DETAILED
INSTRUCTIONS
FOR USE OF THE
ELECTRIC OVEN
GB IE MT

We thank you for your
trust and the purchase of our
appliance.
This detailed instruction manual is
supplied to make the use of this
product easier. The instructions
should allow you to learn about your
new appliance as quickly as possible.
Make sure you have received an
undamaged appliance. If you do find
transport damage, please contact the
seller from which you purchased the
appliance, or the regional warehouse
from which it was supplied. The
telephone number can be found on
the invoice or on the delivery note.
Instructions for installation and
connection are supplied on a
separate sheet.
Instructions for use are also available
at our website:
www.gorenje.com / < http://www.
gorenje.com />
Important information
Tip, note

3
CONTENTS
789074
MAINTENANCE
& CLEANING
TROUBLE-
SHOOTING
4 IMPORTANT SAFETY INSTRUCTIONS
5 Before connecting the appliance
6 THE ELECTRIC OVEN
10 Control unit
11 Technical specifications
12 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
13 STEPS OF THE COOKING PROCESS (1–4)
13 Step 1: CHOOSING THE COOKING SYSTEM
15 Step 2: CHOOSING THE SETTINGS
18 Step 3: START THE COOKING PROCESS
18 Step 4: END THE COOKING PROCESS AND SWITCHING OFF THE
OVEN
19 DESCRIPTIONS OF SYSTEMS (COOKING MODES) AND COOKING
TABLES
34 MAINTENANCE & CLEANING
35 Conventional oven cleaning
36 Using the aqua clean function to clean the oven
37 Removing and cleaning wire and telescopic extendible guides
38 Cleaning the oven cavity ceiling
39 Removing and inserting the oven door (depending on the model)
42 Removing and inserting the oven door glass pane
43 Replacing the bulb
44 TROUBLESHOOTING TABLE
45 DISPOSAL
INTRODUCTION
PREPARING THE
APPLIANCE FOR
THE FIRST USE
COOKING STEPS

4
789074
IMPORTANT SAFETY
INSTRUCTIONS
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM
FOR FUTURE REFERENCE.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
,WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating ele-
ments. Children less than 8 years of age shall be kept away un-
less continuously supervised.
WARNING: Accessible parts may become hot during use.
Young children should be kept away.
During use the appliance becomes hot. Care should be taken to
avoid touching heating elements inside the oven.
Only use the temperature probe recommended for use in this
oven.
WARNING: Ensure that the appliance is switched off before re-
placing the lamp to avoid the possibility of electric shock.
Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass/ the glass of hinged lids of the hob
(as appropriate), since they can scratch the surface, which may
result in shattering of the glass.
Do not use steam cleaners or high pressure cleaners to clean the
appliance as this may result in an electric shock.

5
789074
The appliance is intended for household
use. Do not use it for any other purpose,
such as room heating, drying of pets or
other animals, paper, fabrics, herbs etc. As
this may lead to injury or fire hazard.
The appliance may only be connected to
the power mains by an authorized service
technician or expert. Tampering with
the appliance or nonprofessional repair
thereof may result in risk of severe injury or
damage to the product.
If the power cords of other appliances
located near this appliance are caught
in the oven door, they may be damaged,
which may in turn result in a short circuit.
Therefore, keep the power cords of other
appliances at a safe distance.
Do not line the oven walls with aluminium
foil and do not place baking trays or other
cookware on the oven bottom. Aluminium
foil would prevent air circulation in the
oven, hinder the cooking process, and ruin
the enamel coating.
Oven door become very hot
duringoperation. A third glass is installed
for extra protection, reducing the
temperature of the outside surface (only
with some models).
Oven door hinges may be damaged when
under excessive load. Do not place heavy
pans on open oven door and do not lean
against open oven door when cleaning the
oven cavity. Never stand on the open oven
door and do not let children to sit on it.
Appliance operation is safe with and
without tray guides.
Make sure the vents are never covered or
obstructed in any other way.
Eventual mismatches in colour shades
between different appliances or
components within a single design
line may occur due to various factors,
such as different angles under which
the appliances are observed, different
coloured backgrounds, materials, and room
illumination.
BEFORE CONNECTING THE APPLIANCE
Carefully read the instructions for use before connecting
theappliance. Repair or any warranty claim resulting from
incorrect connection or use of the appliance shall not be covered
by the warranty.
Means for disconnection must be incorporated in the fixed wir-
ing in accordance with the wiring rules.
If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualified persons in order
to avoid a hazard (only for appliances supplied with connection
cord) .
The appliance must not be installed behind a decorative door in
order to avoid overheating.

6
THE ELECTRIC OVEN
(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON
THE MODEL)
4
3
2
1
Control unit
Oven door
Oven handle
Guides
- Cooking levels
Door switch
789074
The figure represents one of the built-in appliance models. Since the appliances for which
these instructions were drawn up may have different equipment, some functions or
equipment may be described in the manual that may not be present in your appliances.
CONTROL LIGHTS
The red light is no when the oven heaters are activated. When the selected temperature is
reached, the red light is switched off.
When a function is selected, the dial of the selected knob will be lit up. These appliances
do not have a yellow light (only with some models).
Oven lighting will be switched on automatically when the cooking system is selected.

7
WIRE GUIDES
The wire guides allow preparation of the food on four levels (please note that the levels/
guides are counted from the bottom up).
Guides 3 and 4 are intended for grilling.
TELESCOPIC PULL-OUT GUIDES
Telescopic pull-out guides may be fitted for the 2nd, 3rd, and 4th level.
Pull-out guides can be partly or fully extendible.
OVEN DOOR SWITCH
The switches deactivate oven heating and the fan when the oven door is opened during
the cooking process. When the door is closed, the switches turn the heaters back on.
COOLING FAN
The appliance is fitted with a cooling fan that cools the housing and the appliance control
panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues to operate for a short while in
order to cool the oven. (Extended cooling fan operation depends on the temperature in
the center of the oven).
789074
OVEN EQUIPMENT AND ACCESSORIES (depending on the model)
GLASS BAKING DISH is used for cooking
with all oven systems. It can also be used as
a serving tray.
The GRID is used for grilling or as support
for a pan, baking tray or baking dish with
the food.
There is a safety latch on the grid.
Therefore, lift the grid slightly at the front
when pulling it out from the oven.
The SHALLOW BAKING SHEET is used for
baking pastry and cakes.

8
789074
The DEEP BAKING TRAY is used for roasting
meat and baking moist pastry. It can also be
used as a drip tray.
Never place the deep baking tray in the
first guide during the cooking process, except
when grilling food or using the roasting spit
and you are only using the deep tray as a drip
tray.
As baking accessories heat up, their
form may change. This does not affect
their functionality and their original form
will be restored when they cool down.
The grid or the tray should always be
inserted into the groove between the two
wire profiles.
With telescopic extendible guides, first pull
out the guides of one level and place the
grid or the baking tray onto them. Then,
push them in with your hand as far as they
will go.
Close the oven door when the
telescopic guides are retracted all the way
into the oven.
2
3
4

9
789074
The appliance and some of the accessible parts tend to heat up
during cooking. Use oven mitts.
The ROTISSERIE (meat skewer) is used
for roasting meat. The set consists of a
skewer support, skewer with screws, and a
removable handle.

10
CONTROL UNIT
1COOKING SYSTEM
SELECTOR KNOB 2PROGRAM
TIMER 3TEMPERATURE KNOB 4OVEN CONTROL LIGHT
THE RED LIGHT
is no when the
oven heaters are
activated. When the
selected temperature
is reached, the red
light is switched off.
789074

11
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
The rating plate indicating the basic
information about the appliance is located
at the edge of the oven and it is visible
when the oven door is opened.
ASerial number
BCode/ID
CType
DBrand
EModel
FTechnical data
GCompliance symbols
789074

12
789074
BEFORE USING THE APPLIANCE
FOR THE FIRST TIME
Upon receiving the appliance, remove all parts, including any transport equipment, from
the oven.
Clean all accessories and utensils with warm water and regular detergent. Do not use any
abrasive cleaners.
Before using the oven for the first time, heat it with the upper and lower heater system
at 200 °C for approximately one hour. The characteristic "new appliance" scent will be
released; make sure the room is well ventilated.

13
STEPS OF THE COOKING
PROCESS (1–4)
STEP 1: CHOOSING THE COOKING SYSTEM
Rotate the knob (left and right) to select the cooking system (see
program table).
Settings can also be changed during operation.
SYSTEM DESCRIPTION SUGGESTED
TEMPERATURE °C
COOKING SYSTEMS
UPPER AND BOTTOM HEATER
The heaters in the bottom and in the ceiling of the oven
cavity will radiate heat evenly into the oven interior. Pastry or
meat can only be baked/roasted at a single height level.
200
GRILL
Only grill heater, a part of the large grill set, will operate.
This system is used for grilling a smaller amount of open
sandwiches or beer sausages, and for toasting bread.
240
LARGE GRILL
The upper heater and the grill heater will operate. The heat
is radiated directly by the grill heater installed in the oven
ceiling. To boost the heating effect, the upper heater is
activated as well.
This combination is used for grilling a smaller amount of
open sandwiches, meat or beer sausages, and for toasting
bread.
240
GRILL WITH FAN
Grill heater and the fan will operate. This combination is used
to grill meat and to roast larger chunks of meat or poultry at
a single height level. It is also appropriate for dishes au gratin
and for browning to a crispy crust.
170
HOT AIR AND BOTTOM HEATER
The bottom heater, the round heater, and the hot air fan
will operate. This is used to bake pizza, moist pastry,
fruitcakes, leavened dough and shortcrust on several levels
simultaneously.
200
HOT AIR
Round heater and the fan will operate. The fan installed
in the back wall of the oven cavity makes sure the hot air
constantly circulates around the roast or pastry. This mode
is used for roasting meat and baking pastry at several levels
simultaneously.
180
789074

14
789074
SYSTEM DESCRIPTION SUGGESTED
TEMPERATURE °C
TOP AND BOTTOM HEATER WITH FAN
Both heaters and the fan are activated. The fan allows even
circulation of hot air inside the oven. It is used for baking
pastry, for defrosting, and for drying fruit and vegetables.
180
BOTTOM HEATER AND FAN
This is used for baking leavened but low-rising pastry and for
preserving fruit and vegetables.
180
DEFROSTING
The air circulates with no heaters activated. Only the fan will
be activated. This is used to slowly thaw frozen food.
-
AQUA CLEAN
Only the bottom heater will radiate heat. Use this function to
remove stains and food residues from the oven. The program
takes 30 minutes.
70

15
Set the temperature knob to the
position when using the oven system
with the large grill and grill.
789074
STEP 2: CHOOSING THE SETTINGS
ADJUSTING THE COOKING TEMPERATURE
ELECTRONIC TIMER OPERATION
AFunction selection knob
1Oven delayed start
2End oven operation
3Minute minder
4Time display
Select the time settings by consecutively pressing the (A) knob. Selected symbol will flash
on the display. Rotate the (A) knob to set the function and press to confirm. Clock hands
will automatically move to time display. The set symbols will remain lit.
Each time you press the (A) knob, this will be confirmed by a short acoustic signal.
Press and hold the (A) knob for 2 seconds to delete the set function.
SETTING THE TIME OF DAY
If the time display symbol (4) is flashing (after connecting the appliance for the first time
or following a power failure), press the (A) knob and hold it for two seconds until the
flashing stops.
Then select the time display (4) by consecutively pressing the (A) knob. Time display will
flash when selected.
Rotate the (A) knob to set the time.
Confirm the setting by pressing the (A) knob again. If nothing is pressed, the setting will
be stored automatically after a few seconds.
OVEN OPERATION WITHOUT TIMER SETTINGS
After connecting the appliance to the power mains for the first time or after a power
supply failure, time display symbol (4) will flash.

16
789074
In order for the oven to operate, press the (A) knob and hold it for two seconds. Time
display will stop flashing.
The oven can be used without restrictions if no timer settings are made.
OVEN OPERATION WITH PROGRAM TIMER SETTINGS
Program timer can be used to program oven operation in two ways:
A) Setting the stop time
This mode allows you to set the time at which you wish the oven to stop operating. The
longest possible setting is 15 hours from the current time.
• Check if the clock is set accurately to current time.
• Select the (2) symbol by consecutively pressing the (A) knob until the symbol starts to
flash.
• Rotate the (A) knob to set stop time.
• Confirm the setting by pressing the (A) knob again. Clock hands will move to time
display. The oven stop symbol will light up.
• Switch on the oven (use the oven knobs to set the operating mode and temperature).
The oven will start t operate at the set time and stop and the selected stop time.
• When the clock reaches the selected stop time, the oven will be switched o, which will
also be indicated by an intermittent acoustic signal. The acoustic signal can be switched
o by pressing the (A) knob; otherwise, it will switch o automatically after 1 minute.
The symbol (2) will flash. To continue cooking, press the (A) knob and hold it for 2
seconds, and set a new cooking time if necessary.
B) Setting the delayed start
This mode allows you to specify the time when the oven should start to operate (cooking
start time) and the time when you wish the cooking process to stop (end time).
The start of the cooking process can be delayed by a maximum of 12 hours relative to
the current time, and the time when the cooking process is to end can be set for up to 15
hours in advance.
• Check if the clock is set accurately to current time.
• Setting the start time: Select the (1) symbol by pressing the (A) knob. Rotate the (A)
knob to set the start time and confirm it by pressing the (A) knob. The symbol for the
end of operation will start to flash (2).
• Set the stop time: Rotate the (A) knob to set the stop time and confirm it by pressing
the (A) knob.
• The clock hands will turn to clock display. Symbols (1) and (2) will be lit up.
• The timer will wait for the start of the cooking process.
• Set the oven – use the oven knobs to set the operating mode and temperature.
• The oven will start to operate at the start time, and stop operating at the stop time.
• When the clock reaches the selected stop time, the oven will be switched o, which will
also be indicated by an intermittent acoustic signal. The acoustic signal can be switched
o by pressing the (A) knob; otherwise, it will switch o automatically after 1 minute.
The symbol (2) will flash. To continue cooking, press the (A) knob and hold it for 2
seconds, and set a new cooking time if necessary.

17
789074
SETTING THE MINUTE MINDER
The clock can also be used as a minute minder which will sound an alarm upon expiry of a
set amount of time.
The minute minder can only be selected when the program timer is not programmed or in
use.
• Select the (3) symbol by consecutively pressing the (A) knob until the symbol starts to
flash.
• Rotate the (A) knob to set the time when you wish the minute minder to sound the
alarm. The longest possible setting is 3 hours.
• Confirm the setting by pressing the (A) knob again. Clock hands will automatically turn
to lock display and the symbol (3) will be lit up.
• When the time you set runs out, an intermittent acoustic signal will be sounded. The
acoustic signal can be switched o by pressing the (A) knob and holding it for 2
seconds; otherwise, it will switch o automatically after 1 minute.
DISPLAYING THE SETTING
Whenever a timer function is set, you may check it by pressing the (A) knob. The clock
hands will briefly move to the set value and then return to display the current time.
DELETING A SETTING
Delete the setting by pressing the (A) knob and holding it for 2 seconds. The symbol of
the deleted function will be switched off.

18
STEP 3: START THE COOKING PROCESS
Set the system and the temperature; then, start the cooking process.
STEP 4: END THE COOKING PROCESS AND
SWITCHING OFF THE OVEN
Turn the COOKING SYSTEM SELECTOR KNOB to position "0".
789074

19
789074
DESCRIPTIONS OF SYSTEMS
(COOKING MODES) AND
COOKING TABLES
If your desired food cannot be found in the cooking table, find information for similar
food. The information displayed applies to cooking in a single level.
An interval of suggested temperature is indicated. Start with a lower temperature setting
and increase it if you find the food is not browned sufficiently.
Cooking times are rough estimates and may vary subject to some conditions.
Only preheat the oven if required by the recipe of in the tables in this instruction manual.
Heating an empty oven consumes a lot of energy. Hence, baking several types of pastry
or several pizzas successively will save a lot of energy as the oven will already have been
preheated.
Use dark, black silicon-layered or enamel-coated baking sheets and trays as they conduct
the heat very well.
When using parchment paper, make sure it is resistant to high temperatures.
When cooking larger chunks of meat or pastry, a lot of steam will be generated inside the
oven, which in turn may condense on the oven door. This is a normal phenomenon which
will not affect the operation of the appliance. After the cooking process, wipe the door
and the door glass dry.
Switch off the oven approximately 10 minutes before the end of the cooking process to
save energy by making use of the accumulated heat.
Do not cool the food in a closed oven to prevent condensation (dew).

20
789074
Standard doneness levels and recommended final core
temperature for different types of meat
Type of food Food core temperature
(°C)
Meat colour on cross-
section, and colour of juices
BEEF
Rare 40-45 meaty red, like raw meat,
little juice
Medium rare 55-60 light red, a lot of light red
juice
Medium 65-70 pink, small amount of pale
pink juice
Well done 75-80 evenly greyish brown, little
colourless juice
VEAL
Well done 75-85 red-brown
PORK
Medium 65-70 light pink
Well done 75-85 yellow-brown
LAMB
Well done 79 grey, pinkish juice
MUTTON
Rare 45 meaty red
Medium rare 55-60 light red
Medium 65-70 pink in the middle
Well done 80 grey
GOAT MEAT
Medium 70 pale pink, pink juices
Well done 82 grey, juices only slightly pink
POULTRY
Well done 82 light grey
FISH
Well done 65-70 white to grey-brown
