Grundfos ALPHA 15-55 HWR-T User manual

ALPHA 15-55 HWR-T
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

ALPHA 15-55 HWR-T
English (US)
Installation and operating instructions ..........................................................4
3
Table of contents

English (US) Installation and operating instructions
Original installation and operating instructions
Table of contents
1. Limited warranty ..........................4
2. General information ........................4
2.1 Hazard statements..........................4
2.2 Notes ..................................5
3. Receiving the product .......................5
3.1 Inspecting the product........................5
3.2 Scope of delivery ...........................5
4. Installing the product .......................5
4.1 Location ................................5
4.2 Tools ..................................5
4.3 Insulation of the pump housing ..................5
4.4 Mechanical installation .......................5
4.5 Electrical connection.........................7
5. Starting up the product ......................8
5.1 Venting the system..........................8
5.2 Starting the pump ..........................8
6. Product introduction........................8
6.1 Product description .........................8
6.2 Accessories ..............................8
6.3 Intended use .............................8
6.4 Pumped liquids ............................9
6.5 Identification..............................9
6.6 Approvals for ALPHA 15-55 HWR-T ...............9
7. Control functions .........................10
7.1 Pump display ............................10
7.2 Temperature sensor display ...................11
7.3 Performance curve.........................11
8. Servicing the product ......................11
8.1 Product maintenance .......................11
9. Fault finding the product ....................12
9.1 Fault finding table .........................12
10. Technical data ...........................13
10.1 Operating conditions........................13
11. Disposing of the product ....................13
1. Limited warranty
Products manufactured by Grundfos Pumps Corporation (Grundfos)
are warranted to the original user only to be free of defects in
material and workmanship for a period of 36 months from the date
code listed on the nameplate of the pump. Grundfos' liability under
this warranty shall be limited to repairing or replacing at Grundfos'
option, without charge, F.O.B. Grundfos' factory or authorized
service station, any product of Grundfos manufacture. Grundfos will
not be liable for any costs of removal, installation, transportation, or
any other charges that may arise in connection with a warranty
claim. Products which are sold, but not manufactured by Grundfos,
are subject to the warranty provided by the manufacturer of said
products and not by Grundfos' warranty. Grundfos will not be liable
for damage or wear to products caused by abnormal operating
conditions, accident, abuse, misuse, unauthorized alteration or
repair, or if the product was not installed in accordance with
Grundfos' printed installation and operating instructions and
accepted codes of good practice. The warranty does not cover
normal wear and tear. To obtain service under this warranty, the
defective product must be returned to the distributor or dealer of
Grundfos' products from which it was purchased together with proof
of purchase and installation date, failure date and supporting
installation data. Unless otherwise provided, the distributor or dealer
will contact Grundfos or an authorized service station for
instructions. Any defective product to be returned to Grundfos or a
service station must be sent freight prepaid; documentation
supporting the warranty claim and/or a Return Material
Authorization must be included if so instructed. Grundfos will not be
liable for any incidental or consequential damages, losses, or
expenses arising from installation, use, or any other causes. There
are no express or implied warranties, including merchantability or
fitness for a particular purpose, which extend beyond those
warranties described or referred to above. Some jurisdictions do not
allow the exclusion or limitation of incidental or consequential
damages and some jurisdictions do not allow limitations on how
long implied warranties may last. Therefore,the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights and you may also have other rights which vary from
jurisdiction to jurisdiction. Products which are repaired or replaced
by Grundfos or authorized service center under the provisions of
these limited warranty terms will continue to be covered by
Grundfos warranty only through the remainder of the original
warranty period set forth by the original purchase date.
2. General information
2.1 Hazard statements
The symbols and hazard statements below may appear in Grundfos
installation and operating instructions, safety instructions and
service instructions.
DANGER
Indicates a hazardous situation which, if not avoided, will
result in death or serious personal injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
The hazard statements are structured in the following way:
SIGNAL WORD
Description of the hazard
Consequence of ignoring the warning
• Action to avoid the hazard.
4
English (US)

2.2 Notes
The symbols and notes below may appear in Grundfos installation
and operating instructions, safety instructions and service
instructions.
FM
Observe these instructions for explosion-proof products.
A blue or gray circle with a white graphical symbol
indicates that an action must be taken.
A red or gray circle with a diagonal bar, possibly with a
black graphical symbol, indicates that an action must not
be taken or must be stopped.
If these instructions are not observed, it may result in
malfunction or damage to the equipment.
Tips and advice that make the work easier.
3. Receiving the product
3.1 Inspecting the product
CAUTION
Crushing of feet
Minor or moderate personal injury
‐Wear safety shoes when handling the product.
• Make sure that the delivered product corresponds to the order.
• Make sure that the supply voltage and frequency correspond to
the values stated on the product nameplate.
3.2 Scope of delivery
The box contains the following items:
Quantity Description
1 ALPHA HWR-T pump
1 Timer
2 Isolation valve sets
1 Temperature sensor HWR
1 Check valve
1 "Check valve installed" sticker
1 Installation and operating instructions
4. Installing the product
4.1 Location
TM077506
Location of the pump and accessories
The system is intended for indoor use only in areas protected from
droplets and splashes.
The maximum ambient temperature at the location of the pump
is 104 °F (40 °C).
4.2 Tools
The following tools are needed to install the system:
• Hexagon key 4 mm
• Pipe wrench
• Phillips PH1 screwdriver (for temperature sensor screws).
4.3 Insulation of the pump housing
Heat loss from the pump can be reduced by insulating the pump
housing.
Do not insulate the control box. Do not cover the
operating panel.
TM077507
Insulating the pump housing
4.4 Mechanical installation
4.4.1 Installing the pump
When making pipe connections, follow the pipe manufacturer's
recommendations and all code requirements for the pipe material.
WARNING
Pressurized system
Death or serious personal injury
‐Do not over torque the nuts on the pump housing while
tightening.
WARNING
Hot surface
Death or serious personal injury
‐Do not touch a hot pump without protective
equipment to avoid burn injuries.
1. Flush the system of debris before installation.
2. Fit the two supplied isolation valves
5
English (US)

3. Insert the check valve if one is not installed.
4. Refer to the arrows on the pump housing indicating the
direction of the liquid flow through the pump.
5. Install the pump with horizontal motor shaft.
Remember to use the two isolation valves included with
the pump.
The pump must be installed with the proper direction of
flow.
TM072178
Check valve installation
TM072176
Installation positions
4.4.2 Changing the power head position
CAUTION
Hot surface
Minor or moderate personal injury
‐Position the pump so that persons cannot accidentally
come into contact with hot surfaces.
WARNING
Electric shock
Death or serious personal injury
‐Switch off the power supply before you start any work
on the product. Make sure that the power supply
cannot be switched on accidentally.
WARNING
Pressurized system
Death or serious personal injury
‐Before dismantling the pump, drain the system or close
the isolating valve on either side of the pump before
you remove the screws. The pumped liquid may be
scalding hot and under high pressure.
If you change the position of the pump head, fill the
system with the liquid to be pumped or open the isolating
valves.
• Any change to the power head orientation should be made
before filling the system with liquid.
• You can turn the pump head in steps of 90°. See figure for
permissible positions.
• Only use orientations C and D for CSA, enclosure type 2.
Proceed with changing the power head position as follows:
1. If liquid is present, drain the liquid from the pump or isolate the
liquid from the pump.
2. Remove the four socket head cap screws.
3. Turn the pump head to the desired position.
4. Cross-tighten the screws to: 7 ft-lbs torque.
TM077508
Removing the four socket head cap screws on the pump head
A
B
C
D
TM077633
Pump head positions
4.4.3 Installing the temperature sensor
Use thermal compound (heat-conducting grease) between
the temperature sensor and the pipe system. Thermal
compound is not included.
Use only one temperature sensor per system.
Follow the steps below to install the temperature sensor:
1. Remove the lid of the temperature sensor case.
2. Remove the pull-tab from the end of the AA lithium battery in
the sensor case. The temperature sensor will start up.
6
English (US)

3. Mount the temperature sensor on a straight section of pipe.
Position the temperature sensor to have the best possible
contact with the pipe surface. Apply thermal compound (heat-
conducting grease) to the back of the sensor case as shown in
figure "Area on the back of the sensor for applying thermal
compound". Loosely position the pipe clamp strip around the
end of the temperature sensor.
4. Tighten the pipe clamp strip. Keep the clamp on the opposite
side of the pipe from the temperature sensor.
a. To pair the pump and the temperature sensor, press and
hold the connect button on the pump for 2 seconds. The
blue connect symbol on the pump will flash. Then press and
hold the connect button on the temperature sensor for more
than 2 seconds. The internal blue LED of temperature
sensor will flash. After successful pairing of the pump and
the temperature sensor, the blue light will be on continuously
for 5 seconds on both devices. Following the initial pairing,
the connect LED on the pump will flash green every 5
seconds. If the pairing fails, the connect symbol on the pump
will flash red for 5 seconds. If pairing fails, retry the pairing
procedure.
5. Replace the lid of the temperature sensor case.
6. Tighten the two end screws on the temperature sensor case.
For best performance, fully tighten the screws but do not over-
tighten.
TM072159
Removing the screws from the lid
TM072158
Removing the lid and the pull-tab
TM072157
Area on the back of the sensor for applying thermal compound
Pipe clamp strip
Clamp
TM072161
Positioning the clamp
TM072160
Replacing the lid and and the screws
4.5 Electrical connection
DANGER
Electric shock
Death or serious personal injury
‐All electrical work must be carried out by a qualified
electrician in accordance with the latest edition of the
National Electric Code and state, local codes and
regulations.
DANGER
Electric shock
Death or serious personal injury
‐Switch off the power supply before starting any work
on the product. Make sure that the power
supply cannot be switched on accidentally.
DANGER
Electric shock
Death or serious personal injury
‐Do not use the pump in swimming pools or marine
areas.
DANGER
Electric shock
Death or serious personal injury
‐This pump is supplied with a grounding conductor and
grounding-type attachment plug. To reduce the risk of
electric shock, be certain that it is connected only to a
properly grounded, grounding-type receptacle in
accordance with the National Electric Code and any
state, local governing codes and regulations.
WARNING
Electric shock
Death or serious personal injury
‐Use of the product on a circuit equipped with a GFCI
can cause improper operation of the GFCI. Consult an
electrician and observe all national, state, and local
electrical regulations, as applicable.
The motor is protected by the electronics in the control box and
requires no external motor protection.
• Confirm that the supply voltage and frequency of the
installation site correspond to the values stated on the pump.
• Only use the line cord supplied with the pump to connect the
pump to the power supply.
• The POWER on symbol indicates that the electrical supply has
been switched on.
4.5.1 Connecting the line cord
TM072125
Inserting the line cord plug into the pump (side view)
To connect the line cord with the pump:
7
English (US)

1. Align the line cord plug with the pump.
2. Insert the line cord plug into the pump as shown on the side
view above.
3. Push the line cord plug into the pump.
4.5.2 Removing the line cord
1
2
3
TM072126
Removing the line cord plug from the pump (bottom view)
To remove the line cord from the pump:
1. Insert a 1/8 inch flat blade screwdriver into the slot.
2. Twist the screwdriver.
3. Pull the cord to remove it.
5. Starting up the product
5.1 Venting the system
WARNING
Hot water
Death or serious personal injury
‐If the hot water temperature is too high, it can cause
severe burns or scalding.
‐To prevent burns or scalding, make sure the
temperature of the hot water source is controlled
before you vent the system.
To vent the system:
1. Turn on the water supply to the hot water source.
2. Make sure that there are no leaks in any of the connections.
3. Turn on the tap or faucet furthest from the hot water source
until there is a steady stream of water with no evidence of air in
the system.
5.2 Starting the pump
1 2 3 4 5
TM077570
ALPHA 15-55 HWR-T display
Pos. Description
1 "Connect" LED
2 "Temperature sensor" LED
3 "Power ON" LED
4 Pairing button
5 "Pump operation" LED
1. Connect the line cord to the power supply to start the pump.
2. The pump will run for up to 10 minutes and then stop.
If the water heater system is tankless, check that the heater
turns on when connecting the power supply to the pump.
3. The green POWER on LED on the pump display will be lit
when the power is on.
6. Product introduction
6.1 Product description
TM077505
ALPHA 15-55 HWR-T pump, and temperature sensor
The ALPHA HWR-T system is a temperature-controlled hot water
recirculation system for use in domestic hot water applications.
6.2 Accessories
One temperature sensor is either included or may be
purchased as an accessory.
TM077571
Temperature Sensor HWR
6.3 Intended use
The ALPHA 15-55 HWR-T system is intended for domestic hot-
water recirculation with a dedicated return line.
8
English (US)

6.4 Pumped liquids
CAUTION
Chemical hazard
Minor or moderate personal injury
‐Do not use the pump for flammable liquids, such as
diesel or gasoline.
WARNING
Biological hazard
Death or serious personal injury
‐In domestic hot water systems, the temperature of the
pumped liquid must always be above 122 °F (50 °C)
due to the risk of legionella.
WARNING
Biological hazard
Death or serious personal injury
‐In domestic hot water systems, the pump is
permanently connected to the main water supply.
Therefore, do not connect the pump by a hose.
WARNING
Hot water
Death or serious personal injury
‐If the hot water temperature is too high, it can cause
severe burns or scalding.
‐Ensure that the temperature of the hot water source is
not high enough to cause burns or scalding.
CAUTION
Corrosive substance
Minor or moderate personal injury
‐Do not use the pump for aggressive liquids such as
acids or seawater.
The pump is suited for domestic hot water.
Maximum hardness 14 °dH
Maximum potable water
temperature 140 °F (60 °C)
For water with a higher degree of hardness, contact Grundfos.
6.5 Identification
6.5.1 Nameplate
Prod. No. XXXXXXXX
CSA ENC 2 Nonsubmersible Pump
Electronically Protected Class F
Min
Amp
Max water temp 140 °F
1
2
3 4
5
6
Max
Watt
1 Ph 115V 60Hz
TM077632
Nameplate
Pos. Description
1 Product number
2 Voltage [V]
3
Rated current [A]:
Min.: Minimum current [A]
Max.: Maximum current [A]
4
Input power [W]:
Min.: Minimum power [W]
Max.: Maximum power [W]
5 Maximum liquid temperature [°F]
6 FCC and IC ID
6.6 Approvals for ALPHA 15-55 HWR-T
Approval marks
TM073285
W
A
TER QUALITY
Drinking water system component
NSF/ANSI 61
NSF/ANSI 372
TM076608
TM073284
FCC sections
Section 15.19 (a) 3
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Section 15.21
Any changes or modifications to this equipment not expressly
approved by the party responsible for compliance could void the
user's authority to operate this equipment.
9
English (US)

Section 15.105 (b)
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This equipment complies with FCC/IC radiation exposure limits set
forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines and RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment should be installed
and operated keeping the radiator at least 8 in (20 cm) or more
away from person's body.
Canadian ISED information
These devices (ALPHA 15-55 HWR-T, Temperature sensor HWR)
contain license-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s license-
exempt RSS(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, (2) this
device must accept any interference, including interference that
may cause undesired operation of the device. Innovation, Science
and Economic Development Canada ICES-003 Compliance Label:
CAN ICES-3(B)/NMB-3(B).
These devices (ALPHA 15-55 HWR-T, Temperature sensor HWR)
comply with Industry Canada RSS-247 and license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
7. Control functions
The pump operation is controlled by temperature measured at the
wireless temperature sensor mounted on the hot water return line.
When the pump has mains connected it starts to circulate hot water.
During the first minutes of operation, up to 5 minutes, it learns the
system temperature, Tsys. On the basis of the system temperature,
the pump calculates the start and stop temperature:
Tstop = Tsys - 5 °F (maximum: 110 °F)
Tstart = Tsys - 16 °F
Example 1:
if Tsys = 110 °F (maximum: 115 °F) then
Tstop = 105 °F
Tstart =102 °F
Every 12 hours or at each power cycle the pump performs the
above sequence to calibrate and flush the system.
If system temperature, Tsys, is below 85 °F the pump operates with
5 minutes on and 15 minutes off cycles and Tstart and Tstop is
omitted.
If the temperature sensor is not paired or connected to the pump
the pump operates with 5 minutes on and 15 minutes off cycles and
can be used during commissioning etc.
7.1 Pump display
1 2 3 4 5
TM077570
LED symbols and buttons on the pump display
Pos. Description
1Connect LED
2Temperature sensor LED
3POWER on LED
4 Pairing button
5Pump operation LED
Pump
display
symbol
Status Explanation
POWER on Green The LED lights green when the pump is
powered on.
Connect Flashing
blue
The LED flashes blue when the pump
is ready for pairing with
the temperature sensor. The symbol
flashes blue when the paired
temperature sensor is disconnected.
Connect Blue
The LED lights blue for 5 seconds
when pairing is successful between the
pump and the temperature sensor.
Connect Flashing
green
The LED light flashes green every 5
seconds when the pump and
the temperature sensor are paired
Connect Flashing
red
The LED flashes red for 5
seconds when pairing has failed with
the temperature sensor.
Pump
operation Green
The LED lights green when the pump
circulates water during normal
operation and is connected to the
temperature sensor.
Pump
operation Yellow
The LED lights yellow when the pump
has timed out. The pump does not
circulate water.
Pump
operation Red The pump is in an alarm state (see fault finding section).
Temperatur
e sensor Red
The LED lights red when the battery
level in the temperature sensor is at a
critically low level (see fault finding
section). Replace the battery in the
temperature sensor.
10
English (US)

7.2 Temperature sensor display
The LED is located on the temperature sensor beneath the lid. You
must remove the lid in order to pair the temperature sensor with the
pump.
Status Explanation
Flashing blue The LED flashes blue when the temperature
sensor is ready for pairing with the pump.
Blue
The LED lights blue for 5 seconds when
pairing between the temperature sensor
and the pump has succeeded.
Flashing red
The LED flashes red for 5 seconds when
pairing between the temperature sensor
and the pump has failed. Restart of the
installation procedure is recommended.
7.3 Performance curve
The pump runs at constant speed and consequently on a constant
curve. The pump is set on the maximum curve under all operating
conditions.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
Q [US GPM]
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
[ft]
H
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
[m]
H
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 Q [m³/h]
ALPHA 15-55 HWR-T
60 Hz
Without check valve installed
With check valve installed
TM077509
Performance curve, ALPHA 15-55 HWR-T
8. Servicing the product
8.1 Product maintenance
The ALPHA HWR-T pump is maintenance-free.
If the pump is damaged, for example with fractures or dents,
replace the pump.
8.1.1 Battery replacement
WARNING
Biological hazard
Death or serious personal injury
‐Keep batteries out of reach of small children, the
elderly, and pets. Batteries can cause permanent injury
if ingested or placed in the nose, mouth, or ears.
‐Immediate emergency room treatment is required for
anyone who ingests a battery. In addition, in the US,
consult the 24-hour National Battery Ingestion Hotline
at 800-498-8666 for assistance.
CAUTION
Corrosive substance
Moderate to minor personal injury and risk of property
damage
‐The temperature sensor must be replaced if battery
leakage occurs.
CAUTION
Flammable material
Minor or moderate personal injury
‐Do not attempt to recharge non-rechargeable batteries.
To clean the temperature sensor, wipe it with a clean,
damp cloth.
Ensure that disposal of old batteries is in accordance with local
regulations. Recycle old batteries where possible.
8.1.1.1 Replacing battery for temperature sensor
The temperature sensor uses AA 3.6 V lithium-thionyl batteries. To
change the battery in the temperature sensor, follow steps below:
1. Remove the lid of the temperature sensor.
2. Remove the old battery.
3. Insert the new battery.
4. Replace the lid of the temperature sensor.
11
English (US)

9. Fault finding the product
9.1 Fault finding table
Fault: The pump does not start.
Status Cause Remedy
POWER on LED on the pump operating
panel is not lit.
The pump is not connected to the power
supply.
Make sure the power supply is switched on.
Check if external protection has tripped.
Make sure the cables and connections are
free from defects and connected securely.
The POWER on LED on the
pump operating panel is green. The Pump
Operation LED is red.
The pump is in alarm state. Contact your local Grundfos representative.
The POWER on LED on the
pump operating panel is green, but the pump
does not start.
If the Pump operation LED on the
pump operating panel is yellow, the pump has
timed out.
Wait until the yellow Pump operation LED
turns off. The pump restarts when the timed
out period is over.
Fault: The "Connect" LED is flashing blue continuously.
Status Cause Remedy
The Connect LED on the
pump operating panel is flashing blue. The
temperature sensor has been disconnected
from the pump.
The temperature sensor is out of range. Ensure the temperature sensor is in proximity
to the pump.
The temperature sensor batteries need
replacing.
Replace the batteries in the temperature
sensor.
The temperature sensor is not working.
Replace the temperature sensor. Follow the
pairing procedure for the new temperature
sensor.
Fault: There is noise in the hydraulic system.
Status Cause Remedy
There are no indicators lit on the pump or
accessories. Air in the system. Open a faucet or tap to let trapped air escape.
Fault: There is noise in the circulator pump.
Status Cause Remedy
There are no indicators lit on the pump or
accessories.
Air is trapped in the pump. Open a faucet or tap to let trapped air escape.
No liquid. Ensure there is liquid in the hot-water supply
source.
12
English (US)

10. Technical data
10.1 Operating conditions
Supply voltage
- Pump 1 x 115 V, +10 % / -10 %, 60 Hz
Motor protection The pump requires no external
motor protection.
Enclosure class Indoor use only, IP42. CSA
enclosure type 2.
Insulation class F
Relative humidity Maximum 95 %
Max. outlet pressure 150 psi (10.34 bar)
Sound pressure level 43 dB (A)
Ambient temperature 34 to 104 °F (1 to 40 °C)
Inlet pressure
Liquid temperature Min. inlet pressure
167 °F (75 °C) 0.75 psi (0.05 bar)
194 °F (90 °C) 4.06 psi (0.28 bar)
230 °F (110 °C) 15.7 psi (1.08 bar)
Liquid temperature
36 °F (2 °C) to 230 °F (110 °C)
In domestic hot water systems, keep the liquid
temperature below 149 °F (65 °C) to eliminate the risk of
lime precipitation.
To avoid condensation in the control box and stator, the liquid
temperature must always be higher than the ambient temperature.
Ambient
temperature
[°F (°C)]
Min. liquid
temperature
[°F (°C)]
Max. liquid
temperature
[°F (°C)]
34 (1) 36 (2) 230 (110)
50 (10) 50 (10) 230 (110)
68 (20) 68 (20) 230 (110)
86 (30) 86 (30) 230 (110)
95 (35) 95 (35) 194 (90)
104 (40) 104 (40) 158 (70)
Approximate power usage
Minimum 2 W
Maximum 45 W
11. Disposing of the product
CAUTION
Magnetic field
Minor or moderate personal injury
‐Persons with pacemakers dismantling this product
must exercise care when handling the magnetic
materials embedded in the rotor.
This product or parts of it must be disposed of in an environmentally
sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company or
service center.
See also end-of-life information at www.grundfos.com/product-
recycling.
13
English (US)

U.S.A.
GRUNDFOS Water Utility Head Quarters
Brookshire, Texas 77423 USA
GRUNDFOS CBS Inc.
902 Koomey Road
Brookshire, TX 77423 USA
Phone: [phone]
Toll Free: 1-800-955-5847
Fax: [phone]
GRUNDFOS Pumps Corporation
9300 Loiret Boulevard
Lenexa, Kansas 66219 USA
Tel.: [phone]
Fax: [phone]
Canada
GRUNDFOS Canada Inc.
2941 Brighton Road
Oakville, Ontario
L6H 6C9
Tel.: [phone]
Fax: [phone]
Mexico
Bombas GRUNDFOS de México
S.A. de C.V.
Boulevard TLC No. 15
Parque Industrial Stiva Aeropuerto
Apodaca, N.L. 66600
Tel.: [phone]
Fax: [phone]
Revision Info
Last revised on 12-11-2020
Grundfos companies

99984088 112020
ECM: 1301041
Trademarks displayed in this material, including but not limited to Grundfos, the Grundfos logo and “be think innovate” are registered trademarks owned by The Grundfos Group. All rights reserved. © 2020 Grundfos Holding A/S, all rights reserved.
