HVLP SPRAY GUN SET
MODEL H7671/H7672
INSTRUCTION MANUAL
H7671 H7672

Model H7671/H7672 HVLP Spray Gun -3-
Table of Contents
SECTION 1: SAFETY .......................................................................................................4
Safety Instructions For Pneumatic Tools ....................................................................5
Additional Safety Instructions for HVLP Spray Guns .................................................6
SECTION 2: INTRODUCTION .........................................................................................7
Foreword .....................................................................................................................7
Contact Information ....................................................................................................7
Tool Data Sheet ..........................................................................................................8
SECTION 3: SET UP ........................................................................................................9
Inventory .....................................................................................................................9
Assembly ..................................................................................................................10
Controls ....................................................................................................................10
SECTION 4: OPERATIONS ...........................................................................................11
Spraying ....................................................................................................................11
Atomizing Cap and Fan Adjustments .......................................................................13
SECTION 5: ACCESSORIES .........................................................................................14
SECTION 6: MAINTENANCE ........................................................................................15
Cleaning ....................................................................................................................15
Lubrication ................................................................................................................16
Troubleshooting ........................................................................................................17
Notes ........................................................................................................................19
Parts Breakdown H7671-H7672 ...............................................................................20
Parts List H7671-H7672 ...........................................................................................21
WARRANTY AND RETURNS ........................................................................................22

Model H7671/H7672 HVLP Spray Gun-4-
SECTION 1: SAFETY
Indicates a potentially hazardous situation which, if
not avoided, MAY result in minor or moderate injury.
It may also be used to alert against unsafe practices.
Indicates a potentially hazardous situation which, if
not avoided, COULD result in death or serious injury.
This symbol is used to alert the user to useful infor-
mation about proper operation of the equipment.
For Your Own Safety Read Instruction Manual
Before Operating This Equipment
The purpose of safety symbols is to attract your attention to possible hazard-
ous conditions. This manual uses a series of symbols and signal words which
are intended to convey the level of importance of the safety messages. The
progression of symbols is described below. Remember that safety messages by
themselves do not eliminate danger and are not a substitute for proper accident
prevention measures.
NOTICE
Indicates an imminently hazardous situation which, if
not avoided, WILL result in death or serious injury.
Safety Instructions For Pneumatic Tools
1. KEEP ALL SAFETY DEVICES IN
PLACE and in working order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of check-
ing to see that keys and adjusting
wrenches are removed from tool
before operation.
3. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite
accidents.
4. DO NOT USE IN DANGEROUS
ENVIRONMENT. Do not use pneu-
matic tools in damp or wet loca-
tions, or where any flammable or
noxious fumes may exist. Keep
work area well lighted.
5. KEEP CHILDREN AND VISITORS
AWAY. All children and visitors
should be kept at a safe distance
from work area.
6. MAKE WORKSHOP CHILD
PROOF by locking your shop and
shutting off air valves.
7. DO NOT FORCE TOOL. It will do
the job better and safer at the rate
for which it was designed.
8. USE THE RIGHT TOOL. Do not
force tool or attachment to do a job
for which it was not designed.
9. DO NOT USE UNDER THE
INFLUENCE OF DRUGS OR
ALCOHOL.

Model H7671/H7672 HVLP Spray Gun -5-
10. USE PROPER AIR HOSE for the
tool. Make sure your air hose is in
good condition and is long enough to
reach your work without stretching.
11. WEAR PROPER APPAREL. Do not
wear loose clothing, gloves, neck-
ties, rings, bracelets, or other jew-
elry which may get caught in moving
parts. Non-slip footwear is recom-
mended. Wear a protective hair cov-
ering to contain long hair.
12. ALWAYS USE SAFETY GLASSES.
Also use a face or dust mask if cut-
ting operation is dusty. Everyday
eyeglasses only have impact resis-
tant lenses, they are NOT safety
glasses.
13. WEAR APPROVED HEARING
PROTECTION. Air escaping from
pneumatic tools can exceed safe
exposure limits and may cause
hearing damage with prolonged
exposure.
14. SECURE WORK. Use clamps or a
vise to hold work when practical. It is
safer than using your hand and frees
both hands to operate tool.
15. MAINTAIN TOOLS WITH CARE.
Keep tools lubricated and clean
for best and safest performance.
Follow instructions for lubricating
and changing accessories.
16. REDUCE THE RISK OF
UNINTENTIONAL STARTING. Do
not carry tool with hand on trig-
ger and always disconnect from air
when not in use.
17. DISCONNECT TOOLS before ser-
vicing and changing accessories.
18. DO NOT OVERREACH. Keep
proper footing/balance at all times.
19. USE THE RECOMMENDED
ACCESSORIES. Consult owner’s
manual for recommended acces-
sories. The use of improper acces-
sories may cause risk of injury.
20. CHECK FOR DAMAGED PARTS
BEFORE USING. Check for bind-
ing and alignment of parts, broken
parts, part mounting, loose bolts,
and any other conditions that may
affect machine operation. Repair or
replace damaged parts.
21. NEVER LEAVE UNATTENDED
TOOL CONNECTED TO AIR.
Disconnect the air hose and do not
leave tool until it is relieved of any
built up pressure.
22. NEVER ALLOW UNTRAINED
USERS TO USE THIS TOOL
WHILE UNSUPERVISED.
23. IF YOU ARE UNSURE OF THE
INTENDED OPERATION, STOP
USING TOOL. Seek formal training
or research books or magazines
that specialize in pneumatic tools.
24. BE AWARE OF HOSE LOCATION
WHEN USING PNEUMATIC
TOOLS. Hoses can easily become
a tripping hazard when laid across
the floor or spread out in a disorga-
nized fashion.
Safety Instructions For Pneumatic Tools

Model H7671/H7672 HVLP Spray Gun-6-
1. READ THIS MANUAL. This manual
contains proper operating instruc-
tions for this spray gun.
2. READ MATERIAL LABELS
and MATERIAL SAFETY DATA
SHEETS (MSDS). Read and know
all the instructions on the packag-
ing label and the MSDS before
opening the package. This informa-
tion could save your life.
3. RESPIRATORY PROTECTION.
Always wear a NIOSH approved
respirator when spraying or work-
ing around finishing materials.
4. FIRE EXTINGUISHERS. Always
have a fully charged multi class
or class B fire extinguisher in the
immediate area.
5. FLAMMABLE MATERIAL. NEVER
spray near open flame or where
any spark could occur.
6. FRESH AIR. Always provide ade-
quate exhaust to keep area free of
built up vapors, NEVER spray in an
enclosed space.
7. DISCONNECT COMPRESSED
AIR. Always disconnect the spray
gun from compressed air before
cleaning, changing attachments or
when performing maintenance of
any kind on this tool.
Additional Safety Instructions for HVLP Spray
Guns
8. PROTECTIVE CLOTHING. Protect
exposed skin from overspray by
wearing a protective suit or other
approved garment.
9. INAPPROPRIATE USE. DO NOT
point or shoot spray gun directly
at yourself or another person or
animals. Do not attempt to use the
spray gun for any other use than it
was intended.
10. STORAGE. Thoroughly clean and
dry spray gun before storage. Store
in an approved cabinet.
11. SOLVENTS. Always store solvents
and shop towels soaked in solvent
in approved containers.
12. EYE PROTECTION. Wear eye pro-
tection whenever spraying or clean-
ing. Solvents and chemicals can
cause serious eye injury, which
could lead to blindness.
13. OPERATING PRESSURE. DO
NOT exceed the recommended
inlet air pressure. Excessive pres-
sure could cause the spray gun to
burst or cause other internal equip-
ment damage.
14. LOCAL LAWS. Consult local
authorities regarding exhaust and
waste disposal requirements.

Model H7671/H7672 HVLP Spray Gun -7-
We are proud to offer the Grizzly Model
H7671/H7672 HVLP Spray Gun Set. These
models are part of a growing Grizzly family
of fine tools. When used according to the
guidelines set forth in this manual, you can
expect years of trouble-free, enjoyable
operation, and proof of Grizzly’s commit-
ment to customer satisfaction.
The Model H7671/H7672 features HVLP
technology, which has greater transfer
efficiency than suction feed spray guns
by reducing overspray, saving on material
costs.
It is our pleasure to provide this manual
with the Model H7671/H7672. It was writ-
ten to encourage safety considerations
and guide you through general operating
procedures and maintenance.
The specifications, details, and pho-
tographs in this manual represent the
Model H7671/H7672 as supplied when the
manual was prepared. However, owing
to Grizzly’s policy of continuous improve-
ment, changes may be made at any time
with no obligation on the part of Grizzly.
SECTION 2: INTRODUCTION
Foreword Contact Information
If you have any comments regarding this
manual, please write to us at the following
address:
Grizzly Industrial, Inc.
C/O Technical Documentation
P.O. Box 2069
Bellingham, WA 98227-2069
Most importantly, we stand behind our
tools. If you have any service questions or
parts requests, please call or write us at
the location listed below.
Grizzly Industrial, Inc.
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Web Site: http://www.grizzly.com
Read the manual before operation.
Become familiar with this tool, its
safety instructions, and its operation
before beginning any work. Serious
personal injury may result if safety or
operational information is not under-
stood or followed.

Model H7671/H7672 HVLP Spray Gun-8-
Customer Service #: [phone] • To Order Call: [phone] • Fax #: [phone]
TOOL DATA SHEET
HVLP SPRAY GUN SET MODEL
H7671/H7672
MODEL H7671 H7672
CUP SIZE 100ml 600ml 100ml 600ml
TYPE OF FEED GRAVITY GRAVITY GRAVITY GRAVITY
FLUID TIP 0.8MM 1.4MM 0.8mm 1.4mm
AIR CONSUMPTION 5 CFM 11 CFM 5 CFM 11 CFM
INLET AIR
PRESSURE
1.5-3.5 BAR
21-50 PSI
2.0-3.5 BAR
28.8-51 PSI
1.5-3.5 BAR
21-50 PSI
2.0-3.5 BAR
28.8-51 PSI
FLUID PRESSURE LESS THAN
10 PSI
LESS THAN
10 PSI
LESS THAN
10 PSI
LESS THAN
10 PSI
CUP MATERIAL METAL METAL PLASTIC PLASTIC
MAX. PATTERN
WIDTH 190mm 230mm 190mm 230mm
BODY MATERIAL POLISHED
METAL
POLISHED
METAL
POLISHED
METAL
POLISHED
METAL
MATERIAL USAGE
SMALL TO
MEDIUM
SOLIDS
MEDIUM
TO HIGH
SOLIDS
SMALL TO
MEDIUM
SOLIDS
MEDIUM TO
HIGH SOLIDS
WATERBORNE
MATERIAL
COMPATIBLE
YES YES YES YES

Model H7671/H7672 HVLP Spray Gun -9-
SECTION 3: SET UP
Figure 1. Model H7671 inventory.
B
C
Your spray gun left our warehouse in a
carefully packed box. If you discover the
spray gun is damaged after you have
signed for delivery, please immediately
call Customer Service at [phone]
for advice.
Save the containers and all packing materi-
als for possible inspection by the carrier or
its agent. Otherwise, filing a freight claim
can be difficult.
After you have unpacked the carton you
should find the following:
Model H7671 Inventory (Figure 1)
A. Large Spray Gun ............................... 1
B. Cup 600ml .......................................... 1
C. Small Spray Gun ................................ 1
D. Cup 100ml .......................................... 1
E. Cleaning Brushes ............................... 2
F. Service Wrenches .............................. 2
G. Filters ................................................. 4
H. Regulators .......................................... 2
I. Baffle Wrenches ................................. 2
Inventory
E
A
Model H7672 Inventory (Figure 2)
A. Large Spray Gun . ............................. 1
B. Cup 600ml .......................................... 1
C. Small Spray Gun ................................ 1
D. Cup 100ml .......................................... 1
E. Cleaning Brushes ............................... 2
F. Service Wrenches .............................. 2
G. Filters ................................................. 4
H. Regulators .......................................... 2
I. Baffle Wrenches ................................. 2
D
F
G
H
I
Figure 2. Model H7672 inventory.
B
C
E
A
D
F
G
H
I

Model H7671/H7672 HVLP Spray Gun-10-
1. Fluid Control: Controls the volume of
material that travels through the fluid
tip.
2. Pattern Control: Adjusts the spray
pattern from a round pattern to a wide
fan.
3. Air Flow Control: Controls the fluid
pressure inside the spray gun (H7672
only).
4. Atomizing Cap: Controls the spray
pattern from vertical to horizontal.
5. Trigger: Two stage trigger. Stage
one only releases compressed air for
blowing off the work piece. Stage two
sprays material.
6. Regulator/Gauge: Regulates inlet
air pressure to the spray gun. It can
be attached directly to the gun for on-
the-spot air adjustments or directly
from the air source.
Note: DO NOT attach the regula-
tor to an unregulated air source that
exceeds 120 PSI.
Figure 3. Installing filter.
Figure 4. Controls.
2. Screw the cup onto the top of the
body.
3. Attach the air hose to the spray gun
with a 1⁄4" NPS quick connect fitting
(not included).
4. Attach the spray gun to an air hose
regulated between 29 and 50 PSI.
Note: For the best results, use a hose
that will be dedicated for spray use
only. Do not use a hose that has been
used with an in-line oiler or other pos-
sible contaminant.
If you need additional help with this assem-
bly, call our Technical Support at: (570)
546-9663.
1. Insert the filter into the gun body (see
Figure 3). Fluid Control
Pattern Control
Atomizing Cap
Trigger
Assembly Controls
Air Flow Control
Regulator Control
