6486R-2-INS-LAB-RevA11 1
6482R-2/6482ER-2: DELUXE TOILET SEAT RISER WITH ARMRESTS
ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
Info: The most current version of these instructions can be found online at www.grahamfield.com
Tools required: Phillips or blade screwdriver
WARNING:Important!Readandunderstandtheseinstructions
beforeinstallingorusingtheToiletSeatRiser.Ifyoudonotunder-
standanypartofthesewarnings,cautionsorinstructions,contact
ahealthcareprofessionalfordirectionintheuseofthisproduct.If
thetoiletseatriserisnotproperlyassembledandinstalled,person-
alinjuryanddamagetothetoiletseatrisercouldresult.
WARNING:Ifcomponentsaredamagedormissing,contactyour
dealerimmediately.DONOTusesubstituteparts.UseonlyLumex
replacementparts.Non-Lumexreplacementpartscouldcauseper-
sonalinjuryanddamagetothetoiletseatriser.
WARNING:Thisproducthasaweightlimitof300lb.
WARNING:GFHealthProducts,Inc.assumesnoresponsibilityfor
anydamageorinjurycausedbyimproperassembly,installationor
useofthisproduct.
INSTALLATION
1. Remove toilet seat riser, hardware, and armrests from carton and protec-
tive packaging.
2. Install the armrests with the following steps:
a. Identify the right and left armrests by the R (Right) and L (Left)
stamped into armrest ends.
b. Note that each toilet seat riser armrest socket is also stamped with an R
or L, as shown at right. Insert each armrest marked with R or L into the
socket with the corresponding letter.
c. Push each armrest into its sockets until it clicks into place.
d. Ensure locking buttons protrude fully from holes. Pull on armrests
slightly to test proper installation. If loose, repeat step c.
3. At the toilet, lift the cover plates at top rear toilet bowl rim, exposing the
bolts holding the seat and lid to the toilet bowl.
4. Use a Phillips or blade screwdriver, whichever is appropriate, to unscrew
toilet seat bolts by turning counterclockwise.
5. Remove the toilet seat and lid from the toilet bowl and set them aside.
6. Place the toilet seat riser over the toilet bowl rim so that the toilet seat
riser mounting holes align with the toilet rim holes.
7. Place the toilet seat and lid on top of the toilet seat riser so that the seat/
lid holes align with the riser and rim holes.
8. Install a washer on one of the long bolts included in the box and insert it
through the top of the toilet seat lid, toilet seat riser, and toilet bowl rim.
9. Place a washer and wing nut on the end of the long bolt that protrudes
through the bottom of the toilet bowl.
hardware
bolt
washers
wing
nut
right armrest shown installed
(shown upside down)
“R” on armrest socket
locking button
toilet seat riserarmrest
6482ER-2, one arm attached
(shown upside down)
mounting holes
6482R-2 assembled
6482ER-2 assembled

6486R-2-INS-LAB-RevA11 2
www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. Packaging, warranties, products and specications are subject to change without notice.
Graham-Field and Lumex are registered trademarks of GF Health Products, Inc.
© 2011 GF Health Products, Inc. • 2935 Northeast Parkway • Atlanta, GA 30360 • 770-368-4700
10. Use a Phillips or blade screwdriver, whichever is appropriate, to turn the bolt clockwise until toilet seat
riser and toilet seat lid are snug. Do not overtighten.
11. The toilet seat riser should now be securely installed on the toilet bowl. To ensure that you have a
proper t, intentionally shake the toilet seat riser to ensure proper placement and t. The toilet seat
riser should not move; if it does, re-install.
OPERATION
WARNING:Alwaysensurethetoiletseatriserissecurelyinstalledbeforeuse.
MAINTENANCE
WARNING:Checkthetoiletseatriserweeklyforsignsofdamageorcracking.Ifdamageor
crackingisfound,DONOTusethetoiletseatriser.ContactyourLumexauthorizeddistributor
immediately.
WARNING:Inspectthetoiletseatriserweeklyandtightenitasneededtoensuresecureinstal-
lation.
s NOTICE:Neveruseabrasivecleanersorscouringpadsonanypartofthetoiletseatriser.
• To clean the toilet seat riser, wash it with soap and water or a mild detergent, then rinse it with water.
Ensure the toilet seat riser is rinsed well before use.
• To clean interior of toilet seat riser, ush with warm soapy water, then drain and allow to air dry for sev-
eral hours.
• If moisture accumulates inside toilet seat riser, do the following:
a. Remove toilet seat riser from toilet bowl.
b. Turn toilet seat riser upside down and tilt toward drain opening.
c. Rotate until drain opening is facing downward and moisture drains.
d. Allow toilet seat riser to air dry for several hours before re-installation.
WARRANTY
GF Health Products, Inc. warrants the Lumex 6482R-2/6482ER-2 Toilet Seat Riser as follows: Lifetime limited
warranty against manufacturer’s defects. If a product is deemed to be under warranty, GF Health Prod-
ucts, Inc. shall provide, at its option, (1) replacement of any defective part or product or (2) a credit of the
original selling price made to GF Health Products, Inc.’s initial customer. The warranty does not include any
labor charges incurred in replacement part(s) installation or any associated freight or shipping charges to
GF Health Products, Inc.
The warranties contained herein contain all the representations and warranties with respect to the subject
matter of this document, and supersede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and represents that it has not relied on any
representation, assertion, guarantee, warranty, collateral contract or other assurance, except those set out
in this document.
