INSTRUCTION MANUAL
GATOR®ES32
Battery-powered
Cable Cutter
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
99975815 REV 8 © 2008 Greenlee Textron Inc. 7/08
Serialnummer

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
2
Description
The ES32 Battery-powered Cable Cutter is a hand-held,
self-contained cutting tool intended to cut aluminum
and copper cable only.
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This manual and any
markings on the tool provide information for avoiding
hazards and unsafe practices related to the use of this
tool. Observe all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation and maintenance procedures for the
following Greenlee tool:
ES32 Battery-powered Cable Cutter
Keep this manual available to all personnel.
Replacement manuals are available upon request at
no charge at www.greenlee.com.
All specications are nominal and may change as design
improvements occur. Greenlee Textron Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
GATOR is a registered trademark of Greenlee Textron Inc.
Tellus is a registered trademark of Shell Oil Company.
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Important Safety Information ..................................... 3–4
Identication................................................................... 5
Specications................................................................. 5
Operation........................................................................ 6
Maintenance................................................................... 7
Troubleshooting.............................................................. 8
Illustrations ............................................................... 9–10
Parts List ...................................................................... 11

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
3
IMPORTANT SAFETY INFORMATION
SAFETY
ALERT
SYMBOL
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, dened below,
indicates the severity of the hazard. The message
after the signal word provides information for pre-
venting or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result
in severe injury or death.
Hazards which, if not avoided, COULD result in
severe injury or death.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Failure to observe this warning
could result in severe injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Skin injection hazard:
Do not use hands to check for oil
leaks. High pressure oil easily
punctures skin causing serious
injury, gangrene, or death. If injured,
seek medical help immediately to
remove oil.
Do not use solvents or ammable
liquids to clean the cutting tool.
Solvents or ammable liquids could
ignite and cause serious injury or
property damage.

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
4
Cutting hazard:
Keep hands away from the cutting
head when cutting.
Failure to observe this warning
could result in severe injury or death.
Do not dispose of batteries in a re. They will vent
fumes and may explode.
Failure to observe this warning could result in severe
injury from harmful fumes or burns from ying
debris.
Inspect tool and blades before use. Replace any
worn or damaged parts. A damaged or improp-
erly assembled tool can break and strike nearby
personnel.
Failure to observe this warning could result in severe
injury or death.
This tool is not designed for continuous use. After •
100 cutting cycles, allow the cutter to cool for 15
minutes.
Do not place the tool in a vise. The cable cutter is•
designed for hand-held operation.
This tool may be used in damp or wet environ-•
ments; however, we recommend air-drying the tool
before use if it becomes soaked.
Use this tool for the manufacturer’s intended •
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Do not cut ACSR or steel.
Do not allow anything to contact the battery
terminals.
Do not immerse the batteries in liquid. Liquid may •
create a short circuit and damage the battery.
If batteries are immersed, contact your service
center for proper handling.
Do not place the battery into a pocket, tool pouch, •
or tool box with conductive objects. Conductive
objects may create a short circuit and damage the
battery.
Do not place a battery on moist ground or grass.•
Moisture may create a short circuit and damage
the battery.
Failure to observe these precautions may result in
injury or property damage.
Do not store the battery at more than 60 °C •
(140 °F). Damage to the battery can result.
Do not use another manufacturer’s charger. Other •
manufacturers’ chargers may overcharge and
damage the battery.
Do not attempt to open the battery. It contains no•
user-serviceable parts.
Failure to observe these precautions may result in
injury or property damage.
Do not perform any service or maintenance other
than as described in this manual. Injury or damage
to the tool may result.
Failure to observe this precaution may result in injury
and property damage.
Note: Keep all decals clean and legible, and replace
when necessary.
IMPORTANT SAFETY INFORMATION

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
5
Identification
Specifications
Cutting Tool
Length ........................................................................................... 400 mm (15-3/4")
Width................................................................................................. 60 mm (2-3/8")
Depth............................................................................................... 108 mm (4-1/4")
Mass/Weight (with battery)...................................................................0.8 kg (1.8 lb)
Sound Level .............................................................................. 75 dB (A) at 1 meter
Vibration .................................................................................................... < 2.5 m/s2
Hydraulic Oil...................................................................................Shell Tellus®T 15
Cutting Capacities
Maximum Cable Size with 2 cutting cycles .................. 500 kcmil (MCM) (300 mm2)
(Aluminum & Copper)
Maximum Cable Size with 1 cutting cycle .................... 400 kcmil (MCM) (240 mm2)
(Aluminum & Copper)
Average Cutting Time....................................................................................2 seconds
Average Cuts per Charge.............................................................approximately 150
Battery
Charging Voltage............................................................................................... 9.6 V
Charging Time.................................................................................................45 min
1. Cutting Head
2. Retract Button
3. Battery Lock
4. Battery Cartridge
5. Trigger
6. LED Display
3
2
1
4
5

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
6
Operation
Electric shock hazard:
This tool is not insulated. When
using this unit near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Cutting hazard:
Keep hands away from the cutting
head when cutting.
Failure to observe this warning
could result in severe injury or death.
This tool is not designed for continuous use. After •
100 cutting cycles, allow the cutter to cool for 15
minutes.
Do not place the tool in a vise. The cutting tool is•
designed for hand-held operation.
This tool may be used in damp or wet environ-•
ments; however, we recommend air-drying the tool
before use if it becomes soaked.
Use this tool for the manufacturer’s intended •
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Charging the Battery
Read the instructions supplied with the battery charger.
LED Display
This tool is equipped with a special circuit board
incorporating several important features to inform
the user about the currect status of the unit. The LED
signals in the following cases:
Signal Duration When it occurs What it means
a few seconds
of flashing
battery
insertion self check - O.K.
glowing for
20 seconds after cut battery discharged
flashing for
20 seconds (2Hz)
after cut time for inspection and
preventive maintenace
20 seconds
glowing and
flashing
intermittently
after cut
battery discharged
—time for inspection
and preventive
maintenance
Cutting Cable
1. Insert the cable to be cut into the cutting head.
2. Pull the trigger to make the cut.
3. Hold the trigger down until the cutting tool achieves
pressure relief, which is accompanied by an audible
“pop”.
4. The cutting tool returns automatically.
Note: For some cables more than one cutting cycle may
be required to complete the cut. If the cable is not fully
cut during the first cycle, move the cable as close to the
jaw pivot as possible and cycle the tool again.
Note: If it is necessary to retract the ram before a cutting
cycle is completed, push the retract button. Pushing
the retract button will result in the complete retraction
of the ram.

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
7
Maintenance
Each Operating Day
Before use:
1. Inspect blades for wear or damage such as cracks,
gouges, or chips.
2. Inspect the tool for damage or leaks. If damage is
detected, return the tool to an authorized Greenlee
service center for inspection.
Skin injection hazard:
Do not use hands to check for oil
leaks. High pressure oil easily
punctures skin causing serious
injury, gangrene, or death. If injured,
seek medical help immediately to
remove oil.
After use:
1. Wipe all tool surfaces clean with a damp cloth and
mild detergent.
Do not use solvents or ammable
cleaners to clean the tool body.
Solvents could ignite, causing
serious injury or property damage.
2. Fully retract the ram. Place the tool in the carrying
case. Store in a cool, dry place.
3. Charge the battery.
Monthly
Thoroughly clean all surfaces.
Annually or After 10,000 Cuts
Return the tool to a Greenlee Authorized Service Center
for inspection.

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
8
Troubleshooting
Before You Begin
1. Make sure that the battery is charged. Recheck the battery after several minutes to make sure the battery is
holding its charge.
2. Use a nonflammable contact cleaner or pencil eraser to clean the electrical contacts on the battery and
cutting tool.
3. Reinstall the battery and check the tool again.
Problem Probable Cause Probable Remedy
Tool is inoperative. Dirt, contaminants, etc., in ram area
of tool.
Clean tool.
Cutting tool battery contacts
damaged.
Reform contacts.
Tool components worn or damaged. Return tool to a Greenlee Authorized
Service Center.
Blades stop during operation. Oil level is low. Return tool to a Greenlee Authorized
Service Center.
Air in hydraulic system. Pull trigger and hold retract button
simultaneously. Hold for approximately
10 seconds.
LED glows for 20 seconds. Battery charge low. Charge or replace battery.
Tool loses oil. Damaged internal seal. Return tool to a Greenlee Authorized
Service Center.

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
9
Illustrations—Main
7
90
14
141
10 11
146
12
15
144
143
147
16
142
148
145
140
140
13
141
93
104
103
93 100
96
94
92
91
95
97
17
98
99
101
102

ES32 Battery-powered Cable Cutter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
10
Illustrations (cont’d)
Pump Housing Unit, Relief Valve Unit, and Piston Pump Assembly
Motor Assembly
56
54
53
52
55 50
30
31
32
33
34
35
36 37
38
39
51
123
122
121
120
50
70
71
72
73
74
76
78
75
79
