Grizzly G8688 User manual
MODEL G8688
MINI METAL LATHE
OWNER'S MANUAL
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
This manual provides critical safety instructions on the proper setup,
operation, maintenance and service of this machine/equipment.
Failure to read, understand and follow the instructions given in this
manual may result in serious personal injury, including amputation,
electrocution or death.
The owner of this machine/equipment is solely responsible for its
safe use. This responsibility includes but is not limited to proper
installation in a safe environment, personnel training and usage
authorization, proper inspection and maintenance, manual availability
and comprehension, application of safety devices, blade/cutter integ-
rity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.
Table of Contents
INTRODUCTION............................................................................................................................... 2
SECTION 1: SAFETY....................................................................................................................... 6
SECTION 2: CIRCUIT REQUIREMENTS ........................................................................................ 9
SECTION 3: SET UP ...................................................................................................................... 10
SECTION 4: OPERATIONS ........................................................................................................... 17
SECTION 5: ACCESSORIES......................................................................................................... 28
SECTION 6: MAINTENANCE......................................................................................................... 30
SECTION 7: SERVICE ................................................................................................................... 31
WARRANTY AND RETURNS ........................................................................................................ 45
INTRODUCTION
Contact Info
Machine Description
Manual Accuracy
your machine may not exactly match the
manual
www.grizzly.com
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
Identification
Figure 1.
NOTICE
If you have never used this type of machine or equipment before, WE STRONGLY RECOMMEND
that you read books, trade magazines, or get formal training before beginning any projects.
Regardless of the content in this section, Grizzly Industrial will not be held liable for accidents
caused by lack of training.
The information contained herein is deemed accurate as of 1/3/2010 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3Model G8688
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G8688 7" X 12" MINI METAL LATHE
Product Dimensions:
Weight................................................................................................................................................................ 75 lbs.
Length/Width/Height.................................................................................................................27-3/4 x 11-1/2 x 12 in.
Foot Print (Length/Width)................................................................................................................... 27-3/4 x 8-3/4 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight................................................................................................................................................................ 90 lbs.
Length/Width/Height............................................................................................................................. 30 x 13 x 13 in.
Electrical:
Switch................................................................................................................................................ Forward/Reverse
Switch Voltage...................................................................................................................................................... 110V
Cord Length............................................................................................................................................................ 6 ft.
Cord Gauge....................................................................................................................................................14 gauge
Minimum Circuit Size........................................................................................................................................ 10 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type...........................................................................................................................................Universal Brush
Horsepower..............................................................................................................................................3/4 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................3A
Speed............................................................................................................................................Variable RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds................................................................................................................................ Variable
Power Transfer ...................................................................................................................... Belt Drive to Gear
Bearings.................................................................................................. Shielded and Permanently Lubricated
Main Specifications:
Operation Info
Swing Over Bed........................................................................................................................................... 7 in.
Dist Between Centers.................................................................................................................................12 in.
Swing Over Cross Slide......................................................................................................................... 2-1/8 in.
Swing Over Saddle.......................................................................................................................................5 in.
Swing Over Gap........................................................................................................................................... 7 in.
Max Tool Bit Size.................................................................................................................................... 5/16 in.
Compound Travel...................................................................................................................................2-3/4 in.
Carriage Travel.................................................................................................................................... 10-1/2 in.
Cross Slide Travel..................................................................................................................................2-3/4 in.
Machine Data Sheet
The information contained herein is deemed accurate as of 1/3/2010 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 3Model G8688
Headstock Info
Spindle Bore.............................................................................................................................................20 mm
Spindle Size................................................................................................................................................. 3 in.
Spindle Taper.............................................................................................................................................MT#3
No Of Spindle Speeds........................................................................................................................... Variable
Spindle Speeds..................................................................................................Low:0-1100, High:0-2500 RPM
Spindle Type.........................................................................................................................Intrinsic Back Plate
Spindle Bearings..............................................................................................................................Ball Bearing
Tailstock Info
Tailstock Travel...................................................................................................................................... 2-1/2 in.
Tailstock Taper.......................................................................................................................................... MT#2
Tailstock Barrel Diameter...................................................................................................................... 0.870 in.
Threading Info
No Of Inch Threads.........................................................................................................................................18
Range Of Inch Threads..................................................................................................................... 12 - 52 TPI
Range Of Longitudinal Feeds..................................................................................................................0.04 in.
No Of Longitudinal Feeds................................................................................................................................. 1
No Of Metric Threads......................................................................................................................................10
Range Of Metric Threads...............................................................................................................0.4 - 2.0 mm
Dimensions
Bed Width...............................................................................................................................................3-1/4 in.
Leadscrew TPI................................................................................................................................................ 16
Leadscrew Length................................................................................................................................17-3/4 in.
Follow Rest Capacity....................................................................................................................................1 in.
Faceplate Size....................................................................................................................................... 6-1/4 in.
Leadscrew Diameter................................................................................................................................. 5/8 in.
Floor To Center Height...........................................................................................................................8-1/2 in.
Construction
Base Construction................................................................................................................................ Cast Iron
Headstock Construction....................................................................................................................... Cast Iron
Headstock Gears Construction.................................................................................................................Plastic
Bed Construction.................................................................................................................................. Cast Iron
Body Construction................................................................................................................................ Cast Iron
Paint.......................................................................................................................................................... Epoxy
Other
Kilowatt Output...........................................................................................................................................0.559
Optional Stand..........................................................................................................................................G7313
Other Specifications:
Country Of Origin ................................................................................................................................................China
Warranty ............................................................................................................................................................ 1 Year
Serial Number Location .................................................................................................. Back Right End on Bed Way
Features:
16 TPI Reversible Leadscrew
Chip Tray and Backsplash Guard
Emergency Stop
Forward and Reverse in all Speeds
Inch/Metric Dials
Threading Dial Indicator
Variable Speed
4. ALWAYS USE HEARING PROTECTION
WHEN OPERATING MACHINERY.
5. WEAR PROPER APPAREL.
6. NEVER OPERATE MACHINERY WHEN
TIRED, OR UNDER THE INFLUENCE OF
DRUGS OR ALCOHOL.
1. READ THROUGH THE ENTIRE MANUAL
BEFORE STARTING MACHINERY.
2. ALWAYS USE ANSI APPROVED
SAFETY GLASSES WHEN OPERATING
MACHINERY.
3. ALWAYS WEAR AN ANSI APPROVED
RESPIRATOR WHEN OPERATING
MACHINERY THAT PRODUCES DUST.
For Your Own Safety, Read Instruction
Manual Before Operating this Machine
The purpose of safety symbols is to attract your attention to possible hazardous conditions. This
manual uses a series of symbols and signal words which are intended to convey the level of
importance of the safety messages. The progression of symbols is described below. Remember
that safety messages by themselves do not eliminate danger and are not a substitute for proper
accident prevention measures.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury. It may also be used to alert
against unsafe practices.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
This symbol is used to alert the user to useful information about
proper operation of the machine.
NOTICE
Safety Instructions for Machinery
SECTION 1: SAFETY
7. ONLY ALLOW TRAINED AND PROP-
ERLY SUPERVISED PERSONNEL TO
OPERATE MACHINERY.
8. KEEP CHILDREN AND VISITORS AWAY.
9. MAKE WORKSHOP CHILD PROOF.
10. NEVER LEAVE WHEN MACHINE IS
RUNNING. Off
11. DO NOT USE IN DANGEROUS
ENVIRONMENTS.
12. KEEP WORK AREA CLEAN AND WELL
LIT.
13. USE A GROUNDED EXTENSION CORD
RATED FOR THE MACHINE AMPERAGE.
14.
ALWAYS DISCONNECT FROM POWER
SOURCE BEFORE SERVICING
MACHINERY
15. MAINTAIN MACHINERY WITH CARE.
16. MAKE SURE GUARDS ARE IN PLACE
AND WORK CORRECTLY BEFORE
USING MACHINERY.
Safety Instructions for Machinery
17. REMOVE ADJUSTING KEYS AND
WRENCHES.
ON
18. CHECK FOR DAMAGED PARTS
BEFORE USING MACHINERY.
19. USE RECOMMENDED ACCESSORIES.
20. DO NOT FORCE MACHINERY.
21. SECURE WORKPIECE.
22. DO NOT OVERREACH.
23. MANY MACHINES WILL EJECT THE
WORKPIECETOWARDTHEOPERATOR.
24. ALWAYS LOCK MOBILE BASES
(IF USED) BEFORE OPERATING
MACHINERY
25. BE AWARE THAT CERTAIN MATERI-
ALS MAY CAUSE AN ALLERGIC REAC-
TION
Additional Safety for Metal Lathes
1. READ AND UNDERSTAND THIS
MANUAL BEFORE OPERATING THIS
MACHINE. YOUR SAFETY AND THE
PROPER USE OF THIS MACHINE IS
YOUR RESPONSIBILITY.
2. CLEARING CHIPS.
3. CHUCK KEY SAFETY.
4. TOOL SELECTION.
5.SECURING THE WORKPIECE.
6. SUPPORT LONG STOCK.
7. INSTALLING LARGE CHUCKS.
8. PINCH HAZARDS.
9.LATHE MAINTENANCE.
10. SAFETY CLEARANCES.
11. PROPER FEED RATES.
12. STOPPING LATHE.
13. ATTENDANCE.
14. LONG HAIR.
15. AUTOMATIC FEEDS.
16.TURNING SPEEDS.
17. MOTOR DIRECTION.
18.GUARDS.
19.TOOL POST CLEARANCE.
ON
20. CRASHES.
SECTION 2: CIRCUIT REQUIREMENTS
Figure 2.
Grounding Prong is
Longest of the Three
Prongs
Current
Carrying Prongs Grounded
Outlet
110V Operation
Full Load Amperage Draw
Power Supply Circuit Requirements
If you are unsure about
the wiring codes in your area or you plan to
connect your machine to a shared circuit, con-
sult a qualified electrician.
This machine MUST have a ground prong in
the plug to help ensure that it is grounded.
DO NOT remove ground prong from plug
to fit into a two-pronged outlet! If the plug
will not fit the outlet, have the proper outlet
installed by a qualified electrician.
Extension Cords
Serious personal injury could occur if you
connect the machine to power before com-
pleting the setup process. DO NOT connect
the machine to the power until instructed
later in this manual.
Electrocution or fire could
result if machine is not
grounded and installed in
compliance with electrical
codes. Compliance MUST
be verified by a qualified
electrician!
Power Connection Device
Figure
2
please immediately call Customer Service at
(570) 546-9663for advice.
Otherwise, filing a freight claim can be difficult.
Wear safety glasses dur-
ing the entire set up pro-
cess!
This machine presents
serious injury hazards
to untrained users. Read
through this entire manu-
al to become familiar with
the controls and opera-
tions before starting the
machine!
Unpacking
SECTION 3: SET UP
The Model G8688 is a
heavy machine. DO NOT
over-exert yourself while
unpacking or moving
your machine—get assis-
tance.
Description Qty
Needed for Set Up
Inventory
Box 1: (Figures 3 & 4) Qty
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
O.
Figure 3.
Figure 4.
Hardware Recognition Chart
Workbench Load
Machine Data Sheet
Working Clearances
Figure 6
Site Considerations
Unsupervised children and
visitors inside your shop
could cause serious per-
sonal injury to themselves.
Lock all entrances to the
shop when you are away and
DO NOT allow unsupervised
children or visitors in your
shop at any time!
Figure 5
For optimum performance, clean all moving
parts or sliding contact surfaces.
Clean Up
Gasoline and petroleum
products have low flash
points and can explode
or cause fire if used to
clean machinery. DO
NOT use these products
to clean the machinery.
Many cleaning solvents
are toxic if inhaled.
Minimize your risk by only
using these products in a
well ventilated area.
G2544—Solvent Cleaner & Degreaser
H9692—Orange Power Degreaser
Figure 5.
Figure 6.
111⁄2"
273⁄4"
To bolt the lathe to your workbench:
1.
2. Figure 7
To attach the rubber feet:
1.
2.
Step 1Figure 8
Figure 8.
Moving & Placing
Mini Lathe
The Model G8688 is a
heavy machine. DO NOT
over-exert yourself while
unpacking or moving
your machine—get assis-
tance.
3.
Figure 7.
Installing Handwheel
Handles
Components and Hardware Needed: Qty
To install the handwheel handles:
1.
Figure 9
2.
Figure 10.
3.
Figure 10
Figure 9.
To perform the test run:
1.
2.
Page 18
3.
4.
5
ON
6.
7. Off
Off
8.
Keep clothing rolled
up and out of the way
of machinery and keep
hair pulled back.
Wear safety glasses dur-
ing all operations on the
lathe. Failure to comply
may result in serious
personal injury.
Disconnect power to the
machine when perform-
ing any adjustments or
maintenance. Failure to
do this may result in seri-
ous personal injury.
Test Run
Inspect your machine for
loose nuts and bolts, and
ensure no tools are left
in or around the machine
before connecting power.
Failure to do this may
result in personal injury.
Damage to your eyes, lungs, and ears could
result from using this machine without
proper protective gear. Always wear safety
glasses, a respirator, and hearing protection
when operating this machine.
Loose hair and cloth-
ing could get caught in
machinery and cause seri-
ous personal injury. Keep
loose clothing and long
hair away from moving
machinery.
SECTION 4: OPERATIONS
NOTICE
If you have never used this type of machine
or equipment before, WE STRONGLY REC-
OMMEND that you read books, trade maga-
zines, or get formal training before begin-
ning any projects. Regardless of the con-
tent in this section, Grizzly Industrial will
not be held liable for accidents caused by
lack of training.
Speed & Power
Controls
Figures 11 & 12
Figure 11.
A VARIABLE SPEED CONTROL DIAL:
B. Fuse Socket:
C. FORWARD/OFF/REVERSE Toggle:
D. EMERGENCY STOP Button:
NOTICE
DO NOT VOID YOUR WARRANTY! DO NOT
change spindle or leadscrew direction when
lathe is running! Damage to your lathe will
occur!
Figure 12.
5. HIGH/LOW Range Control:
Note:DO NOT shift from HIGH to LOW while
the lathe is running!
6. LEADSCREW FORWARD/NEUTRAL/
REVERSE Lever:
Note:DO NOT shift leadscrew direction while
the lathe is running!
Chuck Jaws
Figure
13
Figure 14
Figure 13.
Figure 14.
Other manuals for G8688
1
Table of contents
Other Grizzly Lathe manuals
Grizzly
Grizzly G2891 User manual
Grizzly
Grizzly G0698 User manual
Grizzly
Grizzly T10810 User manual
Grizzly
Grizzly G9730 Technical manual
Grizzly
Grizzly G4016 User manual
Grizzly
Grizzly G0492 User manual
Grizzly
Grizzly G0625 User manual
Grizzly
Grizzly T10809 User manual
Grizzly
Grizzly G8688 User manual
Grizzly
Grizzly G0624Z User manual
Grizzly
Grizzly G0554Z User manual
Grizzly
Grizzly G9972Z User manual
Grizzly
Grizzly G0462 User manual
Grizzly
Grizzly G0579 Quick start guide
Grizzly
Grizzly G5979 User manual
Grizzly
Grizzly G0765 User manual
Grizzly
Grizzly G0632Z User manual
Grizzly
Grizzly G0971 User manual
Grizzly
Grizzly T10501 User manual
Grizzly
Grizzly G0745 User manual
Popular Lathe manuals by other brands
Milltronics
Milltronics SL12 Series Instruction handbook
Sharp
Sharp 1840TC-FC Instruction manual and parts list
Axminster
Axminster SIEG X1 Super Micro Mill Mk2 user manual
FOREDOM
FOREDOM M.BL owner's manual
LittleMachineShop.com
LittleMachineShop.com HiTorque 5100 user guide
Rottler
Rottler SG9M Operation and maintenance manual
