Griven Half Moon Marine W User manual

Half Moon Marine User’s Manual
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
© Copyright Griven 2018 -Griven reserves the right to make
changes to this product and related instructions at any time
without prior notice and such changes shall be effective
immediatly.
Tel. [phone]
E-mail: [email protected]
Web: www.griven.com
Rev. 2.0
Date:27/07/2022
page 1 of 6
Size / Dimensioni
551173
Half Moon Marine W Half Moon Marine RGBW
Code / Codice
AL5324 Half Moon Marine INOX / AL5326 Half Moon Marine BRASS
Power consumption
Consumo di energia 3W 3,5W
Remote Power supply
Alimentatore Remoto Constant Current: 900mA Constant Current: 300mA
Foward voltage 3.2 V
Electrical class
Classe elettrica III
Weight / Peso 0,4 Kg / 0,9 lb
Operating temperature
Temperatura di funzionamento -40°C to 50°C / (-40°F to 122°F)
IP rating / Grado IP IP67
IK rating / Grado IK IK07
Half Moon Marine
37.5
1.48
32
1.26
93.5
3.68
56
2.20
6.5
0.26
4
0.16
18
0.71

Half Moon Marine Rev. 2.0
page 2 of 6
551173
Important notices / Avvertimenti importanti
- This product must be installed in accordance with applicable national and local electrical and construction codes by a person familiar with the construction and
operation of the product and the hazards involved. Failure to comply with the following installation instructions may result in death or serious injury.
Questo prodotto deve essere installato secondo le normative locali, da personale specializzato. La mancata osservanza delle istruzioni di installazione può
portare a situazioni di pericolo all’incolumità della persone.
- Do not stare at the operating light source.
Non fi ssare la sorgente luminosa durante il suo funzionamento.
- The fi xture might be damaged by excess voltage. The installation of an overvoltage protection device on the electrical system may
reduce the risk of damage.
Apparecchiatura sensibile alle sovratensioni. L’installazione di un dispositivo di protezione delle sovratensioni sull’impianto elettrico attenua l’intensità di questi
fenomeni proteggendo gli apparecchi dal rischio che vengano danneggiati.
- The use of an adequate magnetothermic switch along the power supply line is recommended.
E’ consigliato l’uso di un adeguato interruttore magnetotermico/differenziale sulla linea di alimentazione.
-Connect the fi xtures to each other only when disconnected from mains.
Collegare tra loro i proiettori solo quando nessuno di essi è collegato alla rete elettrica.
- Never leave cables and connectors unconnected or unprotected for long periods.
Non lasciare mai per lungo tempo agli agenti atmosferici cavi e connettori non collegati o non protetti.
- Disconnect power before installing or servicing to avoid electrical shock.
Togliere l’alimentazione prima di effettuare qualsiasi operazione all’interno dell’apparecchiatura.
- Disconnect power before any connection operation.
Togliere l’alimentazione prima di effettuare qualsiasi operazione di connessione tra gli apparecchi.
- Check voltage and frequency before powering the fi xture. Do not exceed fi xture specifi ed voltage.
Prima di connettere l’apparecchio alla rete elettrica, verifi cate la compatibilità di tensione e frequenza.
- Do not handle the unit with wet hands or in wet environments.
Non maneggiate il prodotto con mani bagnate o in presenza di acqua.
- Apply to qualifi ed staff for any maintenance service not described in this instructions manual.
Rivolgersi ad un tecnico qualifi cato per qualsiasi operazione di manutenzione ordinaria non descritta nel presente manuale.
- Do not exceed the maximum quantity of fi xtures per line in order to avoid power surges.
Non superare il numero massimo specifi cato di apparecchi per linea per evitare pericolori sovraccarichi di corrente.
- Before powering the unit, ensure to use cables and connectors with proper section and length, according to its power consumption.
Prima di effettuare le connessioni verifi care la portata dei cavi / connettori e la lunghezza dei cavi tenendo conto dell’assorbimento del prodotto.
- Fix the projector by using screws, hooks or other adequate supports that can bear its weight.
Fissare il proiettore con viti, ganci o altri supporti in grado di sostenerne il peso.
CAUTION: Prolonged staring at the LED source should be avoided by placing the xture in a proper position.
ATTENZIONE! Fissare la sorgente LED per un periodo prolungato va evitato posizionando l’apparecchio nella posizione appropriata.
WARNING ! Fixing and connecting operations must mandatorily be carried out by qualied personnel only !
WARNING ! Make sure that power supply is o before connecting or disconnecting xtures !
ATTENZIONE ! Le operazioni di ssaggio e collegamento devono essere eseguite solo e obbligatoriamente da personale
qualicato!
ATTENZIONE ! Assicurarsi che l’alimentazione sia spenta prima di collegare o scollegare i dispositivi!

Half Moon Marine Rev. 2.0
page 3 of 6
551173
HALF MOON MARINE
Fixing / Fissaggio
WARNING ! xing and connecting operations must
mandatorily be carried out by qualied personnel only !
ATTENZIONE ! le operazioni di installazione e connessione
devono obbligatoriamente essere eseguite solo da
personale specializzato !
WARNING ! Ensure power supply is o󰀨 before connecting
or disconnecting xtures !
ATTENZIONE ! Assicurarsi che l’alimentazione sia
disattivata prima di collegare o scollegare i proiettori!
Fixing of the xture to the ground
Fissaggio del proiettore alpavimento
18 mm
(1,02 “)
ø 4 mm

Half Moon Marine Rev. 2.0
page 4 of 6
551173
Connection Half Moon W / Connessione Half Moon W
Cable type ( Power in ) - 2x0,25 mm^2 - L= 1 m
POWER IN
Tipo di cavo ( Power in ) - 2x0,25 mm^2 - L= 1 m
Cable type ( Power in ) - 8x0,25 mm^2 - L= 1 m
Tipo di cavo ( Power in ) - 8x0,25 mm^2 - L= 1 m
HALF MOON RGBW
RGBW
MARRONE = LED ROSSO +
BROWN = RED LED +
VERDE= LED VERDE +
GREEN = GREEN LED +
BLU= LED BLU +
BLUE = BLUE LED +
BIANCO= LED BIANCO +
WHITE = WHITE LED +
ROSA= LED ROSSO -
PINK = RED LED -
GIALLO= LED VERDE -
YELLOW = GREEN LED -
GRIGIO= LED BLU -
GRAY = BLUE LED -
ROSSO= LED BIANCO -
RED = WHITE LED -
AL4324/900 POWER SUPPLY UNIT
Costant Current 900 mA
AL5297
POWER SUPPLY UNIT
BLU= - BLUE= -
120-277 Vac
50- 60 Hz
MARRONE= + BROWN= +
HALF MOON W
Make only waterproof connections through IP67 junction boxes
E󰀨ettuare solo connessioni stagne attraverso scatole di derivazione IP67
A
Conguration scheme HALF MOON - White Light
ACABLE/CAVI
Brown/Marrone
Blue/Blu
USE/UTILIZZO
+
-
Schema Congurazione - HALF MOON - Luce Bianca
B
Power Supply Unit
B
Conguration scheme HALF MOON - RGBW Light
Schema Congurazione - HALF MOON - Luce RGBW
ROSSO / RED
Half Moon Marine W
AL4324/900
Code: AL5315 / AL5316 / AL5316
A
CABLE/CAVI USE/UTILIZZO
Power Supply Unit
BHalf Moon Marine
RGBW
AL5297
Code: AL5324 AL5326
+ -
-
Vac
+ - + - + - + - + -
CAVO Ø4mm / 2x0,25 mm²
CABLE Ø4mm / 2x0,25 mm²
Power Supply Unit
Alimentatore
LINE END CAP
INCLUDED IN AL5296 /
TAPPO DI FINE LINEA
INCLUSO IN AL5296
LED OUTPUT 1 +
LED OUTPUT 1 -
LED OUTPUT 2 -
LED OUTPUT 2 +
LED OUTPUT 3 +
LED OUTPUT 3 -
LED OUTPUT 4 -
LED OUTPUT 4 +
RED+ RED- GREEN + GREEN - BLUE - WHITE + WHITE - RED+ RED- GREEN + GREEN - BLUE + BLUE - WHITE + WHITE -
RED+ RED- GREEN + BLUE + BLUE - WHITE -
VERDE / GREEN
GIALLO / YELLOW
GRIGIO / GREY
ROSA / PINK
BLU / BLUE
MARRONE / BROWN
BIANCO / WHITE
RED LED + / LED ROSSO +
RED LED - / LED ROSSO -
GREEN LED - / LED VERDE -
GREEN LED + / LED VERDE +
BLUE LED + / LED BLU+
BLUE LED - / LED BLU -
WHITE LED - / LED BIANCO -
WHITE LED + / LED BIANCO +
MINIMUM 1FIXTURE MAXIMUM 8 FIXTURES
42 m
A
B
LED CODE NTC +
LED CODE NTC -
DMX IN +
DMX IN -
GROUND
DMX SHIELD
L
N
120-250 Vac
50- 60 Hz
DMX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
WHITE + GREEN -
BLUE +
MAXIMUM 10 FIXTURES
Distance between PSU and last fixture: 100m
A
Conguration scheme HALF MOON - White Light
ACABLE/CAVI
Brown/Marrone
Blue/Blu
USE/UTILIZZO
+
-
Schema Congurazione - HALF MOON - Luce Bianca
B
Power Supply Unit
B
Conguration scheme HALF MOON - RGBW Light
Schema Congurazione - HALF MOON - Luce RGBW
ROSSO / RED
Half Moon Marine W
AL4324/900
Code: AL5315 / AL5316 / AL5316
A
CABLE/CAVI USE/UTILIZZO
Power Supply Unit
BHalf Moon Marine
RGBW
AL5297
Code: AL5324 AL5326
+ -
-
Vac
+ - + - + - + - + -
CAVO Ø4mm / 2x0,25 mm²
CABLE Ø4mm / 2x0,25 mm²
Power Supply Unit
Alimentatore
LINE END CAP
INCLUDED IN AL5296 /
TAPPO DI FINE LINEA
INCLUSO IN AL5296
LED OUTPUT 1 +
LED OUTPUT 1 -
LED OUTPUT 2 -
LED OUTPUT 2 +
LED OUTPUT 3 +
LED OUTPUT 3 -
LED OUTPUT 4 -
LED OUTPUT 4 +
RED+ RED- GREEN + GREEN - BLUE - WHITE + WHITE - RED+ RED- GREEN + GREEN - BLUE + BLUE - WHITE + WHITE -
RED+ RED- GREEN + BLUE + BLUE - WHITE -
VERDE / GREEN
GIALLO / YELLOW
GRIGIO / GREY
ROSA / PINK
BLU / BLUE
MARRONE / BROWN
BIANCO / WHITE
RED LED + / LED ROSSO +
RED LED - / LED ROSSO -
GREEN LED - / LED VERDE -
GREEN LED + / LED VERDE +
BLUE LED + / LED BLU+
BLUE LED - / LED BLU -
WHITE LED - / LED BIANCO -
WHITE LED + / LED BIANCO +
MINIMUM 1FIXTURE MAXIMUM 8 FIXTURES
42 m
A
B
LED CODE NTC +
LED CODE NTC -
DMX IN +
DMX IN -
GROUND
DMX SHIELD
L
N
120-250 Vac
50- 60 Hz
DMX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
WHITE + GREEN -
BLUE +
MAXIMUM 10 FIXTURES
Distance between PSU and last fixture: 100m

Half Moon Marine Rev. 2.0
page 5 of 6
551173
Cable type ( Power in ) - 2x0,25 mm^2 - L= 1 m
POWER IN
Tipo di cavo ( Power in ) - 2x0,25 mm^2 - L= 1 m
Cable type ( Power in ) - 8x0,25 mm^2 - L= 1 m
Tipo di cavo ( Power in ) - 8x0,25 mm^2 - L= 1 m
HALF MOON RGBW
RGBW
MARRONE = LED ROSSO +
BROWN = RED LED +
VERDE= LED VERDE +
GREEN = GREEN LED +
BLU= LED BLU +
BLUE = BLUE LED +
BIANCO= LED BIANCO +
WHITE = WHITE LED +
ROSA= LED ROSSO -
PINK = RED LED -
GIALLO= LED VERDE -
YELLOW = GREEN LED -
GRIGIO= LED BLU -
GRAY = BLUE LED -
ROSSO= LED BIANCO -
RED = WHITE LED -
AL4324/900 POWER SUPPLY UNIT
Costant Current 900 mA
AL5297
POWER SUPPLY UNIT
BLU= - BLUE= -
120-277 Vac
50- 60 Hz
MARRONE= + BROWN= +
HALF MOON W
A
Conguration scheme HALF MOON - White Light
ACABLE/CAVI
Brown/Marrone
Blue/Blu
USE/UTILIZZO
+
-
Schema Congurazione - HALF MOON - Luce Bianca
B
Power Supply Unit
B
Conguration scheme HALF MOON - RGBW Light
Schema Congurazione - HALF MOON - Luce RGBW
ROSSO / RED
Half Moon Marine W
AL4324/900
Code: AL5315 / AL5316 / AL5316
A
CABLE/CAVI USE/UTILIZZO
Power Supply Unit
BHalf Moon Marine
RGBW
AL5297
Code: AL5324 AL5326
+ -
-
Vac
+ - + - + - + - + -
CAVO Ø4mm / 2x0,25 mm²
CABLE Ø4mm / 2x0,25 mm²
Power Supply Unit
Alimentatore
LINE END CAP
INCLUDED IN AL5296 /
TAPPO DI FINE LINEA
INCLUSO IN AL5296
LED OUTPUT 1 +
LED OUTPUT 1 -
LED OUTPUT 2 -
LED OUTPUT 2 +
LED OUTPUT 3 +
LED OUTPUT 3 -
LED OUTPUT 4 -
LED OUTPUT 4 +
RED+ RED- GREEN + GREEN - BLUE - WHITE + WHITE - RED+ RED- GREEN + GREEN - BLUE + BLUE - WHITE + WHITE -
RED+ RED- GREEN + BLUE + BLUE - WHITE -
VERDE / GREEN
GIALLO / YELLOW
GRIGIO / GREY
ROSA / PINK
BLU / BLUE
MARRONE / BROWN
BIANCO / WHITE
RED LED + / LED ROSSO +
RED LED - / LED ROSSO -
GREEN LED - / LED VERDE -
GREEN LED + / LED VERDE +
BLUE LED + / LED BLU+
BLUE LED - / LED BLU -
WHITE LED - / LED BIANCO -
WHITE LED + / LED BIANCO +
MINIMUM 1FIXTURE MAXIMUM 8 FIXTURES
42 m
A
B
LED CODE NTC +
LED CODE NTC -
DMX IN +
DMX IN -
GROUND
DMX SHIELD
L
N
120-250 Vac
50- 60 Hz
DMX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
AL5296
3 WAY JUNCTION BOX
WHITE + GREEN -
BLUE +
MAXIMUM 10 FIXTURES
Distance between PSU and last fixture: 100m

Half Moon Marine Rev. 2.0
page 6 of 6
551173
Note: Allowed operation only between sunset and sunrise
Nota: Accensione dell’apparecchio ammessa soltanto tra gli orari di tramonto e alba
Forward
voltage led Current Code Description PSU ON/OFF IP20 1 PSU for (X)  xutures
PSU DALI IP20
1 PSU for (X)  xutures
PSU ON/OFF IP67
1 PSU for 1  xutures
PSU ON-OFF AND DALI IP67
1 PSU for (X)  xutures
PSU 0-10V IP67
1 PSU for (X)  xutures
35V 250mA AL5309 / AL5327 Moon Marine W N.A AL5295/250 (DALI)
(1-3pcs)
AL5363/250 (DALI)
(1pc) N/A N/A
35V 250mA AL5311 / AL5325 Moon Recessed W / Moon Recessed
Adjustable N.A AL5295/250 (DALI) (1-3pcs)
AL5363/250 (DALI)
(1pc) N/A N/A
35V 350mA AL5310 / AL5312 /
AL5314 Moon W AL5360/350 (ON/OFF) (1pc)
AL5295 (DALI) (1-
3pcs)
AL5363/350 (DALI)
(1pc)
AL5364/350
(1pc)
AL5364/350
(1pc)
3V 700mA AL5317 Half Moon Recessed W AL5360/700
(ON/OFF) (1-12pcs)
AL4324/700 (DALI)
(1-9pcs) N/A AL5363/700 (4-14pcs)
AL5364/700
(4-14pcs)
3V 800mA AL5309 / AL5327 Moon Marine Ultraspot W AL5360/800
(ON/OFF) (1-12pcs)
AL4324/800 (DALI)
(1-8pcs) N/A AL5364/800 (4-14pcs)
AL5364/800
(4-14pcs)
3V 800mA AL5311 / AL5325 Moon Recessed Ultraspot W / Moon
Recessed Adjustable Ultraspot W
AL5360/800
(ON/OFF) (1-12pcs)
AL4324/800 (DALI)
(1-8pcs) N/A AL5364/800 (4-14pcs)
AL5364/800
(4-14pcs)
3V 900mA AL5315/ AL5316 /
AL5318 Half Moon W AL5360/900 (ON/OFF) (1-12pcs)
AL4324/900 (DALI)
(1-8pcs) N/A AL5364/900 (4-14pcs)
AL5364/900
(4-14pcs)
3V 900mA AL5324 / AL5326 Half Moon Marine W AL5360/900
(ON/OFF) (1-12pcs)
AL4324/900 (DALI)
(1-8pcs) N/A AL5364/900 (4-14pcs)
AL5364/900
(4-14pcs)
3V 1000mA AL5310 / AL5312 /
AL5314 Moon Ultraspot W AL5360/1000 (ON/OFF) (1-12pcs)
AL4324/1000 (DALI)
(1-8pcs) N/A AL5364/1000 (4-14pcs)
AL5364/1000
(4-14pcs)
Remote PSU / Alimentatori Esterni
