Model G0466/G0469 Air Compressors
-26-
G0469 Parts Breakdown
















 

 




 



 

















































Model G0466/G0469 Air Compressors -27-
G0469 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PB105M HEX BOLT M6-1 X 55 41 P0469041 STATOR 100V/60HZ
2 PLW03M LOCK WASHER 6MM 42 P0469042 REAR MOTOR COVER
3 P0469003 CYLINDER HEAD 43 P0469043 FAN
4 P0469004 EXHAUST ELBOW 44 P0469044 HEX BOLT M5-.8 X 120
5 P0469005 CYLINDER HEAD GASKET 45 PLW01M LOCK WASHER 5MM
6 P0469006 VALVE ASSEMBLY 46 P0469046 GASKET
7 P0469007 VALVE PLATE 47 PR02M EXT RETAINING RING 14MM
8 P0469008 VALVE PATCH 48 P0469048 COVER
9 P0469009 PISTON 49 PB95M HEX BOLT M5-.8 X 15
10 P0469010 CYLINDER GASKET 50 PW02M FLAT WASHER 5MM
11 P0469011 CYLINDER 51 P0469051 QUICK CONNECT-FEMALE
12 PSB31M CAP SCREW M8-1.25 X 25 52 P0469052 PRESSURE GAUGE
13 PLW04M LOCK WASHER 8MM 53 P0469053 PRESSURE GAUGE
14 P0469014 CYLINDER GASKET 54 P0469054 REGULATOR
15 P0469015 COMPRESSION RING 55 P0469055 CONNECT NPT1/4
16 P0469016 OIL RING 56 P0469056 PRESSURE SWITCH
17 P0469017 PISTON PIN 57 P0469057 STRAIN RELIEF
18 PR03M EXT RETAINING RING 12MM 58 P0469058 CONNECT
19 P0469019 CONNECTING ROD 59 P0469059 COMPRESSION NUT 3/8
20 P0469020 ECCENTRIC 60 P0469060 SPECIAL WASHER
21 P0469021 HEX BOLT M8-1.25 X 22 LH 61 P0469061 SAFETY RELIEF
22 P0469022 OIL FILL BREATHER PLUG 62 P0469062 COMPRESSION NUT
23 PB91M HEX BOLT M6-1 X 18 63 P0469063 TUBE
24 P0469024 OIL SIGHT 64 P0469064 POWER CORD
25 P0469025 O-RING 65 P0469065 CABLE CONNECTOR (O)
26 P0469026 CRANKCASE COVER 66 P0469066 CABLE CONNECTOR (U)
27 P0469027 GASKET 67 P0469067 HANDLE GRIP
28 P0469028 OIL SEAL 68 P0469068 CHECK VALVE
29 P0469029 CRANKCASE 69 P0469069 RUBBER FOOT
30 PN03M HEX NUT M8-1.25 70 PW01M FLAT WASHER 8MM
31 PW01M FLAT WASHER 8MM 71 PB09M HEX BOLT M8-1.25 X 20
32 PB15M HEX BOLT M8-1.25 X 40 72 P0469072 DRAIN VALVE
33 P0469033 LOCK GASKET 73 P0469073 TANK
34 P0469034 CAPACITOR 100 MFD 250 VAC 74 P0469074 COMPRESSION NUT 3/4
35 PW07M FLAT WASHER 3MM 75 P0469075 EXHAUST PIPE
36 PLW09M LOCK WASHER 3MM 76 P0469076 FIN TUBING
37 PS12M PHLP HD SCR M3-.5 X 6 77 P0469077 AIR FILTER
38 P6204 BALL BEARING 6204 78 PHTEK15M TAP SCREW M4 X 10
39 P0469039 ROTOR 79 P0469079 GASKET
40 P6202 BALL BEARING 6202 80 P0469080 PLUG
