6460A / 6460R / 6465A-1: ADJUSTABLE VERSAFRAME TOILET
SAFETY FRAME ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
Note: The most current version of these instructions can be found online at www.grahamfield.com
WARNING: Important! Read and understand these instructions before installing or using
the Versaframe Toilet Safety Frame. If you do not understand any part of these warnings,
cautions or instructions, contact a healthcare professional for direction in the use of this
product. If the Versaframe is not properly assembled and installed, personal injury and
damage to the Versaframe could result.
WARNING: If components are damaged or missing, contact your dealer immediately. DO
NOT use substitute parts. Use only Lumex replacement parts. Non-Lumex replacement
parts could cause personal injury and damage to the Versaframe.
WARNING: This product has a weight limit of 250 lb.
WARNING: Users who have limited physical capabilities must be assisted or supervised
when using the Versaframe.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly, installation or use of this product.
INSTALLATION
Unpacking
Remove Versaframe from carton and
protective packaging. Check for obvious
damage to the carton or its contents. If
damage is evident, do not use the prod-
uct; please notify the carrier and your
Graham-Field authorized distributor for
further instruction.
Installation
1. Remove existing toilet seat.
2. Place mounting bracket on at surface
of bowl and align holes. Ensure that
the tube on the bracket is to the rear,
closest to the tank.
3. Replace toilet seat, inserting bolts
through mounting bracket holes and
into toilet seat mounting holes. Re-
place original nuts and tighten.
4. Depress push buttons and install arms
in mounting bracket as shown.
5. Adjust width of Versaframe arms by
engaging push buttons in desired
holes in mounting bracket tube.
WARNING: Ensure that mounting
bracket push buttons are locked in
place before use.
Versaframe toilet
safety frame
push
button
mounting
bracket
lower leg
tip
arm

2 6460-INS-LAB-RevA09
© March 2009 GF Health Products, Inc. • 2935 Northeast Parkway • Atlanta, GA 30360 • tel [phone] • fax [phone] • www.grahameld.com
GF Health Products, Inc. is not responsible for typographical errors. Packaging, warranties, products and specications are subject to change without notice.
Graham-Field and Lumex are registered trademarks of GF Health Products, Inc.
Height Adjustment
1. Adjust height by depressing the lower leg height adjustment button, twisting the lower leg, and
moving leg to desired height.
2. When the desired height is reached, twist the lower leg until you hear the height adjustment
button click into place.
WARNING: Ensure that height adjustment push buttons are locked in place, and both legs
are adjusted to the same height, before use.
WARNING: Ensure that the Versaframe is installed as described. If the Versaframe is not
properly assembled and installed, personal injury and damage to the Versaframe could
result.
OPERATION
WARNING: Always ensure the Versaframe is securely installed before use.
MAINTENANCE
WARNING: Inspect the Versaframe weekly and tighten it as needed to ensure secure
installation. Check all rubber tips for tears, rips or wear. If any of these conditions exist,
replace tips IMMEDIATELY.
Caution: Never use abrasive cleaners or scouring pads on any part of the Versaframe.
To clean the Versaframe, wash it with soap and water or a mild detergent, then rinse it with water.
WARRANTY
GF Health Products, Inc. warrants the Lumex 6460A / 6460R / 6465A-1 Versaframe Toilet Safety
Frame as follows:
Limited lifetime warranty against manufacturer's defects. If a product is deemed to be under war-
ranty, GF Health Products, Inc. shall provide, at its option, (1) replacement of any defective part or
product or (2) a credit of the original selling price made to GF Health Products, Inc.'s initial cus-
tomer. The warranty does not include any labor charges incurred in replacement part(s) installa-
tion or any associated freight or shipping charges to GF Health Products, Inc.
