Guardian 5629 Operating and installation instructions

MODELS
5634 This kit is intended for use with air-cooled product that does
not utilize the digital controller or that is below 8kW. The con-
nection is a 120V plug that will require a voltage source.
5635 This kit is intended for use with air-cooled product that utilizes
the digital controller (10-20kW). The connections consist of 2
ring terminals that are attached to the appropriate neutral and
ground and a bare lead that is inserted into the AC connection
block that is connected inside the generator control panel.
5629
5630
5631
5632
5633
These kits are intended for use with the liquid-cooled product
and include an oil filter for conversion over to 5W-30 synthetic oil.
DESCRIPTION
The Cold Weather Kit consists of a battery warmer that has a
thermostat built into the battery wrap. When temperatures fall below
an acceptable level, the thermostat activates the battery warmer
maintaining optimum battery temperature for the best generator
starting. These kits are recommended for generators installed in
regions where the temperature regularly falls below 10 degrees.
When installing a cold weather kit, it is required that the oil is
replaced with 5W-30 synthetic for better engine start capability.
STANDBY GENERATOR ACCESSORIES
Cold Weather Kits
Battery Warmer
Model 5634
Model 5635
Model 5629
Model 5630
Model 5631
Model 5632
Model 5633
