Grundig GSS SMCIP 402 C User manual

Assembly Instruction
SMCIP 402 C/T

- 2 - SMCIP 402 C/T
Contents
1 Safety regulations and notes ........................................................................4
2 General information ....................................................................................5
2.1 Packing contents ............................................................................5
2.2 Meaning of the symbols used ..........................................................5
2.3 Technical data ...............................................................................6
2.4 Description ...................................................................................7
Block diagram ...............................................................................7
General ........................................................................................8
3 Assembly ....................................................................................................9
3.1 Installing the device .......................................................................9
3.2 device overview ..........................................................................10
3.3 Connecting the device ..................................................................11
Potential equalisation (PE) .............................................................11
Signal Connections ......................................................................11
3.4 Retrofitting a CA module ..............................................................12
3.5 Firmware ....................................................................................13
Firmware query ...........................................................................13
Firmware update .........................................................................13
4 The control panel at a glance .....................................................................16
4.1 Control panel ..............................................................................16
4.2 Menu items .................................................................................16
5 Programming ............................................................................................17
5.1 Notes on frequency setting ...........................................................17
5.2 Notes on level setting ...................................................................17
Input level of multiswitches at multisatellite reception ........................17
Output level of the device .............................................................17
5.3 Programming procedure ...............................................................18
5.4 Programming the cassette ............................................................19
Status menu ................................................................................20
Output mode ...............................................................................21
Output parameter, level – DVB-C version ...................................22
Channel/frequency ............................................................22
Output symbol rate, QAM modulation ..................................23
Output parameter, level – DVB-T version ....................................24
Channel/frequency ............................................................24
COFDM parameters ...........................................................25
Output signal ...................................................................... 28

- 3 - SMCIP 402 C/T
Transmission parameters .....................................................29
Transmitter identification .....................................................30
ASI input selection .......................................................................31
Input parameter ...........................................................................31
LNB oscillator frequency / control voltage .................................32
Input symbol rate ....................................................................33
Input frequency ......................................................................34
Operation with a CA module ...................................................34
Station selection .....................................................................34
Output data rate ..........................................................................36
Transport stream ID and ORGNET-ID ..............................................37
CA data packets .........................................................................38
PID monitoring ............................................................................38
CA module .................................................................................39
Factory reset ...............................................................................40
Saving data ................................................................................40
6 Channel and frequency tables ....................................................................41

- 4 - SMCIP 402 C/T
1 safety regulations and notes
• This device is subject to the provisions of protection class II .
• Do not operate the device without equipotential bonding!
• The standards EN/DIN EN 50083 resp. IEC/EN/DIN EN 60728 must be
observed .
• Observe the relevant standards, regulations and guidelines on the installa-
tion and operation of antenna systems.
• Observe the relevant VDE regulations.
• Do not perform installation and service work during thunderstorms.
• Assembly, installation and servicing should be carried out by authorised
electricians.
• Switch off the operating voltage of the system before beginning with assem-
bly or service work or pull out the mains plug.
• Install the system so it will not be able to vibrate…
- in a dust-free, dry environment
- in such a manner that it is protected from moisture, fumes, splashing wa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +40 °C. In case of the formation of
condensation wait until the system is completely dried.
• Ensure that the device is adequately ventilated.
Do not cover the ventilation slots.
• Do not install the device in cabinets or recesses which are not ventilated.
• Do not place any vessels containing liquids on the device.
• Do not place anything on the device which could initiate fires (e.g. candles).
• Due to the risk of fires caused by lightning strikes, we recommend that all
mechanical parts (e.g. distributor, equipotential bonding rail, etc.) be mounted
on a non-combustible base. Wood panelling, wooden beams, plastic covered
panels and plastic panels are all examples of combustible bases.
• Avoid short circuits
• No liability is accepted for any damage caused by faulty connections or
inappropriate handling.
• Test the firmware versions of the device and update them if necessary. The
current firmware versions can be found at "www.mygss.eu".
Take action to prevent static discharge when working at the device!

- 5 - SMCIP 402 C/T
Electronic devices should never be disposed of in the household rubbish. In accordance
with directive 2002/96/EC of the European Parliament and the European Council from
January 27, 2003 which addresses old electronic and electrical devices, such devices
must be disposed of at a designated collection facility. At the end of its service life,
please take your device to one of these public collection facilities for proper disposal.
2 general information
2.1 PaCkin g C o nt e n t s
1 SMCIP 402 or SMCIP 402 T
1 Assembly instructions
2.2 me a n ing of th e symbol s us e d
Important note
Danger by electrical shock
—> General note
• Performing works
Text describes only the DVB-C version (SMCIP 402 C)
Text describes only the DVB-T version (SMCIP 402 T)

- 6 - SMCIP 402 C/T
2.3 teChn i C al data
The devices meet the following EU directives:
2006/95/EC, 2004/108/EC, 2011/65/EU
The product fulfils the guidelines and standards for CE labelling (page 42).
Unless otherwise noted all values are specified as "typical".
RF input DVB-S2
Frequency range: ....................................................... 950 … 2150 MHz
Level range: ............................................................ 60 dBμV … 80 dBμV
DVB-S modes: .....................................DVB-S 1/2 , 2/3 , 3/4 , 5/6 , 7/8
DVB-S2 modes: .......QPSK 1/2 , 3/5 , 2/3 , 3/4 , 4/5 , 5/6 , 8/9 , 9/10
8PSK 3/5 , 2/3 , 3/4 , 5/6 , 8/9 , 9/10
16APSK 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK 3/4, 4/5, 5/6, 8/9, 9/10
Symbol rate: ..................................................... QPSK: 1 … 53 MSymb/s
8PSK: 1 … 45 MSymb/s
16APSK: 1 … 35 MSymb/s
32APSK: 1 … 28 MSymb/s
Maximum net data rate per tuner ............................................... 72 Mbit/s
DiSEqCTM*: ............................ 1.1 (16 Satellites with 4 levels, max. 60 mA)
*DiSEqCTM is a trademark of EUTELSAT
ASI
Standard: .....................................................................DIN EN 50083-9
Format: ..............................................................MPEG ISO IEC 13818-1
Maximum output data rate RF+ASI mode: ................................ 50.8 Mbit/s
dependent on the QAM output parameter settings
Maximum output data rate RF+ASI mode: ................................ 31.6 Mbit/s
dependent on the COFDM output parameter settings
Maximum output data rate ASI mode: ...................................... 108 Mbit/s
Level (input / output): .................................................... 800 mVPP ± 10%
Return loss (input):...............................................> 17 dB (5 … 270 MHz)
RF output (SMCIP 402 C)
Frequency range: ............................................. 42.0 MHz … 868.0 MHz
Channels: ............................................................................ S21 … C69
Output level: ........................................................................... 102 dBμV
Output impedance: ......................................................................... 75 Ω
COFDM modulator (SMCIP 402 T)
Signal processing: ......................................................... DIN EN 300744
Transmission modes: ........................................................................... 2k
Types of modulation: ........................................ QPSK, 16 QAM, 64 QAM
Code rates: ............................................................ 1/2, 2/3, 3/4, 5/6, 7/8
Guard intervals: ......................................................... 1/4, 1/8, 1/16, 1/32

- 7 - SMCIP 402 C/T
RF output (SMCIP 402 T)
Frequency range: ............................................. 42.0 MHz … 868.0 MHz
Channels: ..........................................................C5 … C12, C21 … C69
Output level: ........................................................................... 102 dBμV
Output impedance: ......................................................................... 75 Ω
Connections
SAT inputs: ............................................................................. 4 F sockets
RF output: .............................................................................. 1 F socket
ASI input: .......................................................................... 1 BNC socket
ASI output: ......................................................................... 1 BNC socket
Micro USB socket: ...................................................... for software update
Common Interface: .......................1 (several channels can be descrambled)
Power Supply
Mains voltage: .................................................... 220–240V~, 50/60 Hz
2.4 desCri P ti on
The transmodulator converts channels from up to 4 DVB-S/DVB-S2 transpond-
ers (four tuners) dependent on the device version into one DVB-C or DVB-T
transponder.
Using an adequate CA module the scrambled signals contained in this mul-
tiplex (MUX) can be descrambled. The number of signals to be descrambled
depends on the CI module and the smart card.
bl o C k d i ag r a m
Tuner "A"
SAT IN "A"
RF OUT
Tuner "D"
CA module
Tuner "B"
Tuner "C"
SAT IN "B"
SAT IN "C"
SAT IN "D"
MUX Modulator 31 dB
Attenuator
ASI IN ASI OUT
The 4 tuners receive their input signal from the outputs of a multiswitch.
In addition it is possible to add the signal from the ASI input instead of the
signal from Tuner D. The desired channels, which are selected via the sta-
tion filter, will be multiplexed, if needed descrambled and modulated to one
DVB-C/T transponder.

- 8 - SMCIP 402 C/T
—> Note the maximum possible output data rate of 50.8 Mbits/s
(DVB-C) resp. 31.6 Mbits/s (DVB-T), which depends on the output
parameter settings!
If only the ASI output is needed, the modulator can be switched off.
—> Then the maximum output data rate is 108 Mbit/s.
gen e r al
As signal source four Tuners (or instead of Tuner D the ASI input signal) are
available.
The status menu informs whether the tuners A…D are "locked"/"not locked" to
an input signal, if stations are selected in the station filter:
DVB-S =>
A–cD
DVB-CT
V 5
In this example …
… no station from tuner B is selected (indication "–"),
… stations from tuners A and D are selected and have reception (capitals),
… a station from tuner C is selected but reception is disturbed (lower case).
—> If the ASI input is selected instead of tuner D, its state is displayed
accordingly.
The output signal (new transponder) can be fit in a gap of the DVB-C/T range.

- 9 - SMCIP 402 C/T
3 assembly
3.1 insta l l i ng t h e d eviCe
– Ensure the device is mounted so it will not be able to vibrate. Avoid, for
example, mounting the device onto a lift shaft or any other wall or floor
construction that vibrates in a similar way.
• Position the device so that the distance on the left side, below and above is
minimum 20 cm.
• Fasten the device at the slots 1.
175 mm
300 mm
216 mm 227 mm
1
—> Use mounting material suitable for the wall properties.

- 10 - SMCIP 402 C/T
3.2 dev i C e ove rvi e w
6
7
9
! 0
21
1 1
1
4 3 5
8
1 Assembling slots 2 PE connection terminal
3 Display 4 Display contrast control
5 Control buttons 6 Slot for CA module
7 Micro USB socket (update) 8 SAT tuner inputs A…D
9 RF output 0 ASI input
! ASI output

- 11 - SMCIP 402 C/T
3.3 Conn eC t i n g t h e d eviCe
Potential equalisation (Pe)
Equalise the potential (PE) in accordance with IEC/EN/DIN EN 60728.
• Connect the PE connection terminal 2 to a PE rail (supplied by customer)
using a PE wire (Cu 4 mm2 - 6 mm2).
signal Conn eC ti o ns
• Connect the SAT IF inputs 8 to the outputs of a multiswitch.
• If necessary connect the ASI input 0 and ASI output ! to corresponding
external devices.
—> If you would like to integrate the device to an existing plant, now
first you should connect it to the mains and perform all settings
(page 18). Therefore especially observe the notes on frequency set-
ting (page 17) and level setting (page 17).
—> In this case the new transponder should work at a unused channel.
• If the programming is finished connect the RF output 9 to your antenna
network.
• Connect the device to the mains power supply.

- 12 - SMCIP 402 C/T
3.4 re tr o fit t i n g a Ca m o d ule
The device is equipped with a common interface. It allows you to connect a
CA module for various scrambling systems and service providers. Scrambled
channels can only be descrambled with a CA module suitable for the scram-
bling system and the corresponding smart card. The smart card contains all
the information for authorisation, descrambling and subscription.
Caution
– Any changes made by programme providers to the structures in the pro-
gramme data might impair or even prevent this function.
– When working with the CA module, please read the corresponding operat-
ing manual from the respective provider.
• Insert the smart card into the CA module so that the chip C on the smart
card A faces the thicker side (top) of the CA module B.
• Insert the CA module into the slot D with the top side of the CA module
facing the rear side of the device.
• Push the CA module without canting into the guide rails of the CA slot D
and contact it to the common interface.
CD AB

- 13 - SMCIP 402 C/T
3.5 fi r m war e
fi r mwa r e qu ery
DVB-S =>
– – – –
DVB-CT
V 5
When the device is switched on, the two-line LC dis-
play shows the firmware version.
fi r mwa r e uP date
The firmware of the device can be updated via the micro USB socket using a PC
and the software "BE-Flash". You can find the current firmware, the software "BE-
Flash" and the current assembly instructions on the website "www.mygss.eu".
—> Depending on requirements, the device can be updated with both
the DVB-C and DVB-T firmware.
• Unpack the downloaded ".zip file", which contains the new device firmware
and the "BE-Flash" application.
• Open the device manager of the PC.
• Note down the already existing USB Serial
Ports (e.g. COM3).
• Connect the Micro USB socket via a commer-
cially available USB cable with the PC.
—> Windows installs the necessary driver automatically. This can take sev-
eral minutes. Do not disconnect the USB connection during installation!
• Use the device manager to identify the
COM port, which is assigned to the
SMCIP 402 C/T.
—> In this example – the new added port COM4.

- 14 - SMCIP 402 C/T
• Start the "BE-Flash" application (BEflash.exe) and select the corresponding
interface (COM port).
• Click on button ,
• Select the .hex file you had unpacked before and click on button .
• Click on button .
—> The update progress is displayed.

- 15 - SMCIP 402 C/T
• Close the "BE-Flash" application.
• Uninstall the COM port driver from the device manager after the update is
finished successfully!
—> Activate the COM port driver (in this example COM4).
Select in menu Action or via the context menu
the menu item Uninstall.
• Disconnect the USB connection.

- 16 - SMCIP 402 C/T
4 the Control Panel at a glanCe
4.1 Co n t ro l Pa n el
The key pad on the device is used to scroll through the menus step-by-step:
MODE scrolls forward through the menus
BACK scrolls backward through the menus
< / > select parameters/submenus
+ / – set values, initiate actions
MULTI selects presets
S saves all entries
F "function"
4.2 me n u items
Programme the cassette using the buttons on the control unit of the device. The
two-line display of the control unit then shows the menus.
The parameters and functions to be set are underlined.
Select the following main menu items:
– Output mode
– Output – level:
Output channel/frequency
Modulation
– ASI input
– Input:
LNB oscillator frequency, DiSEqC
Input symbol rate
Input frequency
Station selection
– Data rate
– TS/ONID
– CA mode
– CA module
– Factory reset

- 17 - SMCIP 402 C/T
5 Programming
5.1 notes on frequen C y s e t t in g
If you fit in the "new" transponder to an existing antenna plant, you have to
set the output frequency to a unused channel.
—> The output signal is normally transmitted with a bandwidth of 8
MHz. This means that you can only use the channel centre frequen-
cy of the existing channel grid in the range of channels C21…C69
(frequency grid 8 MHz). The CCIR channel grid is 7 MHz in the
range of the lower frequency bands (channels C5 … C12). If 8
MHz signal packages are transmitted in these channel ranges, this
will result in interference (overlapping) and transmission problems.
For programming in these channel ranges and in the frequency rang-
es below them, we recommend starting with frequency 306 MHz
going back in steps of 8 MHz (see frequency table on page 41).
Please note thereby that a few older receivers cannot receive the
channel ranges S21…S41 (306 … 466 MHz).
5.2 notes o n l e ve l s e t ti ng
in Pu t l e ve l o f m u ltiswitC hes at multisatellite reC e P ti on
Note that at multisatellite reception the input levels at the multiswitch inputs are
the same.
out P u t l e v el o f t h e d eviCe
Equalize the output level of the device (menu "OUTPUT") to the levels of the
other transponders, in order not to overdrive downstreamed multiswitches/
amplifiers.

- 18 - SMCIP 402 C/T
5.3 Pr og r a m m i n g P ro C ed ure
nur wenn Tuner gewählt ist / only if tuner is selected
OVER
DATARATE
28 / 50.8 OVER
DATARATE
28 / 31.6
aktuell benötigt/max.
current needed/max.
OVER = Overflow
* = verschlüsselt/scrambled
Sender wählen / select station
–/+/X (aus/ein/entschlüsseln)
–/+/X (off/on/descramble)
0x0001
TS/ONID
0x0100
Tuner
A / B / C / D
ASI D
Data –> CA
204/188 Bit
2200…20000MHz
MULTI: 10600/9750
1000…56000ksymb/s
MULTI: 22000/27500
MULTI: alle ein/aus
MULTI: all on/off
DVB-S =>
abcd
DVB-CT
V 5
A
B
Ein / On
DVB-CT
– 3 dB
OUTPUT
=>
FREQ
850.00 MHz
DVB-C
C68
MODE
256 POS
DVB-C
6900 QAM
PID Check Vid
CA
=>
DVB-S
Tuner A
INPUT
OK =>
LNB
–––Hl
A
9750 MHz
SYMBOL
8PSK 2/3
A
22000
FREQ
CN 9
A
11244 +0.7
01/14A TV * +
ORF Sport+
ABCD = Signal
0 … -31 dB
nur mit CA-Modul/
onlywith CA module
*) Die angezeigte Information ist abhängig
vom verwendeten CA-Modul.
The information displayed is dependent
on the CA module used.
01/05
Information *)
MENU
off / Vid / All
INPUT
off
ASI
off / => D
188
CA-MODE
STORE
S => STORE
MEMORY
B
Einstellung speichern
store factory defaults
1000…7500
4…256
POS/ NEG
S21…S41,
C21…C69
42…860 MHz
A
Defaults
FACTORY
=> STORE
FACTORY
=> S
Werkeinstellung
aufrufen
invoke factory defaults
Bedienhinweise
"blättert" Menüs vorwärts
"blättert" Menüs rückwärts
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein
speichert alle Eingaben
wählt Presets
spezielle Funktionen
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu
scrolls backward through the menu
select the enter position
selects a submenu
set values and triggers actions
saves all entries
selects presets
special functions
1 shows the enter position
A
9750 MHz
LNB
S01Hl
Beispiel: S01Hl bedeutet
DiSEqC (S) -Position 1 (01),
Horizontal (H) low (l)
Example: S01Hl means
DiSEqC (S) position 1 (01),
horizontal (H) low (l)
off / _ _ _
h / l (high / low)
H / V (horizontal / vertical)
TA / TB (Tonburst Satellit AB/
sound burst satellite AB)
S01…16 Satellit (DiSEqC-Position)/
satellite (DiSEqC position)
FREQ
850.00 MHz
DVB-T
C68
MODE
POS
DVB-T
8MHZ QAM64
5…8MHz
QPSK/QAM16/QAM64
POS/ NEG
C05…C69
42…860 MHz
MODE
G1/32
DVB-T
2k C7/8
C1/2,2/3,3/4,5/6,7/8
G1/4,1/8,1/16,1/32
TPS
off
DVB-T
CELL 0x0000
off/on
DVB-C-Version/
DVB-C version
DVB-T-Version/
DVB-T version
nur wenn RF + ASI gewählt ist / only if RF + ASI is selected
OUTPUT
RF + ASI
ASI (108MBit)
Page 19
Page 19

- 19 - SMCIP 402 C/T
nur wenn Tuner gewählt ist / only if tuner is selected
OVER
DATARATE
28 / 50.8 OVER
DATARATE
28 / 31.6
aktuell benötigt/max.
current needed/max.
OVER = Overflow
* = verschlüsselt/scrambled
Sender wählen / select station
–/+/X (aus/ein/entschlüsseln)
–/+/X (off/on/descramble)
0x0001
TS/ONID
0x0100
Tuner
A / B / C / D
ASI D
Data –> CA
204/188 Bit
2200…20000MHz
MULTI: 10600/9750
1000…56000ksymb/s
MULTI: 22000/27500
MULTI: alle ein/aus
MULTI: all on/off
DVB-S =>
abcd
DVB-CT
V 5
A
B
Ein / On
DVB-CT
– 3 dB
OUTPUT
=>
FREQ
850.00 MHz
DVB-C
C68
MODE
256 POS
DVB-C
6900 QAM
PID Check Vid
CA
=>
DVB-S
Tuner A
INPUT
OK =>
LNB
–––Hl
A
9750 MHz
SYMBOL
8PSK 2/3
A
22000
FREQ
CN 9
A
11244 +0.7
01/14A TV * +
ORF Sport+
ABCD = Signal
0 … -31 dB
nur mit CA-Modul/
onlywith CA module
*) Die angezeigte Information ist abhängig
vom verwendeten CA-Modul.
The information displayed is dependent
on the CA module used.
01/05
Information *)
MENU
off / Vid / All
INPUT
off
ASI
off / => D
188
CA-MODE
STORE
S => STORE
MEMORY
B
Einstellung speichern
store factory defaults
1000…7500
4…256
POS/ NEG
S21…S41,
C21…C69
42…860 MHz
A
Defaults
FACTORY
=> STORE
FACTORY
=> S
Werkeinstellung
aufrufen
invoke factory defaults
Bedienhinweise
"blättert" Menüs vorwärts
"blättert" Menüs rückwärts
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein
speichert alle Eingaben
wählt Presets
spezielle Funktionen
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu
scrolls backward through the menu
select the enter position
selects a submenu
set values and triggers actions
saves all entries
selects presets
special functions
1 shows the enter position
A
9750 MHz
LNB
S01Hl
Beispiel: S01Hl bedeutet
DiSEqC (S) -Position 1 (01),
Horizontal (H) low (l)
Example: S01Hl means
DiSEqC (S) position 1 (01),
horizontal (H) low (l)
off / _ _ _
h / l (high / low)
H / V (horizontal / vertical)
TA / TB (Tonburst Satellit AB/
sound burst satellite AB)
S01…16 Satellit (DiSEqC-Position)/
satellite (DiSEqC position)
FREQ
850.00 MHz
DVB-T
C68
MODE
POS
DVB-T
8MHZ QAM64
5…8MHz
QPSK/QAM16/QAM64
POS/ NEG
C05…C69
42…860 MHz
MODE
G1/32
DVB-T
2k C7/8
C1/2,2/3,3/4,5/6,7/8
G1/4,1/8,1/16,1/32
TPS
off
DVB-T
CELL 0x0000
off/on
DVB-C-Version/
DVB-C version
DVB-T-Version/
DVB-T version
nur wenn RF + ASI gewählt ist / only if RF + ASI is selected
OUTPUT
RF + ASI
ASI (108MBit)
Page 18
Page 18
5.4 Pro gr a m m i ng the C a ss e t te
—> Pressing the MODE button for longer than 2 seconds cancels the
programming procedure. This takes you back to the "Status menu"
from any menu. Any entries that have not been saved are reset to
the previous settings.
—> Entries in the menus can be saved by pressing the S key. You are
taken back to the "Selecting the cassette" menu item.
—> The cursor position for settings is shown by "_".
• Switch on the device (connect the mains plug to a mains socket).

- 20 - SMCIP 402 C/T
status me n u
The status menu informs about…
– the device version DVB-S =>
– – – –
DVB-C
V 5
DVB-S =>
– – – –
DVB-T
V 5
SMCIP 402 C SMCIP 402 T
– the software version DVB-S =>
– – – –
DVB-CT
V 5
(e.g. V 5) as well as
– the input signales.
By default no stations are selected in menu station selection –> indication
"– – – –". If stations are selected in menu station selection, it is displayed
whether the tuners A…D are "locked"/"not locked" to an input signal:
DVB-S =>
A–cD
DVB-CT
V 5
—> In this example …
… no station from tuner B is selected (indication "–"),
… stations from tuners A and D are selected and have reception,
… a station from tuner C is selected but reception is disturbed.
Input signal locked => capitals
Input signal not locked => lower case
—> If the ASI input is selected instead of tuner D, its state is displayed
accordingly.
If output mode "ASI" is selected (modulator off), you get e.g. the following
indication:
DVB-S =>
A – – –
ASI
V 5
If "=> OUTPUT" is selected in menu ASI input selection (transparent mode,
page 31), you get e.g. the following indication:
ASI =>
– – – D
DVB-CT
V 5
• Press the MODE button.
