Gronomics ECOGW 34-48 EXT User manual

WWW.gronomics.com EastBethel,MNUSA 763-753-7374
Eco Modular Rustic Garden Wedge Extension Kit
(34”W x 48”L x 32”H - 18D) Assembly Instruction
Continued
Parts List Product Care & Maintenance
ITEM QTY. PART # DESCRIPTION Western Red Cedar will turn a
weathered grey if left unfinished.
Although no finish is required for
cedar products when used out-
doors, a natural oil finish applied
regularly will help maintain the
beautyandminimizecrackingand
drying. It is recommended to use
Gronomics Garden Bed Oil
(Item # GBO-1Q), a non-toxic,
food safe finish that is very easy
to apply. Apply Oil when air and
wind temperatures are between
50-90 degrees. Avoid applying in
direct sunlight.
1 2 CP41 Corner Post, 3-1/4” x 3-1/4” x 41-1/4”
2 8 R4501 Front & Back Side Rails, 45” x 5-9/16 x 13/16”
3 1 ES2613L End Side Rails, 25-1/8” x 5-1/2” x 13/16”
4 1 ES2013 End Side Rails, 19-1/4” x 5-1/2” x 13/16”
5 1 ES1313 End Side Rails, 13-1/2” x 4-3/8” x 13/16”
6 1 ES0713 End Side Rails, 7-3/4” x 5-1/2” x 13/16”
7 1 BCR43 Bottom Center Rail, 43-3/8” x 2-1/2” x 13/16”
8 1 SP1-30 Stiffener Plate
9 2 R3100 Post Cap, 4-5/8” x 4-5/8” x 1-1/2”
10 1 FL3652 Fabric Liner, 36” x 52”
Stack matching pieces in piles. Using the parts list,
locate and count the individual pieces and verify that
you have received the correct number of pieces.
If any pieces are missing or replacement parts are
required, contact Gronomics at 1-855-299-6727.
NOTE: Ground preparation is optional, however we
recommend leveling area under frame of product, or
place product directly on a flat level surface before
filling with soil.
Parts Identification Item #: ECOGW 34-48 EXT
1
123456
78
9
10
Packaged & Inspected by:Date:
Post Assembly
2
Place two 3-1/4” x 3-1/4” x 41-1/4” corner posts (Item 1)
together as shown.
Repeat procedure for the two remaining corner posts.
Note: It is a snug fit placing the posts together. You may
need to use a rubber mallet until corner posts are seated
(flush) together
1
Proof 8-18-14

WWW.gronomics.com EastBethel,MNUSA 763-753-7374
Remove the two post caps from the Garden Wedge.
NOTE: The extension kit can be assembled on ether
end of the Garden Wedge.
Install four 45” x 5-5/8” side rails (Item 2) into the upper
part of the slots between the two corner posts and slide
down.
Side Rail Assembly
3
2
2Post Caps Removed
Install the four remaining 45” x 5-5/8” side rails (Item 2)
into the upper part of the slots between the two corner
posts and slide down.
Install the four end side rails (Item 6, 5, 4 & 3) into the
upper part of the slots between the two corner posts
and slide down.
Remove the rubber caps from the post studs. Install a
stiffener plate (Item 8) on the top end rail as shown.
NOTE: May need to lift boards 3,4,5 & 6 slightly by
placing fingertips under board 6 to get the stiffener
plate in place.
End Rail Assembly
4
2
8
4
5
6
3
Install the 43-3/8” x 2-1/2” bottom center rail (Item 7)
with the tapered edges of the rail facing down.
Install the fabric liner into the Garden Wedge.
Soil Capacity: 6.5 Cubic Feet
Bottom Center Rail Assembly
5
7
Align the hole of the 4” x 4” post cap (Item 9) with stud
and tighten until the post cap makes contact with the
post. Do not overtighten.
Post Cap Assembly
6
Stud
9
