Grillo 2500 User manual

ROTAVATORS
MOTOZAPPE
MOTOBINEUSES
MOTORHACKEN
MOTOAZADAS
GRILLO 2500 – 3500 – 11500 – 11HRG
OPERATOR'S MANUAL
MANUALE DELL'OPERATORE
MANUEL D'UTILISATION
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
02040-20

SUMMARY
Safety rules
Instructions
Warnings 5
Identification and servicing 7
Technical specifications 7
Putting the machine into service 9
Instructions for use 9
Maintenance and lubrication 11
Implements 1
Illustrations 54
EC Declaration of conformity - Noise and vibrations levels
INDICE
Norme antinfortunistiche
Istruzioni
Avvertenze 14
Identificazione e assistenza 16
Caratteristiche tecniche 17
Messa in opera della macchina 18
Istruzioni d’uso 19
Manutenzione e lubrificazione 21
Accessori 2
Figure 54
Certificato di conformità CE - Rumorosità e livelli di vibrazione
INDEX
Règles de sécurité
Instructions
Mises en garde 24
Identification et assistance 26
Caractéristiques techniques 27
Mise en service de la machine 28
Mode d’emploi 29
Maintenance et lubrification 1
Outils
Illustrations 54
Certificat de conformité CE - Niveaux sonores et de vibration
INHALTSÜBERSICHT
Sicherheitsvorschriften
Anleitung
Sicherheitsrelevante Hinweise 4
Identifikation der Maschine und Kundendienst 6
Technische Daten 7
Inbetriebnahme der Maschine 8
Betriebsanleitung 9
Wartung und Schmierung 41
Zubehör 4
Abbildungsverzeichnis 54
EG-Konformitätserklärung - Geräuschemission und Vibrationspegel
ÍNDICE
Normas de seguridad
Instrucciones
Advertencias 44
Identificación y asistencia 46
Características técnicas 47
Puesta en servicio de la máquina 48
Instrucciones de uso 49
Mantenimiento y lubricación 51
Equipos 5
Indice de ilustraciones 54
Certificado de conformidad CE - Niveles de ruido y vibración
- i -

SAFETY SYMBOLS - SIMBOLOGIA PER LA SICUREZZA - SYMBOLOGIE POUR LA SECURITE –
SICHERHEITSSYMBOLE- SIMBOLOGÍA DE SEGURIDAD
OPEN MANUAL- means that ou must read the operator's manual ver carefull .
MANUALE APERTO - significa che dovete leggere attentamente il manuale di uso e manutenzione.
MANUEL OUVERT – signifie qu'il faut lire avec attention le présent manuel.
OFFENES HANDBUCH – bedeutet, dass Sie die Gebrauchs- und Wartungsanleitung aufmerksam durchlesen müssen.
MANUAL ABIERTO – es decir que ha que leer mu atentamente el manual del operador.
CAUTION! - means that ou have to pa particular attention to the operation ou have to carr out, in particular if there is the
indication “DANGER”.
ATTENZIONE! - significa che dovete porre particolare attenzione all’operazione che dovete effettuare, in particolare se vi è anche
l’indicazione di “Pericolo”.
ATTENTION! - signifie qu'il faut faire particulière attention dans l'opération que vous allez faire, en particulier s'il a aussi
l'indication “DANGER”.
VORSICHT! - bedeutet, dass Sie besondere Aufmerksamkeit beim Durchführen des Vorgangs haben müssen, insbesondere wenn
auch der Hinweis “GEFAHR” aufgeführt ist.
ATENCIÓN! - es decir que ha que poner ma or atención en la operación a ejecutar si, en particular cuando ha también la
indicación “Peligro”.
INTERDICTION, YOU MUST NOT DO THAT! - means that it is absolutel forbidden to carr out the operations reported under this
s mbol because the could lead to mortal danger.
DIVIETO, NON FARE! - significa che non dovete assolutamente fare le operazioni riportate sotto questo simbolo, potrebbe
comportare un pericolo mortale.
INTERDICTION, NE PAS FAIRE! - signifie qu'il est absolument interdit d' effectuer les opérations reportées sous cette indication,
car elles pourraient conduire au danger de mort.
VERBOT, strengstens untersagt! - bedeutet, dass der Vorgang unter diesem S mbol absolut nicht durchgeführt werden darf, da er
zur einer lebensgefährlichen Situation führen könnte.
PROHIBICIÓN, NO LO HAGAN! - es decir que no ha que hacer absolutamente las operaciones bajo este símbolo, podría
comportar un peligro mortal.
NOTE, ou have to pa particular attention to the note put next to this s mbol
NOTA, dovete porre particolare attenzione alla nota posta accanto a questo simbolo.
NOTE, il faut faire attention particulière à la note mise à côté de ce s mbole.
ANMERKUNG, besondere Aufmerksamkeit muss auf die Anmerkungen neben diesem S mbol gelenkt werden.
NOTA, ha que poner atención particular en la nota puesta a lado de este símbolo.
You must not repair nor lubricate the machine with moving parts or with the engine put on.
Non riparare o lubrificare la macchina con organi in movimento o motore acceso
Ne pas réparer ou lubrifier la machine avec des parties en mouvement ou à moteur en marche.
Niemals bei bewegenden Objekten oder bei laufendem Motor Reparationen oder Einschmierungen durchführen.
No reparar ni lubrificar la máquina con órganos en movimiento o motor en marcha.
You must not smoke, light matches or lift flames, trigger frames nor cause sparks.
Vietato fumare, accendere fiammiferi o fiamme, lasciare fiamme libere o creare scintille.
Il est interdit de fumer, allumer des allumettes ou du feu, laisser des flammes libres ou de causer des étincelles.
Es ist untersagt zu Rauchen, Streichhölzer oder Feuer anzuzünden, Flammen auslösen oder Funken verursachen.
Prohibido fumar, encender cerillas o fuego, dejar llamas o crear chispas.
- 1
-
Use personal protective equipement
Utilizzare mezzi di protezione individuali
Utilisez l'équipement de protection individuelle
Individuelle Schutzausrüstung benutzen
Utilizar dispositivo de proteccion individual

GENERAL SECURITY RULES
NORME DI CARATTERE GENERALE SULLA SICUREZZA
SICHERHEITSHINWEISE
RÈGLES GÉNÉRALES DE SÉCURITÉ
NORMAS DE CARÁCTER GENERAL SOBRE LA SEGURIDAD
NORMAS DE CARÁCTER GENERAL ACERCA DA SEGURANÇA
Pay attention to symbol DANGER! It points out all most dangerous operations according to the situation. All safety rules are important and therefore must be strictly
observed. Always keep this handbook within the reach, read it carefully and learn how to use the equipment in a safe way. Let nobody, not provided with necessary
information, work with the equipment.
Fare attenzione al simbolo PERICOLO! Esso indica la presenza delle principali situazioni di pericolo. Tutte le norme antinfortunistiche contente sono importanti e
vanno rispettate. Tenere sempre questo manuale a portata di mano, leggerlo attentamente ed imparare ad usare l’attrezzatura in modo sicuro. Non permettere che
qualcuno operi con questa attrezzatura senza aver ricevuto istruzioni esaurienti.
Attention au symbole DANGER! Il indique la pr sence des principales situations de danger. Toutes les normes contenues pour la pr vention des accidents sont
importantes et doivent être respect es scrupuleusement. Garder toujours ce manuel à la port e de la main, le lire attentivement et apprendre à utiliser ce mat riel
en toute s curit . Ne pas permettre que d’autres personnes utilisent ce mat riel sans avoir reçus des instructions exhaustives.
Achtung - die mit dem ymbol GEFAHR! gekennzeichneten Hinweise weisen auf potentielle Gefahrensituationen hin. Alle sicherheitsrelevanten Hinweise in
diesem Handbuch sind sehr wichtig und müssen unbedingt befolgt werden. Bewahren ie dieses Handbuch stets griffbereit auf, lesen ie es aufmerksam durch,
und lernen ie, die Maschine und die gesamte Ausrüstung sicher zu benutzen. Die Maschine darf nur von Personen benutzt werden, die vorher entsprechend
unterwiesen wurden.
Preste atención al símbolo ¡PELIGRO! Indica la presencia de situaciones importantes de peligro. Todas las normas de prevención de accidentes detalladas son
importantes y deben respetarse estrictamente. Conserve este manual al alcance de la mano, l alo atentamente y aprenda a utilizar el equipamiento de modo
seguro. No permita que otras personas operen con este equipamiento sin haber recibido instrucciones exhaustivas.
Take special care not to touch hot parts of the engine.
Prestate particolare attenzione a non entrare in contatto con parti surriscaldate
del motore.
Veiller tout particulièrement à ne pas toucher des l ments surchauff s du
moteur.
Achtung – keine heißen Motorteile berühren!
No tocar partes recalentadas del motor.
Tome muito cuidado para não entrar em contacto com as partes aquecidas do
motor.
Engine exhaust fumes can cause sickness or death. If it is necessary to run an
engine in an enclosed area, use an exhaust pipe extension to remove the
fumes. Always try to work in a well ventilated area.
I gas di scarico possono causare malanni o morte. Se è necessario mettere in
moto un motore in uno spazio chiuso, usare una prolunga tubo di scarico per far
uscire il fumo. Lavorare in una zona ben ventilata.
L’exhalation des gaz d’ chappement peut être cause d’intoxication ou de mort.
S’il est vraiment n cessaire d’allumer le moteur à l’int rieur, appliquer au tuyau
d’ chappement un autre tuyau extensible pour permettre la sortie des gaz. Il est
toujours mieux de travailler en plein air.
Auspuffgase können Übelkeit oder Tod verursachen. Wenn es notwendig ist,
einen Motor in einem geschlossenen Raum laufen zu lassen, benützen Sie eine
Verlängerung, um das Auspuffgas abzuleiten. Versuchen Sie immer in einem
gut belüfteten Raum zu arbeiten.
Los gases de escape pueden provocar enfermedades o muerte. De tener que
poner en marcha un motor en un espacio cerrado, usar una prolongación del
tubo de escape para que salga el humo. Trabajar en una zona bien ventilada.
Os gases de escape podem causar danos ou morte. Caso seja necessário
fazer com que o motor funcione num espaço fechado, utilize uma extensão
para o tubo de escape que os fumos sejam expulso para o exterior. Trabalhe
numa área bem ventilada.
Handle fuel with care, it is highly flammable: Do not refuel machine while
smoking, when machine is near an open flame or sparks, or when the engine is
running. Stop the engine.
Maneggiare il carburante con cura, è altamente infiammabile; non fate
rifornimento mentre fumate, o vicino a fiamme o scintille, o quando il motore è
acceso.
Manier avec soin le carburant car c’est très inflammable. Ne pas remplir le
r servoir si vous êtes en train de fumer ou pendant que la machine est près du
feu ou d’ tincelles ou encore pendant que la machine travaille. Arrêter le
moteur.
Treibstoff vorsichtig handhaben, da er sehr entzündbar ist: beim Tanken nicht
rauchen. Nicht tanken, wenn die Maschine in der Nähe von Flammen oder
Funken ist oder wenn der Motor läuft. Immer den Motor abschalten.
Manejar el combustible con cuidado porque es sumamente inflamable; no
repostar mientras se fuma o cerca de llamas o chispas, o cuando el motor está
encendido.
Manuseie o carburante com cuidado, pois este è altamente inflamável; não
fume durante o abastecimento da máquina ou enquanto o motor estiver ligado,
não o aproximado de chama ou de faíscas.
- 2
-

WARNING! SHARP PARTS. Keep hands and feet away. Do not operate the
mower over gravel or foreign bodies which may be sucked up and ejected by
the blades, generating a danger. Keep people away. Remove the key and read
the instruction manual before attempting to carry out any maintenance or
repairs to the machine.
ATTENZIONE! ORGANO TAGLIENTE. Tenere lontano mani e piedi. Non
lavorare col rasaerba sopra alla ghiaia o corpi estranei che possono essere
aspirati e centrifugati dalle lame risultando molto pericolosi, tenere lontano le
persone. Togliere la chiave e leggere le istruzioni prima di effettuare qualsiasi
operazione di manutenzione e riparazione.
ATTENTION! ORGANE TRANCHANT. Éloigner les mains et les pieds. Ne pas
utiliser la tondeuse sur le gravier ou sur des corps qui peuvent être aspir s et
centrifug s par les lames et devenir très dangereux. Les personnes doivent se
trouver à une certaine distance. Enlever la cl et lire les instructions avant toute
op ration de maintenance et de r paration.
ACHTUNG! SCHARFE KLINGEN. Hände und Füße fernhalten. Beim Mähen
nicht über Schotter, Steine oder andere Fremdkörper fahren, da diese durch die
Drehbewegung der Messer angesaugt und weggeschleudert werden können
(Verletzungsgefahr). Nicht in der Nähe von anderen Personen mähen. Vor
jedem Wartungs- bzw. Reparatureingriff den Startschlüssel abziehen und die
Gebrauchsanleitung durchlesen.
¡PELIGRO! ÓRGANO CORTANTE. Mantener alejados los pies y las manos.
No limpiar la herramienta con el motor en marcha. ¡Peligro! Expulsión de
objetos: mantener alejadas a las personas. Atención: quitar la llave y leer las
instrucciones antes de efectuar cualquier operación de mantenimiento o
reparación.
ATENÇÃO! Órgão cortante. Ficar longe com p s e mãos. Não trabalhar com a
máquina sobre cascalho ou objetos que podem ser aspirados e centrifugados
gerando perigo, manter-se longe das pessoas.
Tirar a chave de ignição e ler as instruções antes de efetuar qualquer operação
de reparo ou serviço.
Warning! Cutting edges, keep your hands and feet away.
Do not clean the attachment when the engine is running.
Attenzione! Organo tagliente, tenere lontano piedi e mani.
Non pulire l'attrezzo col motore in moto.
Attention! Organe tranchant, ne pas approcher main et pieds.
Ne pas nettoyer le moteur quand le moteur est en marche.
Achtung! Schneidende Klinge, Hände und Füße fernhalten.
Niemals bei laufendem Motor reinigen.
DANGER! READ THE INSTRUCTION MANUAL. KEEP SAFETY DISTANCES.
PERICOLO! LEGGERE IL MANUALE D’ISTRUZIONE. TENERE LONTANO LE
PERSONE.
DANGER! LIRE LE MANUEL D’INSTRUCTIONS. RESPECTER LES
DISTANCES DE SÉCURITÉ
GEFAHR! DIE GEBRAUCHS ANLEITUNG DURCHLESEN. NICHT IN DER
NÄHE VON ANDEREN PERSONEN MÄHEN.
PELIGRO! LEER LAS INSTRUCCIONES. MANTENER ALEJADAS LAS
PERSONAS.
PERIGO! LER O MANUAL DE INSTRUÇÕES. MANTER AS PESSOAS
AFASTADAS.
Before using the machine, it is mandatory to put on the appropriate individual
safety devices: body protection, protection gloves, security shoes, ear
protection.
Prima di utilizzare la macchina, è obbligatorio indossare gli appositi dispositivi di
sicurezza individuali: protezione del corpo, guanti di protezione, calzature di
sicurezza, protezione dell’udito.
Avant d’utiliser la machine, il est obligatoire de mettre les dispositifs individuels
de s curit appropri s: protection du corps, gants de protection, chaussures de
s curit , protection de l’ouïe.
Vor dem Gebrauch der Maschine ist es vorgeschrieben, die geeignete
persönlichen Schutzkleidung anzuziehen: Körperschutz, Schutzhandschuhe,
Sicherheitsschuhe, Gehörschutz.
Antes de utilizar la máquina es obligatorio ponerse los dispositivos individuales
de seguridad apropiados: protección del cuerpo, guantes de protección,
calzado de seguridad, protección del oído.
- 3
-

Translation of the original instructions
ROTAVATORS
2500 – 3500 – 11HRG – 11500
Dear customer,
thank you for choosing a Grillo rotavator. We are sure that your new machine’s performance will meet
your requirements in full. To ensure optimum service and maintenance of its qualities over time, read this
manual carefully and follow its instructions. This will give you the best results and protect your
investment. lease keep this manual, which must always accompany the machine.
GENERA DESCRIPTION AND INTENDED USE
The rotavator is a single-axle self-propelled machine usually equipped with a rotary tiller for tilling soil.
These machines are used primarily to prepare the soil (elimination of weed, tilling of the soil) and used in
gardening, for small ground work, refinement work and orchard inter-rows. The machine is constructed
on a chassis and fitted with either a petrol or diesel engine that drives a rotary tiller. The Grillo rotavator
is a pedestrian-controlled machine, the operator steers the machine via the handlebar where the controls
are mounted.
CAUTION! Before starting the engine, read this carefully. The following warn-
ings are very important in ensuring safety!
WARNINGS
Caution is the main safeguard in preventing accidents. We urge you to read the warnings that follow
when using the walking tractor, before starting any work at all. Improper use of the walking tractor and its
equipment can be dangerous. To reduce the risks to the minimum, observe the necessary precautions
set out below:
1) Read the whole of this manual before using your walking tractor. Be thoroughly familiar with the
controls and the proper use of the machine before starting.
2) ay special attention to the safety warnings and labels.
3) The rotating tiller is extremely dangerous; never insert hands or feet under the tiller!
4) Before other people are allowed to use the machine, make sure they are informed about the safety
regulations and how to properly use this equipment.
5) Ensure children and animals are kept at a safe distance of about 15 metres. Do not allow people to
come closer to the walking tractor when it is being used.
6) Do not use the machine when physically fatigues or under the influence of alcohol or drugs that could
impair the operator's physical and mental capacities.
7) Thoroughly check the ground before using the walking tractor and remove any object that could
damage the tines (e.g. stones) or that could be caught up and flung down, therefore becoming highly
dangerous. (e.g. branches, stones).
8) Always wear suitable clothing and footwear. It is recommended to wear safety footwear, safety
goggles, ear plugs and gloves, long trousers. Do not wear clothing or accessories that could get
trapped in the controls or in the tiller (e.g. loose trousers, scarves…).
9) ay close attention when working on slopes. Always work across the slope and never
upwards/downwards. ay greater attention when changing direction on slopes and never work on
excessively steep ground.
10) Never allow the machine to be used by anyone under 16 years of age.
11) ay close attention when operating the machine in reverse, make sure that there are no obstacles
behind you. In case of danger release the handlebar and the machine will stop immediately.
12) It is dangerous to sharply activate the levers with the engine at maximum r.p.m.
13) Do not operate the engine in a confined space where dangerous carbon monoxide fumes can
collect.
14) CAUTION: Petrol is highly inflammable. Store fuel in containers especially designed for this
purpose. Refuel outdoors and away from any open flames or sparks. Never smoke when refuelling. Stop
the engine before refuelling and never refuel with the engine running. Never remove the tap of the fuel
tank or add fuel when the engine is hot. If fuel is spilled, do not attempt to start the engine but move the
machine away from the area of spillage and avoid creating any source of ignition until fuel vapours have
dissipated. After refuelling all fuel caps should be closed securely.
5

Translation of the original instructions
15) Avoid spillages and clean up all spills straight away.
16) Store fuel in containers especially designed for this purpose.
17) Make sure you work preferably in natural light or good artificial light.
IMPROPER USE TO BE AVOIDED
18) Never use the walking tractor to crush building, metallic and plastic material nor roots and trunks or
any sort of garbage.
19) Do not use the machine to transport people, animals or objects.
FURTHER SAFETY ADVICE
20) Never disable safety devices.
21) Always stop the engine before making any adjustment or cleaning.
22) Never allow anyone to check the machine with engine running.
23) The user is always responsible for injuries or damages caused to third parties and for any risk they
could run.
24) Damaged tines must always be replaced and never repaired.
25) Always use genuine Grillo spare parts.
26) Before starting any work with the machine, check that all the accident prevention systems with which
it is equipped with are in perfect working order. They must never be disabled or tampered with.
27) Before starting work, check that the nuts and bolts securing the tiller and tines are perfectly secured.
28) Never operate the machine without safety protective devices in place (such as mudguards and
engine bonnets).
29) Never clean the tiller with the engine running.
30) Never use the machine barefoot.
31) Never change the max R M engine settings nor any other engine settings.
32) Allow the engine to cool before storing in any enclosure.
33) CAUTION: To reduce the risk of fire, keep the engine, the exhaust pipe and the exhaust manifolds
free from grass, leaves, dust, etc…
34) Drain the fuel only outdoors.
35) Do not run with the walking tractor.
36) Hold your feet away when starting the machine.
37) Do not lift or transport the machine with the engine running.
38) Do not store the machine with fuel in the tank where petrol vapours could reach an open
flame or source of ignition.
39) Never use the machine to pull nor tow.
40) Grillo walking tractors has been designed with the sole purpose of being used with original Grillo
attachments of with attachments designed by other manufacturers expressively authorized by Grillo. Non
original attachments as well as attachments produced and/or modified by non-authorized manufacturers
must never been connected to the walking tractor. If you have any question or doubt please contact the
nearest Grillo authorized dealer.
Any improper use will void the warranty and the manufacturer will not be held responsible for
any damage that occurs thereafter.
CAUTION!
We recommend the use of ear plugs/protection should the walking tractor be used for a prolonged time.
Use acoustic protections compliant with the current law (see picture below – Fig. A).
Fig. A
6

Translation of the original instructions
IDENTIFICATION AND AFTER-SA ES SERVICE
The rotavator is fitted with a nameplate on the
frame with the serial number of the machine. This
number must be stated when requesting service or
ordering spare parts.
AFTER-SA ES SERVICE
This handbook provides instructions for use of the motor hoe and for correct basic servicing which the
user can carry out himself. For all procedures not described in this handbook, contact your local dealer.
SPARE PARTS
Always use original spare parts, as they are the only ones to offer complete safety and
interchangeability. Always state the serial number of the machine and the code number or the part to be
replaced when ordering. For engine parts, refer to the specific handbook.
WARRANTY
The warranty is given in compliance with the current law. The dealer will have to give the client a copy of
the registration card of the machine, which they will print up from the Grillo website. For the engine the
guarantee of the relative manufacturers apply.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced. Contact your
local dealer. For further information, our address is:
GRILLO S.p.A.
Via Cervese 1701 - 47521 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011
Web site: www.grillospa.it - E-mail: grill[email protected]
TECHNICA SPECIFICATIONS 2500
ENGINES
- ROBIN EX17 169 cm³, 5H (@ 3600 r.p.m.), one-cylinder petrol.
- HONDA GX160 OHV 163 cm³, 4,8H (@ 3600 r.p.m.), one-cylinder petrol.
- KOH ER 3000 196 cm³, 5,5H (@ 3600 r.p.m.), one-cylinder petrol.
STARTER: recoil starter.
FUE TANK: 3,1 Litres (GX160) – 3,6 (EX17- 3000).
TRANSMISSION: with gears in oil bath.
GEARBOX: two forward gears.
PTO:
1) one direct TO running at the engine r.p.m. in anti-clockwise rotation (11UNI 221)
2) one synchronized .T.O with gearbox speeds in clockwise rotation (13 UNI 221).
C UTCH: conic and active.
HAND EBAR: height- and side adjustable.
WORKING AREA WIDTH WITHOUT SIDE DISCS: adjustable at 580-850 mm(with enlargement kit).
ROTARY TI ER RPM: I 53 r.p.m.; II 123 r.p.m.
ATTACHMENTS: furrower, wheel extensions, rubber wheels, transfer wheel, plough.
WEIGHT: kg 72 (with GX160) - kg 75 (with 3000) - kg 74 (with EX17)
7

Translation of the original instructions
TECHNICA SPECIFICATIONS 3500 AND 11HRG
ENGINES
- HONDA GX200 OHV, 196 cm³ 5,5H (@3600 r.p.m.) one-cylinder, petrol.
- KOHLER 3000 OHV, 196 cm³ 5,5H (@3600 r.p.m.) one-cylinder, petrol.
- GR200, 196 cm³ 5,5H (@3600 r.p.m.) one-cylinder, petrol.
STARTER: recoil starter.
FUE TANK: 3,1 L (GX200) – 3,6 L (3000) – 3 L (GR200)
C UTCH: conic and active.
TRANSMISSION: with gears in oil bath.
GEARBOX: 2 forward gears + 1 reverse (3500) – 3 forward gears + 1 reverse (11HRG)
PTO:
1) one direct TO running at the engine r.p.m. in anti-clockwise rotation (11UNI 221)
2) one synchronized .T.O with gearbox speeds in clockwise rotation (13 UNI 221).
HAND EBAR: height-and side adjustable.
WORKING WIDTH without side discs: adjustable at 58-85-111 cm (with enlargement kit).
ROTARY TI ER RPM: I 53 r.p.m.; II 123 r.p.m.; III 162 r.p.m.(for 11HRG only); I REV 53 r.p.m..
ATTACHMENTS: furrower, wheel extensions, rubber wheels, transfer wheel, plough.
WEIGHT: 79 kg with GX200 - 81 kg with 3000 and GR200
TECHNICA SPECIFICATIONS 11500
ENGINES
- ROBIN EX27 265 cm³ 8,3H (@3600 r.p.m.) one-cylinder petrol.
- GR300 302 cm³ 9,3H (@3600 r.p.m.) one-cylinder petrol.
- KOH ER KD15 350 349 cm³ 7,5H (@3600 r.p.m.), one cylinder diesel.
STARTER: recoil starter (electric starter available for diesel engine only).
FUE TANK: 6,1 L (EX27) – 5,5 L (GR300) - 4,3 L (15LD350).
C UTCH: conic and active.
TRANSMISSION: oil bath gears.
GEARBOX: 3 forward gears + 1 reverse gear.
PTO:
1) one direct TO running at the engine r.p.m. in anti-clockwise rotation (11UNI 221)
2) one synchronized .T.O with gearbox speeds in clockwise rotation (13 UNI 221).
HAND EBAR: height and side- adjustable and fitted on anti-vibration blocks.
WORKING WIDTH without side discs: adjustable at 59-86-112 cm (with extensions kit).
ROTARY TI ER R.P.M.: I 53 r.p.m.; II 123 r.p.m.; III 162 r.p.m.; I REVERSE 53 r.p.m..
ATTACHMENTS: plough, furrower, wheel extensions, rubber wheels, transfer wheels, plough.
WEIGHT: 90 kg (EX27) - 92 kg (GR300) - 121 kg (KD15 350 AE)
8

Translation of the original instructions
PUTTING THE MACHINE INTO SERVICE
- Check that the machine has not been damaged during transport.
- Lift the machine out of the packaging paying attention not to damage levers and cables. Use an
appropriate lifting machine (min. capacity 200 kg).
Before putting the machine on the ground:
- Fix the drag stake (fig. 9).
- Fix the bonnets and the tines (fig. 1). Attention: before fixing the tines assembly to the tines shaft,
check that the shaft and the inner part of the tines assembly are perfectly clean. After having
fixed the tines assembly to the shaft, pull the screws tight.
- Fix the engine pin where necessary (fig. 1, no. 20).
- Fill in the engine oil (see engine handbook).
Checks to carried out made before starting, with the machine in horizontal position:
- Check that the gearbox oil level can be seen through the gauge (fig. 2, no. 13), use M 80W90
oil (A I GL5, US MIL-L-2105D).
- To check engine oil, remove the level check cap, following the instructions described in the
engine manual.
- In the versions with air filter in oil bath (fig. 7) fill in the oil using the same as for the engine.
- Ensure that the gear lever is in “neutral” position (F).
- For engines with electric starter check the battery voltage. It must not be inferior to 12,5V. Slowly
recharge the battery for two hours if necessary. CAUTION: when mounting the battery be careful not
to reverse the polarity.
INSTRUCTIONS FOR USE
Before starting the engine always check:
- the engine oil level (see engine manual)
- that all screws and nuts are well tightened, especially those securing the tines
- that all levers are in neutral position
- that the air filter (dry version) is clean (fig. 6). Important: do not blow the cartridge with compressed air.
If it is too clogged, it has to be replaced.
- that the air filter (oil-bath version) is clean and at correct level (fig. 7).
Fill the tank with fuel using a funnel fitted with a very fine filter.
STARTING THE PETRO ENGINE
Open the fuel cock (fig. 3, no. 16), push the throttle lever halfway (fig. 1, no. 3) and engage the choke
device if the engine is cold (fig. 3, no. 10). To start the engine pull hard on the recoil starter (fig. 3, no.
17).
STARTING THE DIESE ENGINE
ush the throttle lever halfway (fig. 3, no. 16) and make sure the switch off button is turned fully upwards
(fig. 1, no. 7).
- Engine with recoil starter: to start the engine pull hard on the recoil starter (fig. 3, no. 17).
- Engine with electric starter: turn the ignition key placed on the handlebar (fig. 4).
STARTING THE MACHINE
- If the machine is equipped with an engine pedestal or a transfer wheel, always remember to raise it.
- Choose the gear via the appropriate lever (fig. 1, no. 1). Should the gear not engage immediately, do
not force the lever but give light touches with the clutch until it engages.
- The machine will start moving forward when pressing the grey safety device (fig. 1, no. 5) and pulling
down the clutch red lever(fig. 1, no. 2).
When the red lever is released the machine stops immediately, while the engine keeps on running and
the clutch red lever comes back into the original vertical position.
CAUTION: KEE HANDS AND FEET AWAY WHILE THE TILLER IS RUNNING.
CAUTION: BEFORE ENGAGING THE REVERSE GEAR MAKE SURE THAT THE GROUND IS CLEAR
OF OBSTACLES AND BE VERY CAREFUL.
9

Translation of the original instructions
IN CASE OF DANGER RE EASE THE C UTCH RED EVER (fig. 1, no. 2), THE TI ER WI
IMMEDIATE Y STOP.
Important: to avoid damages to the clutch always keep the red lever fully pressed down during work. Do
not work with this lever half-pressed.
The operator’s pressure on the steering-wheel determines the tilling depth; it can be increased or
reduced also by raising or lowering the rear drag stake. It is advisable to turn the tip of the drag stake
forward when working on hard and dense ground, or to turn it backwards when the soil is not very firm
(fig. 9). On particularly hard ground it is advisable to remove the side discs (fig. 1, no. 6) in order to
improve the penetration of the tines into the ground.
HAND EBAR ADJUSTMENT
To adjust the height of the handlebar hold the appropriate lever (fig. 1, no. 15), raise or lower the
handlebar and release the lever to lock the handlebar in the desired position. To turn the handlebar hold
the lever (fig. 1, no. 14), turn the handlebar right or left then release the lever to lock it into the desired
position.
HOW TO SWITCH OFF THE PETRO ENGINE
Set the throttle lever into “0” position (fig. 1, no. 5)
HOW TO SWITCH OFF THE DIESE ENGINE
Fully press the lever placed on the left side of the handlebar (fig. 1, no. 7)
IMPORTANT: For engines with electric starter, once the engine has been switched off, turn the
ignition key anti-clockwise to disconnect the battery (fig. 4). eaving the key in the ignition when
the engine is off, will namely drain the battery.
END OF WORK
Switch off the engine and put the gear back to idle position. CAUTION: never leave the machine on
slopes with the machine in idle position. If the machine has to be parked on a slope, always engage the
1st gear.
CAUTION: never leave the machine unguarded or in a place where children or inexperienced people
could have easy access to it.
TROUB ESHOOTING
The following is a list of inconveniences which may occur during the use of the walking tractor,
which the operator himself can remedy.
1) if the petrol engine does not start check:
– that the fuel tank is at least half full;
– that the petrol cock is turned on;
– that the choke is engaged (when the engine is cold);
– that fuel is normally going to the carburettor;
– that the vent hole on the fuel tank is not blocked;
– that the mesh filter at the carburettor intake is clean;
– that the carburettor jets are clean. Check by unscrewing them and if dirty, clean them with a jet of
air;
– that spark plug is generating a spark. To check this, remove the spark plug, re-connect it to the
electricity supply wire, rest the metal side on an electrical earth and turn the engine-pulley as if to
start it. If no spark is seen between the electrodes, check the connection of the spark plug cable; if
there is still no current replace the spark plug with a new one. If a spark is still not obtained, the
problem is in the electric system: capacitor, coil, or in some other component. Contact your nearest
service centre or a specialist workshop.
10

Translation of the original instructions
2) if the diesel engine does not start, check:
– that the fuel tank vent hole is not blocked;
– that the fuel tank is at least half full.
3) If the engine is on but the machine does not move, check:
- that the gear is engaged
- that the clutch red lever is fully pressed and the clutch spring (fig.1, no. 21) is compressed. If
necessary, adjust the spring via the adjusting screw placed on the clutch wire (fig. 1, no. 9).
4) If the petrol engine cannot be switched off, check:
- that the switch off button (fig. 1, no. 5) is fully closed (“0” position)
- that the electric wire for the switching off is properly connected to the throttle lever and to the engine
connector.
5) if the diesel engine cannot be switched off:
– check that the electric wire to switch off is correctly connected to the engine.
MAINTENANCE AND UBRICATION
CAUTION!
- Always switch off the engine before performing any maintenance operation on the machine
- Disconnect the plug before performing any cleaning, maintenance or repair operation. Always
wear suitable clothing and working gloves.
- When the machine or part of it is lifted to carry out maintenance operations, always remember
to use suitable fixing tools such as holders and safety locks.
- When carrying out maintenance operations and/or when the machine is tilted without safety
locks or supports, never leave it unguarded in places where inexperienced people and children
could have easy access to it.
- Protect the environment: carefully dispose of used oils, petrol and any other pollutant product!
- Effective maintenance and correct lubrication help to keep the machine fully efficient.
RUNNING-IN
Replace the engine oil after the first 20 working hours.
ENGINE
Follow the instructions described in the engine manual. It is generally recommended to check the engine
oil level every 8 hours and to replace it every 100 hours.
GEARBOX
Before starting the engine always check the level via the indicator (fig. 4). If necessary, add MP80W90
oil (A I GL5 US MIL-L-2105D). Replace the oil once a year. To replace the oil:
- loosen the screws placed on the cover around the tines shaft (fig. 5, no. 22).
- dispose of the exhausted oil as prescribed by law.
- tighten the screws again
- unscrew the cap on the upper side of the gearbox (fig. 2, no. 13) and fill the gearbox very slowly
(quantity 1,2 kg)
- re-tighten the cap on the upper side of the gearbox.
AIR FI TER
Check that the air filter is clean every 8 hours and even more often if working in very dusty conditions. In
the versions with dry air filter (fig. 6) check that the filter is clean. Attention: if the filter is clogged, do not
blow the cartridge with compressed air, but replace it. In the oil bath version (fig. 7), check that the filter
is clean and the oil is at the right level. Use the same oil as for the engine.
11

Translation of the original instructions
TINE SHAFT
Remove the dust guards periodically (fib. 5 no. 11), clean the underlying area thoroughly, then replace.
The observance of these rules helps to keep all the mechanical parts of your machine fully
efficient.
TIPS FOR EFFICIENT USE
1) Always raise the clutch red lever (fig. 1, no. 2) before shifting from forward to reverse gear.
2) Never leave the machine exposed to bad weather condition.
3) Always keep levers and cables well clean from dust and ground residues.
4) Never force the gear: If the gear does not engage immediately, give light touches on the clutch until it
engages.
5) Never strain the engine: if smoke comes out of the exhaust, slow down.
END OF SEASON MAINTENANCE
Thoroughly clean the machine, replace both the engine and the gearbox oil, clean the air filter, sharpen
and grease the tines and replace them if worn. IMPORTANT: Grillo tines are made of a special steel
subjected to heat treatments. Never weld the tines if broken or cracked, because they could
break and be flung away becoming therefore highly dangerous for people and objects around.
MAINTENANCE SUMMARY TAB E
PROCEDURE EVERY 8
HOURS
AFTER 20
HOURS
EVERY 50
HOURS
EVERY
100
HOURS
EVERY 200
HOURS
Engine oil check the level ●
change ● ●
Air filter
check ●
replace ٭
Spark plug check/adjust ●
replace ●
Gearbox oil Check the level ●
replace ●
Check that the engine intake grid is
clean ●
Check that tines are well-sharpened
and well-fixed ● ٭
● recommended procedure
٭ procedure to be carried out if necessary
TRANSPORTING THE MACHINE
Rotavators cannot be used on plublic roads, If the machine is to be transported on a lorry or a trailer,
lower the handlebar, engage the 1st gear, fasten the rotavator to the lorry/trailer using ropes or belts. If a
lifting machine is used to lift the rotavator, make sure its lifting capacity is suitable for the rotavator.
12

Translation of the original instructions
IMP EMENTS
CAUTION: Before fitting the tines assembly, ratchet hubs or wheel extensions to the tiller shaft, check
that the shaft and the inside of the accessory to be mounted are perfectly clean. After having fitted the
accessory to the shaft, tighten the fixing screws thoroughly.
P OUGHS
There are two kinds of ploughs available: single furrow plough and 180° roll-over plough. The latter is
especially suitable when working forwards and backwards, such as along rows of vines or fruit-trees.
The depth of the furrow may vary from 10 to 15 cm depending on the soil. The plough must be fitted
behind the tiller on the adjustable implement-holder (fig. 12). Remove the drag stake support, the split
pin and the pin, then fit the implement-holder. It is also necessary to remove the two tines assembly. Fit
the wheel extensions with the screws and then the rubber wheels type 5.00×10. In order to increase the
wheel adherence it is recommended to fit weighs on the wheels (fig. 11).
ADJUSTAB E FURROWER
The adjustable furrower is an implement especially designed and manufactured for tracing furrows for
sowing or irrigation (fig. 13). The possibility of adjusting the position of the two wings enables furrow
width to be regulated from minimum of 10 to maximum of 30 cm. Furrow depth can vary from 10 to 20
cm. When working particularly hard ground, it is recommended to till before using the furrower. It is very
easy to mount; just remove the drag stake and fit the furrower (fig. 15). It may be used in combination
with the tiller or fitting the rubber wheels.
WHEE EXTENSIONS
The wheel extensions are fitted onto the tiller axle and they are necessary to fit the rubber wheels (fig.
11). They have no differential function.
SIDE TRANSFER WHEE S
These wheel make it easier to move the machine. They are mounted directly on the tiller side discs.
They do not act as differential and cannot be used together with the plough or the furrower.
FRONT TRANSFER WHEE
The front wheel too is used to move the machine easily. This wheel can be adjusted in two different
positions: a transfer position and a working position, which are adjustable without other tools (fig. 8).
13

Original instructions – Istruzioni originali – Instructions originales – Original-Anleitungen – Instrucciones originales
MOTOZAPPA
MODELLI: 2500 – 3500- HRG - 500
Gentile Cliente,
nel ringraziarLa per la fiducia e la preferenza accordata alla nostra motozappa, confidiamo che l’uso di
questa nuova macchina risponda pienamente alle sue esigenze. Per l’impiego ottimale e per la sua
manutenzione nel tempo, la preghiamo di leggere attentamente e seguire scrupolosamente le indicazioni
di questo libretto; ciò le consentir di ottenere i massimi risultati e salvaguardare la sua spesa.
La preghiamo di conservare questo libretto, che dovr sempre accompagnare la macchina.
DESCRIZIONE GENERALE E USO PREVISTO
La motozappa è una macchina agricola semovente ad un solo asse, normalmente equipaggiata con una
fresa per la lavorazione del terreno.
Queste macchine sono impiegate per effettuare lavori di preparazione del terreno (eliminazione di
infestanti, fresatura) e impiegate per piccole superfici, lavori di rifinitura, nell'interfila dei frutteti e
nell'orticoltura. La macchina è costituita da un telaio portante, sul quale è installato un motore a scoppio
che aziona una fresa. La macchina è comandata da un operatore a terra che segue il movimento della
stessa guidandola mediante un manubrio, su cui sono dislocati i comandi.
ATTENZIONE! Leggere attentamente prima di avviare il motore.
Le seguenti avvertenze sono importanti per l'incolumità dell'operatore!
AVVERTENZE
La prudenza è l'arma principale nella prevenzione degli incidenti. La preghiamo vivamente di leggere
con attenzione le seguenti avvertenze, prima ancora di iniziare il lavoro.
L'uso improprio della motozappa e dei suoi accessori può risultare dannoso; per ridurre queste
possibilit osservare le precauzioni necessarie di seguito riportate:
1) Prima di utilizzare la motozappa, leggere attentamente tutte le istruzioni riportate su questo manuale.
Prendere familiarit con i comandi ed il corretto uso della macchina.
2) Porre particolare attenzione alle etichette di sicurezza poste sulla macchina.
3) La rotazione della fresa è altamente pericolosa, non avvicinare mai le mani o i piedi alla fresa
quando il motore della macchina è acceso.
4) Consentire l'uso della motozappa soltanto a persone che hanno letto il presente manuale o che hanno
ricevuto adeguate istruzioni per un uso sicuro e appropriato della motozappa.
5) Tenere bambini e animali ad una distanza di almeno 15 metri dall'area di lavoro. Non consentire ad
altre persone o animali di avvicinarsi alla motozappa quando questa viene accesa o utilizzata.
6) Non utilizzare la motozappa in condizioni di affaticamento fisico, o sotto l'effetto di alcool, droghe o
farmaci che riducano le capacit fisiche e cognitive dell'operatore.
7) Controllare l'area nella quale deve essere utilizzata la macchina. Prima di procedere alla fresatura
rimuovere tutti gli oggetti che potrebbero danneggiare le zappe (es. pietre) o che potrebbero essere
lanciati dall'apparato fresante (es. sassi, rami ecc.).
8) Quando si lavora con la motozappa utilizzare sempre un abbigliamento adeguato. Si consiglia
d'indossare calzature di sicurezza, occhiali o visiera protettiva, cuffie o tappi antirumore, guanti
da lavoro, pantaloni lunghi. Evitare di indossare indumenti o accessori che possano impigliarsi
nei comandi o nella fresa (es. non indossare pantaloni larghi, sciarpe…).
9) Sui pendii agire sempre con cautela, lavorare trasversalmente rispetto alla pendenza, mai in salita o
in discesa, fare particolare attenzione durante il cambio di direzione, non lavorare su pendii
eccessivamente ripidi.
10) E' vietato l'uso della motozappa ai minori di 16 anni.
11) Prestare molta attenzione nella fase di retromarcia, assicurarsi che il terreno dietro di sé sia libero da
ostacoli. In caso di pericolo lasciare il manubrio. La macchina si arrester immediatamente.
12) È pericoloso azionare le leve bruscamente, col motore a massimo regime.
13) Per evitare il pericolo di esalazioni velenose, non adoperare il motore acceso in un locale chiuso.
14) ATTENZIONE! La benzina è altamente infiammabile. Conservare il carburante in appositi
recipienti. Fare rifornimento di carburante solamente all'aperto lontano da fiamme libere e scintille. Non
14

Original instructions – Istruzioni originali – Instructions originales – Original-Anleitungen – Instrucciones originales
fumare durante questa operazione. Aggiungere il carburante sempre prima di avviare il motore, mai a
motore acceso. Non togliere mai il tappo del serbatoio né aggiungere benzina quando il motore è in
funzione o quando è caldo. In caso di fuoriuscita di benzina, non tentare di avviare il motore, ma
allontanare la macchina dall'area dove è avvenuta la fuoriuscita evitando di creare fonti di accensione
finché non si sono dissipati i vapori della benzina.
15) Evitare fuoriuscite di combustibile e dopo aver riempito il serbatoio pulire ogni fuoriuscita prima di
avviare il motore.
16) Immagazzinare il carburante in contenitori specificatamente costruiti con questo obiettivo.
17) Lavorare solo con la luce del sole o con buona luce artificiale.
USI IMPROPRI DA EVITARE
18) In nessun caso utilizzare la motozappa Grillo per frantumare o schiacciare materiali edilizi, plastici,
metallici, radici, tronchi e rifiuti in genere.
19) Non utilizzare mai la macchina per trasportare persone o animali.
ULTERIORI ACCORGIMENTI PER LA SICUREZZA
20) Non manomettere o disattivare i dispositivi di sicurezza.
2 ) Non fare nessun tipo di regolazione o pulizia col motore in moto.
22) Non fare controllare la macchina da nessuno mentre siete alla guida col motore in moto.
23) L'utilizzatore è sempre responsabile dei danni arrecati a terzi, degli incidenti o dei pericoli nei quali
possono incorrere.
24) Le zappe deformate o danneggiate devono essere sempre sostituite, mai riparate.
25) Usare sempre ricambi originali Grillo.
26) Prima di cominciare qualsiasi lavoro con la macchina, verificare che tutti i sistemi antinfortunistici di
cui essa è dotata siano perfettamente funzionanti. È severamente vietato escluderli o manometterli.
27) Prima di iniziare il lavoro, controllare che le viti e i dadi di bloccaggio della fresa e delle zappette
siano perfettamente serrati.
28) L'attrezzatura protettiva (cofani, parafanghi, ecc.), va assolutamente mantenuta durante i lavori di
zappatura.
29) Non pulire la fresa con il motore acceso.
30) Non utilizzare la macchina a piedi nudi.
31) Non cambiare le regolazioni del motore, in modo particolare il numero di giri massimo.
32) Far raffreddare il motore prima di mettere la macchina in locali chiusi.
33) ATTENZIONE: per ridurre il pericolo di incendio mantenere il motore, la marmitta e i collettori di
scarico liberi da erba, foglie, polvere ecc..
34) Se dovete svuotare il serbatoio carburante eseguite l’operazione all’aperto.
35) Non correre, ma accompagnare la macchina sempre e solo camminando.
36) Avviare la macchina tenendo i piedi ben distanti dalla fresa.
37) Non sollevare o trasportare la macchina quando il motore è acceso.
38) Non immagazzinare mai la macchina con benzina nel serbatoio all'interno di un edificio dove i
vapori possano raggiungere una fiamma libera o una scintilla.
39) Non utilizzare mai la macchina ne per spingere ne per trainare.
40) I motocoltivatori Grillo sono stati progettati unicamente per essere utilizzati con accessori originali
Grillo o con accessori di produttori autorizzati dalla stessa ditta Grillo. Non installare sulla macchina
accessori non originali, o prodotti da aziende non autorizzate da Grillo o comunque modificati da
personale non autorizzato da Grillo. Per qualsiasi dubbio contattare sempre un rivenditore autorizzato
Grillo.
Ogni utilizzo improprio comporta il decadimento della garanzia ed il declino di ogni
responsabilità del costruttore.
15

Original instructions – Istruzioni originali – Instructions originales – Original-Anleitungen – Instrucciones originales
ATTENZIONE!
Nell'uso continuativo della macchina si raccomanda l'utilizzo di sistemi per proteggere l'udito. Utilizzare
tappi e cuffie conformi alle vigenti normative in materia (fig. A).
FIG. A
IDENTIFICAZIONE E ASSISTENZA
SERVIZIO ASSISTENZA
Questo manuale fornisce le indicazioni per l’uso della motozappa e per una corretta manutenzione di
base, eseguibile dall’utilizzatore. Per gli interventi non descritti in questo libretto, interpellare il rivenditore
di zona.
RICAMBI
Si raccomanda di impiegare esclusivamente ricambi originali, gli unici che offrono caratteristiche di
sicurezza e intercambiabilit . Ogni richiesta deve essere corredata dal numero di matricola della
macchina e dal codice del pezzo da sostituire.
Per i ricambi del motore, attenersi a quanto indicato nel libretto specifico.
GARANZIA
La garanzia è fornita nei modi e nei limiti indicati dalla legge vigente. Il rivenditore dovr
obbligatoriamente consegnare il certificato di garanzia della macchina al cliente finale, stampando una
copia della registrazione dal sito Grillo.
Per quanto riguarda il motore, valgono le condizioni previste dai rispettivi Produttori.
COME ORDINARE I RICAMBI
Indicare sempre il numero di matricola della macchina e il codice del pezzo da sostituire. Rivolgersi ai
nostri centri presenti in ogni provincia. Il nostro indirizzo è:
GRILLO S.p.A.
Via Cervese 1701 – 47521 CESENA (FC)
Tel. 0547 – 633111 / Fax 0547 – 632011
Web site: www.grillospa.it / e-mail: [email protected]
IDENTIFICAZIONE
La motozappa è fornita di una targhetta posta sul telaio con
il numero di matricola della macchina.
Questo numero è indispensabile per ogni richiesta di
intervento tecnico e per ordinare i ricambi.
16

Original instructions – Istruzioni originali – Instructions originales – Original-Anleitungen – Instrucciones originales
CARATTERISTICHE TECNICHE MODELLO 2500
MOTORE:
- HONDA GX 60 163 cm³, 4,8 HP a 3600 g/min, monocilindrico a benzina
- ROBIN EX 7 169 cm³, 5 HP a 3600 g/min, monocilindrico a benzina
- KOHLER 3000 196 cm³, 5,5 HP a 3600 g/min, monocilindrico a benzina
AVVIAMENTO: a strappo con autoavvolgente.
SERBATOIO: 3,1 litri (GX160) – 3,6 litri (EX17 – 3000)
TRASMISSIONE: ad ingranaggi bagno d'olio
CAMBIO: 2 marce avanti
PRESE DI FORZA:
) presa diretta ai regimi del motore, rotazione in senso antiorario (caletto11 UNI 221)
2) sincronizzata al cambio, rotazione in senso orario (caletto 13 UNI 221).
FRIZIONE: conica e attiva
STEGOLA: regolabile in altezza e lateralmente
LARGHEZZA DI LAVORO (senza dischi laterali): registrabile a 580 – 850 mm (con kit allargamenti)
GIRI FRESA AL MINUTO: I 53 g/min - II 123 g/min.
ATTREZZI AD ACCESSORI APPLICABILI: assolcatore, prolunghe ruote, ruote gomma, ruotina di
trasferimento, aratro.
PESO: kg 72 (GX160) – kg 74 (EX17) – kg 75 (3000)
CARATTERISTICHE TECNICHE MODELLO 3500 E HRG
MOTORE:
- HONDA GX200 196 cm³, 5,5 HP a 3600 g/min, monocilindrico a benzina
- KOHLER 3000 196 cm³, 5,5 HP a 3600 g/min, monocilindrico a benzina
- LONCIN GR200 196 cm³, 5,5 HP a 3600 g/min, monocilindrico a benzina
AVVIAMENTO: a strappo con autoavvolgente.
SERBATOIO: 3,1 litri (GX200) – 3,6 litri (3000) – 3 litri (GR200)
TRASMISSIONE: ad ingranaggi bagno d'olio
CAMBIO: 2 marce avanti + 1 retromarcia (MOD. 3500), 3 marce avanti + 1 retromarcia (MOD. 11HRD)
PRESE DI FORZA:
) presa diretta ai regimi del motore, rotazione in senso antiorario (caletto11 UNI 221)
2) sincronizzata al cambio, rotazione in senso orario (caletto 13 UNI 221).
FRIZIONE: conica e attiva
STEGOLA: regolabile in altezza e lateralmente
LARGHEZZA DI LAVORO senza dischi laterali: registrabile a 580 – 850 – 1110 mm (con kit
allargamenti)
GIRI FRESA AL MINUTO: I 53 g/min - II 123 g/min - III 162 g/min (solo 11HRD) - RM 53 g/min.
ATTREZZI AD ACCESSORI APPLICABILI: assolcatore, prolunghe ruote, ruote gomma, ruotina di
trasferimento, aratro.
PESO: kg 79 (GX200) – kg 81 (3000) – kg 81 (GR200)
17
