Gurin PU-110 User manual

ULTRASONIC MASSAGER
INSTRUCTION MANUAL
MODEL : PU-110
Relieve muscular spasm / Relax, ease joint stiffness
Improve body circulation / Increase elasticity of collagen tissue
www.gurinproducts.com

sihtdaeruoytahtdednemmocersitI
entire manual thoroughly before using the
device.
Contents
GENERAL INFORMATION......................................1
CONDITIONS TREATED..........................................2
SAFETY....................................................................3
PRECAUTION.........................................................4
SPECIFICATIONS....................................................5
GENERAL DESCRIPTION........................................6
SKIN PREPARATION................................................7
OPERATING INSTRUCTION....................................7
DO’S AND DON’TS...............................................8
SERVICE AND REPAIR............................................9
WARRANTY.............................................................9

Our portable Ultrasonic Massager is an
ultrasound device that can produce one million
vibrations per second. This causes the tissues to
compress and expand at the same frequency
of ultrasound and this effect is called micro
massage. Micro massage, stimulates the tissues
and improves the metablolism of cell membrane
and leads to the generation of frictional heat.
It helps circulation and muscle relaxation during
the process and promotes healthy care for
deep tissue. The ultrasound has an automatic
timer which is preset to operate for 10 minutes
on the treatment area, after which time it will
shut off.
Ultrasound cannot transmit in the air, if the
treatment head does not completely contact
with the skin, the result would not meet your
expectation. We recommend to apply
ultrasound gels to conduct the wave energy to
the skin.
1
Gereral Information
■
■
■
■
■
■
■
■
■
Back pain
Chronic pain
Golfer’s elbow
Muscle spasm
Post exercise recovery
Strains and sprains
Tennis elbow
Tendonitis
Arthritis and more...
To massage with Ultrasound for 10 to 15 minutes
every day, could activate the cells and revive
pain and acelerating recovery. Ultrasonic
Massger excites the cells and strengthens tissue
and recession.
Conditions Treated
2

■
■
■
■
■
■
■
■
The Ultrasonic Massager should not be used
for the treatment of malignancies or in the
region where malignant tumours exist.
This is not a toy for children.
Do not use on people with poor arterial
circulation.
Do not use over an area where bleeding or
infections exist.
Do not used over the eyes, skull, mouth,
nose or vagina.
Do not use on the abdomen if you are
pregnant.
Do not use for patients with demand type
cardiac packemakers
Do not use over the carotid sinus nerves
or arteries and laryngeal or pharyngeal
muscles.
Safety
3
■
■
■
■
■
■
Special care must be given to patients with
sensory losses. Areas that are temporarily
numb or to a part of the body which has
no feelings.
Avoid bony prominences or bones close to
the surface of the skin.
When using ultrasound, keep the sound
head moving while maintainning contact
with the skin.
Do not immerse in water or other solvent.
Do not use over metallic implants, especially
prostheses with a cement-matrix.
Do not use the Ultrasonic Massager without
using a conductive gel.
Precautions
4

Power Source:
AC adapter, 110 V AC (13.5 V DC) or
AC adapter, 220 V AC (13.5 V DC)
Frequency: 1 Mhz ± 5%
Output Power: 0.5 watt ± 20%
Switch: On/Off
Treatment area: 3.8cm2
Times Setting: 10 minutes ± 10%, Auto off
Ultrasound Gel: Water soluble
Dimensions: 50 x 45 x190 mm
Weight: 200 gm
Product includes
Ultrasonic Massager x 1
AC Adaptor x 1
Gel 60 ml x 1
Instruction Manual x 1
Package Box x 1
5 6
■
■
■
■
■
■
The main unit: Easy to handle and
manipulate.
The connector.
ON/OFF switch: switch button, simple ON
and OFF, a built-in time setting of 10 minutes,
auto disconnected power.
110 V AC (or 220 V AC) Adapter
Gel: completely neutral water soluble gel.
Treatment head: 3.8 cm2
Treatment Head
(Power Transfer) On/Off Indicator
General Description

■
■
■
■
■
■
■
■
Connect power wire to wire socket.
Connect to power source.
Apply suitable amount of gel to skin at
target area ( a circle with 2cm diameter).
Switch on the power. If power signal light is
on, start to use massager.
DO NOT stop moving treatment head while
in use.
The power automatically turns off in 10
minutes or, if desired, the power can be
turned off sooner by pushing the ON/OFF
switch to OFF.
After use, wipe excess gel off the treatment
head with a damp cloth. Disinfect treatment
head with antiseptic wipe. Do not immerse
in water or solvent.
After using the device, clean skin with water
to remove gel.
Clean skin before and after use.
Precautions
Skin Preparation
7
■
■
■
■
■
■
■
■
■
■
DO
DON’T
Do follow instructions.
Do keep the treatment head clean.
Do clean cables with water and mild soap.
Do not use rubbing alcohol or any other
solvent.
Do not damage your Ultrasonic Massager
by bumping, dropping, or rough use.
Do not immerse in water or other solvents.
Do not pull or kink cables.
Do not store below 32F（0℃）or over
122F（50℃）
When power shuts off, leave the unit off
for 30 minutes. After every treatment,
disconnect AC adaptor from power source.
Do not impact the treatment head or drop
DO’S and DON’TS
8

To obtain service, call your dealer for
instructions. You may need to send in your
complete unit with the problem stated in
writing for repair.
We warrant each new Ultrasonic Massager
unit for ONE (1) year from defeacts in materials
and workmanship. This warranty only applies to
the original purchaser. This warranty does not
cover damage caused by abuse, or accidental
damage which results in the failure of this unit.
Failure to follow operating instructions, damage
by natural force, dismantled or disassembly will
void this warranty.
Product Name: Ultrasonic Massager
Model No: PU-110
Product serial number: ________________________
Name: _____________________________________
Date of purchase: ___________________________
Distributor: __________________________________
Service And Repair
Warranty
9

Issue date: 2012.02
Rev. E99 V1.0
