Grape Solar GS-600-KIT-BT-INV Assembly instructions

www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000 Document Version 220425
©Copyright 2020, Grape Solar, Inc. All Rights Reserved
600 Watt Off-Grid Charging Kit
(GS-600-KIT-BT-INV)
Quick Connect Guide
IMPORTANT: Please read GS-PWM-COMET-40 charge
controller and Xantrex Prowatt SW 2000 inverter owner’s
manual, and GS-STAR-200W solar panel Connection Guide
(included with products) before assembling kit.
For additional information about Grape Solar products:
email [e-mail], or
GS-600-KIT-BT-INV PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE REV. 220425
1Check your order to make sure that all parts are included:
 GS-PWM-Comet40 Charge Controller
 3x 20-Amp MC4 In-Line Fuse
 2x MC4 Branch Connector Set
 3x GS- STAR-200W Solar Panel
 5-ft. Red/Black 10 AWG Cable Pair
 15-ft. MC4-to-Bare-Wire Cable Pair
 5-ft. Red/Black Lug-to-Lug Cable Pair
 Xantrex Prowatt SW 2000 Inverter
Additional tools and equipment you will need:
◦Screwdriver– Philips Head ◦Electrical Gloves
◦12-Volt Deep-Cycle Battery Bank ◦Voltmeter (for Troubleshooting)

x3

x2



x3

To estimate how much average monthly
power this system should produce in your
area, please use the PV Watts Calculator
found at:
https://pvwatts.nrel.gov/
This System Size= 0.60 kW DC
(only applicable for zip codes in the U.S.A.)

[The Quick Connect Guide
diagrams are not to scale.]


www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000
Document Version 220425
©Copyright 2021, Grape Solar, Inc. All Rights Reserved
4Branch connector sets  are typically clipped
together when shipped. Unclip the branch
connectors until there are 4 separate units.
Connect one branch connector  with the
“female” output to the “male” end of a 15-ft.
MC4-to-Bare-Wire cable . Connect an
additional “female” output branch connector
 to the attached branch connector.
With the other 15-ft MC4-to-Bare-Wire cable ,
connect one branch connector  with the “male”
output to the “female” end of the cable. Connect an
additional “male” output branch connector  to the
attached branch connector.
Now, attach an in-line fuse  to each of the “female”
inputs. There are a total of 3 in-line fuses in this
kit, matching a total of 3 “female” open inputs.
5
Mount the 200-watt solar panels  so that they are facing due South at approximately the same angle as your
latitude. The ideal area has full sun and no shading. If the following connections are made during daylight, cover
the panels with cardboard, cloth, or a similar opaque material so that the panel does not output power.
Connect the bare wire end of the 10 AWG (thinner) red
battery cable  to the (+) battery terminal on the bottom
of the Comet40 charge controller . Connect the bare
wire end of the 10 AWG (thinner) black cable  to the
(-) battery terminal. A Phillips head screwdriver can be
used to loosen and tighten the screw clamps onto the
wires.
Attach the ring lug end of the red cable  to the positive
terminal of a 12V deep cycle battery. Attach the ring lug
end of the black cables  to the negative terminal of the
battery.
The charge controller  display screen will be visible if
the battery has sufficient charge. If the display screen is
not visible, the battery must be charged from an another
source before processing solar power. The charge con-
troller, which regulates solar power flow to the battery, is
powered by the battery.
2
3
 

*12V deep cycle battery
is not included with kit
 




input side
output side
 


GS-600-KIT-BT-INV PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE REV. 220425

6
www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000
Document Version 220425
©Copyright 2021, Grape Solar, Inc. All Rights Reserved
Connect each positive solar panel  cable to
one of the “female” fuse  ends from the
previous connections.
Connect the negative panel cables to the
“male” branch  connector ends .
Attach the bare-wire ends of the 15 ft MC4-to-Bare Wire cable pair  to the charge controller . Make sure the
polarity is matched correctly between the cable and the charge controller input receptor.
7











 





GS-600-KIT-BT-INV PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE REV. 220425

8
www.GrapeSolar.com
Tel. [phone] (toll free), 1-541-349-9000
Document Version 220425
©Copyright 2021, Grape Solar, Inc. All Rights Reserved
Remove the panel covering. In good sunlight, the charge controller’s  ”BAT %” should increase to 100%.
When the controller is set to “LOAD ON,” the system will provide power through the load control output or
through the USB port.
Electrical gloves are required for this step.
Unscrew the screw nuts on the back of the Xantrex Prowatt SW 2000 inverter. Connect the ring lug end of
the 4 AWG (thicker) red battery cable  to the positive terminal on the back of the Xantrex Prowatt SW 2000
inverter . Connect the ring lug end of the 4 AWG (thicker) black battery cable  to negative terminal of the
Xantrex Prowatt SW 2000 inverter . Tighten the screw nuts to lock the ring lugs in place.
Attach the other ring lug end of the 4 AWG red battery cable  to the positive terminal of a 12V deep cycle
battery. Attach the ring lug end of the 4 AWG black battery cable  to the negative terminal of the battery.
Press the power button once and the inverter should turn on if the battery has sufficient charge.
9





GS-600-KIT-BT-INV PHOTOVOLTAIC
POWER GENERATION SYSTEM
QUICK CONNECT GUIDE REV. 220425
