Gudsen MOZA iFocus Wireless Lens Control User guide

© 2020 GUDSEN All Rights Reserved.
System Upgrade Tutorial for MOZA iFocus Wireless Lens Control.
Notice:
1. MOZA iFocus firmware cannot be upgrade separately.
To upgrade the iFocus you will need to use a MOZA Air
2 Gimbal or MOZA Wireless Handunit.
2. MOZAiFocus cannot upgrade with MOZAAircross 2
gimbal currently.
3. Our official video tutorial for this document:
https://www.youtube.com/watch?v=b9R8uTDou_Q&t=313s
Download Software:
Please download MOZA Master Software on your computer and install the software following the
steps below:
https://www.gudsen.com/upfile/admin/file/download/MOZA-Master-1.3.0-Tutorial.pdf?v1
Upgrading iFocus with MOZA Air 2 Gimbal:
1. Turn off the iFocus Motor and Air 2 Gimbal.
2. Connect the Air 2 Gimbal and iFocus via Multi-CAN cable (Fig 2), then connect the Air 2 Gimbal
to the computer via USB Type-C cable (Fig 1).
Fig1. Connect Air 2 Gimbal, iFocus
and Computer
Fig3. IFocus Motor in Boot Mode
Fig2. Connect to the multi-can connector on Air 2 Gimbal
Fig4. Air 2 Gimbal in Boot Mode

© 2020 GUDSEN All Rights Reserved.
3. [iFocus] Press and hold the power button in the iFocus for 3s. The indicator LED will flash white
(iFocus in boot mode, Fig 3).
4. [Air 2 Gimbal] Press and hold the Air 2 Gimbal’s joystick in,don‟t release the joystick. Then
press the power button (hold in the joystick and press the power button at the same time). “Boot
Mode” will be displayed on theAir 2 Gimbal‟s screen (Fig 4). Now the gimbal is in boot mode.
5. Launch the MOZA Master Software from your computer, select “Air 2” from the device list.
6. The software will automatically open the upgrade interface. After the firmware has downloaded,
click the “upgrade” button. Upgrading can take about 30 seconds.
7. During the upgrade, the screen will display “Upgrading”. Once the upgrade is complete, the
screen will display “Upgrade Success”.

© 2020 GUDSEN All Rights Reserved.
8. Restart the Air 2 Gimbal and iFocus.
9. Power on the iFocus. The iFocus status LED light will flash blue, please wait about 10 seconds
for calibration to finish. Once calibration is finished about 10 seconds, please power off the iFocus.
10. Reboot the MOZAAir 2, and iFocus. Now, you are ready to film.
Upgrade with MOZA Wireless Handunit.
1. Turn off the Wireless Handunit and iFocus.
2. Connect the Wireless Handunit to the iFocus via Multi-CAN cable. Then connect the Wireless
Handunit to the computer via Type-C USB cable (Fig 5).
3. [iFocus] Press and hold the power button on the iFocus motor for 3s. The indicator LED will
flash white (Fig 6).
4. [Wireless Handunit] Hold the top button in on the Wireless Handunit (don‟t release the button).
Then press the power button (hold the top button in and then press the power button at the same
time) “Boot Mode” will be displayed on the Wireless Handunit‟s screen. Now, the Wirelsss
Handunit is in boot mode.
5. Launch the MOZA Master software, select “iFocus” from the device list.
Fig5. Connect wireless handunit, ifocus motor and PC together
Fig6. Wireless handunit in boot mode

© 2020 GUDSEN All Rights Reserved.
6. The software will automatically open the upgrade interface. After the firmware has downloaded,
click the “upgrade” button. Upgrading can take about 30 seconds.
7. During the upgrade, the screen will display „Upgrading‟, after the upgrade is complete, the screen
will display “Upgrade Success”
8. Restart the Wireless Handunit and iFocus.
9. Power on the iFocus. The iFocus status LED light will flash blue, please wait about 10 seconds
for calibration to finish. Once calibration is finished about 10 seconds, please power off the
iFocus.
10. Reboot the Wireless Handunit and iFocus. Now, the Wireless Handunit and iFocus firmware
upgrade is finished.
