GRUNDFOS INSTRUCTIONS
TPE2 (D), TPE3 (D)
Single-stage in-line pumps with integrated variable frequency drive
Installation and operating instructions

English (US)
2
English (US) Installation and operating instructions
Original installation and operating instructions.
CONTENTS
Page
1. Symbols used in this document 3
2. Limited warranty 3
3. Abbreviations and definitions 4
4. General information 4
4.1 Radio communication 4
4.2 Battery 4
5. Delivery and handling 4
5.1 Delivery 4
5.2 Handling 4
6. Applications 5
6.1 Pumped liquids 5
7. Operating conditions 5
7.1 Maximum number of starts and stops 5
7.2 Alternating operation of twin-head pumps 5
7.3 Liquid temperature 5
7.4 Ambient temperature 5
7.5 Operating pressure/test pressure 5
7.6 Inlet pressure 6
7.7 Electrical data 6
7.8 Sound pressure level 6
7.9 Environment 6
7.10 Installation altitude 6
7.11 Air humidity 6
7.12 Motor cooling 6
8. Mechanical installation 7
8.1 Pipework 7
8.2 Terminal box positions 8
8.3 Fitting of pump head 8
8.4 Base plate 9
8.5 Insulation 9
8.6 Frost protection 9
8.7 Ensuring motor cooling 9
8.8 Outdoor installation 9
9. Electrical installation 10
9.1 Protection against electric shock, indirect contact 10
9.2 Power supply 10
9.3 Additional protection 11
9.4 Connection terminals 12
9.5 Signal cables 16
9.6 Bus connection cable 16
10. Startup 16
10.1 Flushing the pipe system 16
10.2 Priming 16
10.3 Starting 17
10.4 Shaft seal run-in 17
11. User interfaces 17
12. Standard control panel 18
12.1 Setpoint setting 18
13. Advanced control panel 20
13.1 Menu structure 20
13.2 Menu overview for advanced control panel 21
14. Grundfos GO Remote 23
14.1 Communication 23
14.2 Menu overview for Grundfos GO Remote 24
15. Description of selected functions 26
15.1 Setpoint 26
15.2 Operating mode 26
15.3 Set manual speed 26
15.4 Control mode 26
15.5 FLOWLIMIT 31
15.6 Automatic Night Setback 31
15.7 Analog inputs 31
15.8 Pt100/1000 inputs 31
15.9 Digital inputs 32
15.10 Digital inputs/outputs 32
15.11 Relay outputs 33
15.12 Analog output 33
15.13 Controller settings 33
15.14 Operating range 34
15.15 Setpoint influence 35
15.16 Monitoring functions 38
15.17 Special functions 38
15.18 Communication 38
15.19 General settings 39
16. Assist 39
16.1 Multi-pump setup 39
17. Selection of control mode 40
18. Changing the position of the control panel 42
19. Bus signal 43
20. Priority of settings 43
21. Grundfos Eye 44
22. Signal relays 45
23. Maintenance and service 46
23.1 Maintenance 46
23.2 Service 46
24. Fault finding 47
25. Megging 48
26. Technical data, single-phase motors 48
26.1 Supply voltage 48
26.2 Leakage current 48
27. Technical data, three-phase motors 48
27.1 Supply voltage 48
27.2 Leakage current 48
28. Inputs/outputs 48
29. Other technical data 49
29.1 Torques 49
29.2 Sound pressure level 49
30. Disposal 49

3
English (US)
1. Symbols used in this document
2. Limited warranty
Products manufactured by GRUNDFOS PUMPS CORPORATION
(Grundfos) are warranted to the original user only to be free of
defects in material and workmanship for a period of 24 months
from date of installation, but not more than 30 months from date
of manufacture. Grundfos' liability under this warranty shall be
limited to repairing or replacing at Grundfos' option, without
charge, F.O.B. Grundfos' factory or authorized service station,
any product of Grundfos' manufacture. Grundfos will not be liable
for any costs of removal, installation, transportation, or any other
charges which may arise in connection with a warranty claim.
Products which are sold but not manufactured by Grundfos are
subject to the warranty provided by the manufacturer of said
products and not by Grundfos' warranty. Grundfos will not be
liable for damage or wear to products caused by abnormal
operating conditions, accident, abuse, misuse, unauthorized
alteration or repair, or if the product was not installed in
accordance with Grundfos' printed installation and operating
instructions.
To obtain service under this warranty, the defective product must
be returned to the distributor or dealer of Grundfos' products from
which it was purchased together with proof of purchase and
installation date, failure date, and supporting installation data.
Unless otherwise provided, the distributor or dealer will contact
Grundfos or an authorized service station for instructions.
Any defective product to be returned to Grundfos or a service
station must be sent freight prepaid; documentation supporting
the warranty claim and/or a Return Material Authorization must
be included if so instructed.
GRUNDFOS WILL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, LOSSES, OR EXPENSES
ARISING FROM INSTALLATION, USE, OR ANY OTHER
CAUSES. THERE ARE NO EXPRESS OR IMPLIED
WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, WHICH EXTEND BEYOND
THOSE WARRANTIES DESCRIBED OR REFERRED TO
ABOVE.
Some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages and some jurisdictions do
not allow limit actions on how long implied warranties may last.
Therefore, the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights and you may
also have other rights which vary from jurisdiction to jurisdiction.
Warning
Prior to installation, read these installation and
operating instructions. Installation and operation
must comply with local regulations and accepted
codes of good practice.
Warning
If these safety instructions are not observed,
it may result in personal injury.
Warning
If these instructions are not observed, it may lead
to electric shock with consequent risk of serious
personal injury or death.
Warning
The surface of the product may be so hot that
it may cause burns or personal injury.
Warning
Risk of dropping objects which may cause
personal injury.
Warning
Escaping vapor involves the risk of personal
injury.
Caution
If these safety instructions are not observed,
it may result in malfunction or damage to the
equipment.
Note
Note
Notes or instructions that make the job easier
and ensure safe operation.

English (US)
4
3. Abbreviations and definitions
4. General information
These installation and operating instructions apply to the
Grundfos TPE2 (D) and TPE3 (D) pumps.
The pumps are fitted with frequency-controlled
permanent-magnet motors for single-phase or three-phase power
supply connection.
4.1 Radio communication
This product incorporates a radio module for remote control
which is a class 1 device and can be used anywhere in the EU
member states without restrictions.
For use in USA and Canada, see page 50.
This product can communicate with the Grundfos GO Remote
and other products of the same type via the built-in radio module.
In some cases, an external antenna may be required.
Only Grundfos-approved external antennas may be connected to
this product, and only by a Grundfos-approved installer.
4.2 Battery
Pumps fitted with the advanced functional module (FM 300)
incorporate a Li-ion battery. The Li-ion battery complies with the
Battery Directive (2006/66/EC). The battery does not contain
mercury, lead and cadmium.
5. Delivery and handling
5.1 Delivery
The pump is delivered from the factory in a carton with a wooden
bottom, which is specially designed for transport by fork-lift truck
or a similar vehicle.
5.2 Handling
Lift the pump by means of nylon straps. See figs 1and 2.
Fig. 1 TPE2, TPE3
Fig. 2 TPE2 D, TPE3 D
AI Analog input.
AL Alarm, out of range at lower limit.
AO Analog output.
AU Alarm, out of range at upper limit.
Current sinking The ability to draw current into the terminal and
guide it towards GND in the internal circuitry.
Current
sourcing
The ability to push current out of the terminal
and into an external load which must return it
to GND.
DI Digital input.
DO Digital output.
ELCB Earth leakage circuit breaker.
FM Functional module.
GDS Grundfos Digital Sensor.
Factory-fitted sensor in some Grundfos pumps.
GENIbus Proprietary Grundfos fieldbus standard.
GFCI Ground fault circuit interrupter.
(USA and Canada).
GND Ground.
Grundfos Eye Status indicator light.
LIVE Low voltage with the risk of electric shock if the
terminals are touched.
OC Open collector:
Configurable open-collector output.
PE Protective earth.
PELV
Protective extra-low voltage.
A voltage that cannot exceed ELV under
normal conditions and under single-fault
conditions, except earth faults in other circuits.
SELV
Safety extra-low voltage.
A voltage that cannot exceed ELV under
normal conditions and under single-fault
conditions, including earth faults in other
circuits.
TPE2 Single-head TPE2 pump without factory-fitted
differential-pressure and temperature sensor.
TPE2 D Twin-head TPE2 D pump without factory-fitted
differential-pressure and temperature sensor.
TPE3 Single-head TPE3 pump with factory-fitted
differential-pressure and temperature sensor.
TPE3 D Twin-head TPE3 D pump with factory-fitted
differential-pressure and temperature sensor.
Note
Note
Some variants of these products and all products
sold in China and Korea have no possibility of
radio communication according to local
legislation.
Warning
TPE2 D, TPE3 D: The centrally positioned thread
of the pump housing must not be used for lifting
purposes as the thread is placed below the
center of gravity of the pump.
TM05 7914 1613TM05 7915 1613

5
English (US)
6. Applications
The pumps are designed to circulate hot or cold water in:
• heating systems
• district heating plants
• air-conditioning systems
• cooling systems.
In addition, the pumps are used for liquid transfer and water
supply in:
• washing systems
• domestic hot-water systems
• industrial systems in general.
To ensure optimum operation, the sizing range of the system
must fall within the performance range of the pump.
6.1 Pumped liquids
The pump is suitable for thin, clean, non aggressive and
nonflammable liquids, not containing solid particles or fibers that
may attack the pump mechanically or chemically.
Examples:
• central heating system water (the water should meet the
requirements of accepted standards on water quality in
heating systems)
• cooling liquids
• domestic hot water
• industrial liquids
• softened water.
The pumping of liquids with a density and/or kinematic viscosity
higher than that of water will cause the following:
• a considerable pressure drop
• a drop in hydraulic performance
• a rise in power consumption.
In such cases, fit the pump with a bigger motor. If in doubt,
contact Grundfos.
The EPDM O-rings fitted as standard are primarily suitable for
water.
If the water being pumped contains minerals, synthetic oil,
chemicals, or any liquids other than water, choose the O-rings
accordingly.
7. Operating conditions
7.1 Maximum number of starts and stops
The number of starts and stops via the power supply must not
exceed four times per hour.
When switched on via the power supply, the pump will start after
approx. 5 seconds.
If you want a higher number of starts and stops, use the input for
external start/stop when starting/stopping the pump.
When started via an external on/off switch, the pump will start
immediately.
7.2 Alternating operation of twin-head pumps
On twin-head pumps, the duty and backup pumps must be
alternated on a regular basis, i.e. once a week, to ensure an even
distribution of the operating hours on both pumps. As default, the
pumps alternate automatically. See section 16.1 Multi-pump
setup.
If you use twin-head pumps for pumping domestic hot water, the
duty and backup pumps must be alternated on a regular basis,
i.e. once a day, to avoid blocking of the backup pump due to
deposits (calcareous deposits, etc.). As default, the pumps
alternate automatically. See section 16.1 Multi-pump setup.
7.3 Liquid temperature
-13 °F (-25 °C) up to 248 °F (+120 °C).
The maximum liquid temperature depends on the mechanical
shaft seal type and the pump type.
Depending on the cast-iron version and the pump application, the
maximum liquid temperature may be limited by local regulations
and laws.
The maximum liquid temperature is stated on the pump
nameplate.
7.4 Ambient temperature
7.4.1 Ambient temperature during storage and transportation
-22 to 140 °F (-30 to +60 °C).
7.4.2 Ambient temperature during operation
-4 to 122 °F (-20 to +50 °C).
The motor can operate with the rated power output (P2) at
122 °F (50 °C), but continuous operation at higher temperatures
will reduce the expected product life. If the motor is to operate at
ambient temperatures between 122 and 140 °F (50 and 60 °C),
select an oversized motor. Contact Grundfos for further
information.
7.5 Operating pressure/test pressure
The pressure test has been made with water containing
anti-corrosive additives at a temperature of +68 °F (+20 °C).
Warning
If the pump is used for a liquid which is
hazardous, it will be classified as contaminated.
In such cases, the proper precautions must be
taken to avoid injury to health when operating or
working on the pump.
Note
Note
If the pump is operating with liquids at high
temperatures, the life of the shaft seal may be
reduced. It may be necessary to replace the shaft
seal more often.
Operating pressure Test pressure
[bar] [psi] [bar] [psi]
10 145 15 218

English (US)
6
7.6 Inlet pressure
To ensure optimum and quiet pump operation, the inlet pressure
(system pressure) must be adjusted correctly. See table on
page 51.
For the calculation of specific inlet pressures, contact the local
Grundfos company or see the data booklet for TP(D), TPE(D),
TPE2 (D) and TPE3 (D) on www.grundfos.us.
7.7 Electrical data
See sections 26. Technical data, single-phase motors and
27. Technical data, three-phase motors.
For specific motor data, see the motor nameplate.
7.8 Sound pressure level
The sound pressure level of the pump is lower than 70 dB(A).
7.9 Environment
Non-aggressive and non-explosive atmosphere.
7.10 Installation altitude
Installation altitude is the height above sea level of the installation
site.
• Motors installed up to 3281 ft (1000 m) above sea level can be
loaded 100 %.
• Motors installed more than 3281 ft (1000 m) above sea level
must not be fully loaded due to the low density and
consequent low cooling effect of the air. See fig. 3.
Fig. 3 Derating of motor output power (P2) in relation to
altitude above sea level
7.11 Air humidity
Maximum air humidity: 95 %.
If the air humidity is constantly high and above 85 %, one of the
drain holes in the drive-end flange must be open. See section
5. Delivery and handling.
7.12 Motor cooling
To ensure cooling of motor and electronics, observe the following:
• Position the motor in such a way that adequate cooling is
ensured. See section 8.7 Ensuring motor cooling.
• The temperature of the cooling air must not exceed
122 °F (50 °C).
• Keep cooling fins and fan blades clean.
Caution
The motor must not be installed more than
6562 ft (2000 m) above sea level.
TM05 6400-U.S. 1013
1
0.99
0.98
0.97
0.96
0.95
0.94
0.93
0.92
0.91
0.90
0.89
0.88
0
0
3281 3937 4593 5249 5906 6562 7218
[ft]
P2
[%]

7
English (US)
8. Mechanical installation
Install the pump in a dry well-ventilated, but frost-free position.
When installing pumps with oval bolt holes in the pump flange,
use washers as shown in fig. 4.
Fig. 4 Use of washers for oval bolt holes
Arrows on the pump housing show the direction of flow of liquid
through the pump.
You can install the pump in horizontal or vertical pipes.
For inspection and removal of motor or pump head, a clearance
of 11.81" (300 mm) is required above the motor. See fig. 5.
Fig. 5 Required clearance above the motor
Twin-head pumps installed in horizontal pipes must be fitted with
an automatic air vent in the upper part of the pump housing.
See fig. 6.
The automatic air vent is not supplied with the pump.
Fig. 6 Automatic air vent
If the liquid temperature falls below the ambient temperature,
condensation may form in the motor during inactivity. In this case,
make sure that one of the drain holes in the motor flange is open
and points downwards. See fig. 7.
Fig. 7 Drain hole in motor flange
If twin-head pumps are used for pumping liquids with a
temperature below 32 °F (0 °C), condensed water may freeze
and cause the coupling to get stuck. You can solve the problem
by installing heating elements. Whenever possible, install the
pump with the motor shaft in horizontal position. See fig. 6.
8.1 Pipework
Fit isolating valves on either side of the pump to avoid draining
the system if the pump needs to be cleaned or repaired.
The pump is suitable for pipeline mounting, provided that the
pipes are adequately supported on either side of the pump.
Single-head pumps are designed for pipeline mounting only.
Twin-head pumps are prepared for installation on a mounting
bracket or base plate.
When installing the pipes, make sure that the pump housing is
not stressed by the pipework.
The suction and discharge pipes must be of an adequate size,
taking the pump inlet pressure into account.
To avoid sediment build-up, do not fit the pump at the lowest point
of the system.
Install the pipes so that air locks are avoided, especially on the
suction side of the pump. See fig. 8.
Fig. 8 Correct pipework on the suction side of the pump
If there is any risk of the pump running against a closed discharge
valve, ensure a minimum liquid flow through the pump by
connecting a bypass/a drain to the discharge pipe. You can for
instance connect the drain to a tank. A minimum flow rate equal
to 10 % of the flow rate at maximum efficiency is needed at all
times.
Flow rate and head at maximum efficiency are stated on the
pump nameplate.
Warning
When pumping hot or cold liquids, make sure
that persons cannot accidentally come into
contact with hot or cold surfaces.
Note
Note
In order to maintain the UL mark, additional
installation procedures must be followed.
See page 50.
TM01 0683 1997
Caution
The motor must never fall below the horizontal
plane.
TM05 7916 1613TM05 7983 1713
Installation
Washer Pump
11.81" [300 mm]
TM05 7917 1613
Caution
Observe the conditions in section 11. User
interfaces.
TM00 2263 0195
Caution
The pump must not run against a closed
discharge valve as this will cause an increase in
temperature/formation of steam in the pump
which may cause damage to the pump.

English (US)
8
8.2 Terminal box positions
The terminal box can be turned to any position. Change the
terminal box position as follows:
1. Loosen the clamp securing the pump head to the pump
housing. See fig. 9.
Fig. 9 Clamp (A)
2. Turn the pump head to the required position.
3. Check the following before you tighten the clamp:
– The contact face of the pump housing and that of the pump
head must be in full contact.
– Position the clamp correctly in the flange recess of both the
pump head and the pump housing. See fig. 12.
Tightening torque: 5.9 lbf-ft (± 0.75) (8 Nm (± 1)).
8.3 Fitting of pump head
If for some reason the pump head has been lifted from the pump
housing, follow the following procedure in order to mount the
pump head correctly:
1. Visually check that the neck ring is centered in the pump
housing. See fig. 10.
Fig. 10 Centering of neck ring
2. Gently lower the pump head with rotor shaft and impeller into
the pump housing. See fig. 11.
Fig. 11 Lowering of pump head
Warning
Before starting work on the pump, make sure that
the power supply has been switched off for at
least 5 minutes. Make sure that the power supply
cannot be accidentally switched on.
Warning
If the pump head has been lifted partly or
completely from the pump housing, pay special
attention when fitting the pump head again.
See 8.3 Fitting of pump head.
Warning
When loosening the clamp, do not drop the pump
head. See fig. 9.
Warning
When loosening the clamp, there is a risk of
escaping vapor. See fig. 9.
TM06 0721 0814
A
Warning
Before starting work on the pump, make sure that
the power supply has been switched off for at
least 5 minutes. Make sure that the power supply
cannot be accidentally switched on.
Warning
If the pump head has been lifted partly or
completely from the pump housing, pay special
attention when fitting the pump head again.
See instructions below.
Warning
Do not drop the pump head. See fig. 9.
Warning
When loosening the clamp, there is a risk of
escaping vapor. See fig. 9.
TM06 0722 0814TM06 0723 0814

9
English (US)
3. Check the following before you tighten the clamp:
– The contact face of the pump housing and that of the pump
head must be in full contact.
– Position the clamp correctly in the flange recess of both the
pump head and the pump housing. See fig. 12.
Tightening torque: 5.9 lbf-ft (± 0.75) (8 Nm (± 1)).
Fig. 12 Positioning of clamp ring
8.4 Base plate
Twin-head pumps have tapped holes in the bottom of the pump
housing. The holes can be used for mounting a base plate.
8.5 Insulation
Follow the guidelines in fig. 13 when insulating the pump.
Fig. 13 Insulation of TPE2, TPE3 pumps
8.6 Frost protection
Pumps which are not being used during periods of frost must be
drained to avoid damage.
8.7 Ensuring motor cooling
Fig. 14 Minimum distance (D) from the motor to a wall or other
fixed objects
8.8 Outdoor installation
When installed outdoors, the motor must be provided with a
suitable cover to avoid condensation on the electronic
components. See fig. 15.
The cover must be sufficiently large to ensure that the motor is
not exposed to direct sunlight, rain or snow. Grundfos does not
supply covers. We therefore recommend that you have a cover
built for the specific application. In areas with high air humidity,
we recommend that you enable the built-in standstill heating
function.
Fig. 15 Examples of covers (not supplied by Grundfos)
TM06 0724 0814
Caution
Do not insulate the motor stool as this will trap
any vapor escaping from the shaft seal, thus
causing corrosion. Covering the motor stool with
insulation will also make inspection and service
difficult.
TM05 7918 1613
Pos. Description
A Without insulation
B Correct insulation
C Incorrect insulation
A
BC
Note
Note
In order to ensure sufficient cooling of the motor,
the distance (D) between the end of the fan cover
and a wall or other fixed objects must always be
at least 2.0" (50 mm), irrespective of motor size.
See fig. 14.
TM05 5236 3512
Note
Note
When fitting a cover to the motor, observe the
guideline in section 8.7 Ensuring motor cooling.
TM05 7919 1613
D

English (US)
10
9. Electrical installation
Carry out the electrical connection according to local regulations.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
9.1 Protection against electric shock, indirect contact
9.1.1 Protection against power supply voltage transients
The motor is protected against power supply voltage transients in
accordance with EN 61800-3.
9.1.2 Motor protection
The motor requires no external motor protection. The motor
incorporates thermal protection against slow overloading and
blocking.
9.2 Power supply
9.2.1 Single-phase supply voltage
• 1 x 200-240 V - 10 %/+ 10 %, 60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
The wires in the motor terminal box must be as short possible
except for the separated ground conductor which must be so long
that it is the last one to be disconnected in case the cable is
inadvertently pulled out of the cable entry.
For maximum backup fuse, see section 26.1 Supply voltage.
Fig. 16 Example of a power supply-connected motor with
power supply switch, backup fuse and additional
protection
Fig. 17 Power supply connection, single-phase motors
Warning
Before making any connections in the terminal
box, make sure that the power supply has been
switched off for at least 5 minutes. Make sure that
the power supply cannot be accidentally
switched on.
The motor must be connected to an external
all-pole power supply switch according to local
regulations.
The motor must be grounded and protected
against indirect contact in accordance with local
regulations.
If the power supply cable is damaged, it must be
replaced by the manufacturer, the manufacturer's
service partner or a similarly qualified person.
Note
Note
The user or the installer is responsible for the
installation of correct grounding and protection
according to local regulations. All operations
must be carried out by a qualified electrician.
Warning
The motor must be grounded and protected
against indirect contact in accordance with local
regulations.
TM05 4034 1912TM05 3494 1512
GFCI

11
English (US)
9.2.2 Three-phase supply voltage
• 3 x 440-480 V - 10 %/+ 10 %, 60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
The wires in the motor terminal box must be as short as possible.
Excepted from this is the separated earth conductor which must
be so long that it is the last one to be disconnected in case the
cable is inadvertently pulled out of the cable entry.
For maximum backup fuse, see section 27.1 Supply voltage.
Fig. 18 Example of a power supply-connected motor with
power supply switch, backup fuses and additional
protection
Fig. 19 Power supply connection, three-phase motors
9.3 Additional protection
9.3.1 Single-phase motors
If the motor is connected to an electric installation where an earth
leakage circuit breaker (ELCB) or ground fault circuit
interrupter (GFCI) is used as additional protection, this circuit
breaker or interrupter must be marked with the following symbol:
The leakage current of the motor can be found in section
26.2 Leakage current.
9.3.2 Three-phase motors
If the motor is connected to an electric installation where an earth
leakage circuit breaker (ELCB) or ground fault circuit interrupter
(GFCI) is used as additional protection, this circuit breaker or
interrupter must be of the following type:
• It must be suitable for handling leakage currents and cutting-in
with short pulse-shaped leakage.
• It must trip out when alternating fault currents and fault
currents with DC content, i.e. pulsating DC and smooth DC
fault currents, occur.
For these motors an earth leakage circuit breaker or ground fault
circuit interrupter, type B, must be used.
This circuit breaker or interrupter must be marked with the
following symbols:
You find the leakage current of the motor in section 27.2 Leakage
current.
Protection against phase unbalance
The motor must be connected to a power supply with a quality
corresponding to IEC 60146-1-1, class C, to ensure correct motor
operation at phase unbalance.
This also ensures long life of the components.
Caution
In order to avoid loose connections, ensure that
the terminal block for L1, L2 and L3 is pressed
home in its socket when the supply cable has
been connected.
Note
Note
Corner grounding is not allowed for supply
voltages above 3 x 480 V, 60 Hz.
TM05 3942 1812TM05 3495 1512
L1
L2
L3
L2
L1
L3
PE
GFCI
Note
Note
When an earth leakage circuit breaker or ground
fault circuit interrupter is selected, the total
leakage current of all the electrical equipment in
the installation must be taken into account.
Note
Note
When you select an earth leakage circuit breaker
or ground fault circuit interrupter, take into
account the total leakage current of all the
electrical equipment in the installation.
ELCB
(GFCI)
ELCB
(GFCI)

English (US)
12
9.4 Connection terminals
The descriptions and terminal overviews in this section apply to
both single-phase and three-phase motors.
For maximum tightening torques, see section Torques, page 49.
The number of terminals depends on the functional module (FM).
You can identify the fitted module on the motor nameplate.
See fig. 20.
Fig. 20 Identification of functional module
9.4.1 Connection terminals, advanced functional module
(FM 300)
The advanced functional module is only available as an option.
The advanced module has these connections:
• three analog inputs
• one analog output
• two dedicated digital inputs
• two configurable digital inputs or open-collector outputs
• Grundfos Digital Sensor input and output
• two Pt100/1000 inputs
• two LiqTec sensor inputs
• two signal relay outputs
• GENIbus connection.
See fig. 21.
•Inputs and outputs
All inputs and outputs are internally separated from the power
supply-conducting parts by reinforced insulation and
galvanically separated from other circuits.
All control terminals are supplied by safety extra-low voltage
(SELV), thus ensuring protection against electric shock.
•Signal relay outputs
– Signal relay 1:
LIVE:
Power supply voltages up to 250 VAC can be connected to
this output.
SELV:
The output is galvanically separated from other circuits.
Therefore, the supply voltage or safety extra-low voltage
can be connected to the output as desired.
– Signal relay 2:
SELV:
The output is galvanically separated from other circuits.
Therefore, the supply voltage or safety extra-low voltage
can be connected to the output as desired.
•Power supply (terminals N, PE, L or L1, L2, L3, PE).
A galvanically safe separation must fulfil the requirements for
reinforced insulation including creepage distances and
clearances specified in EN 61800-5-1.
TM05 7928 1613
Env.Type :
Serial no :
SF CL:
PF:
PB
FM
HMIEff
n max:
CIMWgt:
DE :
kg
NDE :Tamb:
:FAA
V
~
P.C. :
Made in Hungary
OUTPUT VARIANT INPUT
TEFC
Type :
P.N. :Uin :
I1/1 :
fin
Hp
Hz
P2
I SF Amp:
rpm
:::
:
:
:
:
Xxxxxxxxxxx
E.P. Motor
DK- 8850 Bjerringbro, Denmark
E
n
v
.
T
y
y
p
e
p
:
S
eri
a
l
n
o
:
SF
C
L
:
P
F
:
Eff
n
W
g
g
t
:
DE
:
k
g
g
N
D
E
:
T
a
m
b
:
:
F
A
A
V
~
P.
C
.
:
INPU
T
T
E
F
C
T
yp
yp
e
:
P.
N
.
:
U
in
:
I
1
/
1
:
f
in
H
z
P
I
SF Am
p
p
:
:
PB
FM
HMI
CIM
VARIANT
Hp
rpm
:
:
:
:
PB
:
HMI
:
C
IM
:
H
p
rp
m
Note
Note
Digital input 1 is factory-set to be start/stop input
where open circuit will result in stop.
A jumper has been factory-fitted between
terminals 2 and 6. Remove the jumper if digital
input 1 is to be used as external start/stop or any
other external function.
Note
Note
As a precaution, the wires to be connected to the
connection groups below must be separated
from each other by reinforced insulation in their
entire lengths.

13
English (US)
* If you use an external supply source, there must be a
connection to GND.
Fig. 21 Connection terminals, FM 300 (option)
TM05 3509 3512
3
15
8
26
23
25
24
7
21
20
22
B
Y
6
5
2
4
10
A
+24 V*
1
14
9
12
17
19
11
18
+24 V*
+
+24 V* OC DI
+24 V*/5 V*
+24 V*
+
++
+24 V*/5 V*
+24 V*
+24 V*
+
+
+24 V*/5 V*
+24 V*
+5 V*
AI2
GDS RX
GDS TX
GND
GENIbus A
GENIbus B
+5 V
+24 V
+24 V
GND
GENIbus Y
GND
+5 V
DI1
AI1
DI3/OC1
LiqTec
AI3
GND
DI2
LiqTec
GND
AO
Pt100/1000
Pt100/1000
DI4/OC2
GND
+24 V* OC DI
GND
NC
C2
NO
NC
C1
NO
+5 V*
Terminal Type Function
NC Normally closed
contact Signal relay 1
(LIVE or SELV)C1 Common
NO Normally open contact
NC Normally closed
contact Signal relay 2
(SELV only)C2 Common
NO Normally open contact
18 GND Ground
11 DI4/OC2
Digital input/output,
configurable.
Open collector: Max. 24 V
resistive or inductive.
19 Pt100/1000 input 2 Pt100/1000 sensor input
17 Pt100/1000 input 1 Pt100/1000 sensor input
12 AO
Analog output:
0-20 mA / 4-20 mA
0-10 V
9 GND Ground
14 AI3
Analog input:
0-20 mA / 4-20 mA
0-10 V
1 DI2 Digital input, configurable
21 LiqTec sensor input 1 LiqTec sensor input
(white conductor)
20 GND
Ground
(brown and black
conductors)
22 LiqTec sensor input 2 LiqTec sensor input
(blue conductor)
10 DI3/OC1
Digital input/output,
configurable.
Open collector: Max. 24 V
resistive or inductive.
4AI1
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V
2 DI1 Digital input, configurable
5+5V Supply to potentiometer
and sensor
6 GND Ground
A GENIbus, A GENIbus, A (+)
Y GENIbus, Y GENIbus, GND
B GENIbus, B GENIbus, B (-)
3 GND Ground
15 +24 V Supply
8 +24 V Supply
26 +5 V Supply to potentiometer
and sensor*
23 GND Ground
25 GDS TX Grundfos Digital Sensor
output
24 GDS RX Grundfos Digital Sensor
input
7AI2
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V

English (US)
14
9.4.2 Connection terminals, standard functional module
(FM 200)
The standard module has these connections:
• two analog inputs
• two digital inputs or one digital input and one open-collector
output
• Grundfos Digital Sensor input and output
• two signal relay outputs
• GENIbus connection.
See fig. 22.
•Inputs and outputs
All inputs and outputs are internally separated from the power
supply-conducting parts by reinforced insulation and
galvanically separated from other circuits.
All control terminals are supplied by safety extra-low voltage
(SELV), thus ensuring protection against electric shock.
•Signal relay outputs
– Signal relay 1:
LIVE:
Power supply voltages up to 250 VAC can be connected to
this output.
SELV:
The output is galvanically separated from other circuits.
Therefore, the supply voltage or safety extra-low voltage
can be connected to the output as desired.
– Signal relay 2:
SELV:
The output is galvanically separated from other circuits.
Therefore, the supply voltage or safety extra-low voltage
can be connected to the output as desired.
•Power supply (terminals N, PE, L or L1, L2, L3, PE).
A galvanically safe separation must fulfil the requirements for
reinforced insulation including creepage distances and
clearances specified in EN 61800-5-1.
Note
Note
Digital input 1 is factory-set to be start/stop input
where open circuit will result in stop.
A jumper has been factory-fitted between
terminals 2 and 6. Remove the jumper if digital
input 1 is to be used as external start/stop or any
other external function.
Note
Note
As a precaution, the wires to be connected to the
connection groups below must be separated
from each other by reinforced insulation in their
entire lengths.

15
English (US)
* If an external supply source is used, there must be a
connection to GND.
Fig. 22 Connection terminals, FM 200
TM05 3510 3512
3
15
8
26
23
25
24
7
B
Y
6
5
2
4
10
A
AI2
GDS RX
GDS TX
GND
GENIbus A
GENIbus B
+5 V
+24 V
+24 V
GND
GENIbus Y
GND
+5 V
DI1
AI1
DI3/OC1
+24 V*
+
+
+24 V*/5 V*
+24 V*
+5 V*
NC
C2
NO
NC
C1
NO
+24 V*
++
+24 V*/5 V*
+24 V*
+24 V* OC DI
GND
Terminal Type Function
NC Normally closed
contact Signal relay 1
(LIVE or SELV)
C1 Common
NO Normally open
contact
NC Normally closed
contact Signal relay 2
(SELV only)
C2 Common
NO Normally open
contact
10 DI3/OC1
Digital input/output,
configurable.
Open collector: Max. 24 V
resistive or inductive.
4AI1
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V
2 DI1 Digital input, configurable
5+5V Supply to potentiometer and
sensor
6 GND Ground
A GENIbus, A GENIbus, A (+)
Y GENIbus, Y GENIbus, GND
B GENIbus, B GENIbus, B (-)
3 GND Ground
15 +24 V Supply
8 +24 V Supply
26 +5 V Supply to potentiometer and
sensor*
23 GND Ground
25 GDS TX Grundfos Digital Sensor
output
24 GDS RX Grundfos Digital Sensor input
7AI2
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V

English (US)
16
9.5 Signal cables
• Use screened cables with a cross-sectional area of
min. 20 AWG and max. 16 AWG (0.5 mm2and max. 1.5 mm2)
for external on/off switch, digital inputs, setpoint and sensor
signals.
• Connect the screens of the cables to frame at both ends with
good connection. The screens must be as close as possible to
the terminals. See fig. 23.
Fig. 23 Stripped cable with screen and wire connections
• Screws for frame connections must always be tightened
whether a cable is fitted or not.
• The wires in the motor terminal box must be as short as
possible.
9.6 Bus connection cable
9.6.1 New installations
For the bus connection, use a screened 3-core cable with a
cross-sectional area of min. 20 AWG and max. 16 AWG (0.5 mm2
and max. 1.5 mm2).
• If the motor is connected to a unit with a cable clamp which is
identical to the one on the motor, connect the screen to this
cable clamp.
• If the unit has no cable clamp as shown in fig. 24, leave the
screen unconnected at this end.
Fig. 24 Connection with screened 3-core cable
9.6.2 Replacing an existing motor
• If a screened 2-core cable is used in the existing installation,
connect the cable as shown in fig. 25.
Fig. 25 Connection with screened 2-core cable
• If a screened 3-core cable is used in the existing installation,
follow the instructions in section 9.6.1 New installations.
10. Startup
10.1 Flushing the pipe system
10.2 Priming
Closed systems or open systems where the liquid level is
above the pump inlet
1. Close the discharge isolating valve and loosen the air vent
screw in the motor stool. See fig. 26.
2. Slowly open the isolating valve in the suction pipe until a
steady stream of liquid runs out of the vent hole.
3. Tighten the air vent screw and completely open the isolating
valve(s).
TM02 1325 4402TM05 3973 1812
A
Y
B
A
Y
B
1
2
3
1
2
3
Motor
TM02 8842 0904
Caution
The pump is not designed to pump liquids
containing solid particles such as pipe debris
and welding slag. Before starting up the pump,
clean the pipe system thoroughly, and flush and
fill it with clean water.
The warranty does not cover any damage caused
by flushing the pipe system by means of the
pump.
Caution
Do not start the pump until it has been filled with
liquid and vented. To ensure correct venting, the
vent screw should point upwards.
Warning
Pay attention to the direction of the vent hole,
and make sure that the escaping hot or cold
liquid does not cause injury to persons or
damage to the equipment.
A
Y
B
A
Y
B
1
2
1
2
Motor

17
English (US)
Open systems where the liquid level is below the pump inlet
The suction pipe and the pump must be filled with liquid and
vented before you start the pump.
1. Close the discharge isolating valve and open the isolating
valve in the suction pipe.
2. Loosen the air vent screw. See fig. 26.
3. Remove the plug from one of the pump flanges, depending on
the pump location.
4. Pour liquid through the priming port until the suction pipe and
the pump are filled with liquid.
5. Replace the plug and tighten securely.
6. Tighten the air vent screw.
The suction pipe can to some extent be filled with liquid and
vented before it is connected to the pump. You can also install a
priming device before the pump.
Fig. 26 Position of air vent screw
10.3 Starting
1. Before starting the pump, completely open the isolating valve
on the suction side of the pump and leave the discharge
isolating valve almost closed.
2. Start the pump. See section 11. User interfaces.
3. Vent the pump during starting by loosening the air vent screw
in the motor stool until a steady stream of liquid runs out of the
vent hole. See fig. 26.
4. When the pipe system has been filled with liquid, slowly open
the discharge isolating valve until it is completely open.
10.4 Shaft seal run-in
The seal faces are lubricated by the pumped liquid, meaning that
there may be a certain amount of leakage from the shaft seal.
When the pump is started up for the first time, or when a new shaft
seal is installed, a certain run-in period is required before the
leakage is reduced to an acceptable level. The time required for
this depends on the operating conditions, i.e. every time the
operating conditions change, a new run-in period will be started.
Under normal conditions, the leaking liquid will evaporate. As a
result, no leakage will be detected.
However, liquids such as kerosene will not evaporate. The leakage
may therefore be seen as a shaft seal failure.
11. User interfaces
Pump settings can be made by means of the following user
interfaces:
Control panels
• Standard control panel.
See section 12. Standard control panel.
• Advanced control panel.
See section 13. Advanced control panel.
Remote controls
• Grundfos GO Remote.
See section 14. Grundfos GO Remote.
If you switch-off the power supply to the pump, the settings will be
stored.
Factory settings
TPE2 (D) pumps have been factory-set to constant-curve control
mode. See section 12.1.2 Pump in constant-curve control mode.
The setpoint value corresponds to 100 %, of maximum pump
performance. See data booklet or WebCAPS.
TPE3 (D) pumps have been factory-set to AUTOADAPT control
mode. See section 15.4.1 AUTOADAPT.
TM05 7922 1613
Warning
Pay attention to the direction of the vent hole,
and make sure that the escaping hot or cold
liquid does not cause injury to persons or
damage to the equipment.
Warning
The product may be so hot that only the buttons
must be touched to avoid burns.

English (US)
18
12. Standard control panel
This control panel is fitted as standard on TPE2 (D) pumps.
Fig. 27 Standard control panel
12.1 Setpoint setting
Set the desired setpoint of the pump by pressing or .
The light fields on the control panel will indicate the setpoint set.
12.1.1 Pump in differential-pressure control mode
The following example applies to a pump in an application where
a pressure sensor gives a feedback to the pump. If you retrofit the
sensor to the pump, you must set it up manually as the pump
does not automatically register a connected sensor.
Figure 28 shows that the light fields 5 and 6 are activated,
indicating a desired setpoint of 4.3 psi (3 m) with a sensor
measuring range from 0 to 8.5 psi (0 to 6 m). The setting range is
equal to the sensor measuring range.
Fig. 28 Setpoint set to 4.3 psi (3 m), differential-pressure
control
12.1.2 Pump in constant-curve control mode
In constant-curve control mode, the pump performance will lie
between the maximum and minimum curve of the pump.
See fig. 29.
Fig. 29 Pump in constant-curve control mode
TM05 4848 3512
Pos. Symbol Description
1
Grundfos Eye
Shows the operating status of the pump.
See section 21. Grundfos Eye for further
information.
2 - Light fields for indication of setpoint.
3 Changes the setpoint.
4
Enables radio communication with the
Grundfos GO Remote and other products of
the same type.
5
Makes the pump ready for operation/starts
and stops the pump.
Start:
If you press the button when the pump is
stopped, the pump will only start if no other
functions with higher priority have been
enabled. See section 20. Priority of settings.
Stop:
If you press the button when the pump is
running, the pump will always be stopped.
When the pump is stopped via this button, the
"Stop" text next to the button will illuminate.
1
2
3
4
5
Stop
TM06 1116 1714TM05 4895 2812
4.3
8.5 psi
H
Q

19
English (US)
Setting to maximum curve:
•Press continuously to change over to the maximum curve
of the pump (top light field flashes). When the top light field is
on, press for 3 seconds until the light field starts flashing.
• To change back, press continuously until the desired
setpoint is indicated.
Example: Pump set to maximum curve.
Figure 30 shows that the top light field is flashing, indicating
maximum curve.
Fig. 30 Maximum curve duty
Setting to minimum curve:
•Press continuously to change over to the minimum curve
of the pump (bottom light field flashes). When the bottom light
field is on, press for 3 seconds until the light field starts
flashing.
• To change back, press continuously until the desired
setpoint is indicated.
Example: Pump set to minimum curve.
Figure 31 shows that the bottom light field is flashing, indicating
minimum curve.
Fig. 31 Minimum curve duty
12.1.3 Start/stop of pump
Start the pump by pressing or by continuously pressing
until the desired setpoint is indicated.
Stop the pump by pressing . When the pump is stopped, the
"Stop" text next to the button will illuminate. You can also stop the
pump by continuously pressing until none of the light fields
are on.
If you have stopped the pump by pressing , it can only be
given free to operation by pressing again.
If you have stopped the pump by pressing , it can only be
restarted by pressing .
You can also stop the pump with the Grundfos GO Remote or via
a digital input set to "External stop". See section 20. Priority of
settings.
12.1.4 Resetting of fault indications
You can reset a fault indication in one of the following ways:
• Via the digital input if it has been set to "Alarm resetting".
• Briefly press or on the pump. This will not change the
setting of the pump.
You cannot reset a fault indication by pressing or if the
buttons have been locked.
• Switch off the power supply until the indicator lights are off.
• Switch the external start/stop input off and then on again.
• With the Grundfos GO Remote.
TM05 4896 2812TM05 4897 2812
H
Q
H
Q

English (US)
20
13. Advanced control panel
This control panel is fitted as standard on TPE3 (D) pumps.
TPE2 (D) pumps can be fitted with the advanced control panel as
an option.
Fig. 32 Advanced control panel
13.1 Menu structure
The pump incorporates a startup guide which is started at the first
startup. After the startup guide, the four main menus will appear
in the display.
1. Home
This menu shows up to four user-defined parameters with
shortcuts or a graphical illustration of a Q/H performance curve.
2. Status
This menu shows the status of the pump and system as well as
warnings and alarms.
3. Settings
This menu gives access to all setting parameters. A detailed
setting of the pump can be made in this menu.
See section 15. Description of selected functions.
4. Assist
This menu enables assisted pump setup, provides a short
description of the control modes and offers fault advice.
See section 16. Assist.
TM05 4849 1013
Pos. Symbol Description
1
Grundfos Eye
Shows the operating status of the pump.
See section 21. Grundfos Eye for further
information.
2 - Graphical color display.
3 Goes one step back.
4
Navigates between main menus, displays and
digits.
When the menu is changed, the display will
always show the top display of the new menu.
Navigates between submenus.
Saves changed values, resets alarms and
expands the value field.
Enables communication with the Grundfos GO
Remote.
5
Makes the pump ready for operation/starts and
stops the pump.
Start:
If you press the button when the pump is
stopped, the pump will only start if no other
functions with higher priority have been
enabled. See section 20. Priority of settings.
Stop:
If you press the button when the pump is
running, the pump will always be stopped.
When you stop the pump via this button, the
"Stop" text next to the button will illuminate.
6 Goes to the "Home" menu.
1
2
3
4
5
6
Note
Note
You cannot make any settings in this menu.
