Graco Line Driver 233725 Operating instructions

309404JREPAIR
Line Driverr
Model 233725
U.S. Patent Number 6,883,633
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
10 mph (16 kph) Maximum Operating Speed
Related Manuals
Operation 309402. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hitch Receiver Kit 245321 309405. . . . . . . . . . . . . . . . .
Battery Kit 245343 309406. . . . . . . . . . . . . . . . . . . . . . . .
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Repair Information 3. . . . . . . . . . . . . . . . . . . . . .
Maintenance 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission and Brake Adjustments 5. . . . . . . . . . . . .
Tire and Wheel Motors 6. . . . . . . . . . . . . . . . . . . . . . . . . .
Battery/Light Regulator 7. . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Variable Displacement Pump 9. . . . . . . . . . . . . . . . . . . . .
Parts Drawing 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Number 15. . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Warranty 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 2001, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
ti650a

3094042
WARNING
FIRE AND EXPLOSION HAZARD
Fuel spilled on a hot surface can
cause a fire or explosion and serious
bodily injury or death. Shut off engine
and let engine cool before filling tank.
HOT SURFACE HAZARD
Engine and drive housing may be very
hot during operation and could burn skin
if touched.
MOVING VEHICLE HAZARD
Careless and reckless behavior causes
accidents. Falling from vehicle, running into
people or objects, or being struck by other
vehicles may result in serious injury or
death.
DUse appropriate traffic control in all traffic
areas
DDo not step on forward/reverse pedals
DMake turns slowly
DDo not carry passengers
DDo not operate on slopes greater than 15_
DLoss of traction may occur going downhill
DReference Manual on Uniform Traffic
Control Devices (MUTCD), U.S. Depart-
ment of Transportation, Federal Highway
Administration or local highway and trans-
portation regulations for proper traffic
control.
DDo not make turns greater than 45_
DDo not tow
DUse with line striping equipment only
TOXIC FUMES HAZARD
Engine produces carbon monoxide which is a
deadly gas. Do not operate in an enclosed
area. Breathing carbon monoxide may result
in serious injury or death.
FIRE AND EXPLOSION HAZARD
Fuel spilled on a hot surface can
cause a fire or explosion and serious
bodily injury or death. Shut off engine
and let engine cool before filling tank.
HOT SURFACE HAZARD
Engine and drive housing may be very
hot during operation and could burn skin
if touched.
MOVING VEHICLE HAZARD
Careless and reckless behavior causes
accidents. Falling from vehicle, running into
people or objects, or being struck by other
vehicles may result in serious injury or
death.
DUse appropriate traffic control in all traffic
areas
DDo not step on forward/reverse pedals
DMake turns slowly
DDo not carry passengers
DDo not operate on slopes greater than 15_
DLoss of traction may occur going downhill
DReference Manual on Uniform Traffic
Control Devices (MUTCD), U.S. Depart-
ment of Transportation, Federal Highway
Administration or local highway and trans-
portation regulations for proper traffic
control.
DDo not make turns greater than 45_
DDo not tow
DUse with line striping equipment only
TOXIC FUMES HAZARD
Engine produces carbon monoxide which is a
deadly gas. Do not operate in an enclosed
area. Breathing carbon monoxide may result
in serious injury or death.

3309404
General Repair Information
WARNING
MOVING PARTS HAZARD
To reduce risk of serious injury, do not
touch moving parts with fingers or tools
while testing repair. Shut off Line Driver
when repairing. Install all covers, gas-
kets, screws and washers before operat-
ing Line Driver.
CAUTION
To reduce risk of electrical malfunction:
DUse needle nose pliers to disconnect wires. Never
pull on wire, pull on connector.
DMate wire connectors properly. Center flat blade of
insulated male connector in female connector.
DRoute wires carefully to avoid interference with
other connections of pressure control. Do not pinch
wires between cover and control box.
1. Keep all screws, nuts, washers, gaskets, and
electrical fittings removed during repair proce-
dures. These parts are not normally provided with
replacement assemblies.
2. Test repair after problem is corrected.
3. If Line Driver does not operate properly, review
repair procedure to verify procedure was done
correctly. If necessary, see Troubleshooting Guide,
page 4, for other possible solutions.
WARNING
HOT SURFACES HAZARD
EXPLOSION HAZARD
Hydraulic reservoir and engine may be
very hot during operation and could burn
skin if touched.
Flammable materials spilled on hot
engine could cause fire or explosion.
Maintenance
CAUTION
For detailed engine maintenance and specifications,
refer to separate Honda Engines Owner’s Manual,
supplied.
DAILY: Check engine oil level and fill as necessary.
DAILY: Check hydraulic oil level and fill as neces-
sary.
DAILY: Check and fill the gas tank.
AFTER THE FIRST 20 HOURS OF OPERATION:
Drain engine oil and refill with clean oil. Reference
Honda Engines Owner’s Manual for correct oil viscos-
ity.
WEEKLY: Remove engine air filter cover and clean
element. Replace element, if necessary. If operating in
an unusually dusty environment: check filter daily and
replace, if necessary.
Replacement elements can be purchased from your
local HONDA dealer.
AFTER EACH 100 HOURS OF OPERATION:
Change engine oil. Reference Honda Engines Owner’s
Manual for correct oil viscosity.
YEARLY OR 500 HOURS:
Replace hydraulic oil and filter element. Use Mobil 1
(15W–50) synthetic oil and Graco filter 245342.
Hydraulic Oil Replacement Procedure:
1. Remove filter and allow oil reservoir to drain from
filter base.
2. Install new filter and fill oil reservoir to top of baffle
with Mobil 1 (15W–50) synthetic oil.
3. Manual 309402. Open drive wheel release. Start
engine and run at low rpm for 3 minutes.
4. Close drive wheel release. Check oil level and top
off to top of baffle.
SPARK PLUG: Use only BPR6ES (NGK) or
W20EPR–U (NIPPONDENSO) plug. Gap plug to
0.028 to 0.031 in. (0.7 to 0.8 mm). Use spark plug
wrench when installing and removing plug.

3094044
Troubleshooting
PROBLEM CAUSE SOLUTION
Engine does not start Parking brake not engaged. Engine
switch OFF, no gasoline or low oil Set Brake. Consult engine manual, supplied
Engine races to high rpm – stalls
during operation Worn governor. Consult engine manual, supplied
Engine operates, Line Driver does
not move forward or reverse Low hydraulic oil Fill with Mobil 1 (15W–50) synthetic oil
Engine operates, Line Driver moves
slowly in forward and reverse Low hydraulic oil. Parking brake is set
Wheel release is open.
Fill with Mobil 1 (15W–50) synthetic oil. Release
parking brake.
CLose; hand tight.
Engine shuts off when operator ex-
its Line Driver Safety switch Set parking brake
Engine continues to run when oper-
ator exits Line Driver and parking
brake is not set
Safety switch Adjust and set parking brake. Replace safety
switch and/or any connecting wires.
Engine misses during turns and for-
ward and reverse changes Engine oil low Consult engine manual for proper oil
Parking brake does not keep Line
Driver from moving Parking brake needs adjustment Adjust brake. Manual 309404.
Line Driver creeps in forward or re-
verse direction Hydraulic motor linkage needs adjust- ment Adjust hydraulic motor linkage. Manual 309404.
Engine light does not turn on Check light bulb
Check connections
Check Switch position on regulator
Replace light bulb
Repair connections
Set Switch position on regulator :
1. Set to No Battery if your Line Driver
has no battery
2. Set to Battery if your Line Driver has a
battery

5309404
Hydraulic Motor Linkage and Brake Adjustments
Hydraulic Motor Linkage
The Line Driver may creep forward or backwards when
no pressure is applied to the pedals. This procedure
helps to attain a neutral condition.
1. Set Line Driver on blocks so wheels are off
ground.
2. Apply weight to center of seat to by–pass safety
switch.
3. Release brake.
4. Fig. 1. Loosen jam nut (18).
5. Turn centering fitting (24) toward rear of Line
Driver to stop forward creep. Turn centering fitting
toward front to stop reverse creep.
6. Tighten jam nut (18).
Fig. 1
18 24
ti654a
Brake
The Line Driver may roll if left unattended and brake not
applied. The brake must be applied in order to start the
engine. After a period of time, tire wear may cause a need
to adjust the brake.
1. Fig. 2. Loosen two lock nuts (86) and bolts (77)
securing brake bracket (62).
2. Slide brake bracket (62) forward or backward to
attain desired brake pressure.
3. Tighten lock nuts (86) and bolts (77) securing
brake bracket (62).
Fig. 2
62
77
86
1/8 in. ti653a

3094046
Tire and Wheel Motors
Hydraulic System Purging
Follow this procedure after replacing any hydraulic com-
ponents:
1. Set Line Driver on blocks so wheels are off
ground.
2. Fill oil reservoir to top of baffle.
3. Open drive wheel release two turns.
4. Start engine and run at low rpm.
5. Slowly move motion control pedals in forward and
reverse directions 10 times.
6. Check oil level and top off to top of baffle.
7. Close drive wheel release and repeat step 5.
8. Increase speed. Move pedals to see if wheels turn
freely.
9. Check oil level. Top off to top of baffle.
Tire
Removal
1. Fig. 3. Set Line Driver on blocks so wheels are off
ground.
2. Remove four lug nuts (22) and tire (16).
Installation
1. Repair tire and install lug nuts. Alternately tighten
lug nuts opposite of each other.
2. Tilt Line Driver back and remove blocks.
22
Fig. 3
16
ti655a
Wheel Motors
Removal
1. Fig. 3. Set Line Driver on blocks so wheels are off
ground.
2. Remove four lug nuts (22a) and tire (16).
3. Remove pin (56), caster nut (21b) and wheel hub
(22b). Wheel hub (22b) may require a wheel puller;
not supplied by Graco.
4. Disconnect two hydraulic hoses (112) from wheel
motor (21a). Elevate hose ends and plug.
5. Remove four bolts (78), lock nuts (79) and wheel
motor (21a).
Installation
1. Install wheel motor (21) with four bolts (78) and
lock nuts (79) .
2. Connect two hydraulic hoses (112) to wheel motor
(21).
3. Install wheel hub (22), caster nut (21), and pin
(56).
4. Install tire (16) with four lug nuts (22).
112
16
56
22b
Fig. 4
21a
22a
21b
78, 79
ti655a

7309404
Battery/Light Regulator
Regulator
The regulator is located under the seat and converts the
engine-generated ac voltage into a dc voltage for the bat-
tery and light.
Removal
1. Fig. 5. Unplug light cord (59) and disconnect leads
(A, B).
2. Remove bolt (77) and nut (76) and regulator (126).
Installation
1. Fig. 5. Install regulator (126) with bolt (77) and nut
(76).
2. Connect leads (A, B) and plug in light cord (59).
Battery Kit
The battery is located under the seat and stores the con-
verted dc voltage for the battery and light.
Use only Graco Battery 115753. Install according to
Manual 309406.
Important: Do not install other 12 Volt equipment without
first installing Graco Battery Kit 245343.
Fig. 5
A To Battery
(optional)
B
59
77 12676
(126) Bottom View (59) Light Jack
(A) Use Only for Graco
Battery Kit 245343
(B) Connects to Honda
Engine Alternator (70 Watt)
Switch
(no battery)
position
ti1656a

3094048
Engine
Removal
1. Fig. 6. Remove cap screw (129), lock nut (130)
and coupler guard (125).
2. Remove set screw (A) from flexible coupling (34).
3. Fig. 5. Disconnect all necessary wiring.
4. Remove four cap screws (70) and washers (71).
5. Fig. 6. Remove four engine mounting screws (69),
lock nuts (82) and engine (3).
NOTE: All service to the engine must be performed by
an authorized HONDA dealer.
Fig. 6 ti657a
A
69
34
71
70
82
3
129
130
125
Installation
1. Fig. 6. Remove four engine mounting screws (69),
lock nuts (82) and engine (3). Torque to 200 in-lb
(22.6 NSm).
2. Install four washers (71) and cap screws (70).
3. Fig. 5. Connect all necessary wiring.
4. Fig. 7. Install set screw (A) in flexible coupling
(34).
5. Install coupler guard (125) with cap screw (129),
and lock nut (130).

9309404
Variable Displacement Pump
Removal
1. Be prepared to plug hydraulic connections.
2. Fig. 7. Disconnect hydraulic lines (109, 110) and
hoses (118, 119) from variable displacement pump
(5).
3. Remove two cap screws (80), two lock washers
(75) and two washers (74).
4. Remove cap screw (87) and washer (71) from
control arm (58).
5. Remove cap screw (129), lock nut (130) and
coupler guard (125).
6. Remove set screw (A) from flexible coupling (34)
and remove variable displacement pump (5) and
key (83).
Installation
1. Install variable displacement pump (5) and key
(83). Install set screw (A) into flexible coupling
(34).
2. Install coupler guard (125) with cap screw (129),
and lock nut (130).
3. Install washer (71) and cap screw (87) into control
arm (58).
4. Install two washers (74), two lock washers (75)
and two cap screws (80).
5. Connect hydraulic lines (109, 110) and hoses (118,
119) to variable displacement pump (5).
Fig. 7
12
119
110
109
118 5
80
75
74
87 71 58
129
125 83
A
130
ti657a

30940410
ti1651c
Parts Drawing
19
69
12
91
16
22
56
21
22
13
68
54
9
51
106
83
105
70
49
88
15 ref
74
75 80
58
86
37
77
70
3
112
78
52
111
112 116
112
110
109
52
46
48
47
35
34
4
71
11928129
130
71
28118
120123
125
Page 12
21
63
66
65
67
64
61
77
6574
62
26 33
33
15
1
86 14
36
73
74
17
75
76
52
23
72
79 108
52
24
18
68
49 88
57
86
74
84
84
85
86 74
200
201
98
202
94
121
122
207
205
206
65
5
25
31
7765

11309404
Parts List
Ref
No. Part No. Description Qty
Ref
No. Part No. Description Qty
1 287679 FRAME, Line Driver 1
3 114530 ENGINE, 5.5 HP, Honda 1
4 116873 BRACKET, mtg, hydro, pump 1
5 116810 PUMP, displacement, hydraulic 1
12 198771 PLATE, floor (198769) 1
13 287684 PEDAL, foot, weldment 2
14 198814 SHAFT, foot pedals 1
15 287585 KIT, throttle, linkage
Includes rod, 25 and 31) 1
16 245340 WHEEL, pneumatic, assy 2
17 116889 COUPLER, ball 1
18 116906 NUT, jam, hex 1
19 198802 PLATE, mntng, mtr (198770) 1
21 116814 MOTOR, wheel with nuts 2
22 116815 HUB, wheel, 4 bolt with nuts 2
23 245313 ARM, linkage, weldment 1
24 198803 FITTING, centering 1
25 15F273 COLLAR, stop 1
26 198805 CAP, fitting, centering 1
28 116829 FITTING, 90_w/adj o–ring 1
31 119663 SCREW, set 2
33 116888 SPRING, compression 2
34 116875 COUPLING, flexible 1
35 290159 LABEL, reflective 2
36 113696 PIN, ball coupler 1
37 116890 SWITCH, plunger 1
46 108851 WASHER, plain 4
47 195515 DAMPENER, motor mount 4
48 195516 SPACER 4
49 116896 LINK, ball joint, qd 2
51 111302 SCREW, cap hex hd 4
52 110838 NUT, lock, nylock 8
54 110037 SCREW, mach, pnh 8
56 100104 PIN 2
57 198806 GUIDE, rod 1
58 198801 ARM, control, hydro 1
61 245336 LEVER, brake 1
62 245332 BRACKET, brake 1
63 245334 HANGER, rod, brake 1
64 245333 ARM, brake 1
65 116937 BEARING, flange, bronze 10
66 198889 SHAFT, brake 2
67 198890 SHAFT, brake 1
68 116940 SCREW, cap, socket head 6
69 110837 SCREW, flange, hex 4
70 109031 SCREW, cap, sch 4
71 104008 WASHER, lock 5
72 802127 SCREW, cap, hex hd 6
73 115348 SCREW, cap, 3/8–16 hex head 2
74 100023 WASHER 8
75 100133 WASHER, lock 4
76 100307 NUT, hex 2
77 116935 SCREW, cap, flnghd 2
78 114766 BOLT, cap, hex hd 8
79 801020 NUT, lock, hex 8
80 100004 SCREW, cap, hex hd 2
83 117222 KEY, square, 5 mm 1
84 109570 WASHER, plain 4
85 116942 SCREW, shoulder, socket hd 2
86 101566 NUT, lock 2
88 100521 BOLT 2
91 198872 PAD, non–slip, pedal 2
94 198922 LABEL, caution 1
98 198920 LABEL, instruction 1
105 116961 ROD, stand–off 1/4” 1
106 111006 SCREW, cap 2
108 116780 SCREW, hex hd, flanged 4
109 198950 TUBE, hydraulic, Line Driver 1
110 198949 TUBE, hydraulic, Line Driver 1
111 116966 FITTING, straight, hydraulic 2
112 116878 HOSE, hydraulic 4
116 116965 FITTING, tee, hydraulic 2
118 198954 HOSE, hydraulic 1
119 198955 HOSE, hydraulic 1
120 114956 TERMINAL, wire tap, insulated 1
123 198977 WIRE, switch, seat 1
125 198984 GUARD, coupler 1
129 101530 SCREW, cap 1
130 102040 NUT, lock 1
200 245321 HITCH KIT, 2
Includes ball and mounting hardware
201 290228 LABEL, caution 1
202 194126 LABEL, warning 1
205 113267 KEY, square, 3/16 in. 1
206 100527 WASHER 1
207 111483 CLAMP, cable 1

30940412
7
128
Page 10
6
126
8
2
52
50
107
40
42
41
39 Ref
39 Ref45
39
59
40
30
20
72
10
9
77
43 44
28 27
60
29
38
76
122
123
53
11
119
118
96
97
113
Parts Drawing
95
201
204
ti652a

13309404
Parts List
Ref
No. Part No. Description Qty
Ref
No. Part No. Description Qty
2 287686 CARRIAGE, seat, Line Driver 1
6 198713 FENDER, Line Driver 1
7 245341 SEAT, with switch 1
8 116827 BRACKET, adjust, seat 1
9 116877 BRACKET, adjust, seat, slave 1
10 116833 SWITCH, safety, seat 1
11 116832 SPACER, seat 4
20 116826 RESERVOIR, hydraulic 1
27 245342 FILTER, oil 1
28 116829 FITTING, 90_w/adj o–ring 1
29 116828 HOUSING, oil filter 1
30 116837 FITTING, straight, o–ring 1
38 287678 ARM, mounting, light 1
39 116892 LIGHT, halogen 1
40 116895 CAP, tube, square 2
41 195428 BOOT, toggle 1
42 107255 GUARD, switch 1
43 105658 RING, locking 1
44 111930 SWITCH, toggle 1
45 114425 BUSHING, strain relief 1
50 116831 CAP, hydraulic, reservoir 1
52 110838 NUT, lock, nylock 8
53 100040 PLUG, pipe 4
59 116910 CORD, power, Line Driver 1
60 224071 CLAMP, extension 1
72 802127 SCREW, cap, hex hd 6
76 100307 NUT, hex 2
77 116935 SCREW, cap, flnghd 2
95 198921 LABEL 1
96 198919 LABEL 1
97 198918 LABEL 2
107 100840 ELBOW, street 1
113 198953 LABEL, instruction 2
118 198954 HOSE, hydraulic 1
119 198955 HOSE, hydraulic 1
122 198976 WIRE, switch, brake 1
123 198977 WIRE, switch, seat 1
126 245421 REGULATOR, battery/light 1
128 198958 LABEL 1
201 290228 LABEL, caution 1
204 108868 CLAMP, wires 2

30940414
Safety Interlock Wiring Diagram
(10) Switch under seat
(3) Engine (37) Switch on Brake
Frame
198977 198976
198975
114956
ti1672a
Safety Interlock Test Procedure
The Line Driver safety Interlock prevents the engine from running if the parking brake is not set and the driver leaves
the seat. Periodically check the interlock.
1. Set parking brake.
2. Sit on Line Driver seat.
3. Start engine.
4. Release parking brake.
5. Get off the Line Driver seat.
6. If engine stalls, safety interlock operates correctly.

15309404
Technical Data
Hydraulic Pressure
psi (bar) Hydraulic System Capacity Quarts (Liters) Engine HP Engine Generator Output Watt
2700 (186) 2 (1.9) 5.5
DIN 6270 B/DIN 6271
NA 2.9 Kw – 4.0 Ps. .
NB 3.6 Kw – 4.9 Ps. .
70
Dimensions
Model Weight lb (kg) Height in. (cm) Width in. (cm) Length in. (cm)
233725 246 (111) 41 (104) 26 (66) 58 (147)
Sound Levels
Line driver (Operating Range)*:
Sound Pressure 94–99 dB(A). . . . . . . . . . . . . . . . . . . . . . . . .
Sound Power 79–83 dB(A). . . . . . . . . . . . . . . . . . . . . . . . . . . .
* Measured at 3.1 feet (1 meter) per ISO 3744.
Line Driver coupled to LineLazer Striper (Operating Range)*:
Sound Pressure 99–102 dB(A). . . . . . . . . . . . . . . . . . . . . . . .
Sound Power 82–86 dB(A). . . . . . . . . . . . . . . . . . . . . . . . . . . .
* Measured at 3.1 feet (1 meter) per ISO 3744.
Graco Phone Number
TO PLACE AN ORDER, contact your Graco distributor, or call this number to identify the distributor closest to you:
1–800–690–2894 Toll Free.

30940416
Graco Standard Warranty
Graco warrants all equipment listed in this manual which is manufactured by Graco and bearing its name to be free from defects in
material and workmanship on the date of sale to the original purchaser for use. With the exception of any special extended or limited
warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment
determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in
accordance with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by
faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or
substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of
Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture,
installation, operation or maintenance or structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for
verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The
equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect
in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and
transportation.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other
remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any
other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the
date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT
NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, gas engines,
switches, hose, etc.), are subject to the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance
in making any claim for breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment
hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract,
breach of warranty, the negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings
entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties
reconnaissent avoir convenu que la rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures
judiciaires exécutés, donnés ou intentés à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées.
ADDITIONAL WARRANTY COVERAGE
Graco does provide extended warranty and wear warranty for products described in the “Graco Contractor Equipment Warranty
Program”.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
This manual contains English. MM 309404
Graco Headquarters: Minneapolis
International Offices: Belgium, China, Japan, Korea
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
www.graco.com
10/2001, Rev 4/2007
