Gossen MetraWatt METRAPHASE 1 User manual

Operating Instructions
METRAPHASE 1
Phase Sequence Indicator 3-348-991-37
13/4.20

2 GMC-I Messtechnik GmbH
(1) Connector sockets for phases L1 ... L3
(2) Rotary LEDs for displaying frequency and phase
sequence
(3) Phase sequence and frequency
Green arrow: Clockwise rotation,
LEDs light up green and rotate clockwise
Momentary frequency:
Indicated by LED which briefly lights up red
Dashed red arrow: Counterclockwise rotation,
LEDs light up red and rotate counterclockwise
Momentary frequency:
Indicated by LED which briefly lights up green
(4) Phase LEDs, indicate voltage at L1 ... L3
(5) Voltage value LEDs, indicate line-to-line voltage value
1
4
2
3
5
208V
120/
400V
230/
690V
400/
L3
L3
L2
L2
L1
L1
600 V CAT IV

GMC-I Messtechnik GmbH 3
GB
Meanings of Symbols on the Device
Warning concerning a point of danger
(attention: observe documentation)
Ground
Continuous, doubled or reinforced
insulation
CAT IV Maximum allowable voltage between the
connector sockets (1) and ground it is
600 V category IV.
EU conformity marking
This device may not be disposed of with house-
hold trash. Further information regarding the
WEEE mark can be accessed on the Internet at
www.gossenmetrawatt.com by entering the
search term “WEEE”.
!

4 GMC-I Messtechnik GmbH
Table of Contents
Page
1 Safety Instructions .......................................................... 5
2 Applications .................................................................... 7
2.1 Intended Use / Use for Intended Purpose ............................. 7
2.2 Use for Other than Intended Purpose .................................. 7
2.3 Liability and Guarantee ...................................................... 7
2.4 Opening the Instrument / Repairs ....................................... 7
3 Initial Startup ................................................................... 8
4 Operation ......................................................................... 8
4.1 Voltage Display .................................................................. 8
4.2 3-Pole Connection ............................................................. 9
4.3 2-Pole Connection ............................................................ 9
5 Characteristic Values, Phase Sequence Indicator ......... 11
6 CE Declaration ............................................................... 13
7 Maintenance ................................................................. 13
7.1 Battery ............................................................................ 13
7.2 Housing .......................................................................... 14
7.3 Returns and Environmentally Sound Disposal .................... 14
8 Accessories (not included) ............................................ 14
9 Repair and Replacement Parts Service
Calibration Center and Rental Instrument Service ........ 15
10 Product Support ............................................................ 15

GMC-I Messtechnik GmbH 5
GB
1 Safety Instructions
Observe this documentation, in particular all included
safety information, in order to protect yourself and others
from injury, and to prevent damage to the instrument.
• Carefully and completely read and adhere to these
operating instructions.
This document can also be accessed at http://
www.gossenmetrawatt.com. Retain this document for
future reference.
• Tests may only be performed by a qualified electrician,
or under the supervision and direction of a qualified
electrician. The user must be instructed by a qualified
electrician concerning performance and evaluation of
the tests.
• Wear suitable and appropriate personal protective
equipment (PPE) whenever working with the instru-
ment.
• Only use accessories which are included with the
instrument or listed as optional accessories.
• Carefully and completely read and adhere to the prod-
uct documentation for accessories. Retain these doc-
uments for future reference.
• The instrument may only be operated by persons who
are capable of recognizing contact hazards and taking
the appropriate safety precautions. Contact hazards
exist anywhere, where voltages of greater than
30 V RMS may occur.
• Do not work alone when performing measurements
which involve contact hazards. Be certain that a sec-
ond person is present.
• If the device doesn’t function flawlessly, remove it from
operation and secure it against inadvertent use.
• The device may only be used as long as it’s in good
working order.
Inspect the housing before use. Pay particular atten-
tion to any possible cracks and the insulation around
the sockets.
Damaged components must be replaced immediately.
• Accessories and cables may only be used as long as
they’re fully intact.
Inspect all cables and accessories before use. Pay
particular attention to damaged housings, interrupted
insulation or kinked cables.
Damaged components must be replaced immediately.
• Do not use the instrument after long periods of storage
under unfavorable conditions (e.g. humidity, dust or
extreme temperature).
• Do not use the instrument after extraordinary stressing
due to transport.
• Use the instrument only within the specified ambient
conditions.
• Use the instrument only in accordance with the speci-
fied protection class (IP code).

6 GMC-I Messtechnik GmbH
• The instrument must not be exposed to direct sunlight.
• The instrument and the included accessories may only
be used for the measurements described here and in
the operating instructions for the instrument.
• Only use the instrument and the accessories within the
specified measuring category.
• Do not perform any measurements in electrical circuits
with corona discharge (high-voltage).
• Do not use the instrument if the battery compartment
cover has been removed. Touch contact with danger-
ous voltage is otherwise possible.

GMC-I Messtechnik GmbH 7
GB
2 Applications
2.1 Intended Use / Use for Intended Purpose
The instrument is a phase sequence indicator with elec-
tronic rotary dial, frequency display and nominal line volt-
age display.
Note!
It’s not a voltmeter in the usual sense of the word –
it only indicates voltage within the specified ranges.
Safety of the operator, as well as that of the instrument, is
only assured when it’s used for its intended purpose.
2.2 Use for Other than Intended Purpose
Use of the instrument for any purposes other than those
described in these operating instructions is contrary to use
for intended purpose.
2.3 Liability and Guarantee
GMC-I Messtechnik GmbH assumes no liability for prop-
erty damage, personal injury or consequential damage
resulting from improper or incorrect use of the product, in
particular due to failure to observe the product documen-
tation. Furthermore, all guarantee claims are rendered null
and void in such cases.
2.4 Opening the Instrument / Repairs
The instrument may only be opened by authorized, trained
personnel in order to ensure flawless, safe operation and to
assure that the guarantee isn’t rendered null and void.
Even original replacement parts may only be installed by
authorized, trained personnel.
Unauthorized modifications to the instrument are prohib-
ited.
If it can be ascertained that the instrument has been
opened by unauthorized personnel, no guarantee claims
can be honored by the manufacturer with regard to per-
sonal safety, measuring accuracy, compliance with appli-
cable safety measures or any consequential damages.

8 GMC-I Messtechnik GmbH
3InitialStartup
Batteries
The phase sequence indicator is shipped ready to use with
four AA batteries. Before initial startup, be sure to read
section 7.1, “Battery”.
Battery Test
If none of the LEDs light up after applying voltage, or if
they’re very dim, the batteries need to be replaced.
Switching the Instrument On Automatically
The instrument is switched on automatically when a volt-
age of at least 100 V is applied to 2 measuring sockets.
Automatic Shutdown
The instrument is switched off automatically when voltage
is no longer applied. Battery service life is extended in this
way.
4Operation
Attention!
!
Measurements per DIN EN 61010-031 may only
be performed in environments in accordance with
measuring categories III and IV with the safety cap
attached to the test probe at the end of the mea-
surement cable.
Note!
In order to establish contact inside 4 mm sockets,
the safety caps have to be removed by prying open
the snap fastener with a pointed object (e.g. the
other test probe).
Note!
The phase sequence indicator does not include
any fuses!
4.1 Voltage Display
Voltage is displayed by means of 3 red LEDs (5) which are
allocated to the respective nominal line voltages. The high-
est voltage which occurs within the circuit between two
phases is always detected.
Voltage is displayed for nominal voltages 120 V/208 V,
230 V/400 V and 400 V/690 V.
Missing or Unconnected Phase
If one of the phases isn’t connected to the phase
sequence indicator, or if it isn’t included in the wiring, its
potential is too small relative to the artificial neutral point.
The corresponding phase LED does not light up in this
case. However, the voltage value LED lights up in accor-
dance with line-to-line voltage.

GMC-I Messtechnik GmbH 9
GB
Special case: If the phase is missing at the L1 connector
socket, the voltage value LED indicates the next lower volt-
age because in this case the instrument no longer has an
internal reference point.
Attention!
!
The L1 socket on the METRAPHASE 1
must always be contacted first
in order to prevent erroneous measurements.
4.2 3-Pole Connection
Symmetrical Clockwise Rotation
If symmetrical clockwise rotation is measured, phase LEDs
L1, L2 and L3 are continuously lit up and an illuminated
green spot (rotary LED) rotates in the clockwise direction
around the display loop (approx. 30 RPM).
Symmetrical Counterclockwise Rotation
In the case of symmetrical counterclockwise rotation,
phase LEDs L1 through L3 light up as well, but color and
direction of the rotating spot are changed: it rotates in the
counterclockwise direction and lights up red.
Frequency Display
In the case of clockwise rotation, the LED assigned to the
momentary frequency briefly lights up red, as soon as the
illuminated rotating spot passes its position. In the case of
counterclockwise rotation, the corresponding LED lights
up green.
Instrument Sockets Connected to N or PE
If one of the sockets is connected to N or PE, the LED for
the incorrectly connected phase doesn’t light up. Phase
sequence indication is the same as for clockwise or coun-
terclockwise rotation.
Incorrect Wiring
If wiring has not been completed correctly, e.g. 2 x L1,
indefinite displays can be expected.
4.3 2-Pole Connection
ABC

10 GMC-I Messtechnik GmbH
Phase sequence can also be determined with just 2 con-
nector cables if line frequency is 50 or 60 Hz:
1 Contact phase L1 first via connector socket L1 and
then connect phase L2 via connector socket L2 (see
figure A).
Phase LEDs L1 and L2, as well as the corresponding
voltage value LED, light up red. The two LEDs for 100
and 400 Hz also light up. This indicates that the instru-
ment has synchronized itself to phases L1 and L2.
2 Disconnect socket L2 from phase L2 (see figure B).
The two LEDs for 50 and 200 Hz light up during this
standby mode.
3
Now connect phase L3 via the L2 socket (see figure C).
Phase LEDs L1 and L3 light up red. L2 is generated in-
ternally. Phase sequence and line voltage value can be
read from the display.
Note!
Changing from L2 to L3 must be completed within
approximately two seconds. If this duration is
exceeded, the instrument is no longer able to
maintain synchronization with the mains. The 60,
100, 300 and 400 Hz LEDs light up simultaneously
to indicate that this is the case. The 100 and
400 Hz LEDs then light up, in order to indicate that
2-pole measurement has been restarted. The
same display sequence is used in the event that
the same phase is contacted again erroneously
instead of changing from one phase to the other.

GMC-I Messtechnik GmbH 11
GB
5 Characteristic Values, Phase Sequence Indicator
Line Frequency
1< 50 Hz/> 400 Hz – both LEDs active
Overall frequency range 15 ... 410 Hz
Overall voltage range 100 ... 690 V
Line Voltage, 3 Phases ~
Phase Sequence
Nominal
Frequency Display Range Tolerance Range Display
50 Hz 149.4 ... 50.7 Hz 49.2 ... 50.9 Hz 50 Hz
– LED active
— 51.1 ... 57.9 Hz 50.9 ... 58.1 Hz 50 Hz and60 Hz
– LED active
60 Hz 58.3 ... 61.0 Hz 58.1 ... 61.2 Hz 60 Hz
– LED active
— 61.4 ... 97.3 Hz 61.2 ... 97.5 Hz 60 Hz and100 Hz
– LED active
100 Hz 97.7 ... 102.8 Hz 97.5 ... 103 Hz 100 Hz
– LED active
— 103.2 ... 195 Hz 103 ... 195.2 Hz 100 Hz and200 Hz
– LED active
200 Hz 195.4 ... 205.6 Hz 195.2 ... 205.8 Hz 200 Hz
– LED active
— 206 ... 298.6 Hz 205.8 ... 298.8 Hz 200 Hz and300 Hz
– LED active
300 Hz 299 ... 303.4 Hz 298.8 ... 303.6 Hz 300 Hz
– LED active
— 303.8 ... 395.3 Hz 303.6 ... 395.5 Hz 300 Hz and400 Hz
– LED active
400 Hz 1395.7 ... 405.8 Hz 395.5 ... 406 Hz 400 Hz
– LED active
Nominal Line Voltage,
LED Display
Corresponding
L-L Voltage
Corresponding
L-N Voltage
120/208V 180 ... 300 V 104 ... 173 V
230/400V 360 ... 470 V 208 ... 271 V
400/690V 530 ... 800 V 306 ... 462 V
Direction Phase
Sequence Phase LEDs Rotary LEDs
Clockwise L1 - L2 - L3 L1, L2, L3 light
up
Green LED
rotates clockwise
Counterclock-
wise L3 - L2 - L1 L1, L2, L3 light up
Red LED
rotates counterclockwise
Asymmetrical
rotary field Lx - N/PE - Lx
Connection
to N/PE,
doesn’t light up
Green or red LED
rotates clockwise or coun-
terclockwise
depending on connection
One missing
phase Lx - X - Lx
Missing phase
doesn’t light up
but the other 2
do
—

12 GMC-I Messtechnik GmbH
Reference Conditions
Ambient temperature +23 C 2K
Relative humidity 40 ... 60%
Battery voltage 4.5 V 0.25 V
Line voltage 230/400 V 0.5%
Line Frequency 50 Hz 0.1 Hz
Line voltage waveform Sine, deviation between TRMS
and rectified value < 1%
Ambient Conditions
Storage temperature –25 C ... +75 C
Operating temperature –10 C ... +50 C
Relative humidity: Max. 75%
no condensation allowed
Elevation To 2000 m
Power Supply
Batteries 4 ea. AA, IEC LR6 alkaline
manganese
Battery voltage 4 V ... 6 V
Service life Approx. 100 hours
Electrical Safety
Protection category II per DIN EN 61010-1
Measuring category IV
Operating voltage 600 V
Pollution degree 2
Test voltage 5.55 kV
Electromagnetic Compatibility
Interference emission DIN EN 61326-1, class B
Interference immunity DIN EN 61326-1
Mechanical Design
Protection IP 40 per DIN VDE 0470, part 1 /
DINEN60529
Table Excerpt Regarding
Significance of IP Codes
Dimensions 84 x 195 x 35 mm
Weight Approx. 0.3 kg with batteries,
without rubber holster
Relevant Standards
The battery tester has been manufactured and tested in
accordance with the following safety regulations:
IP XY
(1st digit X)
Protection against for-
eign object ingress
IP XY
(2
nd
digit Y)
Protection against
ingress by water
41.0 mm 0 Not protected
DIN EN 61010-1/
VDE 0411-1
Safety requirements for electrical equipment for
measurement, control and laboratory use
DIN EN 61557-7/
VDE 0413, part 7 Phase sequence indicators
DIN EN 60 529
VDE 0470, part 1
Test instruments and test procedures
Degrees of protection provided by enclosures (IP code)

GMC-I Messtechnik GmbH 13
GB
6CEDeclaration
The instrument fulfills all requirements of applicable EU
directives and national regulations. We confirm this with
the CE mark.
The relevant declaration of conformity can be obtained
from GMC-I Messtechnik GmbH.
7 Maintenance
7.1 Battery
Make sure that no battery leakage has occurred before ini-
tial start-up, and after long periods of storage. This inspec-
tion should be repeated at regular intervals.
If battery leakage has occurred, carefully and completely
clean the electrolyte from the instrument with a damp cloth
and replace the batteries before using the instrument.
If none of the LEDs light up after applying voltage, or if
they’re very dim, the batteries need to be replaced.
The instrument requires four 1.5 V batteries in accordance
with IEC or four equivalent rechargeable batteries.
Replacing the Batteries
Attention!
!
When the instrument is opened, voltage conduct-
ing parts may be exposed.
Disconnect the instrument from the measuring cir-
cuit and the device under test before opening the
instrument in order to replace the batteries.
Attention!
!
Only the included (rechargeable) batteries or those
specified in the technical data (see section 5 on
page 11) may be inserted and used.
Set the instrument face down onto a suitable working sur-
face, loosen the two screws at the back and lift off the
housing base, beginning at the position where the screws
are located. The housing top and housing base are held
together with the help of snap hooks on the opposite side.
Replace the batteries in the battery compartment with four
new batteries.
Set the housing base back into place. Start on the side
with the snap hooks and make sure they snap into place
correctly.
Secure the housing base with the two screws.
Please dispose of depleted batteries in accordance with
environmental protection regulations, e.g. at a designated
collection point (see section 7.3 on page 14).
DIN EN 61326-1
VDE 0843-20-1
Electrical equipment for measurement, control and labora-
tory use – EMC requirements – Part 1: General require-
ments

14 GMC-I Messtechnik GmbH
7.2 Housing
No special maintenance is required for the housing. Keep
outside surfaces clean. Use a slightly dampened cloth for
cleaning.
Avoid the use of cleansers, abrasives or solvents.
7.3 Returns and Environmentally Sound Disposal
The instrument is a category 9 product (monitoring and
control instrument) in accordance with ElektroG (German
electrical and electronic device law). This device is subject
to the WEEE directive. We also draw attention to the fact
that in this regard, the current status can be found on the
Internet at www.gossenmetrawatt.com by entering the
search term WEEE.
We identify our electrical and electronic devices in
accordance with WEEE 2012/19EU and ElektroG
using the symbol shown at the right per
DIN EN 50419.
These devices may not be disposed of with household
trash. Please contact our service department regarding the
return of old devices.
If the batteries or rechargeable batteries used in your instru-
ment or accessory product are depleted, they must be dis-
posed of properly in accordance with valid national regula-
tions.
Batteries may contain pollutants and heavy metals such as
lead (Pb), cadmium (Cd) and mercury (Hg).
The symbol at the right indicates that batteries
must not be disposed of with household trash,
and must be brought to a designated collection
point.
8 Accessories (not included)
VARIO Plug Adapter Set (article no. Z500A)
Three self-retaining
test probes with touch
protection for the
connection of mea-
surement cables with
4 mm banana plugs,
or with touch pro-
tected plugs for sock-
ets with an opening of
3.5 mm to 12 mm,
e.g. CEE or Perilex
sockets etc.
For example, the test
probes also fit the square PE jacks on Perilex sockets.
Maximum permissible operating voltage: 600 V per
DIN EN 61010.
Pb Cd Hg

GMC-I Messtechnik GmbH 15
GB
9 Repair and Replacement Parts Service
Calibration Center and Rental Instrument Service
If required please contact:
GMC-I Service GmbH
Service Center
Beuthener Str. 41
D-90471 Nürnberg, Germany
Phone: [phone]
Fax: [phone]
e-mail [email protected]
www.gmci-service.com
This address is only valid in Germany.
Please contact our representatives or subsidiaries for
service in other countries.
10 Product Support
If required please contact:
GMC-I Messtechnik GmbH
Product Support Hotline
Phone: [phone]
Fax: [phone]
e-mail: [email protected]

© GMC-I Messtechnik GmbH
Edited in Germany Subject to change without notice / Errors excepted A PDF
version is available on the Internet
All trademarks, registered trademarks, logos, product names, and company
names are property of their respective owners.
GMC-I Messtechnik GmbH
Südwestpark 15
D-90449 Nürnberg, Germany
Phone: [phone]
Fax: [phone]
e-mail [email protected]
www.gossenmetrawatt.com
