Grundfos SCALA1 Operating instructions

SCALA1 SI
Service instructions
GRUNDFOS INSTRUCTIONS

SCALA1 SI
English (GB)
Service instructions ........................................................................4
3
Table of contents

English (GB) Service instructions
Original service instructions
Table of contents
1. General information ........................4
1.1 Hazard statements..........................4
1.2 Notes ..................................4
2. Safety information for working on the product .......4
3. Maintenance .............................5
4. Dismantling the product .....................6
4.1 Before dismantling the product ..................6
4.2 Removing the pump cover .....................6
4.3 Removingthe pressure switch ...................6
4.4 Removing the connection module housing ...........6
4.5 Removing the membrane......................6
4.6 Removing the chamber stack ...................7
4.7 Removing the shaft seal ......................7
4.8 Removing the control box cover..................8
4.9 Removing the printed circuit board cover inside the
control box...............................8
4.10 Removing the printed circuit board from the control box ...8
4.11 Replacing the printed circuit board ................8
4.12 Removing the capacitor from the control box ..........8
4.13 Removing the motor .........................9
4.14 Removing the motor stool and the flange ............9
5. Assembling the product .....................9
5.1 Fitting the motor stool and the flange...............9
5.2 Fitting the motor ...........................9
5.3 Fitting the shaft seal ........................10
5.4 Assembling the chamber stack .................10
5.5 Fitting the chamber stack .....................10
5.6 Connecting thecapacitor to the printed circuit board.....11
5.7 Fitting the printed circuit board..................11
5.8 Fitting the membrane .......................11
5.9 Fitting the cover for hydraulic ..................11
5.10 Fitting the pressure switch ....................11
5.11 Fitting the pump cover.......................11
6. Additional information .....................12
6.1 Lubricant ...............................12
6.2 Torques ...............................12
6.3 Nameplate for SCALA1 ......................12
6.4 Type key for SCALA1 .......................12
6.5 Fault finding the product .....................12
6.6 SCALA1 exploded view ......................13
1. General information
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
Read this document before you install the product.
Installation and operation must comply with local
regulations and accepted codes of good practice.
1.1 Hazard statements
The symbols and hazard statements below may appear in Grundfos
installation and operating instructions, safety instructions and
service instructions.
DANGER
Indicates a hazardous situation which, if not avoided, will
result in death or serious personal injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
The hazard statements are structured in the following way:
SIGNAL WORD
Description of the hazard
Consequence of ignoring the warning
• Action to avoid the hazard.
1.2 Notes
The symbols and notes below may appear in Grundfos installation
and operating instructions, safety instructions and service
instructions.
Observe these instructions for explosion-proof products.
A blue or grey circle with a white graphical symbol
indicates that an action must be taken.
A red or grey circle with a diagonal bar, possibly with a
black graphical symbol, indicates that an action must not
be taken or must be stopped.
If these instructions are not observed, it may result in
malfunction or damage to the equipment.
Tips and advice that make the work easier.
2. Safety information for working on the product
DANGER
Explosion risk
Death or serious personal injury
‐Do not use the product for flammable liquids such as
diesel oil, petrol or similar liquids. The product must
only be used for water.
WARNING
Electric shock
Death or serious personal injury
‐Do not use the product for aggressive liquids. The
product must only be used for water.
WARNING
Toxic material
Death or serious personal injury
‐Do not use the product for toxic liquids. The product
must only be used for water.
WARNING
Electric shock
Death or serious personal injury
‐Switch off the power supply before you start any work
on the product. Make sure that the power supply
cannot be switched on accidentally.
WARNING
Electric shock
Death or serious personal injury
‐Mount the product horizontally to avoid condensation
in the electrical insulation inside the control box.
4
English (GB)

WARNING
Chemical hazard
Death or serious personal injury
‐Before the pump is used for supplying drinking water,
flush the pump thoroughly with clean water.
WARNING
Biological hazard
Death or serious personal injury
‐Before the pump is used for supplying drinking water,
flush the pump thoroughly with clean water.
WARNING
Electric shock
Death or serious personal injury
‐The protective earth (PE) of the power outlet must be
connected to the protective earth of the pump. The
plug must have the same PE connection system as the
power outlet.
‐
WARNING
Electric shock
Death or serious personal injury
‐Make sure that the power plug delivered with the
product is in compliance with local regulations.
‐The plug must have the same protective earth (PE)
connection system as the power outlet. If not, use a
suitable adapter if allowed by local regulations.
WARNING
Electric shock
Death or serious personal injury
‐Power cables without a plug must be connected to a
supply disconnecting device incorporated in the fixed
wiring according to the local wiring rules.
‐The protective earth (PE) of the power outlet must be
connected to the protective earth of the pump. The
plug must have the same PE connection system as the
power outlet.
WARNING
Chemical hazard
Death or serious personal injury
‐Make sure that the product has only been used for
water. If the product has been used for pumping
aggressive liquids, flush the system with clean water
before you start work on the product.
WARNING
Biological hazard
Death or serious personal injury
‐Make sure that the product has only been used for
water. If the product has been used for pumping
aggressive liquids, flush the system with clean water
before you start work on the product.
WARNING
Pressurised system
Death or serious personal injury
‐Before dismantling the pump, drain the system or close
the isolating valves on both sides of the pump. Slowly
loosen the drain plug and unpressurise the system.
CAUTION
Impurities in the water
Minor or moderate personal injury
‐Before the pump is used for supplying drinking water,
flush the pump thoroughly with clean water.
‐Use spare parts approved by Grundfos.
WARNING
Electric shock
Death or serious personal injury
‐Check that the product is intact and not cracked.
Especially if the product was not drained before
standstill or was exposed to frost.
WARNING
Moving parts
Death or serious personal injury
‐Make sure that the product cannot start unexpectedly
while deblocking the pump shaft.
3. Maintenance
The pump is maintenance-free, but we recommend that you check
and clean the condensation plugs and integrated non-return valve
once per year or as needed.
5
English (GB)

4. Dismantling the product
Position part numbers (numbers in brackets) refer to
section SCALA1 exploded view.
4.1 Before dismantling the product
Follow these steps before starting dismantling the pump.
1. Disconnect the power supply to the motor.
2. Remove power cable according to local regulations.
3. Gradually loosen the valves to release the pressure in the
pump.
4. Remove the drain plug to drain the pump.
4.2 Removing the pump cover
1. Loosen the union nuts (100) with your hand and remove the
inlet and outlet connections – fittings (100a), and O-ring (100b)
– from the pump.
Use the tip of a small flat screwdriver to remove the
O-ring.
2. Remove the non-return valve discharge (65a) and the O-ring
(65b) from the top of the pump.
3. Gently push the locking tab at the bottom of the pump with a
flat screwdriver.
4. Loosen and pull away the pump cover (403) to remove it from
the pump.
TM075488
Removing the pump cover
4.3 Removing the pressure switch
Follow these steps to remove the pressure switch:
1. Loosen and remove the screws that hold the pressure switch
cover (184).
2. Remove the pressure switch cover.
3. Disconnect the cable of the pressure switch from the clips that
hold it in place.
4. Loosen the screws which hold the pressure switch to the pump.
5. Remove the pressure switch.
174a
175
184a
184
174b
174c
TM075714
Removing the pressure switch
Tape the pressure switch to the side of the pump
body while you continue the dismantling.
4.4 Removing the connection module housing
1. Loosen and remove the screws (26) that hold the connection
module housing. Remove the washers (26c).
2. Remove the plug (169) at the end of the shaft.
3. Remove the connection module housing(2).
26
26c
2
169
TM075709
Removing the connection module housing
4.5 Removing the membrane
1. Loosen and remove the eight screws (43a) that hold the cover
for the membrane.
2. Remove the cover for the membrane (43).
3. Pull out the membrane (41).
41
43
43a
TM075725
Removing the pump membrane
6
English (GB)

4.6 Removing the chamber stack
1. Remove the plug (169) on the nameplate to access the shaft
end.
2. Find the locknut (67) at the non-drive end of the shaft. To
remove the locking nut, place a 13-mm spanner on the nut and
place the handle so that it rests against a flat surface to avoid
spinning.
3. To loosen the shaft, use a large flat screwdriver at the drive-
end and, at the same time, hold the 13-mm spanner at the non-
drive end.
TM075694
Loosening the shaft
4. Remove the locknut (67) and the washer (66).
5. Remove the impellers and chambers, starting with the inlet part
for the hydraulic (44) and finishing with the final diffusor (3).
44a
44
TM076147
Removal of inlet part of hydraulic
4.7 Removing the shaft seal
Do not touch the ceramic faces of the shaft seal.
103
104
4
TM076148
Shaft seal and seal disc
104
103
TM075708
How to correctly hold the shaft seal
1. Remove the washer (102).
2. Pull off the rotating part of the shaft seal (104) by inserting the
tip of two small flat screwdrivers.
TM076170
Removing the rotating part of the shaft seal
3. Remove the stationary part of the shaft seal (103) by inserting
the tip of two small flat screwdrivers and pulling it off.
7
English (GB)

4.8 Removing the control box cover
Always use an antistatic service kit when handling
electronic components. This will prevent static electricity
from damaging components.
1. Remove the six pan-head Phillips screws (164a) that hold the
the cover.
164
164a
164a
164
TM075711
Removing the control box cover
2. Carefully remove the control box cover (164).
4.9 Removing the printed circuit board cover inside the
control box
1. Gently loosen the locking tabs that hold the printed circuit
board cover.
Use the tip of a small flat screwdriver to open the
locking tabs.
2. Lift and remove the printed circuit board cover (181a).
4.10 Removing the printed circuit board from the control
box
1. Disconnect the wires.
2. Loosen the 3 screws that hold the printed circuit board (181).
3. Lift the printed circuit board to remove it from the control box.
4. Remove the connection pin (181c) that connects the printed
circuit board to the motor.
4.11 Replacing the printed circuit board
1. Remove the lid.
TM075729
Opening lid and disconnecting the wires
2. Disconnect the wires.
3. Remove the screw holding the printed circuit board.
4. Replace the printed circuit board. Make sure that the board fits
on the four metal tabs in the corner.
5. Tighten the screw.
6. Reconnect the wires (two blue to capacitor + three coloured for
power + pressure switch wire plug).
4.12 Removing the capacitor from the control box
When you replace the capacitor, make sure to select the
appropriate spare capacitor (230V or 115V) for your
pump.
1. Disconnect the wires that connect the capacitor (161) to the
printed circuit board (181).
TM077547
Removing the capacitor from the control box
2. Pull the capacitor from under the clip.
8
English (GB)

4.13 Removing the motor
Note that the motor stool is on the outer end of the motor
and the flange is on the inner end of the motor.
1. Loosen and remove the hex screws (152) that hold the motor
stool (156b) to the outer end of the motor (150) using a size 10
hex key.
TM077560
Loosening and removing the hex screws (152)
2. Place the hex key on one of the screw heads (152) that hold
the motor stool (156b) to the motor (150) and pull it out.
3. Apply pressure to pull out the motor stool and the motor.
4. The motor comes off together with the motor stool (front) and
the flange (rear).
5. Make sure you do not break the connection pin on the back of
the motor.
4.14 Removing the motor stool and the flange
1. Mark the position of the motor in the flange before removing
the hex screws (206).
2. Loosen and remove the hex screws (206) that hold the flange
(156a) to the outer motor stool (156b).
3. Remove the motor from the motor stool.
4. Remove the O-ring (150b).
5. Assembling the product
5.1 Fitting the motor stool and the flange
1. Place the O-ring (150b) in the motor stool (156b).
2. Mount the motor (150) in the motor stool (156b).
3. Align the motor with the flange according to the positions that
were marked while dismantling the pump.
4. Attach the flange (156a) to the motor stool (156b).
You can hold the shaft in a vice while you are
attaching the flange.
5. Tighten the hex screws (206) in the flange that secure the
motor (150) in the motor stool. Use a maximum torque of
2.6-3.2 Nm.
6. Place the O-ring (52) on the outer end of the motor (150).
7. Place the O-ring (53) on the motor stool (156b).
5.2 Fitting the motor
1. Insert the motor into pump body.
TM077559
Inserting the assembled motor
Do not damage the connection pin.
2. Tighten the hex screws (152) that hold the motor in the pump
body. Use a maximum torque of 2.6-3.8 Nm.
3. Make sure that the connection pin (181c) can be inserted in the
motor part before proceeding.
9
English (GB)

5.3 Fitting the shaft seal
Do not touch the ceramic faces of the shaft seal.
103
104
4
TM076148
Shaft seal and seal disc
104
103
TM075708
How to correctly hold the shaft seal
1. Lubricate both sealing parts with soapy water.
2. Place the stationary part of the shaft seal (103) in the outer
motor stool (156b).
3. Lubricate the shaft with soapy water.
4. Place the rotating part of the shaft seal (104) on the shaft.
5. Place the washer (102) on the shaft.
5.4 Assembling the chamber stack
Do not touch the inner ceramic faces of the shaft seals
(103) (104).
1. Make sure you have all components ready and place them on
the shaft of the motor unit (150) in the following order.
44a
67 66
44
45
45a 4a
49
4
45
45a
4a
49
4
45
45a 4a
3
102
104
103
49
4
TM075701
Assembling the chamber stack
a. Shaft seal, stationary part (103)
b. Shaft seal, rotating part (104)
c. Diffusor, final (3)
d. Diffusor (4a)
e. Backward bushing for impeller (45a)
f. Impeller (49)
g. Forward bushing for impeller (45)
h. Chamber (4)
i. Inlet part for hydraulic (44)
j. Washer (66)
k. Lock nut (67)
l. O-ring (44a)
5.5 Fitting the chamber stack
Make sure that all the components are on the shaft in the
right order.
1. Once all chambers and impellers are in place, fasten the shaft.
Use a large flat screwdriver at the drive-end and a 13-mm
spanner at the non-drive end. Use a torque of 8 Nm.
TM075695
2. Fit the plug on the nameplate to cover the shaft end.
10
English (GB)

5.6 Connecting the capacitor to the printed circuit board
1. Put the capacitor (161) inside the control box and connect it to
the printed circuit board (181b).
TM077548
Connecting the capacitor to the printed circuit board
5.7 Fitting the printed circuit board
1. Place the printed circuit board (181) into the control box. Make
sure that the printed circuit board fits on the four metal tabs in
the corner.
2. Tighten the three screws that hold the printed circuit board.
3. Reconnect the wires (two blue to capacitor + three-coloured for
power + pressure switch wire plug).
4. Refit the upper enclosure.
5.8 Fitting the membrane
1. Insert the membrane (41) into the smaller hole of the
connection part for hydraulic (2).
2. Fit the cover for the membrane (43) on top of the membrane.
3. Fit the eight screws that hold the cover for membrane (43) and
the membrane (41) onto the connection part for hydraulic (2).
4. Tighten the screws.
41
43
43a
TM075726
Fitting the pump membrane
5.9 Fitting the cover for hydraulic
1. Prepare the six screws that hold the cover for hydraulic (2) to
the pump.
2. Place the cover for hydraulic over the chamber stack and the
shaft and push it as close to the pump as possible.
3. Place a washer on each screw, and tighten all screws with a
torque of 8 Nm.
26
26c
2
169
TM075710
Fitting the cover for hyraulic
5.10 Fitting the pressure switch
1. Prepare the O-ring (174b), the inductive sensor (174c) and the
three screws (175) that hold the pressure switch onto the
pump.
2. Place the O-ring (174b) on the pressure switch fitting.
3. Fasten the pressure switch onto the pump with the screws.
4. Connect the pressure switch coupling (174a) to the printed
circuit board if it is disconnected.
5. As a final step, attach the pressure switch cover on top of the
pressure switch.
174a
175
184a
184
174b
174c
TM075713
Fitting the pressure switch
5.11 Fitting the pump cover
1. Place the pump cover (403) on the pump housing until you
hear a click of the locking tab.
2. Fit the inlet and outlet connections, the union nut (100), the
fitting (100a) and the O-ring (65b) onto the pump.
3. Screw the non-return valve (65a) with its O-ring (65b) onto the
pump.
100
100a
100b
711a
403
65b
65a
TM075718
Fitting the pump cover
11
English (GB)

6. Additional information
6.1 Lubricant
We recommend using soapy water for the shaft seal and ROCOL
SAPPHIRE Aqua-Sil for the O-rings.
6.2 Torques
Pos. Description Torque [Nm]
206
Screws that hold the
flange (156a) to the
motor (150)
3.0
152 Screws for motor
stool (156b) 3.5
26
Screws for
connection module
housing (2)
7.0
67 Lock nut for chamber
stack 8.0
6.3 Nameplate for SCALA1
DK-8850 Bjerringbro Denmark
SCALA1 3-35
PN 99530404
Model A
1x230 V 50Hz
SN 00001
PC 19 36
Hmax
Hnom
Made in Hungary
Qnom
T.amb.max
Tliq.max/Psyst.max:
IP X4D
P1(W)I(A)
750
1,50,01Min.
Max. 3,3
45°C/0.8Mpa
35 m
20 m
3 m
3
/h
55 °C
1
2
3
4
5
6
7
8
9
10
11
12
17
16
13
14
15
TM075340
Example of nameplate
Pos. Description
1 Type designation
2 Product number
3 Serial number
4Production code (year and
week)
5 Max. head
6 Nominal head
7 Nominal flow rate
8 Max. ambient temperature
9 Enclosure class
10 Max. operating pressure
11 Max. liquid temperature
12 Minimum and maximum rated
power
13 Model
14 Voltage and frequency
15 Approvals
16 Product QR code
17 Minimum and maximum rated
current
6.4 Type key for SCALA1
Example:
SCALA1 . 5- . 25 . 1x230V . 50 Hz . SCHUKO
Description
SCALA1 Type range
3
5Max. flow rate [m3/h]
25
35
45
55
Max. head [m]
1x230V
1x115V Voltage [V]
50 Hz
60 Hz Frequency [Hz]
SCHUKO (Type E/F)
No plug
Thailand (Type O)
Australia (Type I)
UK (Type G)
US (Type NEMA 5-15, NEMA 6-15)
Argentina (Type I)
Plug type
6.5 Fault finding the product
Fault finding procedures are described in the installation and
operating instructions. Use the QR code or link below:
QR99735528
http://net.grundfos.com/qr/i/99735528
12
English (GB)

6.6 SCALA1 exploded view
TM075873
SCALA1 3-25, 5-25 exploded view
13
English (GB)

164a
164
181a
181
181b
181c
180
169a 169
52
53
206
156a
150
4
45
49
45a
4a
3
102 104 103
37
156b
150b
4a
45a
4
4a
45a
49
45
4
44
66
67
44a
100
100a
100b
7
11a
174b
26 26c
65a
65b
175 174a 2
41
43a
11
10 177a
43
184a
184
178a
116
177
178
174c
403
45
49
152
161
TM075294
SCALA1 3-35, 3-45, 5-55 exploded view
14
English (GB)

Argentina
Bombas GRUNDFOS de Argentina S.A.
Ruta Panamericana km. 37.500 Centro
Industrial Garin
1619 - Garín Pcia. de B.A.
Tel.: [phone]
Fax: [phone]
Australia
GRUNDFOS Pumps Pty. Ltd.
P.O. Box 2040
Regency Park
South Australia 5942
Tel.: [phone]
Fax: [phone]
Austria
GRUNDFOS Pumpen Vertrieb Ges.m.b.H.
Grundfosstraße 2
A-5082 Grödig/Salzburg
Tel.: [phone]
Fax: [phone]
Belgium
N.V. GRUNDFOS Bellux S.A.
Boomsesteenweg 81-83
B-2630 Aartselaar
Tel.: [phone]
Fax: [phone]
Belarus
Представительство ГРУНДФОС в Минске
220125, Минск
ул. Шафарнянская, 11, оф. 56, БЦ «Порт»
Тел.: [phone]
[phone]
Факс: [phone]
E-mail: [email protected]
Bosnia and Herzegovina
GRUNDFOS Sarajevo
Zmaja od Bosne 7-7A
BiH-71000 Sarajevo
Tel.: [phone]
Fax: [phone]
www.ba.grundfos.com
E-mail: [email protected]
Brazil
BOMBAS GRUNDFOS DO BRASIL
Av. Humberto de Alencar Castelo Branco,
630
CEP 09850 - 300
São Bernardo do Campo - SP
Tel.: [phone]
Fax: [phone]
Bulgaria
Grundfos Bulgaria EOOD
Slatina District
Iztochna Tangenta street no. 100
BG - 1592 Sofia
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Canada
GRUNDFOS Canada Inc.
2941 Brighton Road
Oakville, Ontario
L6H 6C9
Tel.: [phone]
Fax: [phone]
China
GRUNDFOS Pumps (Shanghai) Co. Ltd.
10F The Hub, No. 33 Suhong Road
Minhang District
Shanghai 201106 PRC
Tel.: [phone]
Fax: [phone]
Columbia
GRUNDFOS Colombia S.A.S.
Km 1.5 vía Siberia-Cota Conj. Potrero
Chico,
Parque Empresarial Arcos de Cota Bod. 1A.
Cota, Cundinamarca
Tel.: [phone]
Fax: [phone]
Croatia
GRUNDFOS CROATIA d.o.o.
Buzinski prilaz 38, Buzin
HR-10010 Zagreb
Tel.: [phone]
Fax: [phone]
www.hr.grundfos.com
Czech Republic
GRUNDFOS Sales Czechia and Slovakia
s.r.o.
Čajkovského 21
779 00 Olomouc
Tel.: [phone]
Denmark
GRUNDFOS DK A/S
Martin Bachs Vej 3
DK-8850 Bjerringbro
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
www.grundfos.com/DK
Estonia
GRUNDFOS Pumps Eesti OÜ
Peterburi tee 92G
11415 Tallinn
Tel.: + 372 606 1690
Fax: + 372 606 1691
Finland
OY GRUNDFOS Pumput AB
Trukkikuja 1
FI-01360 Vantaa
Tel.: [phone]
France
Pompes GRUNDFOS Distribution S.A.
Parc d’Activités de Chesnes
57, rue de Malacombe
F-38290 St. Quentin Fallavier (Lyon)
Tel.: [phone]
Fax: [phone]
Germany
GRUNDFOS GMBH
Schlüterstr. 33
40699 Erkrath
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Service in Deutschland:
[email protected]
Greece
GRUNDFOS Hellas A.E.B.E.
20th km. Athinon-Markopoulou Av.
P.O. Box 71
GR-19002 Peania
Tel.: [phone]
Fax: [phone]
Hong Kong
GRUNDFOS Pumps (Hong Kong) Ltd.
Unit 1, Ground floor, Siu Wai Industrial
Centre
29-33 Wing Hong Street & 68 King Lam
Street, Cheung Sha Wan
Kowloon
Tel.: [phone]
Fax: [phone]
Hungary
GRUNDFOS Hungária Kft.
Tópark u. 8
H-2045 Törökbálint
Tel.: [phone]
Fax: [phone]
India
GRUNDFOS Pumps India Private Limited
118 Old Mahabalipuram Road
Thoraipakkam
Chennai 600 097
Tel.: [phone]
Indonesia
PT GRUNDFOS Pompa
Graha Intirub Lt. 2 & 3
Jln. Cililitan Besar No.454. Makasar,
Jakarta Timur
ID-Jakarta 13650
Tel.: [phone]
Fax: [phone]
Ireland
GRUNDFOS (Ireland) Ltd.
Unit A, Merrywell Business Park
Ballymount Road Lower
Dublin 12
Tel.: [phone]
Fax: [phone]
Italy
GRUNDFOS Pompe Italia S.r.l.
Via Gran Sasso 4
I-20060 Truccazzano (Milano)
Tel.: [phone]
Fax: [phone]
Japan
GRUNDFOS Pumps K.K.
1-2-3, Shin-Miyakoda, Kita-ku
Hamamatsu
431-2103 Japan
Tel.: [phone]
Fax: [phone]
Korea
GRUNDFOS Pumps Korea Ltd.
6th Floor, Aju Building 679-5
Yeoksam-dong, Kangnam-ku, 135-916
Seoul, Korea
Tel.: [phone]
Fax: [phone]
Latvia
SIA GRUNDFOS Pumps Latvia
Deglava biznesa centrs
Augusta Deglava ielā 60
LV-1035, Rīga,
Tel.: + 371 714 9640, 7 149 641
Fax: + 371 914 9646
Lithuania
GRUNDFOS Pumps UAB
Smolensko g. 6
LT-03201 Vilnius
Tel.: + 370 52 395 430
Fax: + 370 52 395 431
Malaysia
GRUNDFOS Pumps Sdn. Bhd.
7 Jalan Peguam U1/25
Glenmarie Industrial Park
40150 Shah Alam, Selangor
Tel.: [phone]
Fax: [phone]
Mexico
Bombas GRUNDFOS de México
S.A. de C.V.
Boulevard TLC No. 15
Parque Industrial Stiva Aeropuerto
Apodaca, N.L. 66600
Tel.: [phone]
Fax: [phone]
Netherlands
GRUNDFOS Netherlands
Veluwezoom 35
1326 AE Almere
Postbus 22015
1302 CA ALMERE
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
New Zealand
GRUNDFOS Pumps NZ Ltd.
17 Beatrice Tinsley Crescent
North Harbour Industrial Estate
Albany, Auckland
Tel.: [phone]
Fax: [phone]
Norway
GRUNDFOS Pumper A/S
Strømsveien 344
Postboks 235, Leirdal
N-1011 Oslo
Tel.: [phone]
Fax: [phone]
Poland
GRUNDFOS Pompy Sp. z o.o.
ul. Klonowa 23
Baranowo k. Poznania
PL-62-081 Przeźmierowo
Tel.: [phone]
Fax: [phone]
Portugal
Bombas GRUNDFOS Portugal, S.A.
Rua Calvet de Magalhães, 241
Apartado 1079
P-2770-153 Paço de Arcos
Tel.: [phone]
Fax: [phone]
Romania
GRUNDFOS Pompe România SRL
S-PARK BUSINESS CENTER, Clădirea
A2, etaj 2
Str. Tipografilor, Nr. 11-15, Sector 1, Cod
013714
Bucuresti, Romania
Tel.: [phone]
E-mail: [email protected]
Russia
ООО Грундфос Россия
ул. Школьная, 39-41
Москва, RU-109544, Russia
Тел. [phone] [phone]
Факс [phone]
E-mail [email protected]
Serbia
Grundfos Srbija d.o.o.
Omladinskih brigada 90b
11070 Novi Beograd
Tel.: [phone]
Fax: [phone]
www.rs.grundfos.com
Singapore
GRUNDFOS (Singapore) Pte. Ltd.
25 Jalan Tukang
Singapore 619264
Tel.: [phone]
Faxax: [phone]
Slovakia
GRUNDFOS s.r.o.
Prievozská 4D 821 09 BRATISLAVA
Tel.: [phone]
sk.grundfos.com
Slovenia
GRUNDFOS LJUBLJANA, d.o.o.
Leskoškova 9e, 1122 Ljubljana
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
South Africa
GRUNDFOS (PTY) LTD
16 Lascelles Drive, Meadowbrook Estate
1609 Germiston, Johannesburg
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Spain
Bombas GRUNDFOS España S.A.
Camino de la Fuentecilla, s/n
E-28110 Algete (Madrid)
Tel.: [phone]
Fax: [phone]
Sweden
GRUNDFOS AB
Box 333 (Lunnagårdsgatan 6)
431 24 Mölndal
Tel.: [phone]
Fax: [phone]
Switzerland
GRUNDFOS Pumpen AG
Bruggacherstrasse 10
CH-8117 Fällanden/ZH
Tel.: [phone]
Fax: [phone]
Taiwan
GRUNDFOS Pumps (Taiwan) Ltd.
7 Floor, 219 Min-Chuan Road
Taichung, Taiwan, R.O.C.
Tel.: [phone]
Fax: [phone]
Thailand
GRUNDFOS (Thailand) Ltd.
92 Chaloem Phrakiat Rama 9 Road
Dokmai, Pravej, Bangkok 10250
Tel.: [phone]
Fax: [phone]
Turkey
GRUNDFOS POMPA San. ve Tic. Ltd. Sti.
Gebze Organize Sanayi Bölgesi
Ihsan dede Caddesi
2. yol 200. Sokak No. 204
41490 Gebze/ Kocaeli
Tel.: +90 - 262-679 7979
Fax: +90 - 262-679 7905
E-mail: [email protected]
Ukraine
Бізнес Центр Європа
Столичне шосе, 103
м. Київ, 03131, Україна
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
United Arab Emirates
GRUNDFOS Gulf Distribution
P.O. Box 16768
Jebel Ali Free Zone, Dubai
Tel.: [phone]
Fax: [phone]
United Kingdom
GRUNDFOS Pumps Ltd.
Grovebury Road
Leighton Buzzard/Beds. LU7 4TL
Tel.: [phone]
Fax: [phone]
U.S.A.
GRUNDFOS Pumps Corporation
9300 Loiret Boulevard
Lenexa, Kansas 66219 USA
Tel.: [phone]
Fax: [phone]
Uzbekistan
Grundfos Tashkent, Uzbekistan
The Representative Office of Grundfos
Kazakhstan in Uzbekistan
38a, Oybek street, Tashkent
Tel.: [phone]
Fax: [phone]
Revision Info
Last revised on 09-09-2020
Grundfos companies

99830441 10.2020
ECM: 1298119
Trademarks displayed in this material, including but not limited to Grundfos, the Grundfos logo and “be think innovate” are registered trademarks owned by The Grundfos Group. All rights reserved. © 2020 Grundfos Holding A/S, all rights reserved.
