GREENS OXI User manual

ADJUSTING FLOW LIMITER:
A flow limiter is fitted to this mixer to limit the flow of water in high pressure situations.
1. Remove handle by loosening grub screw through access hole under the handle button
with a 2.5mm Allen key.
2. Turn mixer on full and wind in grub screw clockwise to achieve desired flow rate.
3. Replace handle.
ADJUSTING ANTI-SCALD RING:
An anti-scald ring is fitted to this mixer to limit the maximum movement of the handle when
turned to the “HOT” position.
Ex factory the cartridge is set to the maximum HOT water flow.
1. Remove handle by loosening grub screw through access hole under the handle button
with a 2.5mm Allen key. Unscrew cover sleeve.
2. Lift the red anti-scald ring sufficiently to disengage. Turn anti-clockwise and replace until
the desired maximum temperature is obtained. Each notch on the ring gives a tempera-
ture change of approximately 2°C.
3. Replace cover sleeve and handle.
OXI SHOWER MIXER
(For All Pressure Installations)
INSTALLATION INSTRUCTIONS
#41690 01/19
BATCH #
PRODUCT #
ATTENTION PLUMBER
To ensure the optimum performance and customer satisfaction please adhere to the following:
 Flush out all pipe work prior to installation
 Installation shall be in accordance with the AS/NZS3500 series of standards.
The maximum operating pressure within any building should not exceed 500kpa.
Pressure above 500kpa can cause damage from water hammer, reducing life of appliances,
taps and fittings and cause excessive noise in the plumbing system.
 Pressure over 1000kPa will require a limiting valve.
 Inline filters must be installed on both hot and cold supplies.
TECHNICAL DATA
 Minimum Water pressure for satisfactory operation: 20kPa
 Maximum Water pressure: 1000KPa
 Maximum hot water temperature: 70ºC
If the Water temperature exceeds 70ºC an approved Tempering Valve must be fitted.
 The flow rate of the sink and basin mixers has been rated under the Australian Water
Efficiency Labeling Scheme (WELS).
Please leave this form with the product once installed.
For full warranty terms and conditions, please see the warranty card enclosed with this product
or visit www.greenstapware.com/warranty-and-care/
Distributed by: Greens Global (Australia) Ltd
10/101 Wedgewood Rd, Hallam, Victoria 3803
Phone: [phone] Fax: [phone]
Email: [email protected]
Website: www.greenstapware.com
Service Hotline: [phone]

Faceplate nut (4 grooves)
Cover sleeve (4 lugs)
Nut trim ring
Faceplate
Handle
Insert
Grub screw
Button
HC
Note: The Mixer can be mounted 47-65m behind finished wall surface.
Locate the correct position of the mixer by ensuring the “Hot” inlet (H), enters from the left,
when the outlet to the shower is at the top.
Note: Unequal pressure only install the adjustable flow limiter.
Installing Valve Body:
1. Remove the cover sleeve, white plastic nut and trim ring by gripping the cover sleeve
and turning anti-clockwise.
2. Position the mixer against a mounting board within the maximum and minimum
depth allowed and fix.
3. Unequal Pressure Only: Install the adjustable flow limiter.
a. To the mains cold water inlet, on right hand side of valve body.
b. Slotted screw head is to be accessible for adjustment purposes.
c. Do not install for equal pressure installations.
4. Connect water supply to the mixer and from the mixer to the shower outlet.
a. Do not pressure test with valve in the open position when the outlet is closed .
b. Turn on water supply to the mixer and check for leaks.
5. Cut out an access hole in the wall lining for the mixer, as per drawing and fix lining
in place.
Install Trim Set:
1.. For Unequal pressure, adjust the flow regulator before installing the face plate.
a. Adjust the volume of cold water to match the hot water.
b. The shower rose/slide shower must be installed before making adjustment.
2. To secure the faceplate to the wall, remove the protective tape from the seal and
slide the faceplate over the mixer body and position against the wall lining.
a. Sealant will be required behind faceplate on uneven surfaces for water seal.
3. Slide the cover sleeve inside the 4 grooves of the faceplate nut and install to the
valve body using the cover sleeve as a tool and tighten.
a. Apply grease to the O-ring on the valve body for cover sleeve install.
b. Note: The edge of the faceplate nut holds the faceplate firm against the
finished wall.
c. Sealant will be required behind faceplate on uneven surfaces for water seal.
4. Slide the nut trim cover over cover sleeve and against the faceplate.
5. Install the handle onto the cartridge lever and tighten the screw under the handle
fit button.
PTO
INSTALLATION INSTRUCTIONS
SHOWER MIXER
