GST I-9305 User manual

30303454 Issue 5.05
Features
A pair of input signals. Working mode can be set
to normally open, normally closed through
P-9910B programmer. Input signal is insulated
from loop.
Two separate pairs of converting output contacts.
Occupying one address. It can be modified
through a programmer or fire alarm control panel
(FACP).
Monitoring power supply.
Plug-in structure.
Description
With a microprocessor, I-9305 Voice Alarm Zone
Control Module can communicate with FACP,
monitor power supply, control output, indicator and
judge logic state of input signal.
The module is designed to switch between normal
broadcasting and voice alarm broadcasting. The
module can switch those two channels, receive
external answering signal and feed back
automatically after switching to fire alarm
broadcasting. The switching is successful if the
relative information has been transmitted to fire
alarm control panel.
Connection and Cabling
Fig. 1 shows terminals on the module.
910 15 16
8721
Mounting
Hole Mounting Hole
Mounting Direction
D1 D2 GI1 Z1 Z2
SP1 XF1 ZC1 SP2 XF2 ZC2
65mm
Fig. 1
D1, D2: 24VDC power, non-polarized
Z1, Z2: Connecting with loop of FACP, non-polarized
I1, G: Volt-free input terminal
ZC1, ZC2: Normal broadcasting input terminal
XF1, XF2: Fire alarm broadcasting input terminal
SP1, SP2: Output terminal connecting with speaker
Recommended Cabling
1.0mm2 or above fire cable for Z1, Z2, ZC1, ZC2,
XF1, XF2, SP1 and SP2. 1.5mm2 or above fire cable
for 24VDC power line, subject to local codes.
Installation
The module is simply plugged onto the base after
corresponding terminals are connected.
If the cable conduit is inside the wall, the base is
installed onto the Back Box (Fig. 2). If the cable
conduit is on the surface of the wall, B-9310 Back
Box is available (Fig. 3).
Conduit
B-9310
Back Box
Conduit ModuleModule
Back Box
Fig. 2 Fig. 3
Note the upward arrow for mounting direction (Fig.1).
Application
Address and working mode can be set in field
through P-9910B programmer, please refer to
P-9910B Hand Held Programmer Installation and
Operation Manual for specific operation. The working
mode of module is defaulted auto feedback (3),
which can be modified to normally open (4) or
normally closed (7) in field.
The module can be connected to addressable fire
alarm broadcasting system, as shown in Fig. 4.
I-9305
Voice Alarm Zone Control Module

30303454 Issue 5.05
Z2
XF2
Z1
D2D1
SP2
ZC2SP1ZC1
I-9305
XF1
Voice Alarm Zone Control Module
Speaker
G
Z1
Z2
+24V
Cable for
Background
Music
Broadcasting
Fire Alarm
Broadcasting
Cable
Fig. 4
Note: Please don’t connect contact of the module
to AC loop directly, preventing strong AC
interference signal from damaging the module or
controlled devices.
Specification
Operating Voltage
Loop: 24V (16V~28V)
Power:24VDC(20VDC~28VDC)
Standby Current
Loop≤1mA Power≤2mA
Action Current
Loop≤3mA Power≤30mA
Output Control
Type
Dry contact output
Programming
Method
Electrically addressed, one
address within 1～242.
Indicator
Red ( Flashes in polling and
illuminates in action)
Ingress Protection
Rating
IP30
Operating
Temperature
-10℃～+50℃
Relative Humidity
≤95%, non condensing
Material and Color
of Enclosure
ABS, white (RAL 9016)
Dimension
(L×W×H)
120mm×80mm×43mm
(with base)
Weight
About 206g (with base)
Accessories and Tools
Model
Name
Remark
P-9910B
Hand Held
Programmer
Order separately
B-9310
Back Box
Order separately
Limited Warranty
GST warrants that the product will be free of charge
for repairing or replacing from defects in design,
materials and workmanship during the warranty period.
This warranty shall not apply to any product that is
found to have been improperly installed or used in any
way not in accordance with the instructions supplied
with the product. Anybody, including the agents,
distributors or employees, is not in the position to
amend the contents of this warranty. Please contact
your local distributor for products not covered by this
warranty.
