Gourmia GPC 600 User manual

01
When using electrical appliances, basic safety precautions should always be followed.
1. This product is for household use only. Do not use outdoors.
2. Do not use pressure cooker for other than intended use.
3. Do not place the unit on or near a hot gas or electric burner, or in a heated oven.
4. Do not operate the unit near water or fire. Do not expose the unit to direct sunlight. Keep out
of reach of children.
5. Do not operate the unit on an unstable surface. Never operate the unit on or near flammable
materials, such as newspapers or paper plates.
6. Close supervision is necessary when the pressure cooker is used by or near children.
7. To protect against electrical shock, do not immerse cord, plugs, or appliance in water or other
liquid.
8. Be sure that handles are assembled and fastened properly before each use. Cracked, broken or
charred handles should be replaced.
9. In the event of a damaged cord, plug, or product malfunction, refrain from use and return the
device to the nearest service center for examination or repair.
10. Never use unauthorized accessories or replacement parts, since they may cause electrical
shock or burn injuries.
11. Never place the cord on or near hot surface or flammable sources and adequately check for
12. Caution: to reduce the risk of electrical shock, cook only in the provided removable container
(cooking pot).
13. Prior to each use: check the anti block shield, float valve, and exhaust valve for obstruction.
Wipe the heating plate and the inner pots surface and be sure the exhaust valve is in the
correct location. Be sure to check the pressur release devices for clogging incidences prior
IMPORTANT SAFEGUARDS
proper wire placement to avoid trip and fall accidents.
to each use and refrain from covering pressure valves.

17. Be aware that certain food, such as applesauce, cranberries, pearl barley, oatmeal or other
cereals, split peas, noodles, macaroni, rhubarb, or spaghetti can foam, froth, sputter , and
clog the pressure release device. (steam vents). These foods should only be cooked in a
pressure cooker with caution with the inner pot never more than 1/2 full and using natural
release.
18. Never fill the unit over MAX level (2/3 full). When cooking foods that expand during cooking,
such as rice or dried vegetables, do not fill the unit above the halfway point. Overfilling may
cause a risk of clogging the vent pipe and developing excess pressure. Please see
“Cooking Preparation”.
19. This appliance cooks under pressure. Improper use may result in scalding injury. Be sure
unit is properly closed before operating. Please see “Cooking Preparation”.
20. Never deep fry or pressure fry in the unit with oil. It is dangerous and may cause a fire or
serious damage.
21. Do not move this product or force to remove the lid when the unit is in operation.
22. Extreme caution must be used when moving the unit containing hot oil or other hot liquids.
23. To avoid scalding, never place your hands or face over the exhuast/ float valves during use.
24. After cooking, use extreme caution when removing the lid. Always open the lid away from you
to avoid skin contact with any heat or steam. Serious burns can result from stream inside the
unit.
25. When opening the lid after cooking, do not touch the inner pot.
26. Do not open the pressure cooker until the unit has cooled and all internal pressure has been
released. If the handles are difficult to push apart, this indicates that the cooker is still
pressurized-do not force it open. Any pressure in the cooker can be hazardous. Please see
“Cooking Preparation”.
27. To disconnect, turn the control setting off and remove from the wall outlet.
28. Always unplug from outlet when not in use, before removing parts and cleaning. Allow to cool
before putting on or taking off parts, and before cleaning.
29. A short power supply cord is provided to reduce the hazards resulting from entanglement and
tripping. An extension cord may be used if care is exercised in its use. If an extension cord is
used, the electrical rating of the cord must be at least 20 amps and 120 volts. The extension
cord must be arranged so that it will not drape over edge of table or counter where it can be
pulled by children or tripped over accidentally. This appliance has a fitted plug. Do not attempt
to modify the plug in any way.
SAVE THESE INSTRUCTIONS
02
IMPORTANT SAFEGUARDS
This appliance has a polarized plug (one blade is wider than the other). As a safety feature,
this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat
this safety feature.

Pow er W orking
pressure
M odel Pow er Supply Volum e C alibero
f
innerpot
W arm
Tem perature
A ccessories
Specifications
1000W 70kPa 22cm 60°C80°C
120V~60Hz
GPC 400
Manual
RiceScoop Soup Scoop Measuring Cup
Handle cover
Cover
Exhaust valve
Float valve
Anti-block shield
Gasket
Inside of cover
Gasket ring
of float valve
Housing
Base Rice paddle shelf
Control panel
Exterior pot
Handle
Inner pot
P ro d u c t Dia g ra m
S tru c tu re dia g ra m
of floa t va lv e
M e th o d of us in g
s c o o p ho ld e r
Warm tip:
1.Prior to each use,
inspect the float valve's
anti block shield and
gasket for optimal
2. Before affixing the inner
pot to the outer pot,
remove debris and
water from both.
3. Lift the cooker handle
when moving the device.
4. Wipe the outer casing
with a soft cloth if it
gets wet.
03
QQQqqqq4 Qq qt
Q
mounting.

Cooking Preparation
Open the cover correctly
Remove the stainless steel inner pot,
proceed with placing food and water within.
Check whether parts on the cover are
mounted properly
1
2
Check the float valve and exhaust valve for
obstruction, and confirm whether such parts as
gasket and anti-block shield are installed properly.
Put the inner pot in the electric pressure cooker
4
3
Total amount of food and water shall not exceed the
MAX level of inner pot height.
6Proper positioning of the exhaust valve
5Close the cover completely
“▼”
Release Position
05
Hold the cover handle in a counter clockwise rotation
of approximately 30' until the cover marking
aligns with the outer casing's 'open' marking. Then lift the cover.
Before insertion, remove any foreign objects or water
droplets from the inner pot surfaces. After insertion,
rotate the inner pot slightly to ensure
adequate contact between the inner pot and heating
plate.
“▼”
Hold the cover handle in a clockwise rotation of
approximately 30s until the cover marking
aligns with the outer casings close marker.
Align the exhaust valves handle with the sealing
icon to maintain airtight cooking conditions.
When exhaust specs are required, align the exhaust
valves small handle with the icon until an indication
shows that the cooker is in the exhaust position.
When in sealing zone, inspect whether the float valve
has fallen, as it does prior to heating.

1. Disconnects the power or take off the power plug.
2. Exhaust method
A. Quick opening method
Slide the exhaust valve to the exhaust position until the float valve falls. (for non-fluid food)
Allow the pressure cooker to cool naturally until the float valve falls. (for non-fluid food)
B. General opening method
Have the pressure cooker to cool naturally, until the float valve falls.
3. Open the cover
Hold the cover handle firmly, turn the cover clockwise to the spacing edge, and pull up the cover.
Do not open the cover until pressure inside the pot is released adequately .
Never pull out the exhaust valve when it is exhausting.
For fluid foods (porridge and sticky liquid), do not slide the exhaust valve for exhaust when
cooking is just finished, and otherwise the food will eject from the exhaust valve core. Be sure
to disconnect the power supply, have the unit cool naturally or put a wet towel around the cover
to speed up cooling until the float falls, and finally open the cover.
When large quantity food cooked, do not exhaust immediately after cooking. It is recommended
to open the cover and consume food once it is been in keep warm mode for some time.
Function Selection
General Functions
1. Finish cooking preparation according to Page 5
2. Switch on
The nixie tube flashes and displays a red horizontal
line “---”, indicating that the electric pressure cooker
has entered preparation state.
3. Select a required function level
5. After cooking, enter the warm-keep state automatically
Function key
Rice Yogurt Meat/Poultry
Soup
Bean/tendons
Multigrain
Cooking time (min) About 35 About 55 About 360 About 45 About 45
Within 10s, you can re-select preset time and function level, and finally confirm that the electric pressure
cooker will start work in 10s after selection.
The red horizontal line “---” on the display screen is bright, indicating that the electric pressure cooker has
entered working state.
During the operation, you can cancel current working state and return to standby state by pressing the
“Keep Warm/Cancel” key.
After cooking, a corresponding function indicator goes out, the warm indicator illuminates ,
the display screen shows “0.0”, and gives out the prompt sound (10 beeps), with the electric
pressure cooker going into warm state.
In standby mode, press the “Keep Warm/Cancel” key, the warm indicator illuminates , and gives
out the prompt sound (1 beep), indicating that the electric pressure cooker goes into warm state.
Once a function key is pressed, the indicator of a corresponding
function level will illuminate (red);
The rice congee function and cake function are only applicable
to products with such function.
Cooking time varies with different function level. The bigger the
food amount, the longer the cooking time. The cooking times listed in the table below are only for reference
(e.g. food amount + water = 8 scales): Cooking time = heating time + holdup time
Warm Tips:
Safe Cover Opening
About 40
06
4. Select a function and within 10 seconds the cooker will perform the function corresponding to the selection
During any operational mode, press "keep
warm/ cancel" to return to standby mode.
A"cluck" sound during use is not indicative
of a malfunction.
When cooking low amounts of food, removing
the cover may result in suction of the inner pot.
Manually shift the inner casing to remove it

1. Finish cooking preparation according to Page 5
2. Select a corresponding function level
3. Select adjust by pressing “Adjust” key
4. After cooking, the unit will automatically revert to its keep warm state.



When any function key is pressed after preparation, a corresponding function indicator
illuminates, and the pressure cooker will perform the cooking procedure of the corresponding
function level. Adjust default is “Normal” level.
 Once a function level is selected, you can also select another function level within 10s, and the
pressure cooker will perform the cooking procedure of the finally selected function level.
 If selection of another function is impossible after the pressure cooker enters working state, you
can cancel the operation by pressing the “Keep Warm/Cancel” key for selection.
After the “Adjust” key is pressed continuously, the screen displays Fragrant, Standard and Full
cyclically. when one Adjust is selected, corresponding text appears on the screen.“soup”
“Congee” “Meat/Chicken” “Bean/Tendons” have Adjust function.
After cooking, the warm indicator illuminates and the unit will go into warm-keeping state.
Prolonged warm-keeping is not recommended.
Cooking Examples
Adjust Selection
Timer Function
1. Finish cooking preparation according to Page 5
2. Select a corresponding function level
When any function key is pressed after preparation, a corresponding function indicator
illuminates; you can also select another function level within 10s. (To cancel the
operation, press the “Keep Warm Cancel” key)
3.Press “Timer” key to Set end time of cooking
This product is equipped with 24 hour default function, to be operated as indicated.
4. After cooking, the unit enters the warm state automatically
Within 10s after function selection, press the “Timer” key to set a cooking end time.
Once the key is pressed, the screen displays “Timer End Time 2.0 ”, To press the “+”
or “-” key to adjust the appointed time.
Timer time shall not be more than 24h, if so, it will return to “2” .
After completion of seting, the time displayed on the screen means working end time of
pressure cooker. (to cancel the operation, press the “Keep Warm Cancel” key)
07
After preset cooking time is complete, the warm indicator will illuminate and enter a keep
warm state. Prolonged keep warm status is not recommended.

Store it in a cool and dry place;
Pay attention to shelf life of rice;
Odor may occur if rice is retained for
a long time;
Do not buy too much rice at one time.
Tip: method of rice storage
One measuring cup of rice is about 150g, a portion
served for one person;
It is recommended not to wash rice in the inner pot;
Correct methods of using
the measuring cup:
After putting in, rotate the inner pot lightly from left
to right to ensure full contact between inner pot and
heating plate.
Cooking Examples
09
Cooking
Rice
Put the cleaned rice into the interior pot and fill
it with water to a corresponding water level;
The scale line inside the inner pot means the
one for cooking reference water level;
Example: to cook 2 cups of rice, add water to
the scale line “2”;
Water quantity can vary with rice category and
hardness of rice, but never have water to exceed
the MAX level inside the inner pot.
At the moment, the “Rice” function indicator
illuminates, with other function indicators going
out.
The electric pressure cooker begins cooking
within 10s after selection.
Cooking time is around 35min, but the time may
slightly vary with rice amount or rice quality;
After cooking, the rice is recommended to be
served after 1-3 min warm-keep, but long time
warm-keep is not recommended to avoid
influence on rice quality.
Measure the rice portion with a measuring
cup and clean it
Add water to corresponding water level
Replace the wiped inner pot to the cooker body
According to Page 5, put the cover in place and
switch on
Press the “Rice” key
After cooking, the unit enters warm state
automatically
Open the cover according to “Safe Cover
Opening” on Page 5

Cautions
CAUTIONS
A socket shall be used independently.
Using other cover during heating is strictly prohibited
Stop the use of a damaged power cord
Do not insert foreign object
Keep away from children
No modifications Do not wash or immerse it in water
As this may cause electric
shock and short circuit.
Warning on cover lifting Regular inspection
Do not insert foreign objects
such as metal scraps and
needles into a gap.
May cause electric shock or
unusual action.
It is strictly prohibited to use
non-brand cover during
heating.
May cause electric shock or
other serious injury.
It is prohibited to modify or
repair the unit by a non-
technician.
As this may cause fire or
electric shock.
Please send it to a
designated service agency
for repair or replacement of
spare parts.
When the electric pressure cooker does not work,
there is no pressure inside the pot and the float
valve falls down.
When the unit works, pressure inside is on the
rise, and so is the float valve. Do not open the
cover forcibly until pressure is completely
discharged.
Otherwise scald or other injury may be caused.
Please use an individual
socket with an earthed wire of
more than 10A rated current;
Joint use of the same socket
with other appliance may
cause unusual heat and fire.
The damaged power cord
must be replaced with a
special flexible cord or a
special component bought
from the manufacturer or
service agency.
Place it away from children.
This may cause burn or
electric shock.
Carry out regular inspection
of the exhaust valve and
anti-block shield to make
sure that they are
unobstructed.
Do not add any heavy object
to the exhaust valve, neither
replace it with other objects.
Please use a 120V-60Hz socket
Fire or electric shock may
occur if 120V AC-60Hz
is not used.
AC 120V
11

Cautions
CAUTIONS
Do not insert and pull off
the plug with wet hand
May cause electric
shock.
When removing the plug, be
sure to pinch the plug handle
When not in use, remove plug from socket.
May cause creepage,
fire or malfunction.
During operation, never move your
hand to the exhaust valve vent
Never touch the cover during operation
Cooking amount shall not
exceed MAX level
Use only the special inner pot Do not place the inner pot on
other appliance for heating
When moving the product,
please hold the cooker handle
Never use the product in
following places
Unstable place.
Places near water or fire.
Adjacent to walls and furniture.
Places exposed to direct sunshine or oil splash.
When pulling out the plug,
be sure to pinch the plug
handle;
Never pull the power cord
as this may cause damage
to the power cord and
result in electric shock or
short circuit.
When cooking, avoid scalding
by your hand or face
exposure over the exhaust
valve.
In cooking, do not cover
the exhaust valve vent with
a rag.
Food to be cooked should
not exceed the MAX level,
and otherwise the food
may be half-cooked or
failure may happen.
When the unit is operating,
the cover has a higher
temperature, so never
touch it with your hand;
This may cause scalding.
12
When cooking, avoid scalding
Remove any foreign objects
lodged between the inner
pot and heating plate before
using.
Lodged parts may cause
overheating or inhibit normal
operation.
To avoid deformation or
failure of the inner pot,
always use the supplied
inner pot included with
your device.
To prevent cover falls, never
directly lift the cover handle
when moving the unit.

Cleaning
Circuit Diagram
1.After each use, give timely cleaning of the product.
2.Before cleaning, unplug the unit and carry out cleaning and
maintenance after the product cools down completely.
3.Take out the cover and inner pot, wash them with a detergent, rinse
with fresh water and then wipe them dry with a soft c loth.
4.Using clear water, clean the cover, including the gasket, exhaust
valve, anti-block shield, exhaust valve core and float valve, and
wipe it clean with a rag. After cleaning install it on the cover
correctly .
5.Clean the cooker body with a rag. Do not immerse the cooker in
water or wash with splashing water.
Cooking plate
Socket
Connecting line
Display panel
Detective switch
Temperature sensor
Temperature fuse
Power board
Pressure
switch
120V~60Hz
N
L
N
L
Power panel
power supply
13

Troubleshooting
The following unusual cases are not completely caused by mechanical failures.
Please carry out a careful examination before sending the unit for repair.
S/N Problem Possible Reason Solution
Difficult to close the cover
Push rod jammed by float valve
Difficult to open the cover
Pressure exists inside the cooker
Float valve fails to fall after steam
release
Press the float valve lightly with
chopsticks
Open the cover after the pressure
lowers down
Leakage from cover
No gasket Put the gasket according to the
requirement
Food remnants attached to gasket
Push the push rod lightly with
a hand
Gasket not positioned well Locate the gasket well
Replace the gasket ring
Cover not closed firmly Close the cover again
Gasket worn
Clean the gasket ring
Leakage from float valve
Food remnants attached to float
valve gasket ring Clean the float valve gasket
Float valve gasket ring worn Replace the float valve gasket
Float valve unable to rise
Too little food and water
inside pot
Send it to the service agency for
inspection
Put food and water according to
the rule
Little leakage from cover or
exhaust valve
Exhaustion from exhaust
valve does not stop
Exhaust valve not in sealing
position
Pressure control fails
Slide the exhaust valve to the
sealing position
Send it to the service agency
for maintenance
Lamp not bright after power on Bad contact with socket Please inspect the socket
All
lamps
flash
C1 appears on nixie tube
C2 appears on nixie tube
C5 appears on nixie tube
C6 appears on nixie tube
Sensor fails Send it to the service agency
for inspection
Temperature is too high because
there is no water inside the inner pot
Add water as required
Temperature is too high because
inner pot is not placed Put the inner pot properly
Pressure switch fails Send it to the service agency
for inspection
Rice half cooked/too hard
Too little water added Add more water
Cover closed prematurely After the time is up, release steam
and open the cover in 5 minutes
Rice too soft Too much water added Reduce water level
14

9H06
E214884
