Graco FinishPro II 395 User manual

333154A
EN
Parts
FinishPro II 395/595
Airless/Air-Assisted Sprayer
Maximum Working Pressure Airless Spraying: 3300 psi (227 bar, 22.7 MPa)
Models:
Region FinishPro II 395 FinishPro II 595
US
24U065 24U073
Europe CEE 7/7
24U067 24U075
Europe Multi Cord
24U069 24U077
UK
24U070 ---------
Asia/Australia
24U071 24U071
- For the application of architectural paint and coatings -
ti22591a
ti22592a
FinishPro II 395
FinishPro II 595

FinishPro II 395
2333154A
FinishPro II 395
45
54
42
22
8
10
91
40
44 25
10
47
15
47
36
17
12
12
16
2
24
4
35
47
109
18
38
3
27
23 12
63 111
70
41
43
84
60
14
102
57
120
24
45
32
29
62
55
39
109a 109b 109c 109d
126
125 127
112
65
110
ref. 109
ti22770a

FinishPro II 395
333154A 3
Parts List
Ref. Part Description Qty.
1 107434 BEARING, thrust 1
2 117828 O-RING, ptfe encapsulated 1
3 111457 PACKING, o-ring 1
4 111600 PIN, grooved 1
8 116073 WASHER, thrust 1
9 116074 WASHER, thrust 1
10 116079 BEARING, thrust 2
12 117501 SCREW, mach, slot hex wash hd 18
14 103413 PACKING, o-ring 1
15 15G455 MANIFOLD, fluid 1
16 246382 FILTER, fluid, 100 mesh 1
17 CAP, filter 1
18 287902 INSERT, filter 1
22 287058 COVER, front, Graco, paint 1
23 287056 SHIELD, motor, painted
(includes 12, 63, 65)
1
24 162453 FITTING, 1/4 npsm x 1/4 npt 2
25 180131 BEARING, thrust 1
27 187625 HANDLE, valve, drain 1
29 195150 NUT, jam, pump 1
32 196762 PIN, straight 1
35 235014 VALVE, drain, Japan 1
36 224807 BASE, valve 1
38 243222 TRANSDUCER, pressure control
(includes 3)
1
39 241920 DEFLECTOR, threaded 1
40 287057 GEAR, reducer (first stage)
(includes 8, 10)
1
41 246428 PUMP, displacement, st 1
42 287055 HOUSING, drive (includes 12, 47) 1
43 287053 ROD, connecting 1
44 287054 GEAR, crankshaft 1
45 287003 HOSE, cpld 1
47 117493 SCREW, mach, hex washer HD 12
54 MOTOR, 395
288859 Models 24U065, 24U070 1
287060 Models 24U067, 24U069, 24U070 1
55 244240 HOSE, drain, Ultra hi-boy
(includes 39)
1
57 246385 STRAINER, 7/8-14 unf 1
60 246387 TUBE, suction
(includes 14, 57, 102, 120)
1
62 276888 CLIP, drain line 1
63 LABEL, warning, fire/expl, skin
15B516 Model 24U065 1
16G596 Models 24U067, 244069, 24U070 1
65 LABEL, warning
195793 Model 24U065 1
195792 Model 24U071 1
70 15C146 HOOK, pail 1
84 115099 WASHER, garden hose 1
102 15E813 NUT, jam 1
109 CORD, power
15D029 Model 24U065 1
15B469 Model 24U070 1
15B470 Model 24U067 1
15B471 Models 24U069, 24U071 1
110 16X344 LABEL, brand, front, FinishPro 395 1
111 16X343 LABEL, brand, side, FinishPro 395 1
112 195551 RETAINER, plug, adapter 1
120 15B652 WASHER, suction 1
125 242001 CORD SET, adapter, Europe
(Models 24U069, 24U071)
1
126 242005 CORD SET, adapter, Australia
(Model 24U071)
1
127 287121 CORD SET, Italy, Denmark,
Switzerland (Model 24U069)
1
Ref. Part Description Qty.

FinishPro II 395
4333154A
FinishPro II 395
59
78
76
103
66 87
77
12
13
64
12
68
21
6
67
8888
80
94
96
114
116
124
145
166
33 61
88
69
46
46a
46c
46d 46e
46b
46f
ti22771a
200

FinishPro II 395
333154A 5
Parts List
Ref. Part Description Qty.
6 115494 SCREW, mach, phillips pan hd 9
12 117501 SCREW, mach, slot hex wash hd 18
13 120643 GAUGE, pressure, panel mount,
1.5
1
21 127330 REGULATOR, air, 1/4 in. npt 1
26 CLAMP, wire 1
33 238049 FLUID, TSL, 4 oz 1
46 3300 psi hose set
24U578 Models 24U067, 24U068, 24U070 1
24U579 Models 24U065, 24U071 1
59 24U249 FRAME, cart, hi, AA 1
61 GUN, assy, AA G40
262929 Models 24U065, 24U071 1
262932 Models 24U067, 24U069, 24U070 1
64 15K053 PLATE, rear, painted 1
66 287489 HANDLE, assy, hi cart 1
67 109032 SCREW, mach, pnh 4
68 104641 FITTING, bulkhead 1
76 15B999 CLIP, retaining 2
77 15K052 PLATE, front, painted 1
78 106062 WHEEL, semi pneumatic 2
80 120685 GROMMET 1
87 287253 TOOL BOX (includes 88) 1
88 118852 SCREW, thd forming, hex washer
hd
3
94 15K040 NUT, regulator, metal 1
96 100015 NUT, hex mscr 1
103 104811 CAP, hub 2
114 15K468 LABEL, AA, regulator/gauge 1
116 15K465 LABEL (Models 24U065, 24U071) 1
124 290228 LABEL, caution 1
145 111909 PLUG, button 1
200 24U981 KIT, inline desiccant (5 pack)
24U982 KIT, inline desiccant (25 pack)
Ref. Part Description Qty.

FinishPro II 395 Compressor
6333154A
FinishPro II 395 Compressor
89
136
141
92
93
85
146
31
146 95
112
131
146
138 134 133
150
86 86a
91
92
95
106
140
147
135
107
108
148
113
166 165
167
ti22773a
ti22774a
48
51
58
49
20
37
11
6
308112 12
115
ti22772a

FinishPro II 395 Compressor
333154A 7
Parts List
Ref. Part Description Qty.
6 115494 SCREW, mach, phillips pan hd 9
11 116167 KNOB, potentiometer 1
12 117501 SCREW, mach, slot hex wash hd 18
20 15B120 GROMMET, transducer 1
30 195428 BOOT, toggle 1
31 117633 SCREW, slot hex wash hd 5
37 256219 POTENTIOMETR, assembly 1
48 CONTROL BOX, machined
15J469 Model 24U065 1
15M176 Model 24U067, 24U069, 24U070,
24U071
1
49 CONTROL BOARD
288840 Model 24U065 1
288842 Model 24U067, 24U069, 24U071 1
288843 Model 24U070 1
51 24B026 KIT, display, st 1
58 120544 SWITCH, toggle 1
81 15J988 PLATE, switch 1
85 109575 SCREW, threadforming, hexhead 2
86 AIR COMPRESSOR (includes 86a)
288720 Models 24U065, 24U070 1
288722 Models 24U067, 24U069, 24U071 1
86a 288724 KIT, compressor, filter 1
89 127341 FITTING, brass, elbow 1
91 187357 ELBOW, street 1
92 16X397 TUBE, heat exchange, 395/595 1
93 SOLENOID, 2 way, norm open 1
16X399 Model 24U065, 24U070 1
16X526 Model 24U067, 24U069, 24U071 1
95 120732 FITTING, compression, male con-
nect
2
106 120753 FITTING, push to connect elbow 1
107 16X512 TUBE, air 1
108 15B822 TUBE, air 2
112 195551 RETAINER, plug, adapter 1
113 16X530 CORD, pwr, comp. female end 1
115 15K470 LABEL, switch, AA, 395 1
131 16X915 TANK, painted 1
133 16X477 HOSE, air 1
134 16X478 HOSE, air 1
135 127343 SWITCH, pressure 1
136 127339 VALVE, check, 1/8 in. mnpt x fnpt 1
138 801012 GROMMET 1
140 115942 NUT, hex, flange head 2
141 127340 VALVE, check, 1/4 in. mnpt x fnpt 1
146 597151 FITTING, elbow 3
147 113630 ELBOW, street 45 degree 1/8 npt 1
148 16X827 CORD, compress/control board 1
150 16X906 LABEL, brand, smartcomp 1
165 TIMER, solid state 120V
16Y436 Models 24U065, 24U070 1
16Y437 Models 24U067, 24U069, 24U071 1
166 125483 SCREW, mach, pnh, sems, phillips 2
167 C19862 NUT, lock, hex 2
Ref. Part Description Qty.

FinishPro II 595
8333154A
FinishPro II 595
59
78
76
103
66 87
77
12
13
64
12
68
21
6
67
8888
80
94
96
114
116
124
145
166
33 61
88
69
46
46a
46c
46d 46e
46b
46f
ti22771a
200

FinishPro II 595
333154A 9
Parts List
Ref. Part Description Qty.
6 115494 SCREW, mach, phillips pan hd 9
12 117501 SCREW, mach, slot hex wash hd 18
13 120643 GAUGE, pressure, panel mount,
1.5
1
21 127330 REGULATOR, air, 1/4 in. npt 1
26 CLAMP, wire 1
33 238049 FLUID, TSL, 4 oz 1
46 24U579 3300 psi hose set, 50 ft 1
59 24U249 FRAME, cart, hi, AA 1
61 GUN, assy, AA G40
262929 Models 24U073, 24U077 1
262932 Models 24U074, 24U075, 24U070 1
64 15K053 PLATE, rear, painted 1
66 287489 HANDLE, assy, hi cart 1
67 109032 SCREW, mach, pnh 4
68 104641 FITTING, bulkhead 1
76 15B999 CLIP, retaining 2
77 15K052 PLATE, front, painted 1
78 106062 WHEEL, semi pneumatic 2
80 120685 GROMMET 1
87 287253 TOOL BOX (includes 88) 1
88 118852 SCREW, thd forming, hex washer
hd
3
94 15K040 NUT, regulator, metal 1
96 100015 NUT, hex mscr 1
103 104811 CAP, hub 2
114 15K468 LABEL, AA, regulator/gauge 1
116 15K465 LABEL 1
124 290228 LABEL, caution 1
145 111909 PLUG, button 1
200 24U981 KIT, inline desiccant (5 pack)
24U982 KIT, inline desiccant (25 pack)
Ref. Part Description Qty.

FinishPro II 595
10 333154A
FinishPro II 595
55
8
1010
43
32
22
146
36
27 4
24 47
12
60
55
47
65
110
12
47
41
84
120
102
62
57
39
24
45
29
144
91
25
44
42
47
40
23
12
145
54
45
38
3
47
2
17
18
20
16
35
56
70
130
111
56a56b56c 112
127
125
126 14
63
ti22636a
