Gram KSI 401754/1 User manual

BUILT IN FRIDGE
User manual
FULDT INTEGRERBART KØLESKAB
Betjeningsvejledning
FULLT INTEGRERBART KJØLESKAP
Bruksanvisning
HELINTEGRERAD KYLSKÅP
Bruksanvisning
TÄYSIN INTEGROITAVA
Käyttöohje
KSI 401754/1
EN
DA
NO
SE
FI

EN
2
Index
BEFORE USING THE APPLIANCE................................. 3
General warnings...................................................................... 3
Safety warnings ........................................................................ 7
Installing and operating your fridge........................................... 8
Before using your fridge............................................................ 8
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS ........................................................... 9
Dimensions.............................................................................. 10
USAGE INFORMATION.................................................. 11
Display and Control Panel ........................................................11
Operating Your Fridge...............................................................11
Super Cool Mode..................................................................11
Economy Mode.................................................................... 12
Screen Saver Mode ............................................................. 12
Door Open Alarm Function .................................................. 13
Temperature Settings............................................................... 13
Cooler Temperature Settings ............................................... 13
Warnings About Temperature Adjustments.............................. 14
Accessories ............................................................................. 15
Fresh dial ............................................................................. 15
ARRANGING FOOD IN THE APPLIANCE..................... 16
CLEANING AND MAINTENANCE.................................. 17
Defrosting the Refrigerator Compartment................................ 18
Replacing the LED strip........................................................... 18
SHIPMENT AND REPOSITIONING................................ 19
BEFORE CALLING YOUR AFTER SALES SERVICE... 20
Tips for saving energy ............................................................. 22
TECHNICAL DATA.......................................................... 23
INFORMATION FOR TEST INSTITUTES....................... 24
CUSTOMER CARE AND SERVICE................................ 25

EN
3
BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
WARNING: When positioning the appliance, ensure
the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and installation
to prevent the cooler elements from being damaged.
R600a is an environmentally friendly and natural gas,
but it is explosive. In the event of a leak due to damage
of the cooler elements, move your fridge away from open
ames or heat sources and ventilate the room where the
appliance is located for a few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.

EN
4BEFORE USING THE APPLIANCE
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- sta󰀨 kitchen areas in shops, o󰀩ces and other work-
ing environments which can be equated with ordi-
nary household
- farm houses and by clients in hotels, motels and oth-
er residential type environments which can be equat-
ed with ordinary household
- bed and breakfast type environments which can be
equated with ordinary household
- catering and similar non-retail applications which can
be equated with ordinary household.
• The appliance is supplied with a plug approved in the
EU, which must not be used in a Danish installation, as
the unit thereby is not earthed acc. Local regulations.
Replacing the to Danish plug must be performed by
a qualied electrician. Alternatively, use an adapter
to transition between Schuko plug and Danish earth
system.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• Børn fra 3 til 8 år må lægge varer i og tage varer

EN
5
BEFORE USING THE APPLIANCE
ud af køleapparater. Børn forventes ikke at udføre
rengøring eller vedligeholdelse af apparatet. Meget
små børn (0-3 år) forventes ikke at bruge apparater.
Mindre børn (3-8 år) forventes ikke at kunne bruge
apparater på sikker vis, medmindre det sker under
supervision.Størrebørn(8-14år)ogsårbarepersoner
kan bruge apparater sikkert, når de superviseres
og har fået den nødvendige vejledning i brugen af
apparatet. Meget sårbare personer forventes ikke at
bruge apparater på sikker vis, medmindre det sker
under supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN
6BEFORE USING THE APPLIANCE
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip
onto other food.

EN
7
BEFORE USING THE APPLIANCE
Old and out-of-order fridges or freezers
• If your old fridge has a lock, break or remove the lock before
discarding it, because children may get trapped inside it and may
cause an accident.
• Old fridges and freezers may contain isolation material and
refrigerant with CFC or HFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and
using your appliance. We are not responsible for the damage
occurred due to misuse.
• Follow all instructions on your appliance and instruction manual,
and keep this manual in a safe place to resolve the problems that
may occur in the future.
• This appliance is produced to be used in homes and it can only be
used in domestic environments and for the specied purposes.
It is not suitable for commercial or common use. Such use will
cause the guarantee of the appliance to be cancelled and our
company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only
suitable for cooling / storing food. It is not suitable for commercial
or common use and/or for storing substances except for food.
Our company is not responsible for losses to be incurred in the
contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children
to play with the appliance or let them to hang over the door.
• Do not plug-in or out the plug from the receptacle with wet hands
to prevent electrocution!

EN
8BEFORE USING THE APPLIANCE
• Do not place explosive or ammable material in your fridge for
your safety. Place drinks with higher alcohol amount vertically
and by closing their necks tightly in the fridge.
• Do not cover the body or top of fridge with lace. This a󰀨ects the
performance of your fridge.
• Fix the accessories in the fridge during transportation to prevent
damage to accessories.
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to the
following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• We do not take the responsibility of the damages that occur due
to ungrounded usage.
• Place your fridge in a place that it would not be exposed to direct
sunlight.
• Your appliance should be at least 50 cm away from stoves, Gas
ovens and heater cores, and should be at least 5 cm away from
electrical ovens.
• Your fridge should never be used outdoors or left under the rain.
• When your fridge is placed next to a deep freezer, there should
be at least 2 cm between them to prevent humidity on the outer
surface.
• Do not place heavy items on the appliance.
• Do not place anything on your fridge, and install your fridge in
a suitable place so that at least 15 cm is available on the upper
side.
• The adjustable front legs should stabilized in an appropriate
height to allow your fridge operate in a stable and proper way.
You can adjust the legs by turning them clockwise (or in the
opposite direction). This should be done before placing food in
the fridge.
• Before using your fridge, wipe all parts with warm water added
with a tea spoonful of sodium bicarbonate, and then rinse with
clean water and dry. Place all parts after cleaning.
Before using your fridge
• When it is operated for the rst time or after transportation,
keep your fridge in the upright position for 3 hours and plug it
on to allow e󰀩cient operation. Otherwise, you may damage the
compressor.
• Your fridge may have a smell when it is operated for the rst time;
the smell will fade away when your fridge starts to cool.

EN
9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
This presentation is only for information about the parts of the appliance. Parts
may vary according to the appliance model.
1. Control panel
2. Turbo fan
3. Wine rack
4. Fridge shelves
5. Upper crisper cover
6. Upper crisper
7. Bottom crisper cover
8. Bottom crisper
9. Bottle shelf
10. Door shelf (Adjustable door shelf *)
11. Door shelf
12. Egg holder
13. Upper side LED strip *
14. Left / Right side LED strip *
General notes:
Fresh Food Compartment (Fridge): Most e󰀩cient use of energy is ensured in
the conguration with the drawers in the bottom part of the appliance, and shelves
evenly distributed, position of door bins does not a󰀨ect energy consumption.
* In some models

EN
10
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
Dimensions
560 - 570 mm
560 mm
(recommended)
min. 550 mm
1770 - 1790 mm
max 2100 mm
min 200 cm
2
min 40 mm
545 mm
540 mm
1770 mm
* 1770 - 1778 for metal top cover

EN
11
USAGE INFORMATION
Display and Control Panel
1 2 3 4 5 6
Using the Control Panel
1. Alarm indicator
2. Cooler set value screen.
3. Super Cool mode indicator
4. It enables the setting value of cooler to be modied and super cool mode to
be activated if desired. Cooler maybe set to 8, 6, 5, 4, 2 °C, super cool.
5. It enable the economy mode to be activated if desired.
6. Eco mode indicator
Operating Your Fridge
If your product has lighting
When the product is plugged in for the rst time, the interior lights may turn
on 1 minute late due to opening tests.
Super Cool Mode
How Would It Be Used?
Press cooler set button (#4 on control panel diagram) until Super cool symbol (#3)
will be seen on the screen. Buzzer will sound beep beep. Mode will be set.
During This Mode:
• Economy mode can not be selected.
• Super cool mode can be cancelled by the same operation of selecting.

EN
12 USAGE INFORMATION
Economy Mode
How Would It Be Used?
• Push "MODE" button (#5 on control panel diagram) until eco symbol appears.
• If no button is pressed for 1 second. Mode will be set. Eco symbol (#6) will
blink 3 times. When mode is set, buzzer will sound beep beep.
• Cooler temperature segments (#2) will show "E".
• Economy symbol and E will light till mode nishes.
During This Mode:
• Cooler may be adjusted. When economy mode will be cancelled, the selected
setting values will proceed.
• Super cool mode can be selected. Economy mode is automatically cancelled
and the selected mode is activated.
• To cancel, you will just need to press on mode button.
Screen Saver Mode
Purpose
This mode saves energy by switching o󰀨 all control panel lighting when the panel
is left inactive.
How to Use
• Screen saver mode will be activated automatically after 30 seconds.
• If you press any key while the lighting of the control panel is o󰀨, the current
machine settings will reappear on the display to let you make any change
you wish.
• If you do not cancel the screen saving mode or press any key for 30 seconds,
control panel will remain o󰀨.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of all, you need to press any key to
activate the keys and then press and hold the Mode button " " (#5) for 3
seconds.
• To reactivate screen saving mode, press and hold the mode button " " (#5)
for 3 seconds.

EN
13
USAGE INFORMATION
Door Open Alarm Function
If cooler door is opened more than 2 minutes, appliance sounds ‘beep beep’.
Temperature Settings
Cooler Temperature Settings
• Initial temperature value for the cooler setting indicator is +4 °C.
• Press the cooler button once (#4 on control panel diagram).
• When you rst push this button, the last value will appear on the cooler setting
indicator (#2).
• Whenever you press this button (#4), a lower temperature will be set. (+8°C,
+6°C, +5°C, +4°C, +2°C, super cool)
• When you push the cooler set button until the super cool symbol (#3) appears,
and if you do not push any button within 1 second, super cool will ash.
• If you continue to press the button(#4), it will restart from +8°C.
• The temperature value selected before super cool mode or economy mode is
activated and will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
Recommended Temperature Values for Cooler
When to adjust Inner Temperature (oC)
For cooling the fridge at minimum capacity 8
In normal usage 4, 5, 6
For cooling the fridge at maximum capacity 2

EN
14 USAGE INFORMATION
Warnings About Temperature Adjustments
• Do not pass to another adjustment before completing an adjustment.
• Temperature adjustments should be made according to the frequency of door
openings, the quantity of food kept inside the fridge and ambient temperature
of the place of your fridge.
• Your fridge should be operated up to 24 hours according to the ambient
temperature without interruption after being plugged in to be completely
cooled.
• Do not open doors of your fridge frequently and do not place much food
inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor
of your fridge, when you take the plug o󰀨 and then plug it on again to operate
it or when an energy breakdown occurs. Your fridge will start to operate
normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated
in the standards, according to the climate class stated in the information
label. We do not recommend operating your fridge out of stated temperatures
value limits in terms of cooling e󰀨ectiveness.
• This appliance is designed for use at an ambient temperature within the 10°C
- 38°C range.
Climate class and meaning:
T (tropical): This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C.
ST (subtropical): This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C.
N (temperate): This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C.
SN (extended temperate): This refrigerating appliance is intended to be used at
ambient temperatures ranging from 10 °C to 32 °C.

EN
15
USAGE INFORMATION
Accessories
Fresh dial
When the humidity controler in the closed position, it allows fresh fruit and
vegetables to be stored longer.
In case of the crisper is totally full, the fresh dial is located in front of crisper,
should be opened. By means of this the air in the crisper and humidity rate will be
controlled and endurance life will be increased.
If you see any condensation on glass shelf, humidity control should be taken into
the open positions.
Visual and text descriptions on the accessories section may
vary according to the model of your appliance.

EN
16 ARRANGING FOOD IN THE APPLIANCE
• To reduce humidity and consequent increase of frost never place liquids
in unsealed containers in the refrigerator. Frost tends to concentrate in
the coldest parts of the evaporator and in time will require more frequent
defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to
cool at room temperature and should be arranged to ensure adequate air
circulation in the refrigerator.
• Nothing should touch on the back wall as it will cause frost and the packages
can stick on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned sh (wrapped in packages or sheets of plastic)
which you will use in 1-2 days, in the bottom section of the refrigerator (that
is above the crisper) as this is the coldest section and will ensure the best
storing conditions.
• You can put the fruits and vegetables into crisper without packing.
• For normal working conditions, it will be su󰀩cient to adjust the temperature
setting of your refrigerator to +4 °C.
• The temperature of the fridge compartment should be in the range of 0-8 °C,
fresh foods below 0 °C are iced and rotted, bacterial load increases above
8 °C, and spoils.
• Do not put hot food in the refrigerator immediately, wait for the temperature
to pass outside. Hot foods increase the degree of your refrigerator and cause
food poisoning and unnecessary spoiling of the food.
• Meat, sh, etc. should be store in the chiller compartment of the food, and the
vegetable compartment is preferred for vegetables. (if available)
• To prevent cross contamination, meat products and fruit vegetables are not
stored together.
• Foods should be placed in the refrigerator in closed containers or covered to
prevent moisture and odors.

EN
17
CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other
electrical components.
• The refrigerator should be cleaned periodically using a solution
of bicarbonate of soda and lukewarm water.
• Clean the accessories separately with soap and
water Do not clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps.After washing,
rinse with clean water and dry carefully. When you have nished
cleaning, reconnect the plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will
help you to save on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.

EN
18
Defrosting the Refrigerator Compartment
• Defrosting occurs automatically in the refrigerator compartment during
operation; the water is collected by the evaporation tray and evaporates
automatically.
• The evaporation tray and the water drain hole should be cleaned periodically
with the defrost drain plug to prevent the water from collecting at the bottom
of the refrigerator instead of owing out.
• You can also clean the drain hole by pouring ½ glass of water down it.
Replacing the LED strip
1 or 2 led strips in fridge is used to illumianate your appliance. Please call the
service man.
Note: Numbers and location of led strips may be changed according to the model.
!!! Some versions may be without illumination.
CLEANING AND MAINTENANCE
Upper side LED strip
(In some models)
Left / Right side LED strip
(In some models)

EN
19
SHIPMENT AND REPOSITIONING
Transportation and Changing of Installation Position
• The original packages and foamed polystyrene (PS) can be
retained if required.
• During transportation, the appliance should be secured with
a wide string or a strong rope. The instructions written on the
corrugated box must be followed while transporting.
• Before transporting or changing the installation position, all the
moving objects (ie,shelves,crisper…) should be taken out or
xed with bands in order to prevent them from getting damaged.
Carry your fridge in the upright position.

EN
20 BEFORE CALLING YOUR AFTER SALES SERVICE
If your fridge is not working properly, it may be a minor problem, therefore check the
following, before calling an electrician to save time and money.
ERROR TYPE MEANING WHY WHAT TO DO
E01 Sensor warning Call Service for assistance as
soon as possible.
E02 Sensor warning Call Service for assistance as
soon as possible.
E03 Sensor warning Call Service for assistance as
soon as possible.
E06 Sensor warning Call Service for assistance as
soon as possible.
E07 Sensor warning Call Service for assistance as
soon as possible.
E08 "Low voltage
Warning"
When the power supply
gets lower than 170 V
the appliance gets to
steady position.
• This is not a failure. This
prevents any damages
on the compressor. This
warning will o󰀨 after the
voltage gets required
level.
• If the warning continues,
please contact with
authorized technical
service.
E10 "Refrigerator comp.
Not Cold enough"
Ideal temperature for
Ref. Compartment is
+4 oC. If you see this
warning your foods
have risk of spoiling.
This warning
becomes visible
if electricity is o󰀨
for a long time
(most probably) or
the refrigerator is
activated for the
rst time or hot food
is loaded to the
appliance.
1. Set the refrigerator
temperature to colder values
or set the super cooling
mode until the compartment
gets to normal temperature.
2. Do not open the door
much until this failure is o󰀨.
3. Please empty the location
at the front area of air duct
channel holes.
4. Please be careful while
loading the appliance in order
not to avoid the ventilation
at the areas which are very
close to the sensor.
5. Please don’t open the
refrigerator doors frequently
until the warning disappears.
6. If the warning continues,
please contact with
authorized technical service.
