Grizzly G0465 Quick start guide

Model G0464/G0465/G0467/G0468/G0470 Air Compressors
-24-
G0465 Parts Breakdown








 


















 



 










 










 














 





















Model G0464/G0465/G0467/G0468/G0470 Air Compressors -25-
G0465 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PSB07M CAP SCREW M6-1 X 30 42 P0465042 REAR MOTOR COVER
2 PLW03M LOCK WASHER 6MM 42-1 P0465042-1 STATOR COVER
3 P0465003 CYLINDER HEAD 43 PLW01M LOCK WASHER 5MM
4 P0465004 EXHAUST ELBOW 3/8 X 3/8 44 PN06M HEX NUT M5-0.8
5 P0465005 GASKET 45 P0465045 CENTRIFUGAL SWITCH
6 P0465006 VALVE PLATE 46 PS38M PHLP HD SCR M4-0.7 X 10
7 P0465007 VALVE REED 47 PLW02M LOCK WASHER 4MM
8 P0465008 GASKET LOWER 48 P0465048 FAN
9 P0465009 PISTON 49 P0465049 SHROUD
10 P0465010 GASKET UPPER 50 PB95M HEX BOLT M5-.8 X 16
11 P0465011 CYLINDER 51 P0465051 BALL VALVE
12 PSB02M CAP SCREW M6-1 X 20 52 P0465052 REGULATOR
13 P0465013 GASKET LOWER 53 P0465053 PRESSURE GAUGE
14 P0465014 COMPRESSION RING 54 P0465054 SAFETY VALVE
15 P0465015 OIL RING 55 P0465055 PRESSURE GAUGE
16 P0465016 PISTON PIN 56 P0465056 STRAIN RELIEF
17 P0465017 CLIP PIN 57 P0465057 PRESSURE SWITCH
18 P0465018 CONNECTING ROD 58 P0465058 CONNECTOR NPT 1/4 X 27
19 P0465019 ECCENTRIC 59 P0465059 CONNECTOR NPT 1/4 X 48
20 PN01M HEX NUT M6-1 60 P0465060 PRESSURE RELIEF TUBE
21 P0465021 OIL FILLER CAP 61 P0465061 COMPRESSION NUT 1/8
21-1 P0465021-1 O-RING 62 P0465062 POWER CORD 14 GA X 2
22 P0465022 HEX BOLT M5-0.8 X 155 63 P0465063 CABLE CONNECTOR
23 PW02M FLAT WASHER 5MM 64 P0465064 CABLE CONNECTOR
24 P0465024 OIL SIGHT GAUGE 65 P0465065 CABLE CONNECTOR
25 P0465025 OIL SIGHT GAUGE SEAL 66 P0465066 GRIP HANDLE
26 P0465026 CRANKCASE COVER 67 P0465067 CHECK VALVE
27 P0465027 GASKET 68 P0465068 FOOT
28 P0465028 OIL SEAL B16 X 35 X 7 69 PB07M HEX BOLT M8-1.25 X 25
29 P0465029 CRANKCASE 70 PW01M FLAT WASHER 8MM
30 P0465030 CAPACITOR 200MFD 125 VAC 71 P0465071 CABLE CLAMP
31 P0465031 CAPACITOR 40 MFD 250 VAC 72 P0465072 DRAIN VALVE
32 PN06M HEX NUT M5-0.8 73 P0465073 TANK 3 GAL
33 PW01M FLAT WASHER 8MM 74 P0465074 FERRULE
34 PLW09M LOCK WASHER 3MM 75 P0465075 OUTLET TUBE
35 PS12M PHLP HD SCR M3-0.5 X 6 76 P0465076 FIN TUBING
36 P0465036 SPACER 77 P0465077 FLARE NUT
37 P6203 BALL BEARING 6203 78 PB07M HEX BOLT M8-1.25 X 25
38 PR18M EXT RETAINING RING 17MM 79 P0465079 FERRULE
39 P0465039 ROTOR 80 P0465080 AIR FILTER KIT
40 P6004 BALL BEARING 6004ZZ 81 PW05M FLAT WASHER 4MM
41 P0465041 STATOR 115V/60HZ
