Grandbeing EX0101-OP5 User manual

Model No.: EX0101-OP5/OP6
Operating Instructions
Thanks for purchasing our product.
Please be sure to read this instruction manual
carefully before using our product.

Introduction
EX0101-OP5/OP6 is a HDMI extender while using single mode optical fiber as
transmission media.
Benefits from using EX0101-OP5/OP6:
1) By using EX0101-OP5/OP6, the transmission distance for 1080P reaches
5Km. For general HDMI cables, cables must be customized when the
length over 10 meters.
2) EX0101-OP5/OP6 has the ability of buffering and amplifying. Series
connection of EX0101-OP5/OP6 achieves long distance transmission of
HDMI signal. When two pairs or more EX0101-OP5/OP6 are sacked
together, they can be used to create a larger distribution (Daisy chained.)
EX0101-OP5/OP6 offers solutions for digital entertainment center, HDTV retail
and show site, HDTV, STB, DVD and Projector factory, noise, space and security
concerns, data center control, information distribution, conference room
presentation, school and corporate training environments.

Contents
HDMI Extender................................................................................................1
Product Overview ............................................................................................1
Features...........................................................................................................1
Package Contents............................................................................................3
Connections and Operations ...........................................................................3
Specifications...................................................................................................4
Panel Descriptions...........................................................................................5
Typical Application...........................................................................................7
Maintenance....................................................................................................7
Product Service ...............................................................................................8
●Provided Service ..........................................................................................8
●Mail-In Service..............................................................................................8
●Warranty.......................................................................................................9
●Warranty Limits And Exclusions....................................................................9

HDMI Extender(By single mode optical fiber)
■Product Overview ( Model Number: EX0101-OP5/OP6 )
■Features
zUse single mode optical fiber to substitute HDMI cable to achieve long
distance transmission.
zTransmission distance reaches up to 5Km under the video format of 1080P.
zAuto-adjustment of feedback, equalization and amplify, the user does not
need to care about the length of the fiber.
zHDMI V1.3 supported.
zHDCP compliant.
zFull HD support: 1080p@60Hz.
zWith LEDs indicators to show the power status and the signal staus.
zWith ESD protection inside.
zMounting ears supplied.
zThis model could be cascaded.

"Notice
We reserve the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
p
lu
g
s.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.

■Package Contents
① Main unit NO.1. P/N_EX0101-OP5.
② Main unit NO.2. P/N_EX0101-OP6.
③ Operating instructions. P/N_INSEX0101-OP5/OP6.
④ 2x 5VDC power supply P/N_VDC0502.(One for OP5, one for OP6)
NOTE: PART NUMBER (Abbreviation as P/N)
■Connections and Operations
1) Connect the HDMI input source ( such as HD-DVD、PS3、STB etc. ) to
EX0101-OP5.
2) Connect a single mode optical fiber from optical output of EX0101-OP5 to
optical input of EX0101-OP6.
3) Connect the HDMI sink( such as HD-LCD、HD-DLP) to EX0101-OP6.
Attention: Please insert and extract cables gently.
※DIP switch setting instruction:
EX0101-OP5
Position1 Function
0 Range scaling disenable.
1 Range scaling enable.
Position2 Position3 Function
0 0 1080P stereo (Using Embedded EDID) (note1)
0 1 1080P 5.1 (Using Embedded EDID) (note2)
0 1
1080P 7.1 (Using Embedded EDID) (note3)
1 1
1080I stereo (Using Embedded EDID) (note4)

Note1: The OP5 will use the embedded 1080P-stereo EDID when the DIP switch is in this
mode. The EDID will be 1080P video and stereo audio.
Note2: The OP5 will use the embedded 1080P-5.1 EDID when the DIP switch is in this mode.
The EDID will be 1080P video and 5.1 audio.
Note3: The OP5 will use the embedded 1080P-7.1 EDID when the DIP switch is in this mode.
The EDID will be 1080P video and 7.1 audio.
Note4: The OP5 will use the embedded 1080I-stereo EDID when the DIP switch is in this
mode. The EDID will be 1080I video and stereo audio.
EX0101-OP6
Position1 Position2 Position3 Function
0 0 0 Normal mode, 8bit color depth
0 0 1 LC mode(note1), 8bit color depth
0 1 0 Normal mode,color depth decided by the sink.
0 1 1
LC mode (note1), color depth decided by the
sink.
others Normal mode,8bit color depth
Note1: if video appears noise or interference when the long HDMI cable is used or the quality
of HDMI cable is not so good, use this mode.
■Specifications
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Video Format Supported DTV/HDTV; 1080P/720/1080i/576i/480i

Output Video HDMI 1.3+HDCP
(repeat the source to the sink)
Output Audio Support 7.1/5.1/stereo audio (PCM
only)
Maximum Transmission Distance 5Km
Power Supply 5VDC
Power Consumption 5Watts (EX0101-OP5)
5Watts (EX0101-OP6)
Dimensions 125mmH×120mmW×31mmD
/5.98’’W×4.13’’H×1.22’’D
Mass (Main unit) 0.9Kg / 1.98lb (Pairs)
NOTE1: Specifications are subject to change without notice. Mass and dimensions are
approximate.
■Panel Descriptions
1. EX0101-OP5

1. Status of power input. When power input on, the LED inside lights.
2. Status of signal connection. When this works well, the LED inside lights.
3. HDMI input.
4. Power input, 5VDC.
5. Mode setting. Use for setting the EDID.
6. Optical output.
7. ISP port. Use for updata the firmware.
2. EX0101-OP6

1. Status of power input. When power input on, the LED inside lights.
2. Status of signal connection. When this works well, the LED inside lights.
3. HDMI output.
4. Power input 5VDC.
5. Mode setting. Use for setting the work mode.
6. Optical input.
7. ISP port. Use for updata the firmware.
■Typical Application
■Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine
to clean this unit.

■Product Service
●Provided Service
1) Damage Requiring service: The unit should be serviced by qualified
service personnel if:
zThe DC power supply cord or AC adaptor has been damaged;
zObjects or liquids have gotten into the unit;
zThe unit has been exposed to rain;
zThe unit does not operate normally or exhibits a marked change in
performance;
zThe unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to
authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the service uses
parts specified by the manufacturer or parts that have the same
characteristics as the original parts. Unauthorized substitutes may result
in fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the service to perform safety
checks to confirm that the unit is in proper working condition.
●Mail-In Service
When shipping the unit, carefully pack and send it prepaid, adequately insured
and preferably in the original carton. Include a letter detailing the complaint and
provide a daytime phone and/or email address where you can be reached.
If repair is needed during the limited warranty period the purchaser will be
required to furnish a sales receipt/proof of purchase indicating date of
purchase, amount paid and place of purchase. Customer will be charged for
the repair of any unit received without such proof of purchase.

●Warranty
If your product does not work properly because of a defect in materials or
workmanship, we (referred to as “the warrantor”) will, for the length of the
period indicated as below,（Parts (1) Year, Labor(90) Days）which starts with
the date of original purchase (“Limited Warranty period”), at its option either (a)
repair your product with new or refurbished parts, or (b) replace it with a new or
a refurbished product. The decision to repair or replace will be made by the
warrantor.
During the “Labor” Limited Warranty period there will be no charge for labor.
During the “Parts” warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is
extended only to the original purchaser and only covers product purchased as
new. A purchase receipt or other proof of original purchase date is required for
Limited Warranty service.
●Warranty Limits And Exclusions
1) This Limited Warranty ONLY COVERS failures due to defects in
materials or workmanship, and DOES NOT COVER normal wear and
tear or cosmetic damage. The Limited Warranty ALSO DOES NOT
COVER damages which occurred in shipment, or failures which are
caused by products not supplied by the warrantor, or failures which result
from accidents, misuse, abuse, neglect, mishandling, misapplication,
alteration, faulty installation, set-up adjustments, misadjustment of
consumer controls, improper maintenance, power line surge, lightning
damage, modification, or service by anyone other than a Factory Service
Center or other Authorized Service, or damage that is attributable to acts
of God.
2) There are no express warranties except as listed under “limited

warranty coverage”. The warrantor is not liable for incidental or
consequential damages resulting from the use of this product, or
arising out of any breach of this warranty. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install an
installed unit if applicable, travel to and from the service location, loss of
or damage to media or images, data or other recorded content. The items
listed are not exclusive, but are for illustration only.)
3) Parts and service, which are not covered by this limited warranty,
are your responsibility.
