreader.
Your spreader needs to be pushed at three miles per hour, which is a brisk walking
speed. Slower or faster speeds will change the spread patterns. Wet spreading ma-
terial will also change the spread pattern and flow rate. Clean your spreader thor-
oughly after each use. Wash between the shut off plate and bottom of the hopper.
Technical specifications on the push spreader are provided in the “Specifications”
section of this manual.
DANGER
WARNING
CAUTION
CAUTION

4
UK
CONTROLS AND FEATURES IDENTIFICATION
Read this owner’s manual before operating the equipment. Familiarize yourself
with the location and function of the controls and features. Save this manual for
future reference.
1. Handle – Pushes and moves the spreader easily.
2. Flow Control – Controls the flow of material being spread.
3. Hopper – Do not exceed rated load capacity 125lb.
4. Tires / Wheel – Do not exceed recommended rated 30PSI.
5. Impeller – Evenly distributes material.
6. Support Leg – Stabilizes load and spreader.
CAUTION
Read and follow all instructions for assembly and operation. Failure to properly
assemble this equipment could result in serious injury to the user or bystanders,
or cause equipment damage.
PUSH SPREADER COMPONENT PARTS AND ASSEMBLY.
Take all parts out of the shipping crate and inspect components to ensure there
are no missing pieces before starting to assemble the push spreader follow steps 1
through 5.
TOOLS REQUIRED
• Pliers (2 Each)
• 8mm Wrenches (2 Each)
• 10mm Wrenches (2 Each)
• 13mm Wrench
• 14mm Wrench
1. 2.
3.
6.
4.
5.

5
UK
COMPONENT PARTS
Hex Bolt M8X75
1 pc
Hex Bolt M6X40
6 pcs
Hex Bolt M6X35
2 pcs
Hex Bolt M6X20
4 pcs
R Pin Ø3
1 pc
Lock Nut M8
3 pcs
Lock Nut M6
12 pcs
Flat Washer Ø16
6 pcs
Flat Washer Ø8
2 pcs
Spring Washer Ø6
6 pcs
Big
Flat Washer Ø6
6 pcs
Bushing
2 pcs
Bushing
2 pcs
Drive Pin
1 pc
Spacer
1 pc
Cotter Pin Ø5X35
2pcs
㔥Ⲫ
Support Leg
1 pc
Solid Linkage
1 pc
Handle Preas-
sembled
1 pc
Hopper
1 pc
Frame Tube As-
sembly
1 pc
Wheel
2 pcs
Screen
1 pc
Rain Cover
1 pc

6
UK
1. On the left side of axle install a wheel bushing and wheel spacer into the axle.
2. Slide a wheel over the axle.
3. Put an Ø16 flat washer over the axle, insert the cotter pin through the hole
and secure by bending.
4. On the right side of the axle slide a wheel bushing and the wheel spacer into
the axle.
5. Put a wheel over the axle, line up the holes and insert the drive pin through
sleeve and lock.
6. Put an Ø16 flat washer over the axle, insert the cotter pin through the hole
and secure by bending.
NOTE: Four additional flat washers are provided for adjusting the gap between the wheels.
STEP 1: INSTALLING THE WHEELS
Cotter Pin Ø5X35
Flat Washer Ø16
Slide the Wheel Bushing and Wheel into
the Axle and align the two holes then
insert the Drive Pin.
Slide the Wheel Bush-
ing and Wheel into the
Axle
Here are 4 pcs of Flat Washers Ø16
used for adjusting the gap between
the wheels.
Flat Washer Ø16
Cotter Pin Ø5X35

7
UK
STEP 2: ASSEMBLING THE SUPPORT LEG
1. Position the support leg so the J-shaped end is pointing away from the wheel
assembly.
2. Insert the M8x75 hex bolt through the top hole on the support leg and slide
the spacer over the bolt end.
3. Take the support leg and insert the bolt through the upper cross bar on the
mounting assembly and loosely tighten with the M8 lock nut.
NOTE: Before tightening the bolt make sure the support leg flange and the lower cross bar holes line up.
4. Insert M6 x 40 hex bolt through the holes in the flange and cross bar. Use the
Ø6 big flat washer and M6 lock nut and tighten all hardware.
Frame Tube As-
sembly
Big Flat
Washer Ø6
Lock Nut M8
Hex Bolt M6X40
Support Leg
Hex Bolt M8X75
Spacer
Lock Nut M6

8
UK
STEP 3: INSTALLING THE HOPPER
1. Lower the hopper over the mounting assembly, carefully line up the holes in
the bottom of the hopper with the spindle in the mounting plate of the axle.
2. Use the M6 x 40 hex bolt and Ø6 flat washer to attach the hopper to the
mounting assembly and secure with M6 lock nut.
3. Make sure the gear and pinion gear works smoothly. If not, adjust again until
the gear and pinion gear swivel smoothly.
4. Tighten all the hardware on the shaft support plate and hopper.
5. Insert the R pin through the top of the spindle.
R Pin Ø3
Install the hopper onto the frame
tube assembly by 6 pcs of Hex
Bolt M6X40, Big Flat Washer Ø6
and Lock Nut M6
Insert the swivel
axle into the hopper
first.

9
UK
STEP 4: CONNECTING HANDLE TO THE SUPPORT LEG
1. Slide the handle tube into the top of the support leg and align the two holes.
2. Insert M6x35 hex bots through the two holes on the support leg and tighten
with the Ø6 spring washer and M6 lock nut.
3. Insert M6x20 hex bolt through the hole in the side plate and tighten with Ø6
spring washer and M6 lock nut.
Handle
Hex Bolt M6X35
Hex Bolt M6X20
Support Leg
Lock Nut M6
Spring Washer Ø6
Lock Nut M6
Spring Washer
Ø6

10
UK
STEP 5: CONNECTING THE SOLID LINKAGE
1. Connect the solid linkage through the bottom fix plate using the Ø8 flat
washer and tighten with a M8 lock nut.
2. Connect the other end of the linkage to the flow control with an Ø8 flat
washer and M8 lock nut.
3. Install the hopper screen in the bottom of the hopper.
4. Before using the spreader make sure all the hardware is tightened.
5. Use the rain cover as needed to protect material in the hopper or when
spreader is being stored.
Put the Flat washer Ø8 onto one
end of Solid Linkage. Insert it
into the hole on the Bracket and
tighten by Lock Nut M8.
Put the Flat Washer Ø8 on the
Solid Linkage and insert into the
hole. Fasten by Lock Nut M8.
Note: the bracket
needs to face oppo-
site when Assem-
bling to the handle
Screen
Rain Cover
Solid Linkage

11
UK
OPERATION INSTRUCTIONS
WARNING
Before using the push spreader, review the instructions below and safety informa-
tion. Failure to follow these instructions may result in property damage or injury
to the operator or bystanders.
USING YOUR SPREADER
1. Inspect your spreader before each use. Make sure the wheels turn easily, and
the gearbox moves when the spreader is pushed. The hopper should
be clean and free from cracks.
2. Spreader is designed to spread a range of materials (Fertilizer, Grass Seed
and Ice melt). Materials such as Powder, Manure, Top Soil, Gravel, and
Mulch have the wrong physical characteristics and should not be used with
your spreader
3. Do not use spreader on windy days when spreading grass seed or herbicides.
4. Determine approximate square footage of the area to be covered and esti-
mate amount of material required. Please refer to fertilizer manufacturer’s
recommendation. Break up any lumpy fertilizer as you fill the hopper.
5. Before filling the hopper, make sure that the flow control lever is in
the“0”position and the flow control plate is closed.
6. Set the adjustable stop with the flow control lever always in the“0”position.
Every time you are ready to stop or turn back, close the flow control plate
to stop dispersing the material and continue one more stride. This reduces
waste and avoids damaging the lawn with
oversaturated product coverage.
7. Follow fertilizer manufacturer’s recommended coverage rate for each prod-
uct.
8. To maintain the same coverage when walking at a different speed, adjust the
flow rate. Reduce the flow setting for slower speeds and increase the flow
setting for higher speeds.
9. Keep the impeller plate horizontal when operating the spreader. Tilting the
spreader will result in uneven coverage.
10. Make sure the R pin is installed in the hopper before starting the spreader.
11. Always start walking prior to opening the closure plate.
12. Always close the flow control plate before turning or stopping the spreader.
13. If spreading material is accidentally deposited too heavily in a small area,
soak the area thoroughly with a garden hose or sprinkler to prevent burning
of the lawn.
14. To insure consistent coverage, make sure each broadcast pattern slightly
overlaps the
previous broadcast pattern.
15. When spreading material, make sure the broadcast pattern does not hit ever-
green trees, flowers or shrubs.
16. Do not over apply spreading material. Follow the recommended coverage
rate for each product. Over application will lead to lawn damage and contam-
ination.

12
UK
OPERATION INSTRUCTIONS
ADJUSTING THE FLOW
1. You can move up the handle to adjust the spreader setting by following the
direction of the arrowhead. When the handle moves up to “30”, the adjustable
plate is fully open, when it goes to “0”, it’s fully closed.
2. Loosen the wing nut on the Bracket and move the adjustment lever handle up
or down depending on the amount of material required. Pushing the handle
down will release more material and pulling the handle up will stop the flow
entirely.
3. Tighten the wing nut when the desired position is reached.
OFF ON
Adjust the handle fol-
lowing the arrowhead
direction.
Adjust the handle to make sure the adjusting plate is fully
open or closed. If not, please loosen the 2 bolts in the
pictures and push the handle to the “0” position, then
remove the bracket a little to make sure the adjusting plate is
fully closed. Then tighten the 2 bolts.
When the handle moves to
30, the adjustable plate is
fully open.
When the handle moves to 0,
the adjusting plate in the hop-
per is fully closed.

13
UK
OPERATION INSTRUCTIONS
CONSISTENT COVERAGE
To insure consistent coverage, make sure each broadcast pattern slightly overlaps
the previous broadcast pattern as shown in figure below. The approximate broad-
cast widths for different
materials are shown in the application chart.
WARNING
Do not over apply spreading material. Follow the recommended coverage rate for
each product. Over application will lead to damage and contamination. If spread-
ing material accidentally hits or deposits too heavily, soak the area thoroughly
with a garden hose or sprinkler to prevent burning.

14
UK
SPREADING INSTRUCTIONS
CALCULATING AMOUNT OF MATERIAL NEEDED
To calculate the amount of fertilizer you will need to cover your lawn, divide the
coverage amount listed on the label by the weight of the fertilizer bag. For example
a 10LB bag of fertilizer with coverage of 10,000 square feet will distribute 1LB of
fertilizer every 1,000 square feet at full rate or 1/2LB of fertilizer every 1,000 square
feet at half rate. For pre-calculated rates see Chart A
(Example: 25LB bag with 15,000 sq. ft. coverage = 1.7LB/1,000 sq. ft.). Use Chart B
to find the closest spreader setting (Example: 1.7LB/1000 sq. ft. = Spreader Setting
of 8).
Chart A - Square Foot Coverage per Bag*
LBS/1,000 SQ FT
Weight of Bag
(LBS.)
5,000 SQ FT
COVERAGE
10,000 SQ FT
COVERAGE
15,000 SQ FT
COVERAGE
5 1.0 LB 0.5 LB 0.3 LB
10 2.0 LB 1.0 LB 0.7 LB
15 3.0 LB 1.5 LB 1.0 LB
20 4.0 LB 2.0 LB 1.3 LB
25 5.0 LB 2.5 LB 1.7 LB
30 6.0 LB 3.0 LB 2.0 LB
35 7.0 LB 3.5 LB 2.3 LB
40 8.0 LB 4.0 LB 2.7 LB
45 9.0 LB 4.5 LB 3.0 LB
50 10.0 LB 5.0 LB 3.3 LB
55 11.0 LB 5.5 LB 3.7 LB
*These are only estimates actual amounts may vary.
Chart B - Spreader Settings/Spread Widths
MULTI-
USAGES
LBS/1,000
SQ FT
SPREADER
SETTING
•
SMALL PARTICLE
SPREAD
•
MEDIUM PARTICLE
SPREAD
•
LARGE PARTICLE
SPREAD
FERTILIZER
GRASS SEEDS
ICEMELT
15 5-6 FT 6-9 FT 9-12 FT
28 5-6 FT 6-9 FT 9-12 FT
310 5-6 FT 6-9 FT 9-12 FT
413 5-6 FT 6-9 FT 9-12 FT
515 5-6 FT 6-9 FT 9-12 FT
618 5-6 FT 6-9 FT 9-12 FT
720 5-6 FT 6-9 FT 9-12 FT
823 5-6 FT 6-9 FT 9-12 FT
925 5-6 FT 6-9 FT 9-12 FT
10 28 5-6 FT 6-9 FT 9-12 FT
11 30 5-6 FT 6-9 FT 9-12 FT
NOTE: DO NOT USE SALT. Using salt in this spreader will damage the mechanism and shorten the life of the ma-
chine.

15
UK
MAINTENANCE AND STORAGE
WARNING
Improper maintenance and storage of the push spreader may void your warranty.
MAINTENANCE
• After each use clean material out of hopper.
• Rinse/dry inside and outside of the spreader after each use.
• Before operating make sure the tires have the RECOMMENDED TIRE PRES-
SURE 30 PSI.
• Periodically check all fasteners for tightness.
• Annually clean and lightly lubricate parts.
• Use a glossy enamel spray paint to touch up scratched or worn painted metal
surfaces.
• Never exceed load capacity rating of 125lbs it will damage the spreader.
IMPORTANT:
If a part needs replacement, only use parts that meet the manufacturer’s specifica-
tions.
Replacement parts that do not meet specifications may result in a safety hazard or
poor operation.
STORAGE
• Never allow material to remain in the hopper for extended periods of time.
• Before storing make sure the spreader is clean and dry for years of trouble
free service.
• Store indoors or protected area during severe weather and winter months.
SPECIFICATIONS
Load Capacity: 125lb
Spreader Type: Broadcast
Hopper Material: Polypropylene
Hopper Dimensions: 29 1/2” x 16 1/2” x 13 1/2”
Overall Dimensions: 44” x 31 1/2” x 35 1/2”
Wheel size: 15’’
Tire Pressure (PSI): 30
Unit Weight: 38lb

16
UK
PARTS DRAWING & PARTS LIST







































































 










$
$
%
%
&
&
'
'
(
(









Add 4 PCS of Flat Washer Ø16
for adjust the space of Wheel

17
UK
Ref# Description Qty Ref# Description Qty
1 Hopper 1 30 Spacer 1
2 Big Flat Washer Ø6 16 31 Fixed Crossover Tube 1
3 Hex Bolt M6x40 15 32 Plastic Cap 3
4 R Pin Ø3 1 33 Support Tube 1
5 Bearing 2 34 Hex Bolt M6x35 2
6 Fixed Adjustable Plate 1 35 Handle 1
7 Active Adjustable Plate 1 36 Handle Cover 2
8 Base for Spring 1 37 Axle Bushing 2
9 Hex Lock Nut M6 22 38 Crossover Tube 1
10 Spring 1 39 Spring Pin Ø4x30 1
11 Hex Lock Nut M8 3 40 Bracket 1
12 Flat Washer Ø8 2 41 Hex Bolt M6x20 7
13 Fixed Plate for Connecting Rod 1 42 Carriage Bolt M6x25 1
14 Impeller 1 43 Teeth Lock Washer Ø8 1
15 Wheel 2 44 Connecting Plate 1
16 Cotter Pin Ø5x35 2 45 Spacer 1
17 Flat Washer Ø16 8 46 Wing Nut M6 1
18 Screen 1 47 Adjusting Handle 1
19 Axle 1 48 Handle Cover 1
20 Inner Axle Bushing 2 49 Spring Washer Ø6 7
21 Outer Axle Bushing 2 50 Nylon Washer 1
22 Rivet Ø5x8 2 51 Shaft Support Plate 1
23 Frame Tube Assembly 1 52 Rain Cover 1
24 Pinion Gear 1 53 Drive Pin 1
25 Swivel Axle 1 54 Gear (Driver) 1
26 Screw M4x20 1 55 Shaft Support Cap 1
27 Spring Pin Ø3x16 1 56 Wheel Bushing 2
28 Solid Linkage 1 57 Hex Lock Nut M5 1
29 Hex Bolt M8x75 1 58 Hex Bolt M5x40 1

18
DE
ALLGEMEINE WARNHINWEISE
Vor der Benutzung des Schiebestreuers müssen Sie diese Anleitung vollständig gelesen und
verstanden haben.
Vor der Benutzung dieses Geräts müssen alle Sicherheits- und Warnhinweise sowie
alle Anweisungen zu Bedienung, Wartung und Lagerung gelesen und verstanden
werden. Falls der Schiebestreuer nicht ordnungsgemäß benutzt und gewartet wird,
kann dies schwere Verletzungen des Anwenders oder unbeteiligter Personen zur
Folge haben.
Warnhinweise zum Betrieb
• Befördern Sie niemals Personen sitzend oder stehend auf dem Streuer.
• Verhindern Sie, dass Kinder auf dem Streuer spielen, stehen oder auf den
Streuer klettern.
• Prüfen Sie vor der Benutzung des Streuers stets, ob dieser sich in einem ein-
wandfreien Zustand befindet.
• Ersetzen oder reparieren Sie beschädigte oder verschlissene Teile sofort.
• Prüfen Sie vor dem Gebrauch stets alle Befestigungsteile und montierten Bau-
teile und ziehen Sie sie fest.
• Überschreiten Sie niemals die maximale Nutzlast von 57 kg (125 lbs).
• Vermeiden Sie große Löcher und Gräben, wenn Sie Lasten transportieren.
• Seien Sie vorsichtig, wenn Sie an steilen Hängen arbeiten, da der Streuer um-
kippen kann.
• Fahren Sie mit dem Streuer nicht in die Nähe von Bächen, Gräben und öffentli-
chen Schnellstraßen.
• Verwenden Sie den Streuer nicht an windigen Tagen, wenn Sie Grassamen oder
Herbizide streuen.
• Gehen Sie beim Be- und Entladen des Streuers umsichtig vor.
• Ziehen Sie den Streuer niemals mit einem motorisierten Fahrzeug.
Quetsch- und Schneidgefahren
• Halten Sie bei der Nutzung des Geräts Hände und Füße von beweglichen Teilen
fern.
• Entfernen Sie Hindernisse aus dem Arbeitsbereich und halten Sie den Arbeits-
bereich stets sauber, wenn Sie das Gerät benutzen.
• Tragen Sie Sicherheitsausrüstung, Augenschutz, Handschuhe und Arbeitssti-
efel, wenn Sie den Streuer benutzen.
WARNUNG
Die in dieser Bedienungsanleitung aufgeführten Warnhinweise und Anweisungen können sich
nicht auf alle möglichen Bedingungen oder Situationen beziehen. Alle Hinweise können den um-
sichtigen und sorgfältigen Umgang mit dem diesem Produkt natürlich nicht ersetzen!
PROP 65-WARNUNG
Dieses Produkt enthält Chemikalien, die nach Kenntnissen des Bundesstaats Kalifornien (USA)
Krebs, Geburtsfehler oder andere Fortpflanzungsschäden verursachen.
Montage erforderlich
Dieses Produkt muss vor der Nutzung zusammengebaut werden. Anweisungen
hierzu finden Sie im Abschnitt „Montage“. Auf Grund des Gewichts und/oder der
Größe des Schiebestreuers sollte bei der Montage eine weitere erwachsene Person
zur Unterstützung herangezogen werden.

19
DE
WORTDEFINITIONEN GEFAHRENSYMBOLE
Dies ist das Sicherheitswarnsymbol. Es weist
Sie auf die Gefahr von Körperverletzungen
hin. Beachten Sie alle Sicherheitshinweise,
die auf dieses Symbol folgen, um Verletzun-
gen oder Lebensgefahr zu vermeiden.
GEFAHR weist auf eine unmittelbar drohende
Gefahr hin, die zum Tod oder schweren Ver-
letzungen führt, wenn sie nicht vermieden
wird.
WARNUNG weist auf eine mögliche Ge-
fahrensituation hin, die zum Tod oder
schweren Verletzungen führen kann, wenn
sie nicht vermieden wird.
ACHTUNG weist auf eine mögliche Gefahren-
situation hin, die zu moderaten bis geringen
Verletzungen führen kann, wenn sie nicht
vermieden wird.
ACHTUNG ohne das Sicherheitswarnsymbol
weist auf eine mögliche Gefahrensituation
hin, die zu Sachschäden führen kann, wenn
sie nicht vermieden wird.
DER SCHIEBESTREUER
Dieser Schiebestreuer eignet sich zum Streuen verschiedenster Materialien
(Dünger, Grassamen und Streusalz). Materialien wie Pulver, Mist, Humus, Kies und
Mulch sind auf Grund Ihrer physi-
schen Eigenschaften nicht geeignet und dürfen in diesem Streuer nicht verwendet
werden. Über-
schreiten Sie bei der Nutzung des Streuers niemals die Nennnutzlast von 57 kg (125
lbs).
Der Streuer muss mit einer Geschwindigkeit von ca. 5 km/h geschoben werden; das
ist flotte Schrittgeschwindigkeit. Bei einer geringeren oder höheren Geschwindig-
keit ändert sich das Streumuster. Streumuster und Durchsatz werden auch durch
feuchtes Streumaterial verändert. Reinigen Sie den Streuer nach jeder Benutzung
gründlich. Waschen Sie den Bereich zwischen Absperrplatte und Boden des Trich-
ters.
Technische Daten zum Streuer finden Sie in diesem Handbuch im Abschnitt „Tech-
nische Daten“.
GEFAHR
WARNUNG
ACHTUNG
ACHTUNG

20
DE
BEDIENELEMENTE UND AUSSTATTUNGSMERKMALE
Lesen Sie diese Bedienungsanleitung, bevor Sie das Gerät benutzen. Machen Sie
sich mit der Position und Funktion der Bedienelemente und Ausstattungsmerkmale
vertraut. Heben Sie diese Anleitung auf, sodass Sie ggf. jederzeit nachschlagen
können.
1. Griff – Dient zum Schieben des Streuers.
2. Durchsatzsteuerung – Steuert den Durchsatz des gestreuten Materials.
3. Trichter – Überschreiten Sie nicht die Nennnutzlast von 57 kg (125 lbs).
4. Reifen/Rad – Überschreiten Sie nicht den empfohlenen Druck von 2,1 bar (30 psi).
5. Flügelrad – Verteilt das Material gleichmäßig.
6. Stützbein – Stabilisiert Last und Streuer.
ACHTUNG
Lesen und beachten Sie alle Anweisungen zu Montage und Bedienung. Wenn die-
ses Gerät nicht einwandfrei montiert wird, kann dies schwere Verletzungen des
Anwenders oder unbeteiligter Personen oder eine Beschädigung des Geräts zur
Folge haben.
BAUTEILE UND MONTAGE DES SCHIEBESTREUERS
Nehmen Sie alle Teile aus dem Versandkarton, und inspizieren Sie die Bauteile, um
sicherzustellen, dass keine Teile fehlen, bevor Sie mit der Montage des Schiebe-
streuer beginnen (Schritte 1 bis 5).
ERFORDERLICHES WERKZEUG
• Zange (2 Stk)
• 8-mm-Schraubenschlüssel (2 Stk)
• 10-mm-Schraubenschlüssel (2 Stk)
• 13-mm-Schraubenschlüssel
• 14-mm-Schraubenschlüssel
1. 2.
3.
6.
4.
5.
