Graco Magnum X5 User manual

Magnum X7
Magnum X5
(16J750) (16J751)
- For Portable Spray Applications of Architectural Paints and Coatings -
- Not for use in explosive atmospheres -
Models:
Magnum X5 (16J750) - Series A
Maximum Working Pressure: 207 bar, 21 MPa (3000 PSI)
Includes:
• 0.91 lpm (0.24 gpm) stand-mount sprayer
• SG2 gun - Manual 312830
• 0.635 cm (1/4 in) x 7.5 m (25 ft) hose
Magnum X7 (16J751) - Series A
Maximum Working Pressure: 207 bar, 21 MPa (3000 PSI)
Includes:
• 1.17 lpm (0.31 gpm) cart-mount sprayer
• SG3 gun - Manual 312830
• 0.635 cm (1/4 in.) x 15 m (50 ft) hose
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Operation
Magnum X5 and X7 Airless Sprayers 3A1775C
EN
• Use water-based or mineral spirit-type
materials only. Do not use flammable
materials. For more information about your
material, request MSDS from distributor or
retailer.

23A1775C
Table of Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Grounding Instructions . . . . . . . . . . . . . . . . . . . . . . 7
Thermal Overload . . . . . . . . . . . . . . . . . . . . . . . . 7
Component Identification (Magnum X5) . . . . . . . . 8
Component Identification (Magnum X7) . . . . . . . . 9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Pressure Relief Procedure . . . . . . . . . . . . . . . . 10
Pressure Adjustment . . . . . . . . . . . . . . . . . . . . . 10
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Priming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Install Tip and Guard on Gun . . . . . . . . . . . . . . 13
Spraying Techniques . . . . . . . . . . . . . . . . . . . . . 13
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . 13
Unclogging Spray Tip . . . . . . . . . . . . . . . . . . . . 14
Triggering Gun . . . . . . . . . . . . . . . . . . . . . . . . . 14
Aiming Gun . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting the Right Tip . . . . . . . . . . . . . . . . . . . . . 15
Tip Hole Size . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Tip Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleanup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cleaning Gun Filter . . . . . . . . . . . . . . . . . . . . . . 18
Filling Sprayer with Storage Fluid . . . . . . . . . . . 19
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Caring for Sprayer . . . . . . . . . . . . . . . . . . . . . . . 20
Gun Fluid Filter . . . . . . . . . . . . . . . . . . . . . . . . . 20
Paint Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Pump Check Valves . . . . . . . . . . . . . . . . . . . . . . 20
Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 26

Warnings
3A1775C 3
Warnings
The following warnings are for the setup, use, grounding, maintenance and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-spe-
cific risks. Refer back to these warnings. Additional, product-specific warnings may be found throughout
the body of this manual where applicable.
WARNING
GROUNDING
This product must be grounded. In the event of an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire for the electric current. This product is
equipped with a cord having a grounding wire with an appropriate grounding plug. The plug must
be plugged into an outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
• Improper installation of the grounding plug is able to result in a risk of electric shock.
• Check with a qualified electrician or serviceman when the grounding instructions are not
completely understood, or when in doubt as to whether the product is properly grounded.
• Do not modify the plug provided; if it does not fit the outlet, have the proper outlet installed by
a qualified electrician.
• This product is for use on a nominal 230V circuit and has a grounding plug similar to the plug
illustrated in the figure below.
Only connect the product to an outlet having the same configuration as the plug.
Do not use an adapter with this product.
Extension Cords:
• Use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle
that accepts the plug on the product.
• Make sure your extension cord is not damaged. If an extension cord is necessary, use 15m
(49.2 ft) 1.0 mm2, 30m (98.4 ft) 1.5 mm2, or 50m (164.0 ft) 2.5 mm2minimum to carry the
current that the product draws. An undersized cord results in a drop in line voltage and loss of
power and overheating.
ti11376a

Warnings
43A1775C
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help
prevent fire and explosion:
• Do not spray or clean with flammable materials [flash points lower than 100° F (38° C)]. Use
water-based material or mineral spirits-type material only. For complete information about
your fluid, request the MSDS from the fluid distributor or retailer.
• Do not spray flammable or combustible materials near an open flame or sources of ignition
such as cigarettes, motors, and electrical equipment.
• Only use water-based or mineral spirit-type materials with a flash point greater than 70° F
(21° C).
• Paint or solvent flowing through the equipment is able to result in static electricity. Static
electricity creates a risk of fire or explosion in the presence of paint or solvent fumes. All parts
of the spray system, including the pump, hose assembly, spray gun, and objects in and
around the spray area shall be properly grounded to protect against static discharge and
sparks. Use Graco conductive or grounded high-pressure airless paint sprayer hoses.
• Verify that all containers and collection systems are grounded to prevent static discharge. Do
not use pail liners unless they are antistatic or conductive.
• Connect to a grounded outlet and use grounded extensions cords. Do not use a 3-to-2
adapter.
• Do not use a paint or a solvent containing halogenated hydrocarbons.
• Keep spray area well-ventilated. Keep a good supply of fresh air moving through the area.
Keep pump assembly in a well ventilated area. Do not spray pump assembly.
• Do not smoke in the spray area.
• Do not operate light switches, engines, or similar spark producing products in the spray area.
• Keep area clean and free of paint or solvent containers, rags, and other flammable materials.
• Know the contents of the paints and solvents being sprayed. Read all Material Safety Data
Sheets (MSDS) and container labels provided with the paints and solvents. Follow the paint
and solvents manufacturer’s safety instructions.
• Fire extinguisher equipment shall be present and working.
• Sprayer generates sparks. When combustible materials are used in or near the sprayer or for
flushing or cleaning, keep sprayer at least 20 feet (6 m) away from explosive vapors.
ELECTRIC SHOCK HAZARD
This equipment must be grounded.Improper grounding, setup, or usage of the system can
cause electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before
servicing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.
WARNING

Warnings
3A1775C 5
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look
like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not spray without tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop spraying and before cleaning,
checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated
system component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data
in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete
information about your material, request MSDS from distributor or retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in
use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and
create safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot
surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
WARNING

Warnings
63A1775C
PRESSURIZED ALUMINUM PARTS HAZARD
Use of fluids that are incompatible with aluminum in pressurized equipment can cause serious
chemical reaction and equipment rupture. Failure to follow this warning can result in death,
serious injury, or property damage.
• Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents.
• Many other fluids may contain chemicals that can react with aluminum. Contact your material
supplier for compatibility.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled,
or swallowed.
• Read MSDSs to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable
guidelines.
RECOIL HAZARD
Gun may recoil when triggered. If you are not standing securely, you could fall and be seriously
injured.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury,
including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective equipment
includes but is not limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
WARNING

Grounding Instructions
3A1775C 7
Grounding Instructions
Sprayer must be grounded. Grounding reduces
the risk of static and electric shock by providing an
escape wire for electrical current due to static build
up or in the event of a short circuit.
1. This sprayer requires 220-240 VAC, 50/60 Hz
10A circuit with a grounding receptacle. Never
use an outlet that is not grounded.
2. Do not use sprayer if electrical cord has dam-
aged ground prong.
3. Do not use an extension cord with damaged
ground plug.
Recommended extension cords:
• 15 m (49.2 ft) 1.0 mm2
• 30 m (98.4 ft) 1.5 mm2
• 50 m (164.0 ft) 2.5 mm2
4. Smaller gauge or longer extension cords may
reduce sprayer performance.
Thermal Overload
Motor has a thermal overload switch to shut itself
down if overheated. If unit overheats, allow approx-
imately 45 minutes for unit to cool. Once cool,
switch will close and unit will restart.
ti7529b
ti7528a
To reduce risk of injury from motor starting
unexpectedly when it cools, always turn power
switch OFF if motor shuts down.

Component Identification (Magnum X5)
83A1775C
Component Identification (Magnum X5)
Z
C
QS
V
R
P
T
U
M
D
L
H
G
K
A
B
J
ti15963b
A Electric motor (inside enclosure)
BPowerswitch
C Pressure control knob
D Pump fluid outlet fitting
G Suction Tube
H Prime tube (with diffuser)
J Prime/Spray valve control
K Fluid inlet connection and inlet valve
L Inlet screen
M Paint hose
P SG2 airless spray gun
Q Tip guard
R Reversible spray tip
S Trigger safety lever
T Gun fluid inlet fitting
V Gun fluid filter (in handle)
Z Pump Priming Button

Component Identification (Magnum X7)
3A1775C 9
Component Identification (Magnum X7)
B
W
A
J
Z
C
X
D
H
G
L
Q
P
R
S
V
T
U
M
K
ti15964b
A Electric motor (inside enclosure)
BPowerswitch
C Pressure control knob
D Pump fluid outlet fitting
G Suction Tube
H Prime tube (with diffuser)
J Prime/Spray valve control
K Fluid inlet connection and inlet valve
L Inlet screen
M Paint hose
P SG3 airless spray gun
Q Tip guard
R Reversible spray tip
S Trigger safety lever
T Gun fluid inlet fitting
V Gun fluid filter (in handle)
W Hose/cord wrap bracket
X Pail hanger
Z Pump Priming Button

Operation
10 3A1775C
Operation
Pressure Relief Procedure
Follow this Pressure Relief Procedure whenever
you stop spraying and before cleaning, checking,
servicing, or transporting equipment.
1. Turn OFF power switch.
2. Place prime tube in waste pail.
3. Turn Prime/Spray valve to PRIME.
4. Turn pressure control knob left (minimum pres-
sure).
5. Trigger gun into bucket to relieve pressure in
hose.
Pressure Adjustment
1. Align arrow on sprayer with spray symbol on
pressure control knob.
2. Turning knob right (clockwise) increases pres-
sure at gun.
3. Turning knob left (counterclockwise) decreases
pressure at gun.
ti2018a
ti2034a
ti2019a
ti2020a
ti2033a
ti2031a
ti2032a
ti2020a

Setup
3A1775C 11
Setup
1. Turn OFF power switch.
2. Connect one end of grounded fluid hose to
spray gun. Use a wrench to tighten.
3. Connect other end of hose to sprayer fluid out-
let fitting. Use wrench to tighten.
4. Turn pressure control knob left (minimum pres-
sure).
ti2018a
ti2024a
ti15965a
ti2020a

Priming
12 3A1775C
Priming
For flushing storage fluid and loading pump and
hose with paint.
Before priming sprayer, follow Cleaning procedure,
Steps 1-6, page 17.
1. Turn OFF power switch.
2. Submerge suction tube in paint.
3. Turn Prime/Spray valve to PRIME.
4. Point gun into waste pail.
5. Push pump priming button two times.
6. Turn ON power switch. Align arrow on sprayer
and bucket symbol on pressure control knob.
7. When paint, without bubbles, starts to come out
of prime tube, trigger gun and turn Prime/Spray
valve to SPRAY. When paint comes out of gun,
release trigger.
NOTE: The motor stopping indicates the pump
and hose are primed with paint.
8. Transfer prime tube to paint pail.
ti2018a
ti2026a
ti2019a
ti2027a
ti15972a
ti2028a
ti2029a
ti2030a

Priming
3A1775C 13
Install Tip and Guard on Gun
1. Engage trigger lock.
2. Verify tip and guard parts are assembled in
order shown.
3. Screw tip and guard assembly on gun. Tighten
retaining nut.
Spraying Techniques
Motor runs only when gun is triggered. Sprayer is
designed to stop pumping when gun trigger is
released.
Getting Started
Hold gun 30 cm (12 in.) from surface and aim
straight at surface. Tilting gun to direct spray angle
causes an uneven finish.
Flex wrist to keep gun pointed straight. Fanning
gun to direct spray angle causes uneven finish.
ti8908a
retaining nut
black rubber gasket and
guard tip
ti8911a
metal seat
Use tip to align seat Tip must be pushed
all the way into guard
in guard
ti9574a
ti5606a
ti9313a
ti2035a
ti2036a

Priming
14 3A1775C
Unclogging Spray Tip
1. To UNCLOG tip obstruction, engage trigger
lock.
2. Point arrow-shaped handle backward to
UNCLOG position.
3. Aim gun at piece of scrap or cardboard.
4. Unlock trigger lock. Pull trigger to clear clog.
5. When obstruction is cleared, engage trigger
lock and rotate arrow-shaped handle back to
SPRAY position.
Point the arrow-shaped handle on the spray tip for-
ward to SPRAY and backward to UNCLOG
obstructions.
Triggering Gun
Pull trigger after starting stroke, release trigger
before end of stroke. Gun must be moving when
trigger is pulled and released.
Aiming Gun
Aim tip of gun at edge of previous stroke to overlap
each stroke by half.
To avoid fluid splash back:
• Never pull gun trigger when arrow-shaped
handle is between SPRAY and UNCLOG
positions.
• Tip must be pushed all the way into guard.
ti8908a
ti9048a
ti8909a
ti9049a
ti2037a
ti2038a

Selecting the Right Tip
3A1775C 15
Selecting the Right Tip
Tip Hole Size
• Spray should be atomized (evenly distrib-
uted, no gaps or edges). Start at a low
pressure setting, increase pressure a little
at a time until paint atomizes.
• Fluid flow rate is controlled by tip hole size.
• The best tip hole size for fluid you are
spraying is determined by type of coating
and type of surface you are spraying.
• Use large tip hole size when spraying
thicker coatings.
• Use small tip hole size when spraying thin-
ner coatings.
• Tips wear and enlarge when you spray.
Starting with a tip hole size smaller than the
maximum will allow you to spray within
rated flow capacity. To prevent excessive
wear, spray at lowest pressure that atom-
izes paint.
NOTE: If maximum pressure of sprayer is not
enough for good spray pattern, tip is too large or
worn. See Reversible Tip Selection Table, page
16.
Fan Width
Fan Width is the size of the spray pattern.
Narrow Fan
• Thicker coat
• Better control
• Small, confined surfaces
Wide Fan
• Thin coat
• Fast coverage
• Broad, open surfaces
COATINGS
Tip Hole Size
(diameter based on area of
elliptical orifice)
stains enamels
oil-based
primers and
paints
interior latex
paint
exterior latex
paint acrylics
0.013 in. (0.33 mm) X X X X
0.015in.(0.38mm) XXXX
0.017in.(0.43mm) XXXX
Maximum Tip Size:
X5 - 0.015 in. (0.38 mm)
X7 - 0.017 in. (0.43 mm)

Selecting the Right Tip
16 3A1775C
Tip Number
The last three digits of tip number (example
286413) contain information about hole size and
fan width when gun is held 30.5 cm (12 in.) from
surface being sprayed.
Reversible Tip Selection Table
Example: For an 203-254 mm (8-10 in.) fan width
and a 0.33 mm (0.013 in.) hole size, order part no.
286413.
• See manual 312830 for gun operating instructions and spray techniques.
Tip Part Number Fan Width
305 mm (12 in.) from surface Hole Size
286313 152-203 mm (6-8 in.) 0.33 mm (0.013 in.)
286413 203-254 mm (8-10 in.) 0.33 mm (0.013 in.)
286415 203-254 mm (8-10 in.) 0.38 mm (0.015 in.)
286515 254-305 mm (10-12 in.) 0.38 mm (0.015 in.)
286417 203-254 mm (8-10 in.) 0.43 mm (0.017 in.)
286517 254-305 mm (10-12 in.) 0.43 mm (0.017 in.)

Cleanup
3A1775C 17
Cleanup
1. Engage gun trigger lock.
2. Turn OFF power switch. Turn Prime/Spray
valve to PRIME.
3. Place prime tube in waste pail. Submerge suc-
tion tube in water or compatible solvent for
non-water based material.
4. Turn ON power switch. Align arrow on sprayer
and bucket symbol on pressure control knob.
5. While pump continues to stroke, remove trigger
lock. Trigger gun into paint pail. Turn
Prime/Spray valve to SPRAY. Continue to trig-
ger gun until flushing fluid comes out of gun.
Release trigger.
NOTE: To minimize splashing, aim gun at
inside wall of empty waste pail.
6. Move gun to waste pail. Trigger gun until
remaining flushing fluid is gone from flushing
pail. Release gun trigger.
7. Fill unit with Pump Armor or mineral spirits. See
Cleanup, page 17.
ti2048a
ti2018a ti2019a
ti2050a
ti2028a
ti2051a
ti2052a

Cleanup
18 3A1775C
Cleaning Gun Filter
Perform Pressure Relief Procedure, page 10.
1. Engage gun trigger lock.
2. Unscrew hose.
3. Remove filter and clean it in compatible sol-
vent.
NOTE: Do not soak entire gun in solvent. Pro-
longed exposure to solvent can ruin packings.
4. Insert filter.
ti2048a
ti2007
ti2055a
ti2009a

Cleanup
3A1775C 19
Filling Sprayer with Storage Fluid
1. Remove inlet strainer. Place suction tube in
storage fluid bottle and prime tube in waste
pail.
2. Turn Prime/Spray valve to PRIME.
3. Turn pressure control knob all the way left
(counterclockwise) to minimum pressure.
4. Turn ON power switch.
5. Align arrow on sprayer with roller symbol on
pressure control knob.
6. When storage fluid comes out of prime tube
(5-10 seconds) turn OFF power switch.
7. Turn Prime/Spray valve to SPRAY to keep stor-
age fluid in sprayer during storage.
Always pump storage fluid through pump system
after cleaning. Water left in sprayer will corrode
sprayer and damage pump.
ti2057a
ti2019a
ti2020a
ti2028a1
ti2058a
ti2059a
ti2044a

Maintenance
20 3A1775C
Maintenance
Caring for Sprayer
Clean sprayer and accessories thoroughly after
each use.
Do not cover vent holes or shroud while spraying.
Gun Fluid Filter
Clean gun fluid filter with compatible solvent and
brush every time you flush system. Replace when
damaged.
Paint Hoses
Check hose for damage every time you spray. Do
not attempt to clean or repair hose if hose jacket or
fittings are damaged. Do not use hoses shorter
than 7.5 m
(25 ft).
Tips
• Always clean tips with compatible solvent
and brush after spraying.
• Tip life: 57 liters (15 gallons) - 227 liters (60
gallons)*
• Do not spray with worn tip.
Pump Check Valves
• Storing in water, inadequate flushing or
ingested debris can cause either of the two
check valves to malfunction.
• If pump does not prime after 30 seconds,
try to loosen check balls by pushing pump
priming button or by tapping the inlet valve
with a small wrench as the sprayer is strok-
ing.
NOTE: Excessive shock will fracture or cause
other damage to pump.
NOTE: To verify inlet valve ball is sticking,
unscrew valves from pump and check them.
If sprayer continues to cycle (motor and pump
run) after you release gun trigger, pump valves
may be obstructed or worn. Valve repair kits
are available from Graco/MAGNUM authorized
service centers.
Pump
When pump wears, paint will begin to leak down
outside of pump. Replace pump at first sign of leak-
ing or additional damage could occur.
Pump repair kits are available from Graco/MAGNUM
authorized service centers.
NOTICE
Openings in shroud provide air for cooling
mechanical parts and electronics inside. If water
gets in these openings sprayer could malfunction
or be permanently damaged.
ti15970a
ti15972a
