GrillChef 12736 User instructions

12736
Version: 12736uk
reVision: #020-2012
edition: 09/12er
"Gas barbecue kitchen"
Assembly and operating manual
Please read before starting!
Failure to observe these instructions can aect or damage the device and other objects and lead to personal injury.
We therefore recommend that you read the relevant chapter of these instructions prior to assembly and
before each use. Follow the steps in the order they are specied and please observe the safety warnings.
These instructions form part of the product. They should therefore always be
stored with the product and passed on to each subsequent user.


2GRILLCHEF
Table of contents
Technical specications...............................................................................................................................3
Delivery specications.................................................................................................................................4
Exploded View.............................................................................................................................................5
Controls.......................................................................................................................................................6
Utilisation ...................................................................................................................................................7
Warranty and disclaimer.............................................................................................................................7
Safety instructions ......................................................................................................................................8
Denition of terms used.......................................................................................................................8
Danger "Hot surfaces and parts" ..........................................................................................................9
Danger "Gas is highly ammable"......................................................................................................10
Danger "Gas displaces oxygen" ..........................................................................................................11
Assembly ..................................................................................................................................................12
Assembly procedure..................................................................................................................................13
Connecting and disconnecting the gas cylinder........................................................................................21
Connecting the Gas Cylinder...............................................................................................................21
Operation..................................................................................................................................................23
Starting up the burner........................................................................................................................23
Starting up the sideburner .................................................................................................................24
Switching o the barbecue.................................................................................................................24
Cleaning....................................................................................................................................................25
Grill ....................................................................................................................................................25
Gas system .........................................................................................................................................25
Maintenance.............................................................................................................................................26
Environmental information and disposal measures ..................................................................................26
Troubleshooting........................................................................................................................................27
Instructions for using liquid gas cylinders .................................................................................................28
Declaration of conformity .........................................................................................................................29

3
GRILLCHEF
Technical specications
Approvals
ITS Test number - 0359, Pin/no. 359CL1126
Barbecue
Appliance category I3+ according to DIN EN 498
Total weight approx. 29 kg
Dimensions (L x H x W) approx. 1260 x 1055 x 530 mm
Grilling surface (L xW) 2 x approx. 400 x 275 mm
Gas system
Heat output 3x 3,2 kW + 1x 3,2 kW (total heat Input 12,8kW)
Mass ow rate 3x 228,5 g/h + 1x 228,5 g/h = 914 g/h
Gas type Liquid gas (propane/butane)
Gas cylinder Standard gas cylinder with a ll weight of 7 or 11 kg
Gas pressure 28-30 mbar at butane, 37 mbar at propane
Gas hose -approved hose (max 1.5 m)
Ignition Piezo ignition
Flame regulator innitely adjustable 0 - max.
Nozzle diameter 0,85 mm, side burner 0,85 mm

4GRILLCHEF
Exploded View
Delivery specications
Pos*. Qty. Description Pos.* Qty. Description
1 1 Grill unit (pre-assembled) 16 1 Door bracket
2 1 Side shelf 17 1 Knob
3 2 Car bracket 18 1 Knob base
4 1 Trolley back-side panel 19 1 Side burner shelf
5 1 Cart bottom panel 20 1 Igniter wire
5a 1 Magnet 21 1 Side burner
6 2 Trolley side panel 22 1 Side burner rack
7 1 Right back leg 23 2 Cooking grid
8 1 Right front leg 24 3 Flame tamer
9 1 Right door 25 1 Grease tray
10 2 Door handle 27 2 Wheel cap
11 1 Left Door A 44 Bolt M6x10
12 2 Wheel C 6 Bolt M4x10
13 2 Wheel axle D 2 Bolt M3x10
14 1 Left front leg E 2 Nut M3
15 1 Left back leg B 2 Clip
5a

5
GRILLCHEF

6GRILLCHEF
Controls
Pos. Designation Function
B Flame regulator middle Fill burner with gas to ignite (keep depressed and turn to
„large ame“ setting).
After igniting set the heat output for the centre burner (turn).
left Fill burner with gas to ignite (keep depressed and turn to
„large ame“ setting).
After ignition adjust the heat input for the left burner (turn).
right Ignite the right burner (keep depressed briey and turn to
"large ame" setting).
After ignition adjust the heat supply for the right burner (turn).
1 Pressure reducer Reduce gas pressure.
2 Gas cylinder for bottle valve Fuel container
3 Rubber hose Directs gas to burner
4 Proper hose clip Fuel container
5 Regulator handle Cut-o safety device with 2 settings:
„-“ setting: Gas o / shut o gas cylinder
„ame“: Gas is on.
Gas o:
Gas on:

7
GRILLCHEF
Utilisation
Intended use
Thisisa gas barbecue intendedfor outdoor use only.Itis designed tobe used exclusivelyin accordancewiththeseinstructions
for preparing food that is suitable for barbecuing and these instructions must be observed at all times.
Only for private use!
Improper use
Any other application or applications extending beyond the stated purpose are not authorised. This applies to the following
types of misuse in particular:
• Do not operate the barbecue with coal or fuel other than liquid gas (propane/butane).
• Do not operate the barbecue as a stove with pots and pans.
• Do not operate the barbecue as a heater.
Do not use the barbecue to heat materials and substances other than food that is suitable for barbecuing.
Warranty and disclaimer
The barbecue has been manufactured according to the general engineering rules - valid at the time manufacturing was
started - and the requirements of the - sign. It is certied and approved by ITS (test number -0359).The barbecue left
the factory in perfect condition regarding its function and safety.
This barbecue is covered by our warranty for a period of two years from the date of purchase. This warranty covers
manufacturing defects and faulty parts as well as the replacement of these parts.The cost of freight, assembly, replacement
of worn parts, and other such costs are not covered by this warranty.
The warranty shall expire and any responsibility shall pass over to the executor:
• if the barbecue is not used properly.
• if the barbecue is used despite visible damage or if it is not completely assembled.
• if any technical alterations have been made to the barbecue.
• if accessories are used that are not expressly authorised for this barbecue (if in doubt please contact our customer
service department).
• if original spare parts from LANDMANN GmbH & Co. Handels-KG are not used.

8GRILLCHEF
Safety instructions
Denition of terms used
The following pictograms and signal words are used in these instructions to point out hazards and important information.
Safety instructions
Pictogram and signal word Note on ...
Danger
... a possible danger that can result in severe personal injury or damage
to property if the stated measures are not observed.
Caution
... a possible danger that can result in damage to property if the
specied measures are not observed.
Operating notes
Pictogram Note on ...
... a useful function or tip.

9
GRILLCHEF
Danger "Hot surfaces and parts"
During operation some accessible parts of the barbecue can become very hot, particularly
those that are close to the re bowl.
Possible consequences:
• Severe burns from touching parts near the re bowl.
• Fire or smouldering re if ammable materials or substances are near the barbecue.
Safety measures prior to using the barbecue:
• When setting up the barbecue, make sure that
– there are not, and will not be, any ammable materials or substances nearby.
Minimum distance to ammable materials or substances: 2 m above and 1 m to the
side. Distance to highly ammable materials or substances, e.g. walls: min. 0.25 m.
– the barbecue is positioned rmly on a suciently large surface area. It must not be
moved during operation.
Safety measures while barbecueing:
• Wear protective barbecue gloves.
• Never leave the barbecue unattended. Take particular care to ensure that children and
pets are kept away from the barbecue.

10 GRILLCHEF
Danger "Gas is highly ammable"
Liquid gas is highly ammable and explosive.
Possible consequences:
• Serious personal injury or damage to property if escaping gas ignites in an environment
in which it is not controlled.
Safety measures:
• Only use the barbecue outdoors and ensure that the area is well-ventilated.
• Protect the gas cylinder and the gas hose from direct sunlight and other sources of heat
above 50 K. Take particular care to ensure that the gas hose does not touch any part of
the hot barbecue.
• Do not place the gas cylinder on the lower shelf, as it is too near the burner.
• Do not lean over the barbecue when igniting the gas ame.
• Close the valve on the gas cylinder immediately after each use (turn the valve clockwise).
• Never leave the barbecue unattended. If the ame extinguishes, relight immediately or
cut o the supply from the gas cylinder.
• When connecting the gas cylinder make sure that there are no sources of ignition within
a 5 m radius.
Take special care not to light any naked ames, do not smoke or switch on electric
appliances (devices, lights, door bells), etc. (sparkover possible).
• Before each use, make sure that all gas connections are sealed and intact.
If necessary, replace the hose in order to comply with the corresponding national
requirements.
The barbecue must not be used if the connections for the gas supply are porous or faulty.
This also applies, for example, to hoses or ttings blocked by insects, as this can produce
a dangerous ashback.
• Ensure the position of the connection exible tube is not subject to twisting.
• Do not move the appliance during use.
• Turn o the gass supply at the container after use
• Any modication of the appliance may be dangerous

11
GRILLCHEF
Danger "Gas displaces oxygen"
Liquid gas is heavier than oxygen.Therefore it settles on the ground and displaces the oxygen
at that level.
Possible consequences:
• Suocation resulting from a lack of oxygen if the gas concentration is allowed to rise
suciently.
Safety measures:
• Only use the barbecue outdoors in a well ventilated area and above ground (i.e. not in
areas that are below ground level).
• Close the valve on the gas cylinder after each use.
• Never leave the barbecue unattended. If the ame extinguishes, relight immediately or
cut o the supply from the gas cylinder.
• Before each use, make sure that all gas connections are sealed and intact.
If necessary, replace the hose in order to comply with the corresponding national
requirements.
The barbecue must not be used if the connections for the gas supply are porous or faulty.
• If the barbecue is not being used for a prolonged period, cut o the supply from the gas
cylinder and store properly:
– Fit the gas cylinder valve with a cap nut and safety cap.
– Do not store the gas cylinder in rooms below ground level, in or near stairways,
hallways or passages and thoroughfares between buildings.
– Always store gas cylinders upright, even if they are empty.
• The parts sealed by the manufacturer or his agent must not be altered by the user

12 GRILLCHEF
Assembly
Before starting
Here are a few tips to help you assemble your barbecue quickly and successfully:
• Check that no parts are missing by placing all of the individual parts on an empty surface (we reserve the right to make
minor technical alterations, such as the content of the small parts bag).
If, despite careful factory checks, a component is missing, please contact our customer service department (see the last
page). We will immediately attend to your request.
• Sort out the small parts, as some of the screws and bolts, for example, are very similar and can be easily confused.
• For assembly you will need a medium size screwdriver and a suitable spanner (at spanner or box spanner).
You will need a at spanner (AF17) to connect the gas cylinder.
Only use tools that are intact and suitable for the job at hand. Worn or unsuitable tools will not allow you to tighten the
bolts suciently, but will damage them to the extent that they can no longer be turned.
• Always t all connecting elements (screws, bolts, nuts, etc.) as shown in the following illustrations. If you misplace a
connecting element, replace this with an appropriate part. Only by doing this can you ensure that the construction is
strong and safe.
• It is essential that you follow the instructions in the order they are specied!
• Readthetextforeachstepbeforecarryingitout,asusefulinformationissometimesonlyprovidedattheendofthesection.

13
GRILLCHEF
Assembly procedure
Assembly step 1
Assembly step 2

14 GRILLCHEF
Assembly step 3
Assembly step 4
5a

15
GRILLCHEF
Assembly step 5
Assembly step 6

16 GRILLCHEF
Assembly step 7
Assembly step 8

17
GRILLCHEF
Assembly step 9
Assembly step 10

18 GRILLCHEF
Assembly step 11
Assembly step 12

19
GRILLCHEF
Assembly step 13
Assembly step 14

20 GRILLCHEF
Assembly step 15
Assembly step 16
