GUARDIAN INTERLOCK
RESPONSIBLE DRIVER PROGRAM
AMS 2000 USER GUIDE
GI386_REV ©2017 Guardian Interlock GI559_4/17
®
STARTING YOUR VEHICLE
• When you are ready to take the test, make sure the ignition is in the o
position and the Handset is securely connected to the spiral cord, press and
release the white (sometimes green) power button on the top of the AMS
Handset. Do not attempt to turn the key on at this point. Doing so may cause
the Handset to power o.
• Once the power is on you will hear a single beep to conrm power. The Handset
will display “Warm Up, Please Wait, SERV# days”. The sensor is warming up.
You will need to wait about 1-3 minutes before you take the test.
• When the interlock is ready you will hear a beep and the Handset will display
“BLOW NOW”. You will have 30 seconds to begin your breath sample or the
unit will time out and power down.
• Blow into the mouthpiece for approximately 5 seconds. As you blow into the
mouthpiece you will hear a low tone. Maintain a steady breath until you hear
two quick beeps and immediately inhale/suck briey to complete the test.
The inhale must happen immediately after the blow -- do not remove your
mouth from the mouthpiece.
• If your state requires a HUM tone, HUM after the rst beep and inhale after
the second beep. If a HUM tone is required it may help by saying the word
DO, Who or letter Z as you blow.
• The Handset display will change to ANALYZE. If your test result was successful
the display will change to “PASS START CAR”.You will have 30 seconds to turn
the ignition on.
TIME TO TEST
The Guardian
AMS2000 will NEVER
shut your vehicle o
for any reason. It can
only prevent you from
starting your vehicle.
AMS 2000 USER GUIDE
• If the display shows “ABORT”, the most likely causes are:
1. Not blowing hard enough
2. Blowing too hard
3. Not blowing long enough
4. Not humming correctly
• If the display shows “FAIL” the device has detected the presence of alcohol.
Wait for the device to reset before attempting another test.
• When the display shows “BLOW NOW” you can try the test again.
Depending on the regulations in your state you may be allowed 1 or more
opportunities to pass the test.
• If you fail multiple times in a row your Handset may display “TEMP LOCK“.
You will be unable to test or start your vehicle for a set time (5 minutes to 24
hours depending on state regulations). The Handset will automatically power
down after 1 to 3 minutes.
• You may push the Power Button to display the amount of time left in the
“TEMP LOCK”. When time has expired “WARM UP” will be shown.
• If the display shows “PASS, START CAR“ but the vehicle does not turn on
check your vehicles battery.
**You are responsible for all events logged into your device.**
VEHICLE STARTED - ROLLING RETESTS
• After you have started your vehicle you will be required to give a breath
sample at random intervals. The frequency of these tests depends on your
state’s requirements.
• The device will beep the Handset screen will display “BLOW NOW “and start
a countdown of 300 seconds “300 SEC” (in most states).
• You have 5 minutes/300 seconds (in most states) to complete the test. If you
are not comfortable taking the test while driving, you have enough time to
stop at a safe location to deliver the breath test.
• Depending on state requirements, your vehicle’s horn may honk and lights
will ash if the breath test is not delivered before the time to test expires.
Your device’s display will read “TURN OFF IGNITION” if you don’t complete
the Rolling Retest in the time required.
TIME TO TEST
• If you’ve arrived at your destination and the system asks for a rolling retest
YOU MUST submit the test even if the vehicle is turned o. If you refuse,
a violation report will be sent to your monitoring ocial and it may result in
an Early Recall. If an early return to the service provider is necessary, a fee will
be charged.
NOTE: If the system asks for a rolling retest while the car is running at a store,
gas station, etc. and you do not submit the test, your device will record
this event as a “refusal”.
DISCONNECTING THE HANDSET
• In extremely cold weather, remove the Handset and mouthpiece from the
vehicle overnight. (This is not allowed in all states. Please check with your
service provider rst.)
• Don’t unplug the Handset when the vehicle is running or a violation will be
recorded, early service will be required, and a reset fee will apply.
• When the vehicle is turned o and the Handset displays “OK TO UNPLUG”
you may safely unplug it.
• When reconnected the Handset should beep. Push the power button.
The display should show “WARMING UP, PLEASE WAIT, SERV #”. If this does
not occur disconnect the Handset for 2 minutes and try again.
TIME TO TEST
AMS 2000 USER GUIDE
SERVICE AND CALIBRATION
• The device needs to be serviced and calibrated every 30 - 60 days,
depending on state law.
• Each time you power up your Handset it will display “SERV#” days
which represents the number of days you have until you’re next
scheduled service appointment. The system MUST be serviced prior
to midnight “SERV 0”.
• The Handset will begin beeping while warming up before and after
“SERV 0” (except in NM & MA)
• Early Recall due to a rolling retest violation will result in a Violation Reset Fee.
If any of the following situations occur, your service days will be reduced and
the device will need to be reset earlier than originally scheduled (Early Recall).
In addition, your required program time may be extended or you may have
your interlock driving privilege revoked or suspended.
oFailed rolling retest
oIncomplete or refused rolling retest
oFailed breath test (usually multiple times)
oBypass
oDisconnected vehicle battery*
*Ask your service provider for a Mechanics
Adavit form if any maintenance is to be
performed on your vehicle.
SERVICE REQUIREMENTS
AVOID CONTACT WITH MOISTURE OR
DIRT WHEN STORING THE DEVICE
The device is not waterproof. Keep the Handset o the oor of your vehicle and
do not expose it to rain. Excessive contact with moisture, dirt, mud or rain will
damage the internal circuitry. If this occurs, repair or replacement of the
Handset is your responsibility.
VEHICLE ELECTRICAL SYSTEM
The AMS 2000 Interlock operates using your car’s electrical system. If your
vehicle has electrical issues (poor voltage or faulty charging system) you must
have them corrected before installation. Power issues can damage the system,
void the warranty, and are the primary cause of EARLY SERVICE RECALLS and
unscheduled Service Center visits at your expense.
Make sure that:
• Battery terminals are tight and free of corrosion
• Battery voltage is strong
• Water levels in battery are maintained
KEEP OUT OF DIRECT SUNLIGHT
Temperatures inside vehicle on a very hot day can reach 185° F. If the
AMS Handset displays ”OVERTEMP” you must cool it down for it to operate.
“OVERTEMP” will display until the device is serviced.
TIPS AND PROPER CARE
AMS 2000 USER GUIDE
MOUTHPIECES
It is EXTREMELY important that the mouthpiece is dry before you
attempt to deliver a test.
• You will be given several mouthpieces at the time of your enrollment in the
program. More mouthpieces are available upon request.
• Watch for condensation build up inside the mouthpiece. When water
droplets begin to appear, replace the mouthpiece with a dry one.
• Should the mouthpiece break o in the Handset use a #10 screw approximately
2 inches long, screw into the stem of the broken mouthpieces and pull it out
or ask your service provider for assistance. Do not attempt any other methods
as damage to the Handset is your responsibility.
• Do not attempt to glue the mouthpiece, visit your Service Center
for a replacement.
• You can wash the mouthpieces with a mild dish soap and warm water.
Allow to air dry.
DON’T SMOKE, EAT OR DRINK ANYTHING PRIOR TO TESTING
Many products contain small amounts of alcohol which could cause a failed
breath test. Do not eat or drink at least 15 minutes prior to starting your car.
AVOID CONSUMING OR USING:
• Alcoholic Beverages
• Mouthwash
• Hand Sanitizer
• Medications
• Cologne/Perfume
• Energy Drinks
• Glass Cleaners or Windshield Solvents
This list is not all inclusive.
TIPS AND PROPER CARE
TIPS AND PROPER CARE
REPORTING
What information is captured and given to the State?
• Breath Alcohol Content (BrAC) levels detected
• The time the vehicle’s engine was started and stopped
• Vehicle power interruptions
• Key events such as the timing and results of rolling retests
• Handset connections and disconnections
Who takes care of the state paperwork?
All Guardian Interlock Service Centers send the appropriate documentation
to the monitoring authorities. Notication of both your installation and
completion of the program are taken care of as part of our service to you.
Please advise your Service Center, of any out of state reporting requirements,
which require us to submit documentation to another jurisdiction.
What do I do when my driving restriction ends?
Terms of license reinstatement vary by state and by county so it is wise to
check with the agency responsible for your DUI conviction. We monitor your
progress for the duration of your probationary period, then make a nal appoint-
ment to remove the device and hand you your completion report. Your car then
reverts to its original ignition system and we wish you a safe driving future.
It is recommended, where permitted, that you get your unrestricted driver’s
license prior to the interlock system removal from your vehicle. In some states
you must come in for a Pre-Removal data download before removal is granted
by the monitoring authority.
AMS 2000 USER GUIDE
TIPS AND PROPER CARE
IMPORTANT TIPS
• The AMS device will register a failed test if products with alcohol are introduced
into or near the device. You are ultimately responsible for any fails regardless of
the source. If you fail the breath test and don’t know why, rinse your mouth with
water and take 2 cleansing breaths before you test again.
• The Guardian AMS2000 will NEVER turn your vehicle o. It can only prevent you
from starting your vehicle.
•
“FAIL” will display on the Handset followed by low pitched beep which indicates
an alcohol Fail has been recorded.
• “WARN” will be displayed on the Handset when alcohol is detected but is below
the “Fail” alcohol level.
• In most states you have a short grace period after the day of your service
appointment (SERV 0) before the Handset displays “PERM LOCK” (except in
MA & NM). If the Handset displays “PERM LOCK” call the Service Center or
Support at 855-202-0080 for a solution.
• If you experience a unit malfunction call your Service Center or Support
at 855-202-0080.
• The most common causes for system problems are; poor battery, corroded
or lose battery terminals or a malfunction of your vehicle charging system
(conditions which you can prevent). To avoid problems always remember
to maintain your vehicle properly and have it tested.
• The device needs to be serviced and calibrated every 30 - 60 days,
depending on state law.
• We recommend you maintain a journal of events to document all
fails or issues as they occur.
• A Missed Appointment fee will be charged if you fail to keep an appointment.
• 48 hours notice is required to reschedule your appointment or a
Reschedule Fee will be charged.
• In extremely cold weather place the Handset inside your coat to
warm it up faster.
AMS
2OOO
The Guardian
AMS 2000 Display
uses simple
text commands
for easy to
read clarity.
LED DISPLAY DESCRIPTION
TEMP LOCK
300 SEC
TURN OFF
IGNITION
SERV#
OVERTEMP
FAIL
ABORT
PASS, START CAR
ANALYZE
BLOW NOW
WARM UP
PLEASE WAIT
SERV# DAYS
Wait - the device is preparing
to accept a breath test.
The device is ready to accept a breath test. Blow into the mouthpiece
for about 5 seconds. You will hear a low tone followed by 2 beeps.
Inhale when you hear the beeps.*
*If your state requires a hum tone, hum after the rst beep and inhale after the second beep.
The breath test was not successful because:
1. You blew too hard or too soft
2. You didn’t blow long enough
3. You didn’t inhale in time
4. You didn’t hum correctly
Device will default back to WAIT and you may repeat the test.
The device has detected alcohol. It will either show
WAIT then BLOW NOW or TEMP LOCK.
You cannot test or start your car. You may push the Power Button
to display the amount of time left until you can attempt to start
your car.
When time has expired WARM UP will show.
Rolling Retest countdown. This is the amount of seconds you have to
provide a breath sample.
Displays if you don’t complete the Rolling Retest in the time required.
The number of days until your next required service. The system must
be serviced prior to midnight“SERV 0”.
Device is too hot. You must cool it down for it to operate.
You have passed the breath test and have 30 seconds to start the car.
Wait - the device is analyzing your breath sample.
BELOW IS A DESCRIPTION OF EACH TEXT MESSAGE.
Ensuring Safety For Over 30 Years.
855-202-0080
GuardianInterlock.com
Or contact your service provider.
GI386_REV ©2017 Guardian Interlock GI559_4/17
®
Other manuals for AMS2000
1
Table of contents
