Grundig DSR 1510 User manual

ǵ
DIGITAL
SATELLITE
RECEIVER
DSR 1510
DEUTSCH
ENGLISH

2
CONTENTS____________________________________________
4 General information
4 Packing contents
4 Digital satellite reception
5 Special features of your digital receiver
6 Set-up and safety
7-9 Overview
7 The front of the digital receiver
8 The back of the digital receiver
9 The remote control
10-11 Connection and preparation
10 Connecting the satellite antenna
10 Connecting the television
10 Connecting a video recorder
11 Connecting an AV receiver or hi-fi system
11 Connecting a digital multi-channel amplifier
11 Connecting the power cord
11 Inserting batteries in the remote control
12-21 Settings
12 The menu
13 Assigning preset stations
14 Editing the station list
15 Editing the list of favourite stations
16 Setting the local time
17-18 Adjusting the digital receiver to the television set
19 Adjusting the digital receiver to the LNB configuration of the satellite antenna
20-21 Audio settings
22-24 Basic functions
22 Switching on and off
22 Mode selection
22 Selecting preset channels
22 Adjusting the volume
23 Muting the sound
23 Selecting stations from lists
23 Switching from the current station to the previous one
24 TV Guide
24 Subtitles
25-26 Teletext mode
25 Teletext
25-26 Additional functions

ENGLISH
3
CONTENTS _________________________________________________
27-31 Additional functions
27 Setting the menu language
27 Deleting stations automatically
28 Preset satellite stations
28 Automatic station search
29 Manual station search
30-31 Timer functions
32-33 Special settings
32 Resetting the digital receiver to its original state
32 Updating the digital receiver software
33 Selecting the remote control level
34-36 Information
34 Displaying station reception properties
34 Displaying device information
34 Connecting the digital receiver to a PC
35 Technical data
35 Environmental note
36 Troubleshooting

4
Packing contents
1DSR 1510 Digital Satellite Receiver
2Tele Pilot 766 S remote control
3Two batteries for the remote control (2 x 1.5 V, Mignon, e.g.
UM-3 or AA)
4Euro/AV (Scart) cable
5Power cord
6Operating manual
Digital satellite reception
In order to use your new DSR 1510 digital receiver you need a
digital-compatible satellite antenna, which must be installed and
aligned to the required satellites (for example Astra and
EutelSat/Hotbird).
Unlike analogue satellite broadcasting, digital TV or radio stations
are not all assigned their own frequencies; instead, several TV
and/or radio are “transmitted” by a single transponder.
To help you with the choice and settings for satellite stations, a selec-
tion of TV and radio stations have already been programmed for
you. So that all the satellite stations that have since gone on air are
available to you, you can start a station search.
To find out how it works and what you have to do, read page 26 of
this manual.
Of course, you can easily program “new” stations yourself. You can
find the latest transponder information on the teletext pages of
various broadcasters, in a current satellite TV magazine or on the
internet.
GENERAL INFORMATION__________________

ENGLISH
5
Special features of your digital receiver
The DSR 1510 digital receiver can receive and process all unen-
crypted digital satellite stations.
This digital receiver has a built-in digital receiver unit for satellite
stations. The receiver unit converts the signals from digital satellite
stations to provide outstanding audio and picture quality.
To ensure that your digital receiver always uses the latest station
information and operating software, you must first perform an
update.
Using the Astra 19.2° East satellite, you can update the device soft-
ware of the satellite receiver.
To find out how it works and what you have to do, read page 32 of
this manual.
The TV guide also tells you of any schedule changes at short notice,
and provides an overview of all the stations’ schedules for the next
few hours.
You can call up detailed information on each TV programme at the
touch of a button.
This digital receiver has a very comprehensive, user-friendly menu
system.
The menu is displayed on the television screen, and the functions of
the remote control buttons are explained.
GENERAL INFORMATION______________________________

6
SET-UP AND SAFETY___________________________
To ensure that that this high quality, easy-to-use digital receiver
gives you lasting entertainment and enjoyment, please note the
following information.
This digital receiver is designed to receive, record and play back
video and audio signals. Any other use is expressly prohibited.
When setting up the digital receiver, make sure it is in a horizontal
position and that the mains socket is easily accessible.
Please note when setting up the digital receiver that furniture sur-
faces are coated with various types of paint and plastic, which often
contain chemical additives. These additives may cause corrosion to
the feet of the unit. This may leave stains on the surface of the
furniture which can be difficult or impossible to remove.
If the digital receiver is subject to a sudden change in temperature,
for example when brought in from the cold to a warm room, let
it stand for at least two hours before you connect it to the mains
supply.
Do not expose the digital receiver to any moisture.
The digital receiver is designed for use in dry rooms. If you do use it
outdoors, please ensure that it is protected from moisture, such as
rain or splashing water. Do not place any vessels such as vases on
the digital receiver. These may be knocked over and spill fluid on
the electrical components, thus presenting a safety risk.
Do not place the digital receiver close to heating units or in direct
sunlight, as this will impair cooling. Place the digital receiver on a
hard, level surface. Do not lay any objects such as magazines on
the digital receiver. When placed in a cabinet, make sure there is a
minimum space of 10 cm around it.
Thunderstorms are a danger to all electrical devices. Even if the
digital receiver player is switched off, it can be damaged by a
lightning strike to the mains or the antenna.
Always disconnect the mains and antenna plugs during a storm.
Never open the digital receiver casing under any circumstances.
Warranty claims are excluded for damage resulting from improper
handling.
Note:
Do not connect any other equipment while the device is switched
on. Switch off the other equipment as well before connecting it.
Only plug the device into the mains socket after you have connected
the external devices and the antenna.
°C2h
°C
DSR1510DIGITAL SATELLITE RECEIVER
DSR1510 DIGITAL SATELLITE RECEIVER
DSR1510 DIGITAL SATELLITE RECEIVER
Krieg im Balkan
DSR1510 DIGITAL SATELLITE RECEIVER

ENGLISH
7
The front of the digital receiver
ǼSwitches the digital receiver to standby mode and off again.
•(red) Lights up: The digital receiver is in standby mode.
Flashes: No input signal.
OVERVIEW____________________________________________
DSR1510 DIGITAL SATELLITE RECEIVER

8
OVERVIEW_________________________________________________
The back of the digital receiver
INPUT SAT Antenna socket for the satellite antenna.
AUDIO OUT Left/right stereo sockets (cinch) for hi-fi system.
L R
VIDEO OUT Video signal output socket (FBAS) for television
or AV receiver.
DIGITAL Audio output sockets for digital audio signal (cinch)
AUDIO OUT for digital multi-channel amplifier.
EURO AV 2 ɮVCR Euro AV socket (input and output) for the video
recorder.
EURO AV 1 ɮTV Euro-AV (output) socket for the television.
RS 232 Serial interface for connecting to a PC.
230-240V
~ Connection socket for the power cord supplied.
50/60 Hz 12 W
Note:
The model designation can be found on the back
of the digital receiver.

ENGLISH
9
OVERVIEW ________________________________________________
The remote control
ǼSwitches the digital receiver to standby, and from
standby to the channel last selected.
ECalls up the device connections menu.
?Displays programme information.
1 ... 0 Select stations.
dSwitches the sound to mute and on again.
iOpens the main menu.
zSwitches between the two most recently selected
channels.
ǸAdjust the volume.
Ƿ
P+ Switch channels up and down
P- one by one.
OK Opens the station list.
TXT Switches between teletext and TV modes.
TV-G Calls up the TV guide.
TV Switches to TV mode.
RADIO Switches to radio mode.
ȄOpens the »Record timer« menu.
ǷǷOpens the »Subtitles« menu.
FOpens the »Sound« menu.
DR, TV Switches to operating a second GRUNDIG
DVD digital receiver, GRUNDIG television or
GRUNDIG DVD player.
Keep the appropriate button (»DR«, »TV«, »DVD«)
pressed down. Then press the required button.
Note:
The functions available depend on the model of the
device you are using.
Just try it out.
Tele Pilot 766 S
DR DVD
TV
z
TXT
PIP
A/B
MHP
d
TV-G
Radio
TV

10
Connecting the satellite antenna
1Connect the antenna cable of the satellite antenna to the »INPUT SAT«
socket on the digital receiver (screw connector, F connector).
Connecting the television
1Plug the Euro-AV (Scart) cable supplied into the »EURO AV1 ɮTV«
socket on the digital receiver and the corresponding Euro-AV socket
(e.g. EURO-AV, SCART) on the television.
Connecting a video recorder
1Plug a standard Euro-AV (Scart) cable into the »EURO AV2 ɮVCR«
socket on the digital receiver and the Euro-AV socket (e.g. EURO-AV,
LINE IN/OUT, EXT.1) on the video recorder.
Note:
When playing back a video recording, the video and audio signal from
the video recorder is automatically looped through to the television via
the »EURO AV1 ɮTV« socket on the digital receiver.
It may not be switched off by the power switch.
CONNECTION AND PREPARATION__
7
12
SAT
R
L
AV1
AV2
ń
R
L
AUDIO
R
L
I
N
O
U
T
DEC. - AV 2
EURO - AV 1

ENGLISH
11
Connecting an AV receiver or hi-fi system
1Plug a standard cinch cable into the »VIDEO OUT« and
»AUDIO OUT L R« sockets (left/right) on the digital receiver and the
corresponding input sockets on the AV receiver or hi-fi system.
Connecting a digital multi-channel amplifier
1Plug a standard cinch cable into the »DIGITAL AUDIO OUT« socket
on the digital receiver and the corresponding socket on the digital multi-
channel amplifier.
Connecting the power cord
1Plug the power cord supplied into the »230-240V~ 50/60Hz«
socket on the digital receiver.
2Plug the power cord into the wall socket.
Note:
Only plug the device into the mains socket after you have
connected the external devices and the antenna.
Inserting batteries in the remote control
1Open the battery compartment by removing the lid.
2Insert the batteries (Mignon type, for example UM-3 or AA, 2 x 1.5 V).
Observe the polarity (marked on the base of the battery compartment).
3Close the battery compartment.
Note:
If the digital receiver no longer reacts properly to remote control com-
mands, the batteries may be flat. Be sure to remove used batteries.
The manufacturer accepts no liability for damage resulting from leaking
batteries.
Environmental note
Batteries, including those which contain no heavy metal, may not be
disposed of with household waste. Please dispose of used batteries in an
environmentally sound manner. Find out about the legal regulations
which apply in your area.
CONNECTION AND PREPARATION_________________

12
The menu
This digital receiver has a very comprehensive, user-friendly menu
system. The menu is displayed on the television screen.
The digital receiver responds to many functions which you select on
the remote control with informative menus and icons on the tele-
vision screen.
It enables you to select many different settings and contains infor-
mation on using your digital receiver.
The buttons on the remote control for using the menu are explained
on the screen.
The main menu contains the most important controls for your digital
receiver. Its menu system controls the dialogue between you and the
digital receiver.
Press »i« to open the main menu. Press »P-« or »P+« to navigate
the menu and select items. The selected item is highlighted.
When you press »OK« to confirm your selection, a sub-menu
appears. Here too, you can navigate by pressing »P-« or »P+«
and select the item you want. The selected item is highlighted.
Press »OK« to confirm. Normally another menu then appears,
where you can use »P-« or »P+« to navigate and make the setting.
Make settings using »P-«, »P+«, »Ǹ« or »Ƿ«.
Press »z« to quit the current menu level.
Press »i« to quit the menu entirely.
SETTINGS ______________________________________________
Main Menu
Select Back Exit
and open
Settings
Channel lists
Program information
Timer
Installation
ǵ

ENGLISH
13
Assigning preset stations
The digital receiver is already programmed with the stations from
the Astra 19.2° East, Eutelsat/Hot Bird 13° East , Turksat 1C, Sirius
2/3, Amos and Hellas Sat 2 satellites.
The following settings allow you to select the menu language, the
country where you are operating the digital receiver and the main
satellites.
Selected stations from the chosen satellites are transferred to the list
of favourites. You can then sort the stations in the order you require.
1Switch on the digital receiver by pressing »Ǽ« on the receiver.
– The »Language« menu appears when the device is first
switched on.
2Select your language using »P-« or »P+« and press »OK« to
confirm.
– The »Country« menu appears.
3Press »P-« or »P+« to select the country and press »OK« to
confirm.
– The »Satellite« menu appears.
4Select the main satellites with »P-« or »P+« and press »OK« to
confirm.
– The stations are added to the station list.
– The stations of the other satellites are added to the station list
after you set the main satellite.
– After the data is transferred, the receiver switches to preset
station 1.
– You can change the order of the preset stations as required
and delete stations you do not need (see the section on editing
the station list on page 14).
SETTINGS _________________________________________________
Country
Select Back
and confirm
Germany Switzerland
Austria Poland
Spain
Italy
Menüsprache
Auswählen
und bestätigen
Deutsch Español
English Suomi
Svenska
Polski
Français
Italiano
ǵ
Satellite
Select Back
and confirm
Astra 19.2
Hot Bird
Turksat 1C
Hellas Sat 2
Sirius 2/3
Amos 1

14
SETTINGS _________________________________________________
Editing the station list
You can change the order of preset stations as required and delete
stations you do not need.
1In the main menu, select »Channel lists« with »P+« or »P-«
and press »OK« to confirm.
2Select »Channel list« by pressing »OK«.
– The station list appears.
Deleting stations
1Press »P-« or »P+« to select the station to delete and press
»OK« to confirm.
– The station is highlighted in orange.
2Select the next station with »P-« or »P+« and press »OK« to
confirm.
3Press »z« to delete the stations.
– The highlighted stations are deleted.
Moving stations
1Press »P-« or »P+« to select the station to move and press
»OK« to confirm.
– The station is highlighted in orange.
2Select the next station with »P-« or »P+« and press »OK« to
confirm.
3Press »P-« or »P+« to select the channel in front of which the
station is to be inserted.
4Press »ǷǷ« to move the stations.
Ending the settings
1Press »i« and then »OK« to save the settings.
Edit Channel Lists
Select Back Exit
and open
Channel list
Favorites
Edit Channel Lists
Astra 19.2
1 Sat 1
2 ProSieben
3 KABEL1
4 NEUN LIVE Telev
5 DSF
6 HSE24
7SAT.1
8 N24
9 TELE 5
10 Das Erste
Select Back Exit
and mark Delete Move

ENGLISH
15
Editing the list of favourite stations
You can change the order of preset stations as required and delete
stations you do not need.
You can select your favourite stations and save them in the list of
favourites.
1In the main menu, select »Channel lists« with »P+« or »P-«
and press »OK« to confirm.
2Select »Favorites« with »P+« or »P-« and press »OK« to con-
firm.
– The »Edit Favorites« page appears.
3Press »P-« or »P+« to select the station to move and press
»OK« to confirm.
– The station is highlighted in orange.
4Select the next station with »P-« or »P+« and press »OK« to
confirm.
5To move the stations, press »A/B« and then press »OK« or
»ǷǷ« to confirm.
– You can switch between the station list and your favourites by
pressing »A/B«.
– You can store up to 100 stations in the favourites list.
– You can change the order of the stations or delete ones you
do not need (see the section on editing the station list).
Note:
If you delete a station from the station list, it is also deleted from
your favourites.
6Press »i« and then »OK« to save the settings.
Note:
If the favorite channels number is over 100, no more can be
add to the Favorites list. You need to delete some of the chan-
nels.
SETTINGS _________________________________________________
Edit Channel Lists
Select Back Exit
and open
Channel list
Favorites
Edit Favorites
Select Back Exit
and mark A<->B Move
Delete
A: Channel lists
1 Sat 1
2 ProSieben
3 KABEL1
4 NEUN LIVE Telev
5 DSF
6 HSE24
7SAT.1
8 N24
9 TELE 5
B: Favorites
1 Sat 1
A/B

16
Setting the local time
To ensure that the TV guide always shows the current programmes
at the right time, you must enter the difference between your local
time and GMT (Greenwich Mean Time at longitude “0”).
All times given by the TV guide are then converted to your local
time.
With clock changes (e.g. daylight saving time), you need to correct
the time difference.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Time« with »P-« or »P+« and press »OK« to confirm.
3Select »Time Zone« with »OK« and then use »P-« or »P+« to
enter the time difference in 30 minute increments.
Note:
The »Current time« item is for information only and cannot be
selected.
4Select »Daylight saving time« with »P-« or »P+« and press
»OK« to confirm.
5Press »P-« or »P+« to select »Off« (winter time) or »On«
(summer time).
6Press »OK« to confirm the setting.
7Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Installation
Select Back Exit
and open
Menu language
Channel search
Video output
Time
Antenna connection
Special functions
Info
Time
Select Back Exit
and open
Current time 08:05 h
+1.00 h
On
Time Zone
Daylight saving time

ENGLISH
17
Adjusting the digital receiver to the television set
Specifying the video signal at the Euro AV (TV)
output
You can choose between the settings »CVBS« (normal picture
quality), »RGB« (high picture quality) »Y/C« (S-Video signal) and
»YUV« (component signal). The default setting is »RGB«.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »Signal type« by pressing »OK«.
4Press »P-« or »P+« to select the setting and press »OK« to
confirm.
5Press »i« and then »OK« to save the settings.
Selecting the television picture format
If you have a 4:3 format television or flat screen, select the »4:3«
setting.
If you have a 16:9 format television or flat screen, select the »16:9«
setting.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »TV format« by pressing »P-« or »P+« and press »OK«
to confirm.
4Press »P-« or »P+« to select the picture format and press
»OK« to confirm.
Note:
If picture format 4:3 is selected, you can also select picture
conversion.
5Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Installation
Select Back Exit
and open
Menu language
Channel search
Video output
Time
Antenna connection
Special functions
Info
Video output
Select Back Exit
and open
TV format
Signal type RGB
4:3
Letterbox
❙
■■
■■❙
■■■■■■ ❙
Picture conversion
OSD Transparency
Video output
Select Back
and confirm
RGB
16:9
❙
■■
■■❙
■■■■■■ ❙
Signal type 4:3
16:9
TV format
OSD Transparency

18
Selecting the television picture conversion
If you have a 4:3 format television or flat screen, the following
settings are available:
»Pan&Scan« for wide-screen playback without black bars on the
top and bottom edges of the screen.
»Letterbox« for wide-screen playback with black bars on the top
and bottom edges of the screen.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »Picture conversion« with »P-« or »P+« and then press
»OK«.
4Press »P-« or »P+« to select the conversion and press »OK« to
confirm.
5Press »i« and then »OK« to save the settings.
Selecting the transparency of the OSD
You can adjust the transparency of the OSD menu.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »OSD Transparency« with »P-« or »P+« and then press
»OK«.
4Press »P-« or »P+« to select the transparency and press »OK«
to confirm.
5Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Video output
Select Back
and confirm
RGB
4:3
❙
■■
■■❙
■■■■■■ ❙
Signal type
Letterbox
Pan&Scan
TV format
Picture conversion
OSD Transparency
Video output
Modify Back
and confirm
TV format
Signal type RGB
16:9
❙
■■
■■❙
■■■■■■ ❙
OSD Transparency

ENGLISH
19
Adjusting the digital receiver to the
LNB configuration of the satellite antenna
The digital receiver has been factory set so that it is ready for
operation, without time-consuming adjustment, with most satellite
antennas and LNB configurations.
Changes in this menu have a direct effect on the reception charac-
teristics of the digital receiver and should therefore only be made by
an expert.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Antenna connection« with »P-« or »P+« and press
»OK« to confirm.
3Select the item with »P-« or »P+« and press »Ǹ«, »Ƿ« or
»1 ... 0« to make the setting:
– »LNB«: For selecting the satellites.
– »LNB supply«: For switching the LNB power supply on
and off.
– »Low band«: To set the oscillator frequency for the
Low band, select this item and press
»OK« to confirm. Enter the required
value using »1 ... 0«.
– »High band«: To set the oscillator frequency for the
High band, select this item and press
»OK« to confirm. Enter the required
value using »1 ... 0«.
– »DiSEqC«: If you want to receive up to four satel-
lites simultaneously, each LNB must be
assigned to its input on the DiSEqC
switch.
– »Tone burst«: If you want to receive two satellites at
the same time, each LNB is assigned to
its input on the tone burst switch.
4Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Antenna connection
Select Back Exit
and open
LNB
LNB supply
Low band
High band
DiSEqC
Tone burst
1 Astra 19.2
On
9.750 GHz
10.600 GHz
A
A
Installation
Select Back Exit
and open
Menu language
Channel search
Video output
Time
Antenna connection
Special functions
Info

20
Audio settings
1In the main menu, select »Settings« with »P-« or »P+« and
press »OK« to confirm.
2Select »Audio« by pressing »OK«.
– The »Audio settings« menu appears.
Note:
Further operation is explained in the following sections.
Changing the audio channel of the television
With stations broadcasting in several languages you can select a
different language and digital sound (AC-3). The choice of audio
depends on the station and the current programme.
In radio mode, you can switch to other programmes.
1Select »Audio channel« with »P-« or »P+« and then press
»OK«.
2Press »P-« or »P+« to select the setting and press »OK« to
confirm.
Notes:
If you select digital sound (AC-3) for the audio channel, you
can no longer select »Audio output« and »Volume adjustment«.
Digital sound (AC-3) can only be played through an external
receiver or amplifier.
»Digital output« shows you the selected audio format at the
digital output, and cannot be selected.
Sound settings
Here you can select the audio mode, such as stereo, mono (left) and
mono (right).
1Select »Audio output« by pressing »P-« or »P+« and press
»OK« to confirm.
2Press »P-« or »P+« to select the setting and press »OK« to
confirm.
SETTINGS _________________________________________________
Audio settings
Select Back Exit
and open
Audio channel
Audio output
Volume adjustment
Digital output
English
Stereo
❙
■■❙ ■■■■■■ ❙
PCM Format
Audio settings
Select Back
and confirm
Volume adjustment
English
Deutsch
❙
■■❙ ■■■■■■ ❙
PCM Format
Stereo
Mono (Left)
Mono (Right)
Audio output
Digital output
Audio channel
Audio settings
Select Back Exit
and open
Audio channel
Audio output
Volume adjustment
Digital output
English
Stereo
❙
■■❙ ■■■■■■ ❙
PCM Format
