Grundig DSR 3410 CI User manual

ǵ
DIGITAL
SATELLITE
RECEIVER
DSR 3410 CI
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO

2
CONTENTS____________________________________________
4 General information
4 Packing contents
4 GRUNDIG accessories for satellite receivers
4 Digital satellite reception
5 Special features of your digital receiver
5 What is Common Interface?
6 Set-up and safety
7-9 Overview
7 The front of the digital receiver
8 The back of the digital receiver
9 The remote control
10-11 Connection and preparation
10 Connecting the satellite antenna
10 Connecting the television
10 Connecting a video recorder
11 Connecting a hi-fi system
11 Connecting a digital multi-channel amplifier
11 Connecting the power cord
11 Inserting batteries in the remote control
12-21 Settings
12 The menu
13 Assigning preset stations
14 Editing the station list
15 Editing the list of favourite stations
16 Setting the local time
17-18 Adjusting the digital receiver to the television set
18 Encrypted satellite reception
19 Adjusting the digital receiver to the LNB configuration of the satellite antenna
20-21 Audio settings
22-24 Basic functions
22 Switching on and off
22 Mode selection
22 Selecting preset channels
22 Adjusting the volume
23 Muting the sound
23 Selecting stations from lists
23 Switching from the current station to the previous one
24 TV Guide
24 Subtitles
25-30 Additional functions
25 Setting the menu language
25 Deleting stations automatically
26 Preset satellite stations
26 Automatic station search
27 Manual station search
28 Selecting the video channel
29-30 Timer functions

ENGLISH
3
CONTENTS _________________________________________________
31 Special settings
31 Resetting the digital receiver to its original state
31 Updating the digital receiver software
32-34 Information
32 Displaying station reception properties
32 Displaying device information
32 Connecting the digital receiver to a PC
33 Technical data
34 Troubleshooting

4
Packing contents
1DSR 3410 CI Digital Satellite Receiver
2Tele Pilot 765 S remote control
3Two batteries for the remote control (2 x 1.5 V, Mignon, e.g.
UM-3 or AA)
4Euro/AV (Scart) cable
5Power cord
6Operating manual
GRUNDIG accessories for satellite receivers
Your specialist dealer will be happy to tell you about the compre-
hensive range of GRUNDIG accessories for satellite receivers.
Digital satellite reception
In order to use your new DSR 3410 CI digital receiver you need a
digital-compatible satellite antenna, which must be installed and
aligned to the required satellites (for example Astra and
EutelSat/Hotbird).
Unlike analogue satellite broadcasting, digital TV or radio stations
are not all assigned their own frequencies; instead, several TV
and/or radio are “transmitted” by a single transponder.
To help you with the choice and settings for satellite stations, a selec-
tion of TV and radio stations have already been programmed for
you. So that all the satellite stations that have since gone on air are
available to you, you can start a station search.
To find out how it works and what you have to do, read page 26 of
this manual.
Of course, you can easily program “new” stations yourself. You can
find the latest transponder information on the teletext pages of
various broadcasters, in a current satellite TV magazine or on the
internet.
GENERAL INFORMATION__________________

ENGLISH
5
Special features of your digital receiver
The DSR 3410 CI digital receiver can receive and process all unen-
crypted digital satellite stations.
This digital receiver has a built-in digital receiver unit for satellite
stations. The receiver unit converts the signals from digital satellite
stations to provide outstanding audio and picture quality.
To ensure that your digital receiver always uses the latest station
information and operating software, you must first perform an
update.
Using the Astra 19.2° East satellite, you can update the device soft-
ware of the satellite receiver.
To find out how it works and what you have to do, read page 31 of
this manual.
The TV guide also tells you of any schedule changes at short notice,
and provides an overview of all the stations’ schedules for the next
few hours.
You can call up detailed information on each TV programme at the
touch of a button.
This digital receiver has a very comprehensive, user-friendly menu
system.
The menu is displayed on the television screen, and the functions of
the remote control buttons are explained.
What is Common Interface?
Common Interface (CI) is an interface for DVB receivers such as
digital receivers (including set-top boxes).
The digital receiver and CI modules can receive and process all
unencrypted and certain encrypted digital satellite stations.
Encrypted satellite channels can only be viewed with a CI module
suitable for the encryption system and the appropriate smart card.
On the back of the digital receiver there is are two Common Inter-
face slots where CI modules from various providers can be inserted.
You can insert the provider’s smart card into the CI module in order
to enable the encrypted satellite stations you want to see.
To find out how it works and what you have to do, read page 18 of
this manual.
GENERAL INFORMATION______________________________
VID
E
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
PCMCIA SLOT 2
PCMCIA SLOT 1
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz

6
SET-UP AND SAFETY___________________________
To ensure that that this high quality, easy-to-use digital receiver
gives you lasting entertainment and enjoyment, please note the
following information.
This digital receiver is designed to receive, record and play back
video and audio signals. Any other use is expressly prohibited.
When setting up the digital receiver, make sure it is in a horizontal
position and that the mains socket is easily accessible.
Please note when setting up the digital receiver that furniture sur-
faces are coated with various types of paint and plastic, which often
contain chemical additives. These additives may cause corrosion to
the feet of the unit. This may leave stains on the surface of the
furniture which can be difficult or impossible to remove.
If the digital receiver is subject to a sudden change in temperature,
for example when brought in from the cold to a warm room, let
it stand for at least two hours before you connect it to the mains
supply.
Do not expose the digital receiver to any moisture.
The digital receiver is designed for use in dry rooms. If you do use it
outdoors, please ensure that it is protected from moisture, such as
rain or splashing water. Do not place any vessels such as vases on
the digital receiver. These may be knocked over and spill fluid on
the electrical components, thus presenting a safety risk.
Do not place the digital receiver close to heating units or in direct
sunlight, as this will impair cooling. Place the digital receiver on a
hard, level surface. Do not lay any objects such as magazines on
the digital receiver. When placed in a cabinet, make sure there is a
minimum space of 10 cm around it.
Thunderstorms are a danger to all electrical devices. Even if the
digital receiver player is switched off, it can be damaged by a
lightning strike to the mains or the antenna.
Always disconnect the mains and antenna plugs during a storm.
Never open the digital receiver casing under any circumstances.
Warranty claims are excluded for damage resulting from improper
handling.
°C2h
°C
ǵ
ON/OFF
DSR3410 CI DIGITALSATELLITERECEIVER
RADIO
TV
-S
ǵ
ON/OFF
DSR3410 CI DIGITALSATELLITE RECEIVER
RADIO
TV
- S
ǵ
ON/OFF
DSR3410 CI DIGITAL SATELLITE RECEIVER
RADIO
TV
- S
Krieg im Balkan
ǵ
ON/OFF
DSR 3410 CI DIGITAL SATELLITERECEIVER
RADIO
TV
- S
EURO AV1 TV
EURO AV2 VCR
AUDIO OUT
VIDEO OUT
RS 232
L
R
DIGIALAUDIO OUT
DIGIALAUDIO OUT OPTICAL
PCMCIASLOT 2
PCMCIASLOT 1
WITHOUTLNB
230V~ 50 Hz
10W max.
INPUT SAT
950-2150MHz
14/18Vј
max400mA
22kHz

ENGLISH
7
The front of the digital receiver
ON/OFF Switches the digital receiver to standby mode and
Ǽoff again.
•(red) The digital receiver is in standby mode.
•RADIO Lights up in radio mode.
•TV Lights up in TV mode.
iOpens and closes the main menu.
P+, P- Switch channels up and down one by one.
Switch the digital receiver on from standby.
In the menus: move the cursor up/down, select and change
individual entries.
Ǹ, ǷChange the volume.
In the menus: move the cursor left/right, select and change
individual entries.
OK Opens the station list.
In the menus: confirms entries.
OVERVIEW____________________________________________
ǵ
ON/OFF
DSR 3410 CI DIGITAL SATELLITE RECEIVER
RADIO
TV
- S

8
OVERVIEW_________________________________________________
The back of the digital receiver
INPUT SAT Antenna socket for the satellite antenna.
AUDIO OUT Audio output sockets for digital audio signal (cinch)
DIGITAL for digital multi-channel amplifier.
DIGITAL AUDIO Audio output socket for digital audio signal
OUT OPTICAL (optical) for digital multi-channel amplifier.
PCMCIA SLOT 1 Common Interface slots
PCMCIA SLOT 2 for inserting CI modules.
VIDEO OUT Video signal output socket (FBAS) for television
or AV receiver.
AUDIO OUT Left/right stereo sockets (cinch) for hi-fi system.
R L
EURO AV 2 ɮVCR Euro AV socket (input and output) for the video
recorder.
EURO AV 1 ɮTV Euro-AV (output) socket for the television.
RS 232 Serial interface for connecting to a PC.
230 V
~/ 50 Hz Connection socket for the power cord supplied.
10 W max.
Note:
The model designation can be found on the back
of the digital receiver.
EURO AV 1 TV
EURO AV 2 VCR
AUDIO OUT
VIDEO OUT
RS 232
L
R
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
PCMCIA SLOT 2
PCMCIA SLOT 1
WITHOUT LNB
230 V~ 50 Hz
10 W max.
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz

ENGLISH
9
OVERVIEW ________________________________________________
The remote control
ǼSwitches the digital receiver to standby, and from
standby to the channel last selected.
ECalls up the device connections menu.
?Displays programme information.
1 ... 0 Select stations.
dSwitches the sound to mute and on again.
iOpens the main menu.
zSwitches between the two most recently selected
channels.
ǸAdjust the volume.
Ƿ
P+ Switch channels up and down
P- one by one.
Switch the digital receiver from standby to the most
recently selected channel.
OK Opens the station list.
TV-G Calls up the TV guide.
TV Switches to TV mode.
RADIO Switches to radio mode.
zOpens the »Video« menu.
ȄOpens the »Record timer« menu.
ǷǷOpens the »Subtitles« menu.
FOpens the »Sound« menu.
AVR, TV Switches to operating a GRUNDIG AV receiver,
DVD AV receiver, GRUNDIG television or
GRUNDIG DVD player.
Keep the appropriate button (»AVR«, »TV«, »DVD«)
pressed down. Then press the required button.
Note:
The functions available depend on the model of the
device you are using.
Just try it out.
Tele Pilot 765 S
AVR DVD
TV
z
TXT
PIP
A/B
MHP
d
TV-G
Radio
TV

10
Connecting the satellite antenna
1Connect the antenna cable of the satellite antenna to the »INPUT SAT«
socket on the digital receiver (screw connector, F connector).
Connecting the television
1Plug the Euro-AV (Scart) cable supplied into the »EURO AV1 ɮTV«
socket on the digital receiver and the corresponding Euro-AV socket
(e.g. EURO-AV, SCART) on the television.
Connecting a video recorder
1Plug a standard Euro-AV (Scart) cable into the »EURO AV2 ɮVCR«
socket on the digital receiver and the Euro-AV socket (e.g. EURO-AV,
LINE IN/OUT, EXT.1) on the video recorder.
Note:
When playing back a video recording, the video and audio signal from
the video recorder is automatically looped through to the television via
the »EURO AV1 ɮTV« socket on the digital receiver.
The digital receiver must be in standby mode.
It may not be switched off by the power switch.
CONNECTION AND PREPARATION__
7
12
EURO AV 1 TV
EURO AV 2 VCR
AUDIO OUT
VIDEO OUT
RS 232
L
R
O
T 2
O
T 1
EURO AV 1 TV
EURO AV 2 VCR
AUDIO OUT
VIDEO OUT
RS 232
L
R
OT 2
OT 1
EURO AV 1 TV
EURO AV 2 VCR
AUDIO OUT
VIDEO OUT
RS 232
L
R
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
PCMCIA SLOT 2
PCMCIA SLOT 1
WITHOUT LNB
230 V~ 50 Hz
10 W max.
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz
R
L
AV1
AV2
TV R
SAT
ń
R
L
AUDIO
R
L
I
N
O
U
T
DEC. - AV 2
EURO - AV 1

ENGLISH
11
Connecting an AV receiver or hi-fi system
1Plug a standard cinch cable into the »VIDEO OUT« and »AUDIO L R«
sockets (left/right) on the digital receiver and the corresponding input
sockets on the AV receiver or hi-fi system.
Connecting a digital multi-channel amplifier
1Plug a standard cinch cable into the »DIGITAL AUDIO OUT« socket
on the digital receiver and the corresponding socket on the digital
multi-channel amplifier.
or
Plug a standard optical digital cable into the »DIGITAL AUDIO OUT
OPTICAL« socket on the digital receiver and the corresponding socket
on the digital multi-channel amplifier.
Connecting the power cord
1Plug the power cord supplied into the »230V~/50Hz« socket on the
digital receiver.
2Plug the power cord into the wall socket.
Inserting batteries in the remote control
1Open the battery compartment by removing the lid.
2Insert the batteries (Mignon type, for example UM-3 or AA, 2 x 1.5 V).
Observe the polarity (marked on the base of the battery compartment).
3Close the battery compartment.
Note:
If the digital receiver no longer reacts properly to remote control com-
mands, the batteries may be flat. Be sure to remove used batteries.
The manufacturer accepts no liability for damage resulting from leaking
batteries.
Environmental note
Batteries, including those which contain no heavy metal, may not be
disposed of with household waste. Please dispose of used batteries in an
environmentally sound manner. Find out about the legal regulations
which apply in your area.
CONNECTION AND PREPARATION_________________
AUDIO OUT
VIDEO OUT
L
R
C
AL
PCMCIA SLOT 2
PCMCIA SLOT 1
WITHOUT LNB
230 V~ 50 Hz
10 W max.
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
P
P
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
P
P
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz

12
The menu
This digital receiver has a very comprehensive, user-friendly menu
system. The menu is displayed on the television screen.
The digital receiver responds to many functions which you select on
the remote control with informative menus and icons on the tele-
vision screen.
It enables you to select many different settings and contains infor-
mation on using your digital receiver.
The buttons on the remote control for using the menu are explained
on the screen.
The main menu contains the most important controls for your digital
receiver. Its menu system controls the dialogue between you and the
digital receiver.
Press »i« to open the main menu. Press »P-« or »P+« to navigate
the menu and select items. The selected item is highlighted.
When you press »OK« to confirm your selection, a sub-menu
appears. Here too, you can navigate by pressing »P-« or »P+«
and select the item you want. The selected item is highlighted.
Press »OK« to confirm. Normally another menu then appears,
where you can use »P-« or »P+« to navigate and make the setting.
Make settings using »P-«, »P+«, »Ǹ« or »Ƿ«.
Press »z« to quit the current menu level.
Press »i« « to quit the menu entirely.
Note:
In menu mode, you cannot press »Ǽ« to switch the digital receiver
to standby.
SETTINGS ______________________________________________
Main menu
Select Back Exit
and open
Settings
Preset list
Info
Timer
Installation
ǵ

ENGLISH
13
Assigning preset stations
The digital receiver is already programmed with the stations from
the Astra 19.2° East, Eutelsat/Hot Bird 13° East and Turksat 1C
satellites.
The following settings allow you to select the menu language, the
country where you are operating the digital receiver and the main
satellites.
Selected stations from the chosen satellites are transferred to the list
of favourites. You can then sort the stations in the order you require.
1Switch on the digital receiver by pressing »Ǽ« on the receiver.
– The »Language« menu appears when the device is first
switched on.
2Select your language using »P-« or »P+« and press »OK« to
confirm.
– The »Country« menu appears.
3Press »P-« or »P+« to select the country and press »OK« to
confirm.
– The »Satellite« menu appears.
4Select the main satellites with »P-« or »P+« and press »OK« to
confirm.
– The stations are added to the station list.
– The stations of the two other satellites are added to the station
list after you set the main satellite.
– After the data is transferred, the receiver switches to preset
station 1.
– You can change the order of the preset stations as required
and delete stations you do not need (see the section on editing
the station list on page 14).
SETTINGS _________________________________________________
Menüsprache
Auswählen
und aufrufen
Deutsch Türkçe
English Español
Suomi
Polski
Français
Italiano
ǵ
Country
Select Back
and change
Germany Switzerland
Spain Poland
Italy
Austria
Satellite
Select Back
and change
Astra 19.2
Hot Bird
Turksat 1C

14
SETTINGS _________________________________________________
Editing the station list
You can change the order of preset stations as required and delete
stations you do not need.
1In the main menu, select »Preset list« with »P+« or »P-« and
press »OK« to confirm.
2Select »Sort« by pressing »OK«.
– The station list appears.
Deleting stations
1Press »P-« or »P+« to select the station to delete and press
»OK« to confirm.
– The station is highlighted in orange.
2Select the next station with »P-« or »P+« and press »OK« to
confirm.
3Press »z« to delete the stations.
– The highlighted stations are deleted.
Moving stations
1Press »P-« or »P+« to select the station to move and press
»OK« to confirm.
– The station is highlighted in orange.
2Select the next station with »P-« or »P+« and press »OK« to
confirm.
3Press »P-« or »P+« to select the channel in front of which the
station is to be inserted.
4Press »ǷǷ« to move the stations.
Ending the settings
1Press »i« and then »OK« to save the settings.
Preset list
Select Back Exit
and open
Sort
Edit bookmarks
Sort
Astra 19.2
1 Sat 1
2 ProSieben
3 KABEL1
4 NEUN LIVE Telev
5 DSF
6 HSE24
7SAT.1
8 N24
9 TELE 5
10 Das Erste
Select Back Exit
and open Delete Add

ENGLISH
15
Editing the list of favourite stations
You can change the order of preset stations as required and delete
stations you do not need.
You can select your favourite stations and save them in the list of
favourites.
1In the main menu, select »Preset list« with »P+« or »P-« and
press »OK« to confirm.
2Select »Edit bookmarks« with »P+« or »P-« and press »OK«
to confirm.
– The »Edit bookmarks« page appears.
3Press »P-« or »P+« to select the station to move and press
»OK« to confirm.
– The station is highlighted in orange.
4Select the next station with »P-« or »P+« and press »OK« to
confirm.
5To move the stations, press »A/B« and then press »OK« or
»ǷǷ« to confirm.
– You can switch between the station list and your favourites by
pressing »A/B«.
– You can change the order of the stations or delete ones you
do not need (see the section on editing the station list).
Note:
If you delete a station from the station list, it is also deleted from
your favourites.
6Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Preset list
Select Back Exit
and open
Sort
Edit bookmarks
Edit bookmarks
Select Back Exit
and open Delete Add
Change
Preset list
1 Sat 1
2 ProSieben
3 KABEL1
4 NEUN LIVE Telev
5 DSF
6 HSE24
7SAT.1
8 N24
9 TELE 5
Bookmarks
1 Sat 1
A/B

16
Setting the local time
To ensure that the TV guide always shows the current programmes
at the right time, you must enter the difference between your local
time and GMT (Greenwich Mean Time at longitude “0”).
All times given by the TV guide are then converted to your local
time.
With clock changes (e.g. daylight saving time), you need to correct
the time difference.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Time« with »P-« or »P+« and press »OK« to confirm.
3Select »Time difference« with »OK« and then use »P-« or
»P+« to enter the time difference in 30 minute increments.
Note:
The »Current time« item is for information only and cannot be
selected.
4Press »OK« to confirm the setting.
5Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Installation
Select Back Exit
and open
Menu language
Station search
Video output
Time
Antenna connection
Special functions
Info
Time
Select Back Exit
and open Ȅ
Current time 08:05 o’clock
+2.00 Hours
Time difference

ENGLISH
17
Adjusting the digital receiver to the television set
Specifying the video signal at the Euro AV (TV)
output
You can choose between the settings »FBAS« (normal picture
quality), »RGB« (high picture quality) »Y/C« (S-Video signal) and
»YUV« (component signal). The default setting is »RGB«.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »Signal type« by pressing »OK«.
4Press »P-« or »P+« to select the setting and press »OK« to
confirm.
5Press »i« and then »OK« to save the settings.
Selecting the television picture format
If you have a 4:3 format television or flat screen, select the »4:3«
setting.
If you have a 16:9 format television or flat screen, select the »16:9«
setting.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »TV format« by pressing »P-« or »P+« and press »OK«
to confirm.
4Press »P-« or »P+« to select the picture format and press
»OK« to confirm.
Note:
If picture format 4:3 is selected, you can also select picture
conversion.
5Press »i« and then »OK« to save the settings.
SETTINGS _________________________________________________
Installation
Select Back Exit
and open
Menu language
Station search
Video output
Time
Antenna connection
Special functions
Info
Video output
Select Back Exit
and open Ȅ
TV format
Signal type RGB
16:9
Video output
Select Back
and change Ȅ
RGB
16:9
Signal type 4:3
16:9
TV format

18
Selecting the television picture conversion
If you have a 4:3 format television or flat screen, the following
settings are available:
»Pan-Scan« for wide-screen playback without black bars on the top
and bottom edges of the screen.
»Letterbox« for wide-screen playback with black bars on the top
and bottom edges of the screen.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Video output« with »P-« or »P+« and press »OK« to
confirm.
3Select »Picture conversion« with »P-« or »P+« and then press
»OK«.
4Press »P-« or »P+« to select the conversion and press »OK« to
confirm.
5Press »i« and then »OK« to save the settings.
Encrypted satellite reception
This digital receiver has two Common Interface (CI) slots. These
interfaces allow you to connect a CI module for various encryption
systems.
Encrypted satellite channels can only be viewed with a CI module
suitable for the encryption system and the appropriate smart card.
It contains all the functions for authorisation, decryption and sub-
scription for various satellite channels of different providers.
1Insert the CI module into »PCMCIA SLOT 1« or »PCMCIA
SLOT 2«.
Notes:
Push the module carefully into the slot. Do not use force and
make sure the module is straight.
Follow the operating instructions for the CI module.
2In the main menu, select »Installation« with »Ľ« or »Ń« and
press »OK« to confirm.
– A submenu generated by the CI module appears on the
screen.
3Select the submenu of the CI module with »Ľ« or »Ń« and
press »OK« to confirm.
– For more information on using the CI module, see the menus
shown or its instruction manual.
4Press »i« to finish the setting.
SETTINGS _________________________________________________
Video output
Select Back
and change Ȅ
RGB
4:3
Signal type
Letterbox
Pan-Scan
TV format
Picture conversion
VID
E
DIGIAL AUDIO OUT
DIGIAL AUDIO OUT OPTICAL
PCMCIA SLOT 2
PCMCIA SLOT 1
INPUT SAT
950-2150MHz
14/18Vј
max 400mA
22kHz

ENGLISH
19
Adjusting the digital receiver to the
LNB configuration of the satellite antenna
The digital receiver has been factory set so that it is ready for
operation, without time-consuming adjustment, with most satellite
antennas and LNB configurations.
Changes in this menu have a direct effect on the reception charac-
teristics of the digital receiver and should therefore only be made by
an expert.
1In the main menu, select »Installation« with »P-« or »P+« and
press »OK« to confirm.
2Select »Antenna connection« with »P-« or »P+« and press
»OK« to confirm.
3Select the item with »P-« or »P+« and press »Ǹ«, »Ƿ« or
»1 ... 0« to make the setting:
– »LNB«: For selecting the satellites.
– »LNB supply«: For switching the LNB power supply on
and off.
– »LOW band«: To set the oscillator frequency for the
LOW band, select this item and press
»OK« to confirm. Enter the required
value using »1 ... 0«.
– »HIGH band«: To set the oscillator frequency for the
HIGH band, select this item and press
»OK« to confirm. Enter the required
value using »1 ... 0«.
– »DiSEqC switch«: If you want to receive up to four satel-
lites simultaneously, each LNB must be
assigned to its input on the DiSEqC
switch.
– »Tone burst switch«: If you want to receive two satellites at
the same time, each LNB is assigned to
its input on the tone burst switch.
4Press »i« and then »OK« to save the settings.
5Press »i« to finish the setting.
SETTINGS _________________________________________________
Antenna connection
Select Back Exit
and open
LNB
LNB supply
LOW band
HIGH band
DiSEqC switch
Tone burst switch
1 Astra 19.2
On
9.750 GHz
10.600 GHz
A
A
Installation
Select Back Exit
and open
Menu language
Station search
Video output
Time
Antenna connection
Special functions
Info

20
Audio settings
1In the main menu, select »Settings« with »P-« or »P+« and
press »OK« to confirm.
2Select »Sound« by pressing »OK«.
– The »Sound« menu appears.
Note:
Further operation is explained in the following sections.
Changing the audio channel of the television
Here you can find information on the number of audio channels
(i.e. the language of the current TV or radio program). You can
switch to a different language during programs broadcast in
several languages. In radio mode, you can switch to other pro-
grammes.
1Select »Sound channel TV« with »P-« or »P+« and then press
»OK«.
2Press »P-« or »P+« to select the setting and press »OK« to
confirm.
Sound settings
Here you can select the audio mode, such as stereo, mono (left) and
mono (right).
1Select »Sound settings« by pressing »P-« or »P+« and press
»OK« to confirm.
2Press »P-« or »P+« to select the setting and press »OK« to
confirm.
Volume adjustment
You can set the standard volume here. This is the volume of the
device after switching on.
1Select »Volume adjustment« by pressing »P-« or »P+« and
press »OK« to confirm.
2Press »Ǹ« or »Ƿ« to set the level and press »OK« to confirm.
SETTINGS _________________________________________________
Sound
English
Stereo
❙
■■❙ ■■■■■■ ❙
Same as TV
Sound
Select Back Exit
and open
Sound channel TV
Sound settings
Volume adjustment
Sound channel Dig.
English
Stereo
❙
■■❙ ■■■■■■ ❙
Same as TV
Select Back
and change
Sound channel TV
Sound settings
Volume adjustment
Sound channel Dig.
Sound
Sound
Select Back
and change
Volume adjustment
English
Deutsch
❙
■■❙ ■■■■■■ ❙
Same as TV
Stereo
Mono (left)
Mono (right)
Sound settings
Sound channel Dig.
Sound channel TV
Select Back
and change
Sound channel TV
Sound settings
English
Stereo
❙
■■
■■❙
■■■■■■ ❙
Same as TV
Sound channel Dig.
Volume adjustment
