This operating manual contains important instructions for safe and
efficient handling of the Grundig Business Systems Digta 7 (herein-
after referred to as “device”). This operating manual is a part of the
device and must be kept accessible in the immediate vicinity of the
device for persons working on and with the device. Carefully read and
make sure you understand this operating manual and all product safety
labels prior to starting any work with the device. The basic prerequisite
for safe work is compliance with all specified safety and handling instruc-
tions. In addition, all local accident prevention guidelines and general
safety regulations effective at the implementation site of the device apply.
Illustrations in this operating manual are provided for basic understanding
and can vary from the actual model of the device. No claims can be
derived from the illustrations in this operating manual.
Disclaimer
All information and instructions in this operating manual have been pro-
vided under due consideration of applicable guidelines and regulations,
the current and known state of the art, as well as our many years of in-
house experience. The manufacturer assumes no liability for damag-
es due to:
Failure to comply with the instructions in this operating manual•
Improper use / misuse•
Willful operation by non-authorized persons•
Unauthorized conversions or non-approved technical modifications•
Use of non-approved spare parts•
The originator is solely liable to the full extent for damages caused by
such conduct. The agreed upon obligations in the delivery contract, the
general terms and conditions, the manufacturer’s delivery conditions,
and the statutory regulations valid at the time the contract was conclud-
ed, apply.
Copyright
This operating manual is protected by copyright. No part of this operat-
ing manual may be reproduced in any form or incorporated into any infor-
mation retrieval system without written permission Grundig Business Sys-
tems GmbH (“the manufacturer”). Delivery of the operating manual to
third parties, duplication in any form – including excerpts – as well as
exploitation and/or communication of the content, are not permitted with-
out a written declaration of release from manufacturer. Actions to the con-
trary make damage compensations mandatory. We reserve the right to
enforce additional claims.
The manufacturer
© Grundig Business Systems GmbH
Weiherstraße 10
D – 95448 Bayreuth
holds the copyright.

Illustration 1: Device front Illustration 3: Slide switch variants
Illustration 2: Connections top/bottom
16
20 19 18
17
21 22
23
24
Variant 1
REC g
FFWD h
STOP e
START f
REW i
Variant 2
26
25
Illustration 4: Display main screen
6
8
7
15 2
3
4
14
11 10 9
13
5
1
12
FFWD h
REC g
STOP e
PLAY f
REW i
31
40
3228 29 3027
39
33
34
35
36
38
37

No Description Meaning
1 Microphone hole internal microphone
2 Thumb button Variant I: Recording/stop of dictation
Variant II: Fast forward
Only for devices with speech recognition*:•
Keep pressing: Activates speech recognition
for input of numbers and letters
Disengage the button: Deselection of speech
recognition
3 Slide switch Switch-setting functions are configurable by
means of the adjustment screw and in the menu
(see illustration 3)
4 Display buttons Labeling in the display
5 Up-Down-buttons Navigation
6 On/Off button Digta On- and Off switching
7 Battery compartment For rechargeable 962- or AAA-batteries
8 Unlocking button Unlocking button for the battery compartment
9 Menu button Digta menu access
10 OK button Key button
11 New button Create a new dictation
12 Left-right-buttons Navigation
No Description Meaning
13 Display Operational status indicator and indicator of the
adjustable menu functions (for details see illus-
tration 4)
14 lower function button Press button briefly: Help for the current On-/•
Off-setting of functions
Long pressing: Keylock On/Off switch•
15 upper function button Press button briefly: Display illumination On-/Off
16 Memory card* Memory medium for recorded dictations
17 Recording LED Multicolored LED lights up during recording,
blinks regularly during recording pause
red = overwrite•
orange = insert•
green = play-back in USB-audio mode•
yellow = USB-connection/data transmission•
18 Microphone socket Connection for external extra microphone
19 Card slot For memory card
20 Earphone jack Connection for earphone or headphone
21 Contact strip Docking station connection
22 USB-connection Interface for PC and Grundig power supply
23 Thumb button Function depends on the variant
24 Adjustment screw Variant setting for slide switch and thumb grasp
button
Comment Controls/Keys und Connections

Comment Controls/Keys und Connections
No Description Meaning
25 Slide switch Slide switch function depends on the variant
26 Touch Pin Tangible slide switch setting
27 Clock Time in hours and minutes
28 Bluetooth* Bluetooth is active
29 Voice Activation Speech activation On/Off
30 Remaining memo-
ry time
Display of free memory space in minutes and
seconds
31 Card indicator Memory card is inserted in the device, the data
is saved on the external memory card.
32 Battery/rechargeable
battery*
Charge level of battery; blinks when the batter-
ies are low
33 Status bar Device settings (see No 27-32)
34 Advanced status bar Folder name•
File format/recording quality of the next•
recording
Encryption•
Load: charge level in %•
Discharge: display of remaining battery•
charge in hours and minutes
No Description Meaning
35 Slide switch functions Switch-setting functions are configurable by
means of the adjustment screw and in the
menu
hForward/fast forward
e Stop
fPlay-back
gRecording
iRewind
36 Display button
labeling
Function of display buttons in the current opera-
tional status mode
37 Dictation time After dictation selection: length of dictation•
During recording and play-back: dictation•
time at the current recording-/play-back
position
38 Progress bar Shows the current dictation position and marks
Insert Overwrite
Info Index
39 Dictation field Dictation data (dictation name, position number,
dictation ID/bar code)
40 Dictation information Marks further information of each dictation:
Deadline, priority, postponed, encryption, dic-
tation lock
This product or function is not included in the delivery and available*
as an accessory.
