Griven Graph-i-Pix Opaline Series User manual

Graph-i-Pix Opaline User Manual
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
© Copyright Griven 2020 - Griven reserves the right to make
changes to this product and related instructions at any time
without prior notice and such changes shall be effective
immediatly.
Tel. [phone]
Fax [phone]
E-mail: [email protected]
Web: www.griven.com
AL6010 - AL6008 - AL6007
550073 Rev.01
Date: 13/07/2023
page 1 of 6
Size / Dimensioni
AL6010
Graph-i-pix 30
AL6008
Graph-i-pix 50
AL6007
Graph-i-pix 100
Weight / Peso 0.22 Kg / 0,485 lb 0.33 Kg / 0.75 lb 0.65 Kg / 1.433 lb
Housing / Corpo proiettore Alluminum, scratch resistant paint
IK rating / classe IK IK08
IP rating / grado IP IP66
Ambient temp./ Temperatura ambientale -40°C to 60°C ( -40°F to 140°F)
Power supply / Alimentazione +24 VDC ( from external PSU )
Power / Potenza massima 4W RGB
5W RGBW / W / DW
6W RGB
7.5W RGBW / W / DW
12W RGB
15W RGBW / W / DW
Thermal protection / Protezione termica Electronic
Electrical class / Classe elettrica III
Cable / Cavo 200 mm + 200 mm with connectors
Control / Sistema di controllo USITT DMX-512
Led conguration / Congurazione dei led RGB
RGB+W 3000K
RGB+W 4000K
DW FROM 1800K TO 6500K
W (2200K, 2700K, 3000K, 4000K)
Pixels / Pixel 1/2 1/2/4 1/2/4/8
Channels / Canali RGB 3/6 channels
RGBW 4/8 channels
DW 2/4 channels
W 1/2 channels
RGB 3/6/12 channels
RGBW 4/8/16 channels
DW 2/4/8 channels
W 1/2/4 channels
RGB 3/6/12/24 channels
RGBW 4/8/16/32 channels
DW 2/4/8/16 channels
W 1/2/4/8 channels
Resolution / Risoluzione 960 Px/m2 (max)
Luminance / Luminanza RGB 840 cd/m²
RGBW 1200 cd/m²
DW 2000 cd/m²
W 2000 cd/m²
Optics/ Ottiche Opaline diffuser
30mm
1 1/8"
45mm
1 3/4"
200mm
7 7/8"
999mm
39 3/8"
200mm
7 7/8"
499
19 5/8"
299
11 3/4"
Graph-i-pix 30
Graph-i-pix 50
Graph-i-pix 100

Graph-i-Pix - 550073 Rev.01
page 2 of 6
Important notices / Avvertimenti importanti
- This product must be installed in accordance with applicable national and local electrical and construction codes by a person familiar with the construction and
operation of the product and the hazards involved. Failure to comply with the following installation instructions may result in death or serious injury.
Questo prodotto deve essere installato secondo le normative locali, da personale specializzato. La mancata osservanza delle istruzioni di installazione può
portare a situazioni di pericolo all’incolumità della persone.
- Do not stare at the operating light source.
Non fi ssare la sorgente luminosa durante il suo funzionamento.
- The fi xture might be damaged by excess voltage. The installation of an overvoltage protection device on the electrical system may
reduce the risk of damage.
Apparecchiatura sensibile alle sovratensioni. L’installazione di un dispositivo di protezione delle sovratensioni sull’impianto elettrico attenua l’intensità di questi
fenomeni proteggendo gli apparecchi dal rischio che vengano danneggiati.
- The use of an adequate magnetothermic switch along the power supply line is recommended.
E’ consigliato l’uso di un adeguato interruttore magnetotermico/differenziale sulla linea di alimentazione.
- Connect the fi xtures to each other only when disconnected from mains.
Collegare tra loro i proiettori solo quando nessuno di essi è collegato alla rete elettrica.
- Never leave cables and connectors unconnected or unprotected for long periods.
Non lasciare mai per lungo tempo agli agenti atmosferici cavi e connettori non collegati o non protetti.
- Disconnect power before installing or servicing to avoid electrical shock.
Togliere l’alimentazione prima di effettuare qualsiasi operazione all’interno dell’apparecchiatura.
- Disconnect power before any connection operation.
Togliere l’alimentazione prima di effettuare qualsiasi operazione di connessione tra gli apparecchi.
- Check voltage and frequency before powering the fi xture. Do not exceed fi xture specifi ed voltage.
Prima di connettere l’apparecchio alla rete elettrica, verifi cate la compatibilità di tensione e frequenza.
- Do not handle the unit with wet hands or in wet environments.
Non maneggiate il prodotto con mani bagnate o in presenza di acqua.
- Apply to qualifi ed staff for any maintenance service not described in this instructions manual.
Rivolgersi ad un tecnico qualifi cato per qualsiasi operazione di manutenzione ordinaria non descritta nel presente manuale.
- Do not exceed the maximum quantity of fi xtures per line in order to avoid power surges.
Non superare il numero massimo specifi cato di apparecchi per linea per evitare pericolori sovraccarichi di corrente.
- Before powering the unit, ensure to use cables and connectors with proper section and length, according to its power consumption.
Prima di effettuare le connessioni verifi care la portata dei cavi / connettori e la lunghezza dei cavi tenendo conto dell’assorbimento del prodotto.
- Fix the projector by using screws, hooks or other adequate supports that can bear its weight.
Fissare il proiettore con viti, ganci o altri supporti in grado di sostenerne il peso.
CAUTION: Prolonged staring at LED source should be avoided by placing the xture in a proper position.

Graph-i-Pix - 550073 Rev.01
page 3 of 6
Fixing / Fissaggio
WARNING ! xing and connecting operations must mandatorily be carried out by qualied personnel only !
ATTENZIONE ! le operazioni di installazione e connessione devono obbligatoriamente essere eseguite solo da per-
sonale specializzato !
WARNING ! Ensure power supply is o󰀨 before connecting or disconnecting xtures !
ATTENZIONE ! Assicurarsi che l’alimentazione sia disattivata prima di collegare o scollegare i proiettori!
Graph-i-Pix can be xed to a surface by using specic clips.
Graph-i-Pix può essere ssato utilizzando 3 differenti tipi di aggancio.
34mm
1 3/8"
47mm
1 7/8"
50mm
2"
50mm
2"
30mm
1 1/8"
10mm
3/8"
5mm
1/8"
34mm
1 3/8"
47mm
1 7/8"
25mm
1"
25mm
1"
5mm
1/8"
12mm
1/2"
10mm
3/8"
42mm
1 5/8"
70mm
2 3/4"
33mm
1 1/4"
33mm
1 1/4"
31mm
1 1/4"
10mm
3/8"
5mm
1/8"
14mm
1/2"
FIXING BRACKETS
MOUNTING BASE
ELASTIC BUCKLE
Connecting / Connessione
Execute the connections in the start line box AL6004 as shown in the picture here below.
Schema di connessione della Start line Box AL6004.
62
26
19
0.25M
1M 2pin power cable
2*1.0mm²
1M 5pin Data cable
2*1.0mm²+3*0.5mm²
5pin Female connector
Blue +
Brown -
Red(Cut off)
Green - DA (Data +)
Yellow - DB (Data-)
Blue - IP
Black(Cut off)
（Exposed 3pin signal cable）
*DMX cable type: 2x0.34 mmq impedance 110Ω, capacity 43pF/m, resistance 50Ω/Km.

Graph-i-Pix - 550073 Rev.01
page 4 of 6
Setup / Avviamento
The addressing of the single light xture has to be executed by using the AL6012 DMX Address Assigner (purchasable separately).
L’indirizzamento dei proiettori va effettuato mediante AL6012 DMX Address Assigner (acquistabile separatamente).
Conguration scheme / Schema di congurazione
The system conguration of Graph-i-Pix units must always take into consideration two factors:
• The power of the lighting xtures connected in series:
The power of the xtures connected to an AL8294 power supply must not exceed 150W.
The power of the xtures connected to an AL8276 power supply must not exceed 300W (150W on the right and 150W on
the left side of the T-junction).
• The number of DMX channels used by the installed xtures must not exceed 512 per DMX universe.
Different combinations are possible depending on different power supply units, kind of projectors, and features of the system.
The following diagrams show some examples of conguration.
Our CUSTOMER CARE is available to assist you in choosing the best conguration for your installation. Please write an email
to [email protected].
La congurazione di un impianto con Graph-i-Pix va realizzata considerando sempre 2 fattori:
• la potenza degli apparecchi collegati in serie.
La potenza dei proiettori collegati ad un alimentatore AL8294 non deve superare i 150W.
La potenza dei proiettori collegati ad un alimentatore AL8276 non deve superare i 300W (150W a destra e 150W a sinistra
della giunzione a T).
• il numero dei canali DMX utilizzati dai proiettori non deve superare i 512 per universo DMX.
Sono possibili diverse combinazioni a seconda degli alimentatori, del tipo di proiettori e della caratteristiche dell’impianto.
Negli schemi seguenti sono riportati alcuni esempi di congurazione.
Il nostro CUSTOMER CARE è a disposizione per aiutarvi a scegliere la congurazione migliore per la vostra installazione.
Mandate le vostre richieste tramite email a [email protected].

Graph-i-Pix - 550073 Rev.01
page 5 of 6
Conguration sample with Graph-i-Pix 100 RGBW 8 pixel
01
100~277 VAC 50/60Hz
10 Graph-i-Pix 100 RGBW max (320 channels)
100~277 VAC 50/60Hz
Ethernet line
DMX line
100~277 VAC 50/60Hz
DMX Interface
To other DMX interfaces
Ethernet switch
AL8294
Electronic Driver
DMX line
AL6004
Start Line Box
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6004
Start Line Box
01 100~277 VAC 50/60Hz
DMX line
16 Graph-i-Pix 100 RGBW (8 left and 8 right) = 512 DMX channels
DMX Interface
DMX line
AL8252
Line end cap
100~277 VAC 50/60Hz
AL8276
Electronic Driver
AL5226 T Junction
AL6011 T Juntcion
to be used every 10 - 11 projectors,
or in case the Graph-i-pix are
connected by extension cables
100~277 VAC 50/60Hz
AL8276
Electronic Driver
16 Graph-i-Pix 100 RGBW (8 left and 8 right) = 512 DMX channels
AL8252
Line end cap
AL6014
Start line cable
AL8277
Single Joint
AL8277
Single Joint
A6005
Line end cap
AL6005
Line end cap
10 Graph-i-Pix 100 RGBW max (320 channels)
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6004
Start Line Box
AL6014
Start line cable
AL5226 T Junction
01 100~277 VAC 50/60Hz
DMX Interface
DMX line
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6015
Repower Box
AL6005
Line end cap
10 Graph-i-Pix 100 RGBW max (320 channels)
6 Graph-i-Pix 100 RGBW (192 channels)
DMX line
DMX line
Lighting Media Server AL2025

Graph-i-Pix - 550073 Rev.01
page 6 of 6
Conguration sample with Graph-i-Pix 100 RGB 2 pixel
01
100~277 VAC 50/60Hz
10 Graph-i-Pix 100 RGB max (60 channels)
100~277 VAC 50/60Hz
Ethernet line
DMX line
100~277 VAC 50/60Hz
DMX Interface
To other DMX interfaces
Ethernet switch
AL8294
Electronic Driver
DMX line
AL6004
Start Line Box
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6004
Start Line Box
20 Graph-i-Pix 100 RGB max (10 left and 10 right) = 120 DMX channels
100~277 VAC 50/60Hz
AL8276
Electronic Driver
AL5226 T Junction
AL6011 T Juntcion
to be used every 10 - 11 projectors,
or in case the Graph-i-pix are
connected by extension cables
100~277 VAC 50/60Hz
AL8276
Electronic Driver
20 Graph-i-Pix 100 RGB max (10 left and 10 right) = 120 DMX channels
AL8277
Single Joint
A6005
Line end cap
AL6005
Line end cap
10 Graph-i-Pix 100 RGB max (60 channels)
100~277 VAC 50/60Hz
DMX line
AL8294
Electronic Driver
AL6004
Start Line Box
AL6014
Start line cable
AL5226 T Junction
01 100~277 VAC 50/60Hz
DMX Interface
DMX line
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6015
Repower Box
10 Graph-i-Pix 100 RGB max (60 channels) 10 Graph-i-Pix 100 RGB max (60 channels)
DMX line
Lighting Media Server AL2025
AL8277
Single Joint
AL8277
Single Joint
AL6016
End line cable
AL6016
End line cable
DMX line
AL6005
Line end cap
100~277 VAC 50/60Hz
AL8294
Electronic Driver
AL6015
Repower Box
10 Graph-i-Pix 100 RGB max (60 channels)
AL6005
Line end cap
