Grizzly T32859 User manual

COPYRIGHT © AUGUST, 2021 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MFD. SINCE 08/21) #CS22022 PRINTED IN CHINA
Introduction
The Model T32859 Folding Welding Table has a
load capacity of 350 lbs. The table surface has
5⁄8" diameter holes spaced every 2" for welding
operations.
The table collapses for storage when not in use.
V1.08.21
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T32859
24" X 36" FOLDING
WELDING TABLE
INSTRUCTIONS
Specifications
Weight Capacity ......................................350 lbs.
Work Table Size ....................................24" x 36"
Work Table Thickness ........................... 9 Gauge
Work Table Working Height ....................... 3111⁄16"
Inventory
Large Items (Figure 1) Qty
A. Table Assembly .......................................... 1
B. Leg Assembly ............................................. 1
Fasteners (Figure 2) Qty
C. Hex Nuts M10-1.5 (Thin) ............................. 2
D. Shoulder Screws M10-1.5 x 18 ................... 2
E. Flat Washers 10mm ................................... 4
F. Shaft Sleeves ............................................. 2
G. Hinge Pins 10 x 85mm ............................... 2
H. Cotter Pins 3.5 x 75mm .............................. 2
A
B
Figure 1. Large items inventory.
Figure 2. Fasteners.
C E
F
D
G H
Needed for Setup
The following items are needed, but not included,
for the setup/assembly of the Model T32859.
Description Qty
• Safety Glasses ........................................... 1
• Cleaner/Degreaser ..................... As Needed
• Disposable Shop Rags ............... As Needed
• Metal Protectant ......................... As Needed
• Cardboard .................................. As Needed
• Hex Wrench 10mm ..................................... 1
• Wrench or Socket 16mm ............................ 1
• Additional Person ....................................... 1

-2- Model T32859 (Mfd. Since 08/21)
Assembly
The Model T32859 requires assembly before use.
Wear safety glasses during
the entire setup process!
To assemble welding table:
1. Clean factory rust preventative off table with
cleaner/degreaser, then coat all unpainted
surfaces with quality metal protectant to
prevent rust.
2. Place table assembly face down on card-
board on floor to protect it during assembly.
3. Attach long leg to table frame with (2) M10-
1.5 x 18 shoulder screws and M10-1.5 hex
nuts (see Figure 3).
5. Secure fasteners by inserting 3.5 x 75mm cot-
ter pin through hinge pin hole (see Figure 5).
6. Repeat Steps 4–5 with other side of short
leg.
7. Have one other person help you lift welding
table and place on legs.
Figure 5. Cotter pin inserted through hinge pin.
4. Attach one side of short leg to U-brace with
10 x 85mm hinge pin, (2) 10mm flat washers,
and shaft sleeve (see Figure 4).
Figure 4. Short leg attached to U-brace.
Figure 3. Long leg attached to table frame.
Long Leg
Table Frame
x 2
Short Leg
U-Brace

Model T32859 (Mfd. Since 08/21) -3-
Safety & Correct Use Storage
DO NOT exceed table weight capacity of
350 lbs. Sudden change in dynamic load
at maximum weight capacity could cause
table to tip or collapse, resulting in serious
personal injury or property damage.
• Do not apply an unbalanced load.
• Keep unsupervised children away from the
table.
• Do not stand or climb on the table.
• Do not use in wet or damp locations.
• Do not leave rags or other items that are
damp with water, oil, paint, or solvents on the
table.
• Set up the table in a well-ventilated area
where there are no hazardous or combustible
materials that could ignite during welding
operations.
• While using an electric welder, the welder
must be grounded to either the workpiece
or the table before the welding operation.
If grounding to the table, the workpiece
must contact the table so the current may
flow through the workpiece to the grounding
clamp and close the welding circuit. Ensure
there is insulation between the operator and
the electric current (a dry rubber mat, rubber
gloves, etc.).
• Lubricate the hinge pins holding the legs
together and the shoulder screws attaching
the legs to the frame with light machine oil if
folding the table becomes difficult.
1. Lift U-brace toward underside of table, as
shown in Figure 6.
Figure 6. Lifting U-brace to fold table.
Note: You may need to adjust folding lock pin
(see Figure 7) out of the way if pin prevents
folding.
2. Lean top of table against wall or work table to
secure short leg, and lock legs together with
lock pin shown in Figure 7.
Figure 7. Long and short legs secured with lock
pin.
3. Slide into convenient location for storage.
U-Brace
Lock
Pin
Long
Leg
Short
Leg

-4- Model T32859 (Mfd. Since 08/21)
T32859 Parts Breakdown & List
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call [phone] or visit our online parts store at www.grizzly.com to check for availability.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
10
11
12
14
14
14
18
Toreduce risk of serious injury when using this table:
1. Read owner ’s manual before using table.
2. Ensure machine is correctly set up before using.
3. Always wear ANSI-approved eye protection.
4. Do not exceed maximum weight capacity of 350 lbs.
PINCHHAZARD!
Keephandsaway from
hingeareawhen
closingstand.
PINCHHAZARD!
Keephandsaway from
hingeareawhen
closingstand.
20
20 19
T32859
21
T32859
23
22
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT32859001 FRAME 13 PT32859013 HINGE PIN 10 X 80 LOWER
2 PT32859002 LEG (LONG) 14 PT32859014 FLAT WASHER 10MM
3 PT32859003 LEG (SHORT) 15 PT32859015 HINGE PIN 10 X 85 UPPER
4 PT32859004 U-BRACE 16 PT32859016 FLAT HD SCR M6-1 X 12
5 PT32859005 BRACE 17 PT32859017 FOLDING LOCK PIN
6 PT32859006 U-BRACE BRACKET 18 PT32859018 TOUCH-UP PAI NT, GRI ZZLY GREEN
7 PT32859007 SHAFT SLEEVE (LONG) 19 PT32859019 WARNING LABEL
8 PT32859008 SHAFT SLEEVE (SHORT) 20 PT32859020 PINCH HAZARD LABEL
9 PT32859009 TABLE 21 PT32859021 MODEL NUMBER LABEL
10 PT32859010 COTTER PIN M3.5 X 75 HAIRPIN 22 PT32859022 GRIZZLY.COM LABEL
11 PT32859011 SHOULDER SCREW M10-1.5 X 18, 12 X 30 23 PT32859023 QR CODE LABEL
12 PT32859012 HEX NUT M10-1.5 THI N
